Worcester Greenstar CDi Manuale utente

USER INSTRUCTIONS &

CUSTOMER CARE GUIDE

6 720 611 927-00.1O

THE APPLIANCE IS FOR USE

WITH NATURAL GAS OR L.P.G.

(Cat II 2H3P TYPE C13 & C33)

NATURAL GAS:

27CDi GC-Number 47-406-12

30CDi GC-Number 47-406-14

37CDi GC-Number 47-406-08

42CDi GC-Number 47-406-10

LIQUID PETRLOLEUM GAS:

27CDi GC-Number 47-406-13

30CDi GC-Number 47-406-15

37CDi GC-Number 47-406-09

42CDi GC-Number 47-406-11

GREENSTAR CDi

WALL HUNG RSF GAS-FIRED CONDENSING

COMBINATION BOILER

FOR SEALED CENTRAL HEATING SYSTEMS AND MAINS FED

DOMESTIC HOT WATER

2GREENSTAR 27CDi/30CDi/37CDi/42CDi

6 720 614 059b (2007/07)

CONTACT INFORMATION

WORCESTER BOSCH:

TECHNICAL: 08705 266241

SERVICE: 08457 256206

SPARES: 01905 752571

LITERATURE: 01905 752556

TRAINING: 01905 752526

SALES: 01905 752640

WEBSITE:

www.worcester-bosch.co.uk

WATER TREATMENT:

FERNOX 01799 550811

www.fernox.com

SENTINEL 0151 420 9595

www.betzdearborn.com/sentinel

FLUE TERMINAL GUARDS:

TOWER FLUE COMPONENTS

Vale Rise, Tonbridge TN9 1TB

USER INSTRUCTIONS & CUSTOMER

CARE GUIDE

PLEASE READ THESE INSTRUCTIONS

CAREFULLY BEFORE OPERATING YOUR

APPLIANCE

THESE INSTRUCTIONS ARE APPLICABLE TO

THE WORCESTER BOSCH APPLIANCE

MODEL(S) STATED ON THE FRONT COVER

OF THIS MANUAL ONLY AND MUST NOT BE

USED WITH ANY OTHER MAKE OR MODEL

OF APPLIANCE.

THE INSTRUCTIONS APPLY IN THE UK ONLY

AND SHOULD BE FOLLOWED EXCEPT FOR

ANY STATUTORY OBLIGATION.

IF YOU ARE IN ANY DOUBT CONTACT THE

WORCESTER BOSCH TECHNICAL HELPLINE.

DISTANCE LEARNING AND TRAINING COUR-

SES ARE AVAILABLE FROM WORCESTER

BOSCH.

THIS APPLIANCE MUST BE INSTALLED BY A

COMPETENT PERSON. FAILURE TO INSTALL

CORRECTLY COULD LEAD TO

PROSECUTION.

PLEASE LEAVE THIS GUIDE, THE INSTALLA-

TION INSTRUCTIONS AND THE COMPLETED

BENCHMARK LOG BOOK WITH THE USER OR

AT THE GAS METER AFTER INSTALLATION.

ABBREVIATIONS USED IN THIS BOOK:

NG - Natural Gas

LPG - Liquid Petroleum Gas

CH - Central Heating

SEDBUK - Seasonal Efficiency of Domestic

Boilers in the United Kingdom

USER INSTRUCTIONS &

CUSTOMER CARE GUIDE

GUARANTEE MAINTENANCE ENERGY

SAVING

USING YOUR

APPLIANCE INTRODUCTION

CONTENTS

INTRODUCTION

EXCELLENCE COMES AS STANDARD 4

SAFETY PRECAUTIONS 5-7

GENERAL NOTES 8-11

USING YOUR APPLIANCE

CONTROLS 12

OPERATING THE APPLIANCE 13-15

Switching the appliance on/off 13

Setting the central heating temperature 13

Controlling central heating 13

Frost protection 14

Controlling domestic hot water 14

Holyday setting 15

Fault condition 15

ENERGY SAVING

TIPS ON ENERGY SAVING 16-17

MAINTENANCE

MAINTAINING YOUR APPLIANCE 18

FAULT FINDING 19

FAULT OR BREAKDOWN 20-21

GUARANTEE

YOUR GUARANTEE 22

GUARANTEE REGISTRATION 23

CONTENTS

WORCESTER BOSCH GREENSTAR 27CDi/30CDi/37CDi/42CDi

6 720 614 059b (2007/07)

EXCELLENCE

COMES AS STANDARD

WORCESTER BOSCH GREENSTAR 27CDi/30CDi/37CDi/42CDi

6 720 614 059b (2007/07)

EXCELLENCE COMES AS

STANDARD

Thank you for purchasing a Greenstar

27CDi/30CDi/37CDi/42CDi gas-fired

condensing combination boiler manu-

factured by Worcester Bosch. The com-

pany prides itself on manufacturing boi-

lers to the strictest quality control stan-

dards throughout every stage of produc-

tion. Worcester Bosch has led the field

in innovative appliance design and per-

formance for more than 40 years. This

heritage means all products are of

exceptional quality and proven reliability.

The Greenstar range in particular is

extremely energy efficient, converting up

to 97% of gas consumed into heat, offe-

ring you economical running costs and

value for money. It sits in SEDBUK

Band A, and is therefore amongst the

top energy rated appliances available.

There is also the reassurance of our no-

nonsense 2 years parts and labour gua-

rantee - backed up by Worcester Total

Cover, an optional complete maintenan-

ce scheme to keep your boiler operating

at peak condition and efficiency.

To find out more about Worcester

Bosch log onto www.worcester-

bosch.co.uk.

INTRODUCTION

SAFETY PRECAUTIONS

SAFETY

PRECAUTIONS

WORCESTER BOSCH GREENSTAR 27CDi/30CDi/37CDi/42CDi

6 720 614 059b (2007/07)

IF YOU SMELL GAS:

6DON’T SMOKE OR STRIKE

MATCHES

6DON’T TURN ELECTRICAL

SWITCHES ON OR OFF

4DO PUT OUT NAKED FLAMES

4DO OPEN DOORS AND

WINDOWS

4DO KEEP PEOPLE AWAY FROM

THE AREA AFFECTED

4DO TURN OFF THE CONTROL

VALVE AT THE METER

4TELEPHONE THE NATIONAL GAS

EMERGENCY SERVICE ON

0800 111999

BENCHMARK STANDARD

‘Benchmark’ is a code of practice for

correctly installing, commissioning and

servicing of domestic water heating

appliances.

A Benchmark Checklist is provided by

the manufacturer for the installer to

complete ALL details together with their

CORGI registration number and sign to

confirm that the boiler has been instal-

led and commissioned according to the

manufacturer’s instructions.

IMPORTANT: The completed

Benchmark Checklist will be required in

the event of any warranty work and may

be required by the local Building

Control Inspector.

HEALTH & SAFETY

The appliance contains no asbestos and

no substances used in the construction

process that contravene the COSHH

Regulations (Control of Substances

Hazardous to Health Regulations 1988).

SAFETY

PRECAUTIONS

WORCESTER BOSCH GREENSTAR 27CDi/30CDi/37CDi/42CDi

6 720 614 059b (2007/07)

COMBUSTIBLE AND CORROSIVE

MATERIALS

Do not store or use any combustible

materials (paper, thinners, paints etc.)

inside or within the vicinity of the appli-

ance.

Chemically aggressive substances, such

as halogenated hydrocarbons containing

chlorine or fluorine compounds can cor-

rode the appliance and invalidate any

warranty.

FITTING & MODIFICATIONS

Fitting the appliance, any controls to the

appliance and removal of the outer

casing may only be carried out by a

competent engineer in accordance with

the Gas Safety (Installation and Use)

Regulations.

Flue systems must not be modified in

any way other than as described in the

Installation Instructions and any misuse

or unauthorised modifications to the

appliance, flue or associated compo-

nents and systems could invalidate the

warranty. The manufacturer accepts no

liability arising from any such actions.

This does not affect your statutory rights.

SAFETY PRECAUTIONS

INTRODUCTION

SAFETY

PRECAUTIONS

WORCESTER BOSCH GREENSTAR 27CDi/30CDi/37CDi/42CDi

6 720 614 059b (2007/07)

SERVICING

The user is recommended to have the

system regularly serviced by a compe-

tent, qualified engineer (such as British

Gas or CORGI registered personnel)

using original spares, to help maintain

the economy, safety and reliability of the

appliance and to have the Service

Record completed in the Benchmark

Checklist.

The appliance should be serviced annu-

ally after installation unless the particular

installation conditions and usage

demand more frequent services.

IMPORTANT - ensure that the service

engineer completes the Service Record

in the Benchmark Checklist after each

service.

SAFETY PRECAUTIONS

INTRODUCTION

GENERAL

NOTES

WORCESTER BOSCH GREENSTAR 27CDi/30CDi/37CDi/42CDi

6 720 614 059b (2007/07)

INTRODUCTION

GENERAL NOTES

To get the best from your appliance plea-

se read these instructions carefully.

SEALED HEATING SYSTEMS

This appliance is fitted to a sealed hea-

ting system which is pre-pressurised.

Your installer will advise you of the mini-

mum and maximum pressure which

should be indicated on the pressure

gauge.

Check regularly that the pressure is

maintained and contact your installer or

maintenance engineer if a permanent

significant drop in pressure is indicated

on the pressure gauge. If the system

loses pressure it should be re-pressuri-

sed and the cause of the fall investiga-

ted.

CENTRAL HEATING SYSTEMS

During the first few hours of operation of

the central heating system, check that all

radiators are being heated at an even

rate. If the top of a radiator is at a lower

temperature than the bottom then it

should be vented by releasing air

through the venting screw at the top of

the radiator. Ask your installer to show

you how this is done.

This boiler is fitted to a sealed system;

repeated venting will reduce the quantity

of water in the system and this must be

GENERAL

NOTES

WORCESTER BOSCH GREENSTAR 27CDi/30CDi/37CDi/42CDi

6 720 614 059b (2007/07)

replenished for safe and satisfactory

operation of the appliance.

Should water leaks be found in the

system or if excessive venting is requi-

red, then a service engineer must be

contacted to inspect the installation and

rectify any fault.

Only additives that are compatible with

aluminium may be used in the system.

Any incompatible additive used will inva-

lidate the guarantee.

PLUMING AND CONDENSATE DRAIN

This is a condensing appliance and the

terminal will, at times give out a plume of

water vapour. This is quite normal.

The appliance also produces quantities

of condensate which is discharged regu-

larly by a siphon within the boiler via a

pipe to drain. This pipe must not be

blocked or altered in any way.

CLEARANCES

Your installer will have provided adequa-

te space around the appliance for safety

and servicing access. Do not restrict this

space with the addition of cupboards,

shelves etc. next to the appliance.

*600 mm service clearance required to a

fixed surface

(**20 mm from removable door or panel)

GENERAL NOTES

mm mm

+ 30mm

above elbow

5mm

600mm

200mm

*600mm

(**20mm)

INTRODUCTION

GENERAL

NOTES

WORCESTER BOSCH GREENSTAR 27CDi/30CDi/37CDi/42CDi

6 720 614 059b (2007/07)

ROOM THERMOSTAT

A room temperature controller and pro-

grammer should be fitted to control the

central heating. Refer to the instructions

supplied with the thermostat for informa-

tion on siting and setting.

THERMOSTATIC RADIATOR VALVES

It is recommended that this type of valve

is fitted to all but one of the radiators (or

at least those in the sleeping accommo-

dation). The remaining radiator, which

must be where the room thermostat is

located, should be uncontrolled and

must be left open. The thermostatic

radiator valves should conform to the

requirements of BS2767:10.

GENERAL NOTES

INTRODUCTION

Altri manuali per Greenstar CDi

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Worcester Caldaia

Worcester

Worcester Greenstar Heatslave II 12/18 Guida utente

Worcester

Worcester Greenstar 2000 Manuale utente

Worcester

Worcester GREENSTAR CDi CLASSIC 29CDi GC Manuale utente

Worcester

Worcester 9/14CBi Manuale utente

Worcester

Worcester GREENSTAR i SYSTEM Manuale utente

Worcester

Worcester GREENSTAR UTILITY 32/50 Manuale utente

Worcester

Worcester Greenstar Danesmoor External Regular Manuale utente

Worcester

Worcester Greenstar 12Ri Manuale

Worcester

Worcester GREENSTAR CDi CLASSIC SYSTEM Manuale utente

Worcester

Worcester R29 Manuale utente

Worcester

Worcester Greenstar Ri Guida utente

Worcester

Worcester Greenstar i System ErP Series Guida utente

Worcester

Worcester Greenstar Highflow 440 Manuale utente

Worcester

Worcester Greenstar i Series Guida utente

Worcester

Worcester Greenstar i System Compact ErP Series Manuale utente

Worcester

Worcester DANESMOOR Guida utente

Worcester

Worcester GREENSTAR 29 Guida utente

Worcester

Worcester C1 Guida utente

Worcester

Worcester GREENSTAR 24i junior Manuale utente

Worcester

Worcester Greenstar Si Compact ErP Series Manuale utente

Worcester

Worcester GREENSTAR 24i junior Manuale utente

Worcester

Worcester GREENSTAR 24i junior Manuale utente

Worcester

Worcester ZWBR 7-30 R 30 HE PLUS COMBI Guida utente

Worcester

Worcester GREENSTAR II HE OIL 12/22 Guida utente

Manuali Caldaia popolari di altre marche

Vaillant

Vaillant uniSTOR VIH SW GB 500 BES Manuale utente

Radijator

Radijator BIO max 23.1 Manuale utente

Brunner

Brunner BSV 20 Manuale utente

Buderus

Buderus Logamax GB062-24 KDE H V2 Manuale utente

Potterton

Potterton 50e Scheda tecnica

UTICA BOILERS

UTICA BOILERS TriFire Manuale utente

Joannes

Joannes LADY Series Manuale

ECR International

ECR International UB90-125 Manuale di istruzioni

Froling

Froling FHG Turbo 3000 Manuale utente

Froling

Froling P4 Pellet 8 - 105 Manuale utente

U.S. Boiler Company

U.S. Boiler Company K2 Manuale utente

Henrad

Henrad C95 FF Manuale utente

NeOvo

NeOvo EcoNox EF 36 Manuale utente

Potterton

Potterton PROMAX SL 12 Manuale utente

Eco Hometec

Eco Hometec EC 25 COMPACT Manuale utente

Viessmann

Viessmann VITODENS 200 Guida

Baxi

Baxi Prime 1.24 Manuale utente

REXNOVA

REXNOVA ISA 20 BITHERMAL Manuale utente
