Worx WX255 Manuale utente

WX255 WX255.1WX255.2

P09

P18

P27

P36

P45

P54

P63

P72

P81

P90

P99

P108

P117

P126

Original instructions

Übersetzung der Originalanleitung

Traduction des instructions initiales

Traduzione delle istruzioni originali

Traducción de las instrucciones originales

Vertaling van de oorspronkelijke instructies

Tłumaczenie oryginalnych instrukcji

Eredeti használati utasítás fordítása

Traducerea instrucţiunilor iniţiale

Překlad původních pokynů

Preklad pôvodných pokynov

Tradução das instruções originais

Översättning av originalinstruktionerna

Prevod izvirna navodila

678

F2 G

H1 H2

H3 I1

I2 J

F2 G

H1 H2

H3 I1

I2 J

F2 G

H1 H2

H3 I1

I2 J

F2 G

H1 H2

H3 I1

I2 J

F2 G

H1 H2

H3 I1

I2 J

1. SLIDE COVER

2. FORWARD/REVERSE ROTATION CONTROL

3. SOFT GRIP HANDLE

4. CHARGING INDICATOR

5. CHARGING SOCKET

6. ON/OFF SWITCH

7. LED LIGHT

8. SCREW HOLDER

9. CHUCK

10. BIT CARTRIDGE

Not all the accessories illustrated or described are included in standard delivery.

TECHNICAL DATA

Type WX255 WX255.1 WX255.2 (250~269-designation of machinery, representative of Battery-powered

Screwdriver)

Charger voltage 100-240V~ 50/60Hz

Rated voltage 4V Max*

Charger input power 3W

Battery capacity 1.5Ah Li-Ion

No-load speed 230/min

Maximum torque 3N.m

Machine weight 0.5kg

Charger Protection class /II

Charging time 5 hours (Approx.)

For the technical data of the types, the number of cells and the rated capacity of the batteries that can be charged,

please refer the nameplate of the tool supplied by WORX.

*Voltage measured without workload. Initial battery voltage reaches maximum of 4 volts. Nominal voltage is 3.6 volts.

NOISE DATA

A weighted sound pressure LpA: 65dB(A)

A weighted sound power LwA: 76dB(A)

KpA&KwA 3.0dB(A)

Wear ear protection when sound pressure is over 80dB(A)

VIBRATION INFORMATION

Vibration total values (triax vector sum) determined according to EN 60745:

Typical weighted vibration Vibration emission value: ah= 0.70m/s²

Uncertainty K = 1.5m/s²

The declared vibration total value may be used for comparing one tool with another, and may also be used in a

preliminary assessment of exposure.

WARNING: The vibration emission value during actual use of the power tool can differ from the declared value

depending on the ways in which the tool is used dependant on the following examples and other variations on

how the tool is used:

How the tool is used and the materials being cut or drilled.

The tool being in good condition and well maintained

The use the correct accessory for the tool and ensuring it is sharp and in good condition.
