Anleitung Flushingkit
WAC 1200PLUS / WAC 2200
INSTRUCTIONS MANUAL
-3-
A/C SYSTEM FLUSHING KIT
Attention: before flushing, recover the refrigerant of the a/c system using a suitable R&R
machine, then run at least 20 minutes vacuum.
PRINCIPAL COMPONENTS
Refer to Fig.1:
a) a) 6,5l accumulator
a1. filter
a2. inlet
a3. outlet
a4. oil drain
a5. safety valve
b) Clip connections
c) N°2 Check valves
d) A/C adapter fitting (*)
e) Black hose 2,5m 3/8SAE F - 3/8SAE F
f) N°2 Black hoses 150mm with 3/8 SAE F connections
g) N°2 Yellow hoses 150mm with 3/8 SAE F – M12x1,5 F connections
h) N°2 Black hoses 150mm with 3/8 SAE F – M14x1,5 F connections
(*) not supplied with this kit, refer to vehicle manufacturer
ASSEMBLY OF THE FLUSHING KIT
Consider 4 assembly configurations, It can be used with R&R machines with automatic valves
or manual valves and for both gases R134a or R1234yf
1- R134A MANUAL VALVES
Refer to Fig.2, operate as follow:
1) Disconnect the quick coupling from the blue hoses (LP) of the R&R machine
2) Connect the blue hose (LP) to the Black hose 150mm (g), to the check valve (c)
with orientation as showed in the figure and to the black hose 150mm (e).
3) Connect the other terminal of the Black hose 150mm (e) to the outlet (a3) of the 6,5l
accumulator (a)
4) Connect the Black hose 2,5m (d) to the inlet (a2) of the 6,5l accumulator (a)
5) Connect the other terminal of the Black hose 2,5m (d) to the Clip connection (b)
6) Disconnect the quick coupling from the red hoses (HP) of the R&R machine
7) Connect the red hose (HP) to the Black hose 150mm (g), to the check valve (c)with
orientation as showed in the figure and to the black hose 150mm (e).
8) Connect the other terminal of the black hose 150mm (e) to the Clip connection (b)
INSTRUCTIONS MANUAL
-4-
2- R1234YF MANUAL VALVES
Refer to Fig.2, operate as follow:
1) Disconnect the quick coupling from the blue hoses (LP) of the R&R machine
2) Connect the blue hose (LP) to the yellow hose 150mm (f), to the check valve (c)
with orientation as showed in the figure and to the black hose 150mm (e).
3) Connect the other terminal of the Black hose 150mm (e) to the outlet (a3) of the 6,5l
accumulator (a)
4) Connect the Black hose 2,5m (d) to the inlet (a2) of the 6,5l accumulator (a)
5) Connect the other terminal of the Black hose 2,5m (d) to the Clip connection (b)
6) Disconnect the quick coupling from the red hoses (HP) of the R&R machine
7) Connect the red hose (HP) to the yellow hose 150mm (f), to the check valve (c) with
orientation as showed in the figure and to the black hose 150mm (e).
8) Connect the other terminal of the black hose 150mm (e) to the Clip connection (b).
3- R134A AUTOMATIC VALVES
Refer to Fig.3,operate as follow:
1) Disconnect the quick coupling from the blue hoses (LP) of the R&R machine
2) Connect the blue hose (LP) to the Black hose 150mm (g);
3) Connect the other terminal of the Black hose 150mm (g) to the outlet (a3) of the 6,5l
accumulator (a);
4) Connect the Black hose 2,5m (d) to the inlet (a2) of the 6,5l accumulator (a);
5) Connect the other terminal of the Black hose 2,5m (d) to the Clip connection (b);
6) Disconnect the quick coupling from the red hoses (HP) of the R&R machine
7) Connect the red hose (HP) to the Black hose 150mm (g);
8) Connect the other terminal of the Black hose 150mm (g) to the Clip connection (b).
4- R1234YF AUTOMATIC VALVES
Refer to Fig.3, operate as follow:
1) Disconnect the quick coupling from the blue hoses (LP) of the R&R machine
2) Connect the blue hose (LP) to the yellow hose 150mm (f);
3) Connect the other terminal of the yellow hose 150mm (f) to the outlet (a3) of the 6,5l
accumulator (a)
4) Connect the Black hose 2,5m (d) to the inlet (a2) of the 6,5l accumulator (a)
5) Connect the other terminal of the Black hose 2,5m (d) to the Clip connection (b)
6) Disconnect the quick coupling from the red hoses (HP) of the R&R machine
7) Connect the red hose (HP) to the yellow hose 150mm (f);
8) Connect the other terminal of the yellow hose 150mm (f) to the Clip connection (b).
INSTRUCTIONS MANUAL
-5-
CONNECTION TO THE SYSTEM
Refer to Fig.4.
1) Use the correct seat of the rotating disk for the section of the component to be
connected to the rubber cone.
2) Connect the rubber cone of the clip from the red hose (HP) to the inlet of the
component to be flushed, and the clip from the blu hose (LP) to the outlet of the
component to be flushed.
NOTE: could be used also a adapter fitting (ref.C, fig.1) if supplied by the vehicle
manufacturer (Refer to Fig.5)
ENABLING THE FLUSHING KIT
If flushing kit must be enabled (not always, depending on machine model), select OPTIONS
(under CONFIGURATION or SETUP), then enter the code 43210791.
Select A/C SYSTEM FLUSHING, then enter the requested ACTIVATION CODE (retrieved with
the option kit). If the enabler code is not available, call the Service Center.
USING THE FLUSHING KIT
When flushing a system we recommend disassembling the filter and the expansion valve, in
the case of a traditional system, or only the capillary valve in the case of a flooded system. Use
the inlet to the evaporator as washing inlet and the outlet of the condenser as flushing outlet.
1 – MANUAL
In order to flush the A/C system (or one component) using any station recovery-recycling and
operate as follows:
1) Do 10 minutes of vacuum inside the system (or component)
2) Make a filling of 2 to 3 kg of refrigerant
3) Recover the filled refrigerant
4) Drain the oil (separated during recovery)
perform steps 2, 3 and 4 for three times, after which check the oil discharged from the last
cycle, if greater than 10cc make a further round of filling - recycling - waste oil (as in
paragraphs 2, 3 and 4 ).
After the washing operation, disconnect everything and unplug the machine from the power
supply.
NOTE: Every three or four washes remove the cylinder Y filter cap of the receiver, remove the
filter inside and clean it with compressed air.
INSTRUCTIONS MANUAL
-6-
2 – AUTOMATIC (machine w/ alphanumeric screen)
Switch the machine on. The MAIN MENU will appear after a few seconds:
Select ASSISTED PROCEDURE.
Scroll with the down arrow (↓) and select A/C SYSTEM FLUSHING.
You may type in the vehicle license plate number and confirm with ENTER.
select the desired amount of refrigerant, then press ENTER
Press ENTER.
Empty the used oil container, the press START.
At this point, the machine will proceed automatically. When flushing is completed, disconnect
all the couplings and disconnect the machine from the power supply.
Amount of gas to use for
every cycle
xxx g
press ENTER
A/C SYSTEM FLUSHING
Empty the container
Used oil and
press START
A/C System flushing.
Gas inject. xx g
ACp xxx bar
Connect the flushing kit
and open HP and LP.
press ENTER
INSERT PLATE NO.
. . . . . . . . . .
RECOVERY / RECYCLING
VACUUMN X min
OIL X ml
TRACER X ml
FILLING XX g
A/C SYSTEM FLUSHING
AUTOMATIC PROCEDURE
ASSISTED PROCEDURE
DATA AND CONFIGURAT.
MAINTENANCE
INSTRUCTIONS MANUAL
-7-
3 – AUTOMATIC (machine w/ manual valves and graphic b/n screen)
From ASSISTED PROCEDURE, scroll down with the DOWN ARROW , select “A/C System
Flushing”,:
press ENTER , the following screen will be displayed:
press ENTER , the following screen will be displayed:
Use DOWN ARROW and UP ARROW to select the desired amount, then press ENTER
to confirm. NOTE: selectable amount (steps of 500 g) between 1000 and 7500 grams
press START , the following screen will be displayed:
A/C SYSTEM FLUSHING
Open high and low
Pressure taps, then
Press F1 to continue
F2 to Exit
A/C SYSTEM FLUSHING
Connect the flushing
kit as explained in
manual
Press F1 to continue
F2 to Exit
A/C SYSTEM FLUSHING
Flushing refrigerant
Total amount
xxxx g
Press F4
A/C SYSTEM FLUSHING
Vacuum
xx min
Press F4
ASSISTED PROCEDURE
Purification
Bottle Filling
Air Purge
A/C System Flushing
Dynamic Diagnosis
Static Diagnosis
INSTRUCTIONS MANUAL
-8-
press START , the machine will proceed automatically, displaying the quantity of oil
extracted and printing the total volume at the end of flushing. When flushing is completed,
disconnect all the couplings and disconnect the machine from the power supply.
INSTRUCTIONS MANUAL
-9-
4 – AUTOMATIC (machine w/ automatic valves and graphic b/n screen)
From main menu:
Select ASSISTED PROCEDURE , the following screen is displayed (only if the hardware
for hybrid vehicles is installed in the machine).
Press ENTER to confirm STANDARD VEHICLE or press the down arrow ↓ and then ENTER
to select HYBRID VEHICLE.
Scroll down with the DOWN ARROW , select “A/C System Flushing”:
press ENTER , the following screen will be displayed:
press START , the following screen will be displayed:
AUTOMATIC PROCEDURE
Vacuum xx
Oil xx
Tracer Dye xx
Nitrogen Test xx
Gas Filling xxg
SELECT
Standard vehicle
Hybrid vehicle
A/C SYSTEM FLUSHING
Connect and open HP
and LP coupling to
A/C system
F1 to continue
F2 to exit
ASSISTED PROCEDURE
Purification
Bottle Filling
Air Purge
A/C System Flushing
Dynamic Diagnosis
Static Diagnosis
INSTRUCTIONS MANUAL
-10-
press START , the following screen will be displayed:
press START , the following screen will be displayed:
press START , the following screen will be displayed:
the machine will proceed automatically, displaying the quantity of oil extracted and printing the
total volume at the end of flushing. When flushing is completed, disconnect all the couplings
and disconnect the machine from the power supply.
A/C SYSTEM FLUSHING
Empty used oil
container
F1 to continue
F2 to exit
A/C SYSTEM FLUSHING
Oil extraction
Number of cycles: x
Acp x.x bar
A/C SYSTEM FLUSHING
It is necessary to
replenish lubricant
prior to start the
A/C system
F1 to continue
F2 to exit
A/C SYSTEM FLUSHING
This operation
completely remove
all the lubricant
from the A/C system
compressor.
F1 to continue
