Xantrex C40R/100 Remote Manuale utente
www.xantrex.com
Smart choice for power
Installation Guide
C-SeriesMeter
Display
C40R/50 Remote
C40R/100 Remote
DVM/C40 Faceplate
C-Series Meter Display
Installation Guide
About Xantrex
Xantrex Technology Inc. is a world-leading supplier of advanced power electronics and
controls with products from 50 watt mobile units to one MW utility-scale systems for
wind, solar, batteries, fuel cells, microturbines, and backup power applications in both
grid-connected and stand-alone systems. Xantrex products include inverters, battery
chargers, programmable power supplies, and variable speed drives that convert, supply,
control, clean, and distribute electrical power.
Trademarks
C-Series Meter Display is a trademark of Xantrex International. Xantrex is a registered
trademark of Xantrex International.
Other trademarks, registered trademarks, and product names are the property of their
respective owners and are used herein for identification purposes only.
Notice of Copyright
C-Series Meter Display Installation Guide © December 2003 Xantrex International. All
rights reserved.
Disclaimer
UNLESS SPECIFICALLY AGREED TO IN WRITING, XANTREX TECHNOLOGY INC. (“XANTREX”)
(a) MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF ANY
TECHNICAL OR OTHER INFORMATION PROVIDED IN ITS MANUALS OR OTHER DOCUMENTATION.
(b) ASSUMES NO RESPONSIBILITY OR LIABILITY FOR LOSS OR DAMAGE, WHETHER DIRECT,
INDIRECT, CONSEQUENTIAL OR INCIDENTAL, WHICH MIGHT ARISE OUT OF THE USE OF SUCH
INFORMATION. THE USE OF ANY SUCH INFORMATION WILL BE ENTIRELY AT THE USER’S RISK.
Date and Revision
December 2003 Revision A
Part Number
975-0123-01-01 Rev A
Contact Information
Telephone: 1 800 670 0707 (toll free North America)
1 360 925 5097 (direct)
Fax: 1 800 994 7828 (toll free North America)
1 360 925 5143 (direct)
Email: customerservice@xantrex.com
Web: www.xantrex.com
Contents
1. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2. Important Safety Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Warnings and Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Additional Safety Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3. Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
The Liquid Crystal Display (LCD) . . . . . . . . . . . . . . . . . . . . . . . . 5
Amp-Hour Reset and Backlight Button . . . . . . . . . . . . . . . . . . . . 6
LED Status Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4. Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Jumper Installation (Step 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Cable Installation (Step 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Mounting the Remote (Step 3) . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5. Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Status Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Resetting the Amp-Hour Meter . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Turning the Display Backlight On or Off . . . . . . . . . . . . . . . . . . 18
6. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
7. Warranty and Return . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
8. Other Xantrex Products . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
iv
975-0123-01-01 Rev A
1
1 Introduction
Thank you for purchasing the Xantrex C-Series Meter Display. The
C-Series Meter Display is an optional accessory for the C-Series
Multifunction DC controllers C35, C40 and C60. It provides a digital
display of the voltage, current, and amp-hour status for the C-Series
Multifunction DC Controller.
The C-Series Meter Display comes in two versions:
• the faceplate (DVM/C40), which replaces the front cover.
• the remote (C40R/50 and C40R/100), which can be installed
remotely up to 1,000 feet away from the controller.
Please note that labeling shown on the product photographs in this
guide may not exactly match the unit you purchased.
Figure 1
The Faceplate and Remote
Note: The C40R/50 and C40R/100 comes with either a
50 or 100 foot cable. It can also be installed up to 1,000
feet from the Controller. However, Xantrex does not
provide cables exceeding 100 feet.
The Remote
The Faceplate
2
975-0123-01-01 Rev A
Read this guide before connecting or using the C-Series Meter Display,
and save it for future reference. The main topics in the guide are as
follows:
•“Important Safety Information” on page 2
•“Features” on page 4
•“Installation” on page 7
•“Operation” on page 17
•“Troubleshooting” on page 18
•“Warranty and Return” on page 19
2 Important Safety Information
Misusing or incorrectly connecting the C-Series Meter Display may
damage the equipment or create hazardous conditions for users. Read
the following safety instructions and pay special attention to all
Warnings and Cautions statements in the guide.
Warnings identify conditions that may result in personal injury or loss
of life.
Cautions identify conditions or practices that may damage the unit or
other equipment.
975-0123-01-01 Rev A
3
Warnings and Cautions
Failure to follow these safety guidelines may cause personal injury
and/or damage to the C-Series Meter Display. It may also void your
product warranty.
Additional Safety Guidelines
Be sure to read, and adhere to, the Safety Guidelines listed in the
Owner’s Manual for the C-Series Multifunction DC Controller.
WARNING: Explosion Hazard
Do not use the C-Series Meter Display in the presence of flammable
fumes or gases. Do not use the C-Series Meter Display in an enclosure
containing automotive-type, lead-acid batteries. These batteries, unlike
sealed batteries, vent explosive hydrogen gas, which can be ignited by
sparks from electrical connections.
WARNING: Shock Hazard
Ensure all power sources are disconnected before proceeding.
4
975-0123-01-01 Rev A
3 Features
The C-Series Meters have three features:
• a Liquid Crystal Display (LCD) to show current, voltage,
amperage, resettable amp hours and total amp hours,
• an Amp-hour Reset Button, which is also used to illuminate or dim
the display, and
• a Light Emitting Diode (LED) to indicate system status.
The remote is supplied with either a 50-foot (15 m) or a 100-foot
(30.5 m) communications cable. Cable runs up to 1,000 feet (305 m) can
be used, but cables exceeding 100 feet are not provided by Xantrex.
Figure 2
Faceplate and Remote Features
LCD Display
Amp-hour Reset/
Backlight Button
The Remote
The Faceplate
Status LED
