XPower Powerpack 600HD
Owner's Guide
by
XPower Powerpack 600HD
Owner’s Guide
About Xantrex
Xantrex Technology Inc. is a world-leading supplier of advanced power
electronics and controls with products from 50 watt mobile units to one MW
utility-scale systems for wind, solar, batteries, fuel cells, microturbines, and
backup power applications in both grid-connected and stand-alone systems.
Xantrex products include inverters, battery chargers, programmable power
supplies, and variable speed drives that convert, supply, control, clean, and
distribute electrical power.
Trademarks
XPower Powerpack 600HD is a trademark of Xantrex International. Xantrex is a
registered trademark of Xantrex International.
Other trademarks, registered trademarks, and product names are the property of
their respective owners and are used herein for identification purposes only.
Notice of Copyright
XPower Powerpack 600HD Owner’s Guide © April 2005 Xantrex International.
All rights reserved.
Disclaimer
UNLESS SPECIFICALLY AGREED TO IN WRITING, XANTREX TECHNOLOGY INC.
(“XANTREX”)
(a) MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF
ANY TECHNICAL OR OTHER INFORMATION PROVIDED IN ITS MANUALS OR OTHER
DOCUMENTATION.
(b) ASSUMES NO RESPONSIBILITY OR LIABILITY FOR LOSS OR DAMAGE, WHETHER
DIRECT, INDIRECT, CONSEQUENTIAL OR INCIDENTAL, WHICH MIGHT ARISE OUT OF
THE USE OF SUCH INFORMATION. THE USE OF ANY SUCH INFORMATION WILL BE
ENTIRELY AT THE USER’S RISK.
Date and Revision
April 2005 Revision A
Part Number
975-0213-01-01
Contact Information
Telephone: 1 800 394 0440 (toll free North America)
1 360 925 5097 (direct)
Fax: 1 360 925 5143
Email: [email protected]
Web: www.xantrex.com
i
About This Guide
Purpose
The purpose of this Owner’s Guide is to provide explanations
and procedures for installing, operating, maintaining, and
troubleshooting the XPower Powerpack 600HD.
The Guide provides safety guidelines, detailed planning and
setup information, as well as information about operating and
troubleshooting the unit.
Conventions Used
The following conventions are used in this guide.
WARNING
Warnings identify conditions that could result in personal
injury or loss of life.
CAUTION
Cautions identify conditions or practices that could result
in damage to the product or to other equipment.
Important: These notes describe an important action item or an
item that you must pay attention to.
Note:These notes describe additional information which may
add to your understanding of how to use the product.
About This Guide
ii 975-0213-01-01
Related Information
You can find more information about Xantrex Technology
Inc. as well as its products and services at
www.xantrex.com.
iii
Important Safety Instructions
The XPower Powerpack 600HD generates a type of AC
power similar to a normal household wall outlet. Operating
the XPower Powerpack incorrectly or misusing it may
damage the equipment or create hazardous conditions for the
user.
Warnings and Cautions
Important: Before using your XPower Powerpack, be sure to
read and save these safety instructions.
WARNING: Shock hazard. Keep away from
children.
The XPower Powerpack generates the same potentially lethal AC
power as a normal household wall outlet. Do not insert foreign
objects into the AC Outlet, the DC Power Socket, the Jump-Start
Cable Port, or the ventilation holes. Do not expose this product to
water, rain, snow, or spray.
CAUTION
Do not connect any AC appliance with the neutral conductor
connected to ground to the XPower Powerpack.
CAUTION
Do not expose the XPower Powerpack to temperatures over 40 °C
(104 °F).
Safety
iv 975-0213-01-01
-
WARNING: Explosion hazard
Do not use this product where there are flammable fumes or gases,
such as in the bilge of a gasoline-powered boat, or near propane
tanks. Do not use this product in an enclosure containing
automotive-type lead acid batteries. These batteries, unlike the
sealed AGM battery in XPower Powerpack, vent explosive
hydrogen gas which can be ignited by sparks from electrical
connections. When working on electrical equipment, always ensure
someone is nearby to help you in an emergency.
WARNING: Heated surface
Ensure at least 2" (5 cm) air space is maintained on all sides of the
XPower Powerpack. During operation, keep away from materials
that may be affected by high temperatures such as blankets, pillows
and sleeping bags.
WARNING: Fire hazard
Never allow jump-start cables’ red and black clamps to touch each
other or another common metal conductor. This could cause
damage to the unit and/or create a sparking/explosion hazard.
Always disconnect the jump-start cables from the unit after use and
clip the plastic guard over the jump-start cable port.
WARNING: Fire hazard
Jump-start cable clamps must be connected positive to positive (red
clamp to battery “+”) and negative to negative (black clamp to
battery “–”). A reverse polarity connection (positive to negative)
may cause damage to the unit and/or create a sparking/explosion
hazard.
Safety
975-0213-01-01 v
WARNING: Fire hazard
The jump-start feature is designed for short term operation only—
less than 4 seconds. Operating the jump-start feature for more than
4 seconds may cause damage to the unit. Allow the XPower
Powerpack to cool down for at least 3 minutes after each jump-
start.
WARNING: Risk of explosion, fire or burns
The battery terminals exposed at the jump-start cable port have
enough energy present to cause a spark, creating an explosion
hazard, or to cause burns if a metal object contacts both terminals.
Always clip the plastic guard over the port when not in use.
Safety
vi 975-0213-01-01
Precautions When Working With Batteries
1. Follow all instructions published by the battery
manufacturer and the manufacturer of the equipment in
which the battery is installed.
2. Make sure the area around the battery is well ventilated.
3. Never smoke or allow a spark or flame near the engine or
batteries.
4. Be careful not to drop a metal object on the battery or
allow a metal tool to simultaneously touch the positive
and negative cable ends or battery terminals. It might
spark or short-circuit the battery or other electrical parts
and cause an explosion.
5. Remove personal metal items such as rings, bracelets,
necklaces, and watches when working with a lead-acid
battery. A lead-acid battery produces a short-circuit
current high enough to weld a ring or other similar
objects to metal, causing a severe burn.
6. If you need to remove a battery, always remove the
positive terminal from the battery first. Make sure all
accessories are off so you don’t cause an arc.
7. Someone should be within range of your voice, or close
enough to come to your aid when you work near a lead-
acid battery.
8. Have plenty of fresh water and soap nearby in case
battery acid contacts skin, clothing, and eyes.
9. Wear complete eye protection and clothing protection.
Avoid touching your eyes while working near batteries.
WARNING: Explosion and fire hazard
Safety
975-0213-01-01 vii
10. If battery acid contacts skin or clothing, wash
immediately with soap and water. If acid enters your
eyes, immediately flood them with running cold water for
at least twenty minutes and get medical attention
immediately.
11. Keep a supply of baking soda on hand in the area of the
batteries. Baking soda neutralizes lead-acid battery
electrolyte.
Precautions for Using Rechargeable
Appliances
Most rechargeable battery-operated equipment uses a
separate charger or transformer that is plugged into an AC
receptacle and produces a low voltage charging output.
Some chargers for rechargeable batteries can be damaged if
connected to the XPower Powerpack.
Do not use the following with the XPower Powerpack:
• Small battery-operated appliances like flashlights, razors,
and night lights that can be plugged directly into an AC
receptacle to recharge.
• Some chargers for battery packs used in hand power
tools. These chargers display a warning label stating that
dangerous voltages are present at the battery terminals.
CAUTION
The output of the inverter is non-sinusoidal.
Note:If you are unsure about using your rechargeable appliance
with the XPower Powerpack, contact the equipment manufacturer
to determine the rechargeable appliance’s compatibility with the
modified sine wave (non-sinusoidal) AC waveform.
