Xerox CopyCentre C2128 Manuale di istruzioni

www.xerox.com Reference “About Xerox

Product Safety Data Sheet

Product: CopyCentre C2128, C2636, C3545 PSDS No.: 0954

WorkCentre Pro C2128, C2636, C3545 ISSUE DATE: 09/30/04

REV. DATE: 04/02/07

Section I - Product Identification

Manufacturer's Name Emergency No. EH&S Inquiries

Xerox Corporation (585) 422-2177 (800) 828-6571

Manufacturer's Address

Webster, NY 14580

Product Designation Product Identifier:

CopyCentre C2128, C2636, C3545 System ZOC-1

WorkCentre Pro C2128, C2636, C3545 IOT - FAR-8

Section II - Electrical Information

Line Voltage Line Current Freq. Branch Cir. Protection

(Volts) (Amps) (Hertz)(Amps)

120 - 127 12A 60 15A OR 20A

Line Cord/Plug Specification Power Consumption (Watts)*

Equipped with Appliance Coupler Running: 838

Detachable Power cord Standby: 247

Two wire + ground Power Saver: 71

NEMA Type 5-15P OR 5-20P Plug OFF/FEMP: 0

Xerox ENERGY STAR equipment is preset at the factory. Your machine will be delivered with the timer for switching to

Power Save Mode from the last copy/print out, set at 30 minutes. A more detailed description of this feature can be found

in the Products User Guide.

Agency Approval

UL File Number E51242-A10-UL-1 cUL File Number E51242

Section III - Supplies

Material Safety Data Sheet

Toner, Black P-7001

Developer, Black B - 2004

Photoreceptor C - 3004

Section IV - Environmental Information

Product Size (IOT/TTM) Heat Emission* Environmental Limitations

(Meters / Inches) (BTU/HR) Min Max

D: 0.723 / 28.5 Running: 2,858 Relative Humidity (%) 15 85

W: 0.632 / 24.9 Standby: 842 Ambient Temp. (oC) 10 32

H: 0.857/ 33.7 Power Saver: 242

*Based on a five minute average

All measurements were made on products performing within established operating specifications and received

recommended maintenance procedures. Xerox certifies that this product meets or exceeds the applicable standards for

safety and emissions. www.xerox.com Reference “About Xerox

Product: CopyCentre C2128, C2636, C3545 PSDS No.: 0954

WorkCentre Pro C2128, C2636, C3545

Floor Space Requirements Weight

Full System with Professional Finisher (Meters / Inches) (K Grams / Lbs.)

Office 1.956 (D) X 2.286 (W) / 77 X 90 IOT/TTM 125 / 275

Hallway 2.540 (D) X 2.286 (W) / 100 X 90

Full System with Office Finisher (Meters / Inches)

Office 1.956 (D) X 2.032 (W) / 77 X 80

Hallway 2.540 (D) X 2.032 (W) / 100 X 80

Section V - Emission/Exposure Information*

Light Source FDA Accession Number

Class 3b Laser in a Class 1 Laser System, 9220485-70

Registered with the US FDA

Electromagnetic Emissions

US FCC: Class A

Canada DOC: Class A

Audible Noise TLV *

Run 60.5 dB(A) 85.0 dB(A)

Standby 35.4 dB(A)

Impulse 67.4 dB(A)

Ozone TLV

Concentration 0.1 ppm

0.001 ppm (0.002 mg/m3)

Ozone emissions were conducted in accordance to the JMBA-66-1999 test protocol.

Concentration is reported as an hourly average (from 30-90 minutes) in a 90-minute

continuous machine operation.

Total Dust TLV

0.017 mg/m310 mg/m3

Section VI - Product Recycling and Disposal

Xerox operates a worldwide equipment takeback and reuse/recycle program. Contact your Xerox sales

representative (1-800-ASK-XEROX) to determine whether this Xerox product is part of the program. For more

information about Xerox environmental programs, visit www.xerox.com/environment.

If you are managing the disposal of your Xerox product, please note that the product contains lead and other

materials whose disposal may be regulated due to environmental considerations. The presence of lead and is

fully consistent with global regulations applicable at the time that the product was placed on the market. For

recycling and disposal information, contact your local authorities. In the United States, you may also refer to

the Electronic Industries Alliance web site: www.eiae.org.

* TLV (Threshold Limit Value) and PEL (Permissible Exposure Level) respectively set by American Conference of

Government Industrial Hygienists and by Occupational Safety and Health Administration. These levels are considered

maximum exposure permitted to ensure no health hazard. TWA (Time-Weighted Average) for a normal eight-hour

workday.
