DC230LP Windows NT®4.0 TCP/IP Quick Install

Page 1 of 4

2. Access the System Administration menus:

Press [Online] to take the printer off

line. displays.

Press [Menu]. displays.

Press [], then press []or []until

displays.

Press []. displays.

Use the []and []keys to enter

[2222].

Note: 2222 is the factory default password and

may be changed to suit your needs. Refer to the

DC230LP System Administration Guide,

Network Installation and Troubleshooting

Press [Enter]. displays.

3. Access the TCP/IP menus:

Press []. displays.

Press []until

displays.

Press []. displays.

Printer Off Line

Main Menu >

System

Administration >

Enter Password >

System Admin >

Port Setup >

Network Setup >

TCP/IP >

Press []. displays.

4. IP Address Setup (skip this step if using

RARP):

Press []. displays.

Note: Use zeros to supplement each address

segment if fewer than 3 digits are used; e.g.,

13.252.25.08 = 013.252.025.008.

Use the []or []key to enter the

first digit of the IP Address.

Press []to move to the next digit.

Repeat this procedure to enter the

entire IP Address.

Press [Enter]. **SAVED** displays

momentarily, followed by

5. RARP Setup:

Note: If you used a static IP Address, leave the

RARP setting at

Disabled

To change the RARP setting, press

[]until the current setting displays

IP Address

(current entry)

IP Address =

(current entry) *

IP Address

(your entry)

RARP

(current entry)

Over

Installation Requirements:

To install the DC230LP in a DHCP environment,

exclude the addresses assigned to the

DC230LP at the DHCP server.

Before Installation:

Record the following information for use during

setup at the DC230LP:

TCP/IP Address:________________________

Gateway Address: ______________________

Subnet Mask: __________________________

Broadcast Address: _____________________

Host Name:____________________________

This installation procedure assumes that you

know how to navigate through the menu system

on the DC230LP Control Panel. Refer to the

quick reference card,

Using the Menu System,

(701P96834) for assistance.

1. Connect the DC230LP to your network

outlet or cable.

For assistance, contact your local Xerox Customer Support Center:

USA: 1-800-821-2797 Canada: 1-800-939-3769

7+('2&80(17&203$1<



DC230LP Windows NT®4.0 TCP/IP Quick Install

Page 2 of 4

Press [Enter]. **SAVED** displays

momentarily, followed by

7. Enter the Subnet Mask:

Press []until

displays.

Press []. displays.

Use the []or []key to select the

first digit of the Subnet Mask for your

network.

Press []to move to the next digit.

Repeat this procedure to enter the

entire Subnet Mask.

Press [Enter]. **SAVED** displays

momentarily, followed by

8. Enter the Broadcast Address:

Note: Broadcast Address is where all the host

bits are set to either zeros (0) or ones (1).

Default Gateway

(your entry)

Subnet Mask

(current entry)

Subnet Mask =

(current entry)

Subnet Mask

(your entry)

Press []until

displays.

Press []. displays.

Use the []or []key to select the

first digit in the Broadcast Address.

Press []to move to the next digit.

Repeat procedure to enter the entire

Broadcast Address.

Press [Enter]. **SAVED** displays

momentarily, followed by

9. Enter the Printer (Host) Name:

Note: It is recommended that the Printer (Host)

Name be the same as your Share Name.

Press []until

displays.

Press []. displays.

Press []repeatedly until the cursor

reaches the last character. A tone

sounds indicating when the last

character has been reached.

Broadcast Addr

(current entry)

Broadcast Addr =

(current entry)

Broadcast Addr

(your entry)

Printer Name

(current entry)

Printer Name =

(current entry)

Press []. displays.

Press []until the required setting

displays .

Press [Enter]. **SAVED** displays

momentarily, followed by

6. Enter the Gateway Address:

Press []until

displays.

Press []. displays.

Note: Use zeros to supplement each address

segment if fewer than 3 digits are used; e.g.,

13.252.25.08 = 013.252.025.008.

Use the []or []key to select the

first digit in the Gateway Address.

Press []to move to the next digit.

Repeat this procedure to enter the

entire Gateway Address.

RARP =

(current entry) *

RARP =

(required entry)

RARP

(your entry)

Default Gateway

(current entry)

Default Gateway =

(current entry)

7+('2&80(17&203$1<



DC230LP Windows NT®4.0 TCP/IP Quick Install

Page 3 of 4

Press []repeatedly to delete the

current entry.

Use the []or []key to select the

first character in the Printer Name.

Press []to move to the next charac-

ter. Repeat this procedure to enter the

entire Printer Name.

Press [Enter]. **SAVED** displays

momentarily, followed by

10.Enable the Line Printer Daemon (LPD):

Press [Escape] to move back a level

in the menu system.

displays.

Press []until

displays.

Press []. displays.

Press []until

displays.

Printer Name

(your entry)

TCP/IP

Line Printer

Daemon >

Enablement

(current entry)

Enablement =

(current entry)

Enablement =

Enabled

Press [Enter]. **SAVED** displays

momentarily, followed by

Note: The next menu at this level,

Port Setting

has a fixed setting for the LPD (515) and can not

be changed.

11. Save all settings:

Press [Online].

displays.

Press [Enter].

displays. The DC230LP will reboot,

save the settings entered, and print a

Configuration Report in approximately

3 minutes.

12.Check the settings on the Configuration

Report against those entered to be sure

they are correct.

Enablement

Enabled >

Reset Required

Press ENTER key

Warming Up

Please Wait . . . >

13.At the client, install print drivers and map

the printer in the usual manner. Refer to

the CentreWare®manual,

Getting Started

with Print and Fax Services

, for additional

information.

14.TCP/IP protocol and TCP/IP print services

must be installed on the NT Server and the

printer name must be set to [lp] (lower

case) when configuring the LPR port.

Refer to the screen sample below.

Additional information on the Windows NT

TCP/IP setup can be found in the

DC230LP

System Administration Guide, Network Installa-

tion and Troubleshooting

7+('2&80(17&203$1<



DC230LP Windows NT®4.0 TCP/IP Quick Install

701P98454 Version 1.0, 5-98
