Xerox EC8056 Manuale utente
www.xerox.com/office/support
5
9
3
2
1
10
11
8 7
4
6
Available apps can vary based on your printer setup. For details about apps and features, refer to the User Guide.
© 2021 Xerox Corporation. All Rights Reserved. Xerox®is a trademark of Xerox Corporation
in the United States and/or other countries. BR29865
Control Panel
Xerox®EC8036/EC8056 Color Multifunction Printer
Home returns to the main app screen.
Power/Wake starts the printer or provides options to sleep, restart or power off the printer.
Reset restores settings to their default values in all apps.
Language provides choice of screen languages.
Log In provides special access to tools and settings.
Device app provides access to printer information and settings.
Pause Printing temporarily stops an active print job.
Interrupt Print Job interrupts the current job to copy or print another job.
Status messages shows printer status and warnings.
Status LED indicates printer status. For detailed information, refer to the User Guide.
NFC Area allows pairing with a mobile device to print or scan from an app.
1
2
3
4
5
6
7
8
9
10
11
www.xerox.com/office/support
Device app
Billing and Usage Information
The Device app provides access to supplies status, printer information, and settings. Some menus and settings
require log in with the administrator name and password.
In the Device features menu, to view basic impression counts, touch Billing/Usage. To view detailed usage
counts, touch Usage Counters. The list provides detailed impression count categories.
Xerox®EC8036/EC8056 Color Multifunction Printer
© 2021 Xerox Corporation. All Rights Reserved. Xerox®is a trademark of Xerox Corporation
in the United States and/or other countries. BR29865
www.xerox.com/office/support
1
K
Y
CM
2
1
51
2
3
4
Printer Tour
Optional accessories can be part of your printer setup. For details, refer to the User Guide.
To restart the printer, on the control panel, press the secondary power switch.
For full printer power off, press the secondary power switch. Behind the front cover, press the main power switch.
To select sleep mode, press the secondary power switch. At the printer control panel touch screen, touch a selection.
Single-Pass Duplex Automatic Document Feeder (DADF)
Work Surface
USB Port
Output Trays
Left Tray
Paper Trays
Envelope Tray
Second Bias Transfer Roll
LED Print Head Cleaners
Belt Tension Lever
Fuser
Toner Cartridges
Drum Cartridges
Waste Cartridge
Xerox®EC8036/EC8056 Color Multifunction Printer
© 2021 Xerox Corporation. All Rights Reserved. Xerox®is a trademark of Xerox Corporation
in the United States and/or other countries. BR29865
www.xerox.com/office/support
1 2
3
Paper Handling
Loading Paper
Paper Orientation
For a complete list of paper that works with your printer, see the Recommended Media List at:
www.xerox.com/rmlna (U. S. and Canada)
www.xerox.com/rmleu (Europe)
For details about trays and paper, refer to the User Guide.
Letterhead Hole Punched Envelope
Confirm or change size, type, and color settings if
needed.
When printing, select options in the print driver.For the best results, fan the edges of the paper. Adjust
the guides to fit the paper size. Do not load paper above
the maximum fill line.
Xerox®EC8036/EC8056 Color Multifunction Printer
© 2021 Xerox Corporation. All Rights Reserved. Xerox®is a trademark of Xerox Corporation
in the United States and/or other countries. BR29865
www.xerox.com/office/support
X
Y
X
Y
1
123
456
789
0
1
789
0
1
2
3
Copying
Touch Copy, then and select the number of copies.
Select feature settings from the list, then touch Start.
Load the original documents.
38–128 g/m2
(26 lb. Text–34 lb. Bond)
≤130 (80 g/m2, 20 lb. Bond)
X: 85–432 mm (3.3–17 in.)
Y: 125–297 mm (4.9–11.7 in.)
X: 432 mm (17 in.)
Y: 297 mm (11.7 in.)
For details, refer to the User Guide.
Note: Settings from previous users remain
onscreen for a short time. To restore the
default settings in an app, scroll to the
bottom of the feature list and touch Reset.
Xerox®EC8036/EC8056 Color Multifunction Printer
© 2021 Xerox Corporation. All Rights Reserved. Xerox®is a trademark of Xerox Corporation
in the United States and/or other countries. BR29865
www.xerox.com/office/support
X
Y
X
Y
1
2
Scanning and Emailing
If the printer is connected to a network, you can select a destination for the scanned image at the printer
control panel.
This guide defines techniques to scan documents without preparing special setups:
• Scanning documents to an email address.
• Scanning documents to a saved Favorite, Address Book listing, or USB Flash Drive.
• Scanning documents to the Default Public folder on the printer hard drive, and retrieving them using your
Web browser.
For details and more scan setups, refer to the User Guide. For details about address book and workflow template
setup, refer to the System Administrator Guide.
Press Home, then to email the scan, touch Email. To scan to the
Default Public Mailbox or a USB Flash Drive, touch Workflow
Scanning. If your scan destination is stored in the Address Book or
saved as a Favorite, touch Scan To.
Load the original documents.
38–128 g/m2
(26 lb. Text–34 lb. Bond)
≤130 (80 g/m2, 20 lb. Bond)
X: 85–432 mm (3.3–17 in.)
Y: 125–297 mm (4.9–11.7 in.)
X: 432 mm (17 in.)
Y: 297 mm (11.7 in.)
Xerox®EC8036/EC8056 Color Multifunction Printer
© 2021 Xerox Corporation. All Rights Reserved. Xerox®is a trademark of Xerox Corporation
in the United States and/or other countries. BR29865
www.xerox.com/office/support
2
USB
4
3
For Email, touch Manual Entry,
type the email address using the
touch screen keypad, then touch
Add. To add more than one email
address to the list, touch Add
Recipient. To type a subject line for
the email, touch Subject. To select
saved email addresses, use the
Device Address Book or select from
Favorites.
For Workflow Scanning, touch
Default Public Mailbox, or insert
your USB Flash Drive.
For Scan To, touch a destination
type, then enter the appropriate
information. To add more than one
destination to the list, touch Add
Destination.
Scanning and Emailing
Change the settings as needed, then touch Scan, or for Email,
touch Send.
Note: Settings from previous users remain
onscreen for a short time. To restore the
default settings in an app, scroll to the bottom
of the feature list, then touch Reset.
www.xerox.com/office/support
3
http://xxx.xxx.xxx.xxx
http://xxx.xxx.xxx.xxx
2 3
1
Retrieving Scan Files
To download your scanned images from the Default Public Mailbox on the printer, use the Embedded Web
Server. You can set up personal mailboxes and workflow scanning templates in the Embedded Web Server. For
details, refer to the User Guide.
Scanning and Emailing
Note the printer IP address on the touch screen. If the IP Address does not appear in the upper left corner of the
touch screen, press Home, touch Device > About then scroll to check the IP Address.
In a Web browser, type the printer IP address, then
press Enter or Return.
Click the Scan tab.
www.xerox.com/office/support
http://xxx.xxx.xxx.xxx
4.24.1
4
4
Scanning and Emailing
Select the Default Public Mailbox, then find your scan in the list. To download the scan, click Go.
To refresh the list, click Update View.To save the file to your computer, select Download.
To print the saved file again, select Reprint.
To permanently remove the stored job, select Delete.
To open a directory, select Open.
www.xerox.com/office/support
X
Y
X
Y
2
1
Load the original document.
To send the fax to a fax machine, press Home, then touch Fax or
Server Fax.
To send the fax as an email attachment, touch Home, then touch
Internet Fax.
38–128 g/m2
(26 lb. Text–34 lb. Bond)
≤130 (80 g/m2, 20 lb. Bond)
X: 85–432 mm (3.3–17 in.)
Y: 125–297 mm (4.9–11.7 in.)
X: 432 mm (17 in.)
Y: 297 mm (11.7 in.)
Faxing
You can send a fax in one of four ways:
• Fax scans the document then sends it directly to a fax machine.
• Server Fax scans the document then sends it to a fax server, which transmits the document to a fax machine.
• Internet Fax scans the document then emails it to a recipient.
• LAN Fax sends the current print job as a fax.
For details, refer to the User Guide. For details about LAN Fax, refer to the print driver software. For details about
fax setup and advanced settings, refer to the System Administrator Guide.
Xerox®EC8036/EC8056 Color Multifunction Printer
© 2021 Xerox Corporation. All Rights Reserved. Xerox®is a trademark of Xerox Corporation
in the United States and/or other countries. BR29865
