WorkCentre M128/M123 Reference Guide Page

dc05cc0364

Xerox DocuColor

Accessing Extended

Features

Overview

This document enables you to access the extended features of the WorkCentre

M128/M123 in environments where Xerox does not provide a custom driver.

NOTE: Some of the commands and syntax used in this documents requires

familiarity with either PostScript (PS) or Printer Command Language (PCL).

This document provides the Printer Description Language (PDL) commands

and syntax for each feature. The following items are also included:

• A PostScript tables that describes the PostScript features the WorkCentre

supports and the syntax to use the feature.

• A PCL table that describes the PCL features the WorkCentre supports and

the syntax to use the feature.

This document is not intended to be a complete PS or PCL reference manual: it

is a guide for using the PS and PCL commands with WorkCentre. Refer to

these additional reference materials: PostScript Language Reference Manual,

Third Edition, ISBN 0-201-38922-8, PCL5 Printer Language Technical

Reference Manual Hewlett-Packard manual and Printer Job Language

Technical Reference Manual, Hewlett-Packard manual.

Using this Guide

1. Search the Feature Table to determine whether the feature you wish to use

is supported.

2. Verify that the feature is supported by the platform. For example, the

WorkCentre must have the Finisher option installed to use stapling

commands.

3. Following across the table to find the syntax listed for the PDL examples

shown. Read the Dependencies/Caveats section.

Xerox WorkCentre

PDL Reference Guide for the

WorkCentre M128/M123 October 20, 2004

dc05cc0364

Page

WorkCentre M128/M123 Reference Guide

dc05cc0364

PostScript

This WorkCentre supports PostScript 3 commands that enable the features

listed in the following table.

Feature Description

Media Size Physical paper (media) size (width and height)

Media Direction Feed direction of paper

Media Source Feed tray

Media Source

from SMH Specify if you feed from SMH (Sheet Media Handler).

Media Color Paper color

Media Weight Media weight. Unit: (g/㎡) gram per square-meter

Media Class Specify a Media Class value to trigger media-related actions (for

example, half-speed).

Media Type Spefify a paper type (for example, cover stock).

Media Selection Specify if you apply the strict setpagedevice rule to media

selection.

Resolution Horizontal and vertical resolution

Duplex Delivers two-sided output. landscape documents read like a

calendar, and portrait documents read like a book.


Enhancement Specify whether to apply edge-smoothing to output after

rendering.

Toner Save Specify whether to lighten output density to save toner.

Halftone Screen

Selection Screen type

Output Location Output bin

Quantity Number of copies. (maximum: 9999)

Collation Multiple pages in sequential sets (page 1, 2, 3, 4, etc.) or multiple

pages in sets of the same page (4 copies of page 1, 4 copies of

page 2, etc.)

Jog Deliversoffsetting document sets.

Stapling Indicates a staple position.

Interleaving

Paper Insert blank sheet between OHP (transparency) sheets

Process Color

Model Select process color model (DeviceGray, DeviceRGB,

DeviceCMYK,)

Separations Specify to generate multiple color separations for each page of

output

WorkCentre M128/M123 Reference Guide Page

dc05cc0364

Feature Description

Separation Color

Names Specify the process colorant name.

Separation

Order Specify the order of process colorant name.

Use CIE Color Specify to apply CIE-based color space through color conversion

PostScript Implementation

This section describes the PostScript commands required to access specific

WorkCentre features. The following table lists each feature and the PostScript

syntax required to use the feature. After the table are examples of how to use

these commands and what the PostScript file looks like.

For more information about PostScript commands, refer to the PostScript

Language Reference Manual, Third Edition, ISBN 0-201-37992-8.

PostScript Print Features/Implementation

* = default value

Feature Implementation Values

Media Size <</PageSize [width height]>>

setpagedevice

[width x height] in 1/72 inch (points)

[842 1191] = A3

[595 842] = A4

[420 595] = A5 †

[729 1032] = B4

[516 729] = B5

[396 612] = Statement (5.5 x 8.5) †

[612 792] = Letter (8.5 x 11)

[612 936] = Legal 13 (8.5 x 13)

[612 1008] = Legal (8.5 x 14)

[792 1224] = 11 x 17

[522 756] = Executive (7.25 x 10.5) †

[765 1106] = 8Kai †

[757 1100] = 8Kai †

[553 765] = 16Kai †

[550 757] = 16Kai †

†: Each paper size is available based on

non-volatile memory setting.

The following paper sizes are only available

with SMH.

[297 420] = A6

[363 516] = B6

[576 720] = 8 x 10

[609 892] = 8.46 x 12.4

[792 1080] = 11 x 15

[632 842] = A4 Cover

[648 792] = Letter Cover (9 x 11)

[283 420] = Hagaki (Japanese PostCard)

[420 567] = Double Hagaki

[279 540] = Monarch

[297 684] = Com-10

[312 624] = DL

[288 432] = Postcard

[649 918] = C4

Page

WorkCentre M128/M123 Reference Guide

dc05cc0364

Feature Implementation Values

[459 649] = C5

[340 666] = Tyoukei You 3

Media

Direction <</LeadingEdge int >>

setpagedevice Where int is one of the following:

0 = Short Edge; top of page in portrait

orientation.

1 = Long Edge; left side of page in portrait

orientation.

2 = Short Edge; bottom of page in portrait

orientation.

3 = Long Edge; right side of page in

portrait orientation.

null* = Auto

Media Source <</MediaPosition int>>

setpagedevice Where int is one of the following:

0 = Tray1

1 = Tray2

2 = Tray3

3 = Tray4

null* = Auto

Media Source

from SMH <</ManualFeed value>>

setpagedevice Where value is one of the following:

true = Feed paper from SMH

false* = Feed paper from a tray other than

SMH

Media Color <</MediaColor (string) >>

setpagedevice Where string is any value.

Media Weight <</MediaWeight real >>

setpagedevice Where real is in g/㎡(gram per

square-meter) or null

Media Class <</MediaClass (string)>>

setpagedevice

Where string is one of the following:

Stationary = normal paper

recycled = recycled paper

transparency = OHP sheet

thick1 = thick paper 1

thick2 = thick paper 2

user1 = user defined paper 1

user2 = user defined paper 2

user3 = user defined paper 3

user4 = user defined paper 4

user5 = user defined paper 5

thin = thin paper

label = label paper

used = backing paper

Media Type <</MediaType (string)>>

setpagedevice

Where string is any value.

WorkCentre M128/M123 Reference Guide Page

dc05cc0364

Feature Implementation Values

Media

Selection <</DeferredMediaSelection

value>>

setpagedevice

Where value is one of the following:

true* = Deferred media selection by

output device (more powerful and flexible

media selection)

false = Immediate media selection by

strict setpagedevice operator

Resolution <</HWResolution [x y]>>

setpagedevice

Where xand yare one of the following:

600 600*(dpi)

1200 1200

Duplex <</Duplex value>>

setpagedevice Where value is one of the following:

true = Duplex

false* = Simplex

Tumble <</Tumble value>>

setpagedevice

This feature is effective only in

conjunction with Duplex = true.

Where value is one of the following:

true = Tumble (Short edge binding

Duplex)

false* = Duplex (Long edge binding

Duplex)


Enhancement <</PostRenderingEnhance true

/PostRenderingEnhanceDetails

<< /Type 32 /REValue int >>

setpagedevice

Where int is one of the following:

0 = No image enhancement

1* = Activate image enhancement

Toner Save <</PostRenderingEnhance true

/PostRenderingEnhanceDetails

<< /Type 32 /TonerSaver int >>

setpagedevice

Where int is one of the following:

0* = No toner saving

1 = Lighten output density, toner saving

Halftone

Screen

Selection

<</PostRenderingEnhance true

/PostRenderingEnhanceDetails

<< /Type 32 /EngineScreen int >>

setpagedevice

Where int is one of the following:

0* = Low frequency screen

1 = High frequency screen

2 = Compatible screen with FX standard

PDL’s

Output

Location <</OutputType (string)>>

setpagedevice

Where string is one of the following:

CENTER TRAY: facedown tray #1 (w/o

finisher)

CENTER TRAY2: facedown tray #2 (w/

finisher)

SIDE TRAY: faceup tray

FINISHER TRAY1: finisher tray

Null = Not specified

Page

WorkCentre M128/M123 Reference Guide

dc05cc0364

Feature Implementation Values

Quantity <</NumCopies value >>

setpagedevice Where value is one of the following:

integer from 1 to 9999: number of copies

null: Not specified

Collation <</Collate value >>

setpagedevice Where value is one of the following:

true = collated

false* = uncollated

Jog <</Jog int >>setpagedevice Where int is one of the following:

0 = Do not offset

3 = Offset at the beginning of each page

[set]

Stapling <</Staple int1

/StapleDetails << /Type 7

/Location int2 >>

setpagedevice

Where int1 is one of the following:

0* = Do not staple

3 = Staple at the end of each set

Where int2 is one of the following:

0* = top-left-single

1 = bottom-left-single

2 = top-right-single

3 = bottom-right-single

4 = top-double

5 = bottom-double

6 = left-double

7 = right-double

Interleaving

Paper <</SlipSheet int1

/SlipSheetDetails << /Type 1

/AutoTraySelect int2

/SheetTray int3

/MediaClass (string) >>

setpagedevice

Where int1 is one of the following:

0 = Do not deliver interleaving paper.

4 = Deliver interleaving paper at the end

of each page

Where int2 is one of the following:

0 = SheetTray is referred and feed

interleaving paper from the SheetTray

1* = Feed interleaving paper from a tray

following system setting. SheetTray is

not referred.

Where int3 is one of the following:

0* = Feed interleaving paper from Tray1

1 = Tray2

2 = Tray3

3 = Tray4

100 = SMH

Where string is same as the “Media

Class” feature. It means media class for

the interleaving paper.

WorkCentre M128/M123 Reference Guide Page

dc05cc0364

Feature Implementation Values

Process Color

Model <</ProcessColorModel name >>

setpagedevice Where name is one of the following:

/DeviceGray

/DeviceRGB (with Separations true)

/DeviceCMYK (with Separations true)

/DeviceCMY (with Separations true)

/DeviceRGBK (with Separations true)

Separations <</Separations value >>

setpagedevice Where value is one of the following:

true = Multiple color separations will be

generated for each page of output.

false* = All colorants will be combined into a

single composite page on a single

sheet of physical medium.

Separation

Color Names <</SeparationColorNames

value>>

setpagedevice

Where value is an array.

Legal element values are the process

colorant names implied by the process

color model.

Valid colorant names for each process

color model are like the following in case

of separation

DeviceCMYK = Cyan, Magenta, Yellow,

Black

DeviceCMY = Cyan, Magenta, Yellow

DeviceRGB = Red, Green, Blue

DeviceRGBK = Red, Green, Blue, Gray

DeviceGray = Gray

Separation

Order <</SeparationOrder value>>

setpagedevice

Where value is an array.

Legal element values are the process

colorant names implied by the process color

model.

Use CIE Color <</UseCIEColor value>>

setpagedevice Where value is one of the following:

true = Re-map each color from device

color space to device

independent’s CIE- based color

space

false* = Do not re-map color

Job Name

Job Type

Accounting

Delay Print

These features use PJL commands as described in “PCL/PJL Implementation.”

Refer to that section for information about these features.

Page

WorkCentre M128/M123 Reference Guide

dc05cc0364

Sample PostScript Headers

Example 1 Header for Simple Print

%!PS

Example 2 Header for Finishing

(Letter paper, duplex, 10 copies with collation, stapling with left-upper single

and stacker tray for output bin)

%!PS

<</PageSize [612 792]>>setpagedevice

<</Duplex true /Tumble false>>setpagedevice

<</OutputType (FINISHER TRAY1)>>setpagedevice

<</Collate true>>setpagedevice

<</NumCopies 10>>setpagedevice

<</Staple 3 /StapleDetails << /Type 7 /Location 0 >>

>>setpagedevice

PostScript Feature Dependencies/Caveats

• All DSC comments are ignored and not interpreted.

• The WorkCentre supports PostScript resolutions up to and including 1200 x

1200. Some PostScript jobs may not print if you use this resolution. If

printing stops, reprint the same job at a lower resolution.

• Valid media sizes for duplexing are between [253 x 360] and [841 x 1224]

(point) except Hagaki, Double Hagaki, Postcard, Tyou-Youkei 3, Com10,

Monarch, DL, C4, and C5.

• Valid media sizes for stapling includeA3, A4, B4, B5, 8.5x11, 8.5x13,

8.5x14, 11x17, 8-Kai, 16-Kai, and 7.25 x 10.5.

• Do not duplex transparency and recycled paper jobs.

• Do not staple any job with all paper class except stationary, recycled and

used (backing) paper.

WorkCentre M128/M123 Reference Guide Page

dc05cc0364

PostScript Fonts

The following PostScript fonts are resident with Adobe interpreter.

Albertus

Albertus Italic

Albertus Light

Antique Olive Roman

Antique Olive Italic

Antique Olive Bold

Antique Olive Compact

Apple Chancery

Arial

Arial Italic

Arial Bold

Arial Bold Italic

ITC Avant Garde Gothic Book

ITC Avant Garde Gothic Book Oblique

ITC Avant Garde Gothic Demi

ITC Avant Garde Gothic Demi Oblique

Bodoni Roman

Bodoni Italic

Bodoni Bold

Bodoni Bold Italic

Bodoni Poster

Bodoni Poster Compressed

ITC Bookman Light

ITC Bookman Light Italic

ITC Bookman Demi

ITC Bookman Demi Italic

Carta

Chicago

Clarendon Roman

Clarendon Bold

Clarendon Light

Cooper Black

Cooper Black Italic

Copperplate Gothic 32BC

Copperplate Gothic 33BC

Coronet

Courier

Courier Oblique

Courier Bold

Courier Bold Oblique

Eurostile Medium

Eurostile Bold

Eurostile Extended No. 2

Eurostile Bold Extended No. 2

Geneva

Gill Sans

Gill Sans Italic

Gill Sans Bold

Gill Sans Bold Italic

Gill Sans Light

Gill Sans Light Italic

Gill Sans Extra Bold

Gill Sans Condensed

Gill Sans Condensed Bold

Goudy Oldstyle

Goudy Oldstyle Italic

Goudy Bold

Goudy Bold Italic

Goudy Extra Bold

Helvetica

Helvetica Oblique

Helvetica Bold

Helvetica Bold Oblique

Helvetica Narrow

Helvetica Narrow Oblique

Helvetica Narrow Bold

Helvetica Narrow Bold Oblique

Helvetica Condensed

Helvetica Condensed Oblique

Helvetica Condensed Bold

Helvetica Condensed Bold Oblique

Hoefler Text

Hoefler Text Italic

Hoefler Text Black

Hoefler Text Black Italic

Hoefler Ornaments

Joanna

Joanna Italic

Joanna Bold

Joanna Bold Italic

Letter Gothic

Letter Gothic Slanted

Letter Gothic Bold

Letter Gothic Bold Slanted

ITC Lubalin Graph Book

ITC Lubalin Graph Book Oblique

ITC Lubalin Graph Demi

ITC Lubalin Graph Demi Oblique

Marigold

Monaco

ITC Mona Lisa Recut

New Century Schoolbook Roman

New Century Schoolbook Italic

New Century Schoolbook Bold

New Century Schoolbook Bold Italic

NewYork

OCR-B Letterpress M

Optima Roman

Optima Italic

Optima Bold

Optima Bold Italic

Oxford

Palatino Roman

Palatino Italic

Palatino Bold

Palatino Bold Italic

Stempel Garamond Roman

Stempel Garamond Italic

Stempel Garamond Bold

Stempel Garamond Bold Italic

Page

WorkCentre M128/M123 Reference Guide

dc05cc0364

Symbol

Tekton Regular

Times Roman

Times Italic

Times Bold

Times Bold Italic

Times New Roman

Times New Roman Italic

Times New Roman Bold

Times New Roman Bold Italic

Univers 45 Light

Univers 45 Light Oblique

Univers 55

Univers 55 Oblique

Univers 65 Bold

Univers 65 Bold Oblique

Univers 57 Condensed

Univers 57 Condensed Oblique

Univers 67 Condensed Bold

Univers 67 Condensed Bold Oblique

Univers 53 Extended

Univers 53 Extended Oblique

Univers 63 Extended Bold

Univers 63 Extended Bold Oblique

Wingdings

ITC Zapf Chancery Medium Italic

ITC Zapf Dingbat

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Xerox Stampante tutto in uno

Xerox

Xerox 3210 - workcentre b/w laser Manuale utente

Xerox

Xerox WORKCENTRE C2424 Manuale utente

Xerox

Xerox WorkCentre Pro C2128 Manuale utente

Xerox

Xerox M20I - WorkCentre B/W Laser Manuale di istruzioni

Xerox

Xerox WorkCentre Xi70c Manuale utente

Xerox

Xerox WorkCentre 4265 Manuale utente

Xerox

Xerox Copycentre C118 Manuale utente

Xerox

Xerox WorkCentre Pro 423 Manuale utente

Xerox

Xerox WorkCentre M35 Manuale utente

Xerox

Xerox CopyCentre 118 Manuale utente

Xerox

Xerox WorkCentre 3315 Manuale operativo

Xerox

Xerox ColorQube 9301 Manuale utente

Xerox

Xerox WORKCENTRE 7120 Manuale operativo

Xerox

Xerox PHASER 6121MFP Manuale operativo

Xerox

Xerox VersaLink B71 Series Manuale dell'operatore

Xerox

Xerox 4150xf - WorkCentre B/W Laser Manuale utente

Xerox

Xerox 4150 - WorkCentre B/W Laser Manuale del proprietario

Xerox

Xerox PHASER 6121MFP Manuale utente

Xerox

Xerox WorkCentre Pro C2128 Manuale utente

Xerox

Xerox WorkCentre 3315 Manuale utente

Xerox

Xerox Phaser 6140N Istruzioni per l'installazione

Xerox

Xerox WorkCentre 5325 Manuale operativo

Xerox

Xerox DocuColor 3535 Manuale utente

Xerox

Xerox WorkCentre 7245 Manuale utente

Manuali Stampante tutto in uno popolari di altre marche

Triumph Adler

Triumph Adler DC 2016 Manuale

Epson

Epson WorkForce WF-2510 Guida utente

Epson

Epson Stylus Scan 2000 Manuale di installazione e funzionamento

Epson

Epson PictureMate Snap PM 240 Manuale di istruzioni

Konica Minolta

Konica Minolta bizhub C35 Manuale utente

Brother

Brother MFC-J430w Manuale utente

Konica Minolta

Konica Minolta BIZHUB 558 Manuale utente

Lexmark

Lexmark MX710 Series Manuale

Brother

Brother MFC-9760 Manuale utente

Lexmark

Lexmark XC8155 Manuale utente

Lexmark

Lexmark X642E Manuale utente

Sharp

Sharp MX-2310U Guida

Aficio

Aficio 200 Manuale utente

Canon

Canon ImageCLASS 2300 Manuale

Ricoh

Ricoh Pro C900 Manuale utente

Lexmark

Lexmark X925 Manuale utente

Brother

Brother Business Smart MFC-J4510dw Manuale utente

Epson

Epson Stylus CX8400 Series Manuale utente
