Xerox WorkCentre PE120i Manuale utente

copy print scan fax

WorkCentre PE120i

Evaluator

Guide

WorkCentre®PE120i

1 WORKCENTER PE120I EVALUATOR GUIDE

CONTENT

Product Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Configuration Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Competitive Comparison . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Physical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Operating Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Total Satisfaction Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Additional Information Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

PRODUCT OVERVIEW

With the Xerox WorkCentre®PE120i multifunction system you

enjoy large office multi-functionality, scaled for personal use. Easy

and convenient access to high quality printing, copying, scanning, and

faxing right from your desktop. The WorkCentre PE120i combines the

power of four separate devices in one extremely compact package, with

an engine speed of 22 ppm (letter size) and a maximum resolution of

1200 dpi image quality.

Small businesses or individual users looking for a personal multifunction

solution with a recommended volume of up to 2,000 prints per month

and a duty cycle of up to 15,000 prints per month will like the cost and

space savings the WorkCentre PE120i can provide.

An easily replaceable single-component consumable called a SMart Kit™,

and an intuative control panel for all functions, assure that the

WorkCentre PE120i will be easy to use and maintain.

WorkCentre PE120i is the first in this class to provide USB access right

on the front of the device. This allows you to save a document on a

USB storage device as a .prn file and then print it directly at the device.

You can also scan directly to a USB storage device.

One notable feature is a standard color scanner which enables the

scanning and storage of color documents to the desktop or USB device,

as well as submission of color facsimiles. ScanSoft®Omnipage®SE 2.0

and PaperPort®SE 9.0 software are included to convert hard copy

documents into spreadsheets, text, or HTML formats that can be edited

and repurosed.

Two standard features not found in competitive products in this class are

ID Copy and Auto Fit Copy. ID Copy automatically prints both sides

of an ID card on the same side of a letter size page – ideal for medical

or dental offices that need to document patient’s insurance information.

Auto Fit Copy automatically reduces or enlarges an original to fill the

printable area of a letter size page – this is particularly useful for automatic

zoom reduction or enlargement copying of odd-sized originals.

Easy to Use: Powerful Features: Attractively Priced:

• Compact design for

easy desktop placement

• 22 ppm (letter), 20 ppm (A4) • Consolidate assets

into one great device

• Multiple paper sources for

flexible output options

• Color scanning to the

desktop or USB device

• Cost conscience

budget pleaser

• Network printing available

to share capabilities

• Fax at 3 seconds per page • Saves time with

desktop convenience

Workcenter PE120i

Digital copier

Direct connect printer

Network printing

PostScript

Direct connect scan

Fax

Second 250 sheet tray - optional

WORKCENTER PE120I EVALUATOR GUIDE

3WORKCENTER PE120I EVALUATOR GUIDE

CONFIGURATION SUMMARY

What it means to you

PRINTING:

Technology Laser Monochrome

Speed 22 ppm US Letter, 20 ppm A4 FAST

Resolution 600 dpi, 1200 dpi emulated QUALITY

2-Sided No

Page Description Language PCL 6, PostScript

Print Drivers Windows 98/NT4.0/2000/ME/XP, Mac OS 9.x/X

Interfaces USB (cable included) and parallel, PE120i provides 10/100BaseT Ethernet EASY

Memory 32 MB, optional up to 160 MB EASY

COPYING:

Speed 22 copies per minute

Resolution 600 x 600 dpi

First Copy Out less than 10 seconds

Reduce/Enlarge POWERFUL

Platen 25-400% in 1% increments

ADF 25-100% in 1% increments

Productivity Scan Once Print Many with Electronic Pre-Collation PRODUCTIVE

Multiple Copies Up to 99 copies of multiple page originals

FAX:

Transmission Speed 3 seconds per page FAST

Modem Speed 33.6 Kbps

Data Compression MMR/MR/MH/JBIG

Resolution pre-sets up to 300 x 300 dpi QUALITY

Fax Memory 4 MB

Halftones 256 levels

Color Fax Tx/Rec Yes/No

Battery Backup Up to 15 minutes when fully charged SECURITY

SCAN:

Compatibility TWAIN standard CONFORMITY

Technology Direct Connect to PC (USB)

Scan Resolution Settings Variable

Resolution up to 600 x 1200 dpi QUALITY

Pre-scan Yes, 75 dpi

Formats TIFF, Multi-page TIFF, PDF

Bundled Software ScanSoft®PaperPort®SE 9.0 and OmniPage®SE 2.0 PRODUCTIVE

MEDIA HANDLING:

Input Paper Capacity

Standard Tray 250 sheets PRODUCTIVE

Optional Tray 250 sheet

Bypass Tray 50 sheet

Paper Size Mininum 5 x 7 in. (127 x 176 mm)

Maximum 8.5 x 14 in. (216 x 356 mm) FLEXIBILITY

Paper Weight Standard Tray 16-24 lb. (60-90 gsm)

Bypass Tray 16-43 lb. (60-163 gsm) FLEXIBILITY

Automatic Document Feeder 50 Sheets

Output Capacity 150 Sheets

Media Types Paper, envelopes, labels, transparencies FLEXIBILITY

Feature Xerox WorkCentre PE120i HP LaserJet 3380mfp Dell 1600

Canon ImageClass

MF5550

GENERAL

Speed 20/22 ppm 20 ppm 22 ppm 19 ppm

FPOT 10 sec. 8 sec. 10 sec. 10 sec.

Processor 166 MHz 240 Mhz 166 MHz Info. not supplied

Standard Tray 250 sheet 250 sheet 250 sheet 250 sheet

Bypass Tray 50 sheet 10 sheet 1 sheet 1 sheet

Optional Tray 250 sheet N/A 250 sheet N/A

Output Tray 150 sheet 125 sheet 150 sheet 125 sheet

COPIER

Resolution 600 dpi 600 dpi 600 dpi 600 dpi

ADF 50 sheet 50 sheet 50 sheet 50 sheet

Multi-Up Yes N/A Yes N/A

Reduce/Enlarge 25% - 400% 25% - 400% 25% - 400% 50% - 200%

Multiple Copies Up to 99 Up to 99 Up to 99 Up to 99

PRINTER

Resolution 600 dpi, 1200 dpi emulation 1200 dpi 600 dpi 600 dpi

PDL PCL, PS PCL6, PS2 (Emulation) PCL, PS3 CAPT (Canon Proprietary)

Memory 32 MB optional up to 160 MB Up to 96 MB 32 MB Unknown

Connectivity USB 2.0

Parallel

USB 2.0

Parallel

USB 2.0

Parallel

USB 2.0

Network Capable Yes N/A Yes N/A

FAX

Modem Speed 33.6 Kbps 33.6 Kbps 33.6 Kbps 33.6 Kbps

Resolution Up to 300 x 300 dpi Up to 300 Up to 300 x 300 dpi Up to 203 x 196 dpi

Speed Dials 200 speed 120 speed 200 speed 12 speed/100 coded

Fax Memory 4 MB Info. not supplied 4 MB Info. not supplied

SCANNING

Color scanning Yes Yes Yes Yes

Resolution 600 x 1200 dpi 600 x 600 dpi 600 x 1200 dpi 1200 dpi x 2400 dpi

CONSUMABLES

Cartridge 3500 and 5000 2500 and 3500 3500 and 5000 2500

COMPETITIVE COMPARISON

WORKCENTER PE120I EVALUATOR GUIDE

5WORKCENTER PE120I EVALUATOR GUIDE

SUPPLIES

The WorkCentre PE120i is designed for easy user replacement of its all-in-one print cartridge, called a SMart Kit™.

Two cartridges are available; a 3,500 page capacity and a 5,000 page capacity (based on average 5% coverage.)

PHYSICAL SPECIFICATIONS ELECTRICAL SPECIFICATIONS

Dimensions (W x D x H) 17.7 x 17.1 x 18 in.

(450 x 435 x 457 mm)

Weight 37 lbs. (16.7 kg) (with toner)

Power Switch Yes

Power 110 VAC, 50/60 Hz or

220 VAC, 50/60 Hz

Power Consumption Maximum 400 watts

Power Saver Mode: 19 watts

OPERATING ENVIRONMENT

Temperature Maximum Range 50° - 89.6°F

(10° - 32°C)

Recommended Range 60.8° - 86°F

(16° - 30°C)

Humidity Maximum Range 20 - 80%

Recommended Range 30 - 70%

Device Memory 32 MB optional up to 160 MB

Device Management Xerox ControlCentre™5.0

SAFETY

UL Safety Certified

CSA Safety

TOTAL SATISFACTION SERVICES™

The WorkCentre PE120i comes with a one-year depot (carry-in) warranty, web-based technical

support, and telephone technical support. In addition, this product is covered by the Xerox

Total Satisfaction Guarantee.

Optional service offerings available within the first 90 days of product ownership include:

DESCRIPTION US PART NUMBER CANADIAN PART NUMBER

Extended Depot Service

Adds 2 additional years of Depot Service (for a total of 3 years)

Convert 1-year depot warranty to 1-year on-site

PE20D3

PE20S1

PE20D3C

PE20S1C

On-Site Service (uplifts warranty to on-site and extends the length)

Total of 3 years on-site service

Total of 4 years on-site service

PE20S3

PE20S4

PE20S3C

PE20S4C

Help Desk Training A4INST A4INSTC

Additional Information Sources

The Front Panel

The Front Panel offers tools and information pages to help

with machine set-up, feature selections, solve operational

problems, media feed and supply issues.

The PE120i Customer Documentation

CD-ROMs contain:

•User Guide

•Drivers CD

•PCL6, TWAIN, ControlCentre

•PS and Mac

•ScanSoft bundled software

•System Administrator’s Guide

On the Web

Visit www.xerox.com/office for:

•Product, supplies, and support information

•Downloading drivers

•Finding your local reseller

•On-line documentation

Visit www.xerox.com/office/support for:

Support and service information including the same

troubleshooting knowledge base used by Xerox Customer

Support staff to provide the latest technical information on:

•Application issues

•Errors

•Print-quality issues

•Troubleshooting

WORKCENTER PE120I EVALUATOR GUIDE

Questions? Comments? Problems?

If you have any questions or issues with your evaluation multifunction product,

please contact your Xerox sales representative or the Xerox Office Help Desk at:

U.S. and Canada 1-877-362-6567

or visit us on the web at: www.xerox.com/office

WorkCentre®PE120i

© 2009 XEROX CORPORATION. All rights reserved. Xerox®is a registered trademark of XEROX CORPORATION. WorkCentre™ and ControlCentre™ are trademarks of XEROX CORPORATION. Total Satisfaction ServicesSM is a service mark of XEROX CORPORATION. Omnipage®SE is a reg-

istered trademark of ScanSoft. All other trademarks are the property of their respective manufacturers. The information in this brochure is subject to change without notice. 6/09 P20EG-01UD
