Xerox Regal 5790 Manuale utente

copyrightable material and information now allowed by statutory or

judicial law or hereinafter granted, including without limitation,

material generated from the software programs which are displayed

on the screen such as styles, templates, icons, screen displays,

looks, etc.

Xerox®, The Document Company®, the digitized X, and all Xerox

product names and product numbers mentioned in this publication

are trademarks of Xerox Corporation®. Other company trademarks

are also acknowledged.

Changes are periodically made to this document. Technical updates

will be included in subsequent editions.

Printed in the United States of America.

REGAL 5790 MATERIALS USAGE GUIDE iii

Table Of Contents

Introduction 1

Conventions 2

Recommended Materials 3

Not Recommended Materials 6

Applications 7

Usage Guidelines 8

Heavy-Weight Papers 8

Recycled Papers 10

Hole-Punched Papers 11

Pressure-Sensitive Labels 12

Coated Papers 13

Preprinted Papers 16

Single-Step Transfer Paper 17

Transparencies 19

Xerox Docupac Folders 21

Applications 23

Duplex Copies 23

Color Inserts 25

About Paper 27

Paper Weight 28

Grade 31

Moisture Content 32

Curl 33

Grain 35

Smoothness 36

TABLE OF CONTENTS

iv REGAL 5790 MATERIALS USAGE GUIDE

Paper Storage 37

Stacking 38

Temperature and Humidity 38

Conditioning Paper 39

REGAL 5790 MATERIALS USAGE GUIDE 1

Regal 5790 Materials Usage Guide

Introduction

This guide provides the information and guidelines that should be

used when selecting papers or other materials to be used in a 5790

Digital Color Copier/Printer. The feeding reliability and the

performance characteristics that can be expected from the 5790

when using the specified paper stocks and other selected materials

are also provided. In addition, techniques related to the use of these

specific materials are given.

The first section, Recommended Materials,contains a chart

which lists all materials that are recommended for use in the 5790.

Following this chart, a second section, Usage Guidelines,

includes guidelines for selecting and using various materials, such

as transparencies, heavy-weight paper, and the transfer paper used

for T-shirts.

The third section, Applications,provides step-by-step procedures

to use when running certain types of jobs.

The fourth section, About Paper,gives you information about

some of the properties of paper that are important to the operation of

the 5790 and the quality of the copies produced.

The last section, Paper Storage,provides useful tips for the proper

handling and storage of paper.

Xerox has an on-going materials testing program for the 5790. As

new information, materials, or recommendations become available,

they will be included in revisions to this guide. Your Xerox

representative may also advise you of materials usage information

before it can be included in a revision to this guide.

The materials with Xerox part numbers, listed in this guide, can be

purchased by calling the Xerox Supply Net at 1-800-822-2200 (in

U.S. and Canada).

INTRODUCTION

2REGAL 5790 MATERIALS USAGE GUIDE

Conventions

The following symbols are used in this guide to assist you in quickly

locating information.

The Key symbol indicates information that is important to

remember.

The 1, 2, 3 symbol directs you to specific guidelines that should be

followed to obtain the best performance.

The Checkedsymbol indicates that a material has an unqualified

recommendation for use in the 5790.

This Book and Magnifying Glassprompts you to look for the

detailed information and usage guidelines provided for the specific

material type.

A WARNINGalerts you to an operating or maintenance procedure,

practice, or condition, that, if not strictly observed, could result in

injury or loss of life.

The HOT AREAsymbol cautions you to be careful when working in

areas with this symbol. These areas may be very hot and could

cause personal injury.

A CAUTIONalerts you to an operating or maintenance procedure,

practice, or condition that, if not strictly observed, could result in

damage to equipment, destruction of equipment, or loss of data.

123. . .

RECOMMENDED MATERIALS

REGAL 5790 MATERIALS USAGE GUIDE 3

Recommended Materials

This symbol is used to indicate materials that will provide optimum

performance. The Regal 5790 was designed to provide optimum

performance with 16 to 28 lb bond paper (60 to 105 gsm).

Other materials can be used with varying degrees of success. Some

materials will run better if specific guidelines are followed.

This symbol prompts you to refer to the Usage Guidelines later in

this Guide for the type of material shown.

When using materials shown with this symbol, you should expect a

higher jam rate than when using 16 to 28 lb (60 to 105 gsm) paper.

Some of these materials will also cause image quality problems (i.e.

mottle) with certain images.

If you are uncertain of the ability of a specific material to perform well

in your Regal 5790, consult with your Xerox representative and test

the material before purchasing a large quantity.

Order Xerox materials from Xerox Supply Net, 1-800-822-2200 (in

U.S. and Canada).

Regal 5790 Recommended Materials

Material Type Description and order number

Standard Weight Papers:

24 lb Bond (90 gsm) USA and Canada:

•Xerox 24 lb Image Series LX, 8.5 x 11”, 3R3874

•Xerox 24 lb Image Series LX, 11 x 17”, 3R3877

20 lb Bond (80 gsm) USA and Canada:

•Xerox 20 lb Image Series DP, 8.5 x 11”, 3R2950

•Xerox 20 lb Image Series Smooth, 8.5 x 11”, 3R54

28 lb Bond (105 gsm) USA and Canada:

•Xerox 28 lb 4024 DP, 8.5 x 11”, 3R2353

•Xerox 28 lb 4024 DP, 11 x 17”, 3R3873

RECOMMENDED MATERIALS

4REGAL 5790 MATERIALS USAGE GUIDE

Pages 8-9

Heavy-Weight Papers:

32 lb Bond (120 gsm) USA and Canada:

•Xerox 32 lb LXC, 8.5 x 11”, 3R4811

•Xerox 32 lb LXC, 11 x 17”, 3R4813

90 lb Index (163 gsm) USA and Canada:

•Xerox 90 lb Index, 8.5 x 11”, 3R3004

•Xerox 90 lb Index, 17 x 11”, 3R5102

Other Heavy-Weight Papers •Hammermill 32 lb Laser Print, 8.5 x 11”, 10464-6

•Jupiter Thinplate 7 pt. (181 gsm) 8.5 x 11”

•Jupiter Thinplate 7 pt. (181 gsm) 17 x 11”, short grain

•Canon 90 lb, 157 gsm

Page 10

Recycled Papers:

20 lb Bond •Xerox 20 lb Recycled, 8.5 x 11”, 3R5130

•Xerox 20 lb Recycled, 11 x 17”, 3R5133

Pages 11-12

Hole-Punched Paper •Xerox 24 lb Image Series LX, 3 hole drilled, 8.5 x

11”, 3R3875

•Xerox 20 lb 4024DP, 3 hole drilled, 8.5 x 11”,

3R2193

•Xerox 20 lb Image Series DP, 3 hole drilled, 8.5 x

11”, 3R3016

•Xerox 20 lb Recycled, 3 hole drilled, 8.5 x 11”,

3R5131

Pages 12-13

Pressure Sensitive Labels Xerox Copier/Printer Labels 8.5 x 11”:

•1 up 3R4473

•8 up 3R4472

•24 up 3R4471

•30 up 3R4470

•33 up 3R4469

Pages 13-15

Coated Papers

32 lb Ultra Spec (120 gsm)

60 lb Ultra Spec (162 gsm)

USA and Canada:

•Xerox 32 lb Ultra Spec Series, 8.5 x 11”, 3R5093

•Xerox 32 lb Ultra Spec Series, 11 x 17”, 3R5094

•Xerox 60 lb Ultra Spec Series, 8.5 x 11”, 3R5095

•Xerox 60 lb Ultra Spec Series, 11 x 17”, 3R5096

Regal 5790 Recommended Materials

Material Type Description and order number

RECOMMENDED MATERIALS

REGAL 5790 MATERIALS USAGE GUIDE 5

Pages 17-18

Single-Step Transfer Papers USA:

•Xerox Image Transfer Paper, 8.5 x 11”, 3R5811

•Xerox Image Transfer Paper, 11 x 17”, 3R5812

Canada:

•Xerox Image Transfer Paper, 8.5 x 11”, 3R5025

•Xerox Image Transfer Paper, 11 x 17”, 3R5026

Other Single-Step

Transfer Papers •Air Waves Elite

•Magic Touch Mirror Image SS 500

•Paropy CL

Pages 19-20

Transparencies USA:

•Xerox Good Quality Removable Stripe, 11”, 3R3108

•Xerox Good Quality Removable Stripe 17”, 3R5821

•Xerox Premium Quality Removable Stripe, 11”,

3R5765

•Xerox Good Quality Painted Stripe, 11”, 3R5775

Canada:

•Xerox Good Quality Removable Stripe, 11”, 3R3108

•Xerox Good Quality Removable Stripe 17”, 3R5821

•Xerox Premium Quality Removable Stripe, 11”,

3R5765

•Xerox Good Quality Painted Stripe, 11”, 3R4894

Pages 21-22

Docupac Folders Xerox Docupac Folders

•White = 3R4885

•Gray = 3R4927

•Ivory = 3R4928

Regal 5790 Recommended Materials

Material Type Description and order number

RECOMMENDED MATERIALS

6REGAL 5790 MATERIALS USAGE GUIDE

Not Recommended Materials

Testing of the following materials by Xerox engineers has shown

unsatisfactory results:

Note: There are thousands of other materials available today. Most

of these have not been tested and good performance cannot be

guaranteed. If you intend to run a material that has not been

mentioned in this guide, consult with your Xerox Representative and

test the material before purchasing a large quantity.

Material Type Test Results

Dry Gum Labels Unacceptable jam rate

Paper Backed

Transparencies Unacceptable jam rate

Envelopes Unacceptable jam rate &

fuser damage

Papers heavier than 163 gsm Unacceptable jam rate

65 lb Xerox Docupac Folders Unacceptable jam rate

67 lb Vellum Bristol Cover High jam rate and poor image

quality

Xerox 3R2780 transparencies Unacceptable jam rate
