XONTEL XT-07P Manuale utente
XT-07P User Manual
Table of Content
Introduction……………………………………………………………………………………………...3
1
Keypad instruction..................................................................................................................4
2
Wall mount setup.....................................................................................................................6
3
Telephone Setting...................................................................................................................
7
3.1
Getting IP address ....................................................................................................... 7
3.2
Checking IP address.................................................................................................... 7
3.3
How to enter XT-07P web interface ............................................................................ 7
3.4
How to set the memory key......................................................................................... 8
3.5
Network setting............................................................................................................ 9
3.6
SIP setting .................................................................................................................... 10
3.7
LED indicator state ...................................................................................................... 10
4
Basic Operation ....................................................................................................................11
4.1
Making a call................................................................................................................. 11
4.2
Answering a call........................................................................................................... 11
4.3
Holding a call................................................................................................................ 11
4.4
Redialing…. .................................................................................................................. 11
5
Advanced Operation .............................................................................................................12
5.1
Call transfer................................................................................................................ 12
5.2
Messages waiting....................................................................................................... 12
6 FAQ.........................................................................................................................................13
Introduction
XonTel XT-07P is a wall-mounted IP phone which combines the advantages of its space-saving appearance
and most commonly used functions of IP phone. It's a good choice for the application scenarios of hospital,
education, general business, hotel and etc.
1 Keypad instruction
A: Telephone LED Indicator
The light flashes when the telephone rings for incoming calls. When the telephone system
supports Messages Waiting Indication (MWI) function and there are some voice messages, the
light will also flash.
B: Hold Button
Places a call on hold status.
C: Release Button
Hang up again after ending the active call
D: Transfer Button
Transfer a call to another number
E: Redial
Dial the last number you dialed.
F: Dial Pad
Dial the number you want.
G: Programmable Button
Stores phone numbers or feature access codes.
H: Handset LED Indicator
I: Power LED Indicator
J: Cable trough
K: Wan Port
L: Headset Port
Connect the headset cord.
M: Handset Wire trough
N: Wall Mount Hole
O: Power Port
When you don’t use the power supply, please fill the PVC stick in this position to prevent dirt.
P: PVC
2 Wall mount setup
Fix the device on the wall.
1. Screw the embedded junction box on the wall
2. Connect the cable from embedded junction box to the telephone.
3. Hitch the telephone on the screw.
Please refer the dimension when you want to screw the embedded junction box on the wall.
Embedded junction box
8.5cm*8.5cm
Screw
Wall
13.2cm
10.7cm
5.8cm
Screw
3 Telephone Setting
3.1 Getting IP address
DHCP is the default network setting, and telephone will get the IP address from DHCP server
(Router) after the cable connected.
3.2 Checking IP address
Pick up the handset and long press the “#” key, then you can hear the IP address voice
information.
3.3 How to enter XT-07P web interface
Set the telephone through web interface.
1.
Connect the telephone and PC in the same LAN.
2.
Open the web browser in the PC, and input XT-07P IP address in the addressbar.
3.
Enter XT-07P username and password, default username is admin and password is xontel.
4.
Click “Logon” button to enter into the web setting interface.
3.4 How to set the memory key
Enter into the web setting interface and select Function Key-> Function Key. Select the
function and fill the number in the Value items.
3.5 Network setting
Enter into the web setting interface and select Network->Basic, there are three mode of network.
1.
Static IP
2.
DHCP
Get IP address from DHCP server automatically.
3.
PPPoE
PPPoE server, Username, Password
You should choose correct network mode according to your network environment.
3.6 SIP setting
Select Line->SIP and fill in the items that shown in the figure below.
1.
SIP Proxy Server Address: Fill in server IP address or PBX IP address.
2.
Username: Fill in the SIP line number or PBX extension number.
3.
Authentication name: Fill in the SIP line number or PBX extension number.
4.
Authentication Password: Fill in SIP line or PBX extension registration password.
5.
Enable “ Active “ check box.
Click the “Apply”button to save the configuration, you can dial out after the register status is
“Registered” with red color.
3.7 LED indicator state
Incoming call
The telephone LED indicator will flash at 0.5s on, 0.5s off.
MWI
The telephone LED indicator will flash at 0.5s on, 2s off.
Picking up the handset.
All buttons backlight will keep on.
Connecting power.
The power indicator will keep on.
