XPower Inverter 150, 300 & 500 12 VDC to 230 VDC /50 Hz Power Inverters
Portable AC power from the battery in your vehicle
Ideal for powering recreational, mobile office equipment and other electronic appliances, XPower Inverters
convert 12 volts of DC battery power in your vehicle to 230 volts of AC power. Available in a range of
sizes, the inverters can power a variety of electronic products including TVs, VCRs, fax machines, laptop
computers, camcorders, stereos, small power tools and work lights.
Choosing the right size of inverter for a particular application is important. For example, the XPower 150
Inverter can run a laptop for approximately 9 hours from a 75-amp hour battery; the XPower 300 can run a
49 cm TV for approximately 6 hours from a 75-amp hour battery. The exact run time depends on the amount
of power being drawn by the application and the size and condition of the battery. The XPower Inverter 500
can be used instead of a generator for low power or intermitent loads.
Product Features
Available in 150, 300 or 500 watt models
Offer 300, 600 or 1000 watt surge capacity
Available in three AC outlet configurations: Schuko, UK and AUS/NZ
Regulated output protects sensitive equipment
Compact size for convenient use and storage
Auto shutdown prevents total battery discharge
Silent operation
Mounting brackets for convenient installation (XPower Inverter 300 and 500)
Protection Features
Over temperature shutdown
Overload shutdown
Low voltage shutdown (at 10.0 VDC)
Over voltage shutdown (at 15.0 VDC)
Low voltage alarm (at 10.7 VDC)
Short circuit protection
Battery reverse polarity (fuse protected)
LED indicator confirms fault connection
© 2004 Xantrex Technology Inc. All rights reserved. Xantrex is a registered trademark of Xantrex International. Printed in Canada
XPower Inverter 150, 300 & 500 12 VDC to 230 VDC /50 Hz Power Inverters
Models 150 300 500
Output power (continuous) 150 W 300 W 500 W
Surge capacity (peak) 300 W 600 W 1000 W
Output voltage 230 VAC +/- 5% 230 VAC +/- 5% 230 VAC +/- 5%
Output frequency 50 +/- 3Hz 50 +/- 3Hz 50 +/- 3Hz
Output waveform Modified sine wave Modified sine wave Modified sine wave
Peak efficiency 90% 90% 90%
No load current draw <0.18 A <0.2 A <0.3 A
Input voltage range 10 – 15 VDC 10 – 15 VDC 10 – 15 VDC
Electrical Specifications
General Specifications
Operating temperature range 0°C to 40°C (32°F to 104°F) 0°C to 40°C (32°F to 104°F) 0°C to 40°C (32°F to 104°F)
AC receptacle Schuko, UK and AUS/NZ Schuko, UK and AUS/NZ Schuko, UK and AUS/NZ
Display Power ON and Fault LEDs Power ON and Fault LEDs Power ON and Fault LEDs
Battery connection DC lighter plug DC lighter plug and cable clamps Cable clamps and hardwire
Mounting bracket None Built-in Built-in
Internal DC fuse Not user replaceable Not user replaceable Not user replaceable
Dimensions (HxWxL) 63 x 104 x 157 mm (2.5 x 4.1 x 6.2”) 66 x 104 x 200 mm (2.6 x 4.1 x 7.9”) 66 x 112 x 241 mm (2.6 x 4.4 x 9.5”)
Weight 0.65 kg (1.54 lb) 0.79 kg (1.74 lb) 1.2 kg (2.6 lb)
Warranty Two years Two years Two years
Part Number 851-0160R (AUS/NZ) 851-0310R (AUS/NZ) 851-0510R (AUS/NZ)
851-0161R (UK) 851-0311R (UK) 851-0511R (UK)
851-0162R (Schuko) 851-0312R (Schuko) 851-0512R (Schuko)
XP_inv150-300-500_DS20040826.indd
by
XPower Inverter 300
Owner’s Guide
Xantrex300E.book Page i Thursday, February 16, 2006 10:11 AM
About Xantrex
Xantrex Technology Inc. is a world-leading supplier of advanced power
electronics and controls with products from 50 watt mobile units to one MW
utility-scale systems for wind, solar, batteries, fuel cells, microturbines, and
backup power applications in both grid-connected and stand-alone systems.
Xantrex products include inverters, battery chargers, programmable power
supplies, and variable speed drives that convert, supply, control, clean, and
distribute electrical power.
Trademarks
XPower is a trademark of Xantrex International. Xantrex is a registered
trademark of Xantrex International.
Other trademarks, registered trademarks, and product names are the property
of their respective owners and are used herein for identification purposes
only.
Notice of Copyright
XPower Inverter 300 Owner’s Guide © February 2006 Xantrex International.
All rights reserved.
Disclaimer
UNLESS SPECIFICALLY AGREED TO IN WRITING, XANTREX TECHNOLOGY
INC. (“XANTREX”)
(a) MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR
SUITABILITY OF ANY TECHNICAL OR OTHER INFORMATION PROVIDED IN
ITS MANUALS OR OTHER DOCUMENTATION.
(b) ASSUMES NO RESPONSIBILITY OR LIABILITY FOR LOSS OR DAMAGE,
WHETHER DIRECT, INDIRECT, CONSEQUENTIAL OR INCIDENTAL, WHICH
MIGHT ARISE OUT OF THE USE OF SUCH INFORMATION. THE USE OF ANY
SUCH INFORMATION WILL BE ENTIRELY AT THE USER’S RISK.
Date and Revision
February 2006 Revision C
Part Number
975-0093-01-01
Contact Information
Telephone: 1 360 925 5097 (direct)
Fax: 1 360 925 5143 (direct)
Email: customerservice@xantrex.com
Web: www.xantrex.com
Xantrex300E.book Page ii Thursday, February 16, 2006 10:11 AM
iii
1. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2. Important Safety Information . . . . . . . . . . . . . . . . . . 2
Warnings and Cautions . . . . . . . . . . . . . . . . . . . . . . . . 2
3. XPower 300 Inverter Features . . . . . . . . . . . . . . . . . . 6
AC Outlets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4. Connecting the XPower 300 . . . . . . . . . . . . . . . . . . . . 9
Choosing a Location . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Fastening the Inverter to a Mounting Surface . . . . . . . 9
Connecting the XPower 300 to DC Power . . . . . . . . 10
Using the Cigarette Plug Wire Assembly . . . . . . . . 11
Using the Battery Clip Wire Assembly. . . . . . . . . . 12
Hardwiring the Inverter to the Battery . . . . . . . . . . 14
Disconnecting the Battery . . . . . . . . . . . . . . . . . . . . . 18
Replacing the In-Line Fuse . . . . . . . . . . . . . . . . . . . . 18
5. Operating the XPower 300 . . . . . . . . . . . . . . . . . . . . 19
Operating Statuses. . . . . . . . . . . . . . . . . . . . . . . . . . 19
Interference With Electronic Equipment. . . . . . . . . 21
6. Battery Operating Time . . . . . . . . . . . . . . . . . . . . . . 22
7. Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
8. Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Physical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Regulatory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Product Recycling . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
9. Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
10. Other Xantrex Products . . . . . . . . . . . . . . . . . . . . . 36
Table of Contents
Xantrex300E.book Page iii Thursday, February 16, 2006 10:11 AM
iv
Xantrex300E.book Page iv Thursday, February 16, 2006 10:11 AM
1
1 Introduction
Thank you for purchasing the XPower Inverter 300. The
XPower 300 is part of a family of advanced, high-
performance power inverters from Xantrex, the leader in the
field of high-frequency inverter design.
Connected to the 12 volt outlet in your vehicle or directly to
your battery for loads over 150 watts, the XPower 300
efficiently and reliably powers a wide variety of household
AC products, such as TVs and VCRs, laptop computers,
camcorder and cell phone chargers, compact fluorescent
lights, and soldering irons.
The XPower 300 uses reliable solid state power electronics
for years of safe, trouble-free operation and includes
automatic safety monitoring circuitry to protect it from
inadvertent overload conditions.
Read this guide before connecting or using the XPower 300,
and save it for future reference. The main topics in the guide
are:
• Safety information (page 2)
• XPower 300 features (page 6)
• Instructions for connecting the inverter (page 9)
• Operating guidelines (page 19)
• Troubleshooting information (page 23)
• Specifications (page 27)
• Warranty and service information (page 30)
Xantrex300E.book Page 1 Thursday, February 16, 2006 10:11 AM
2
2 Important Safety Information
If the XPower 300 is connected or used incorrectly,
hazardous conditions may be created. Read and save this
safety information, and pay special attention to all Caution
and Warning statements in the guide and on the inverter
itself. Warnings and Cautions are indicated by this symbol:
•Warning statements identify conditions that could
result in personal injury or loss of life.
•Caution statements identify conditions or practices that
could result in damage to the XPower 300 or other
equipment.
Warnings and Cautions
6
WARNING: Shock hazard
The XPower 300 generates the same potentially lethal AC
power as a household wall outlet. Do not insert foreign
objects in the inverter’s AC outlet or any other openings in
the inverter. Do not open the inverter. Have a qualified
individual complete any service work.
WARNING: Shock hazard
Do not expose the XPower 300 to water, rain, snow, or
spray.
Xantrex300E.book Page 2 Thursday, February 16, 2006 10:11 AM
3
WARNING: Risk of fire or explosion
The XPower 300 contains components that tend to produce
arcs or sparks. To prevent fire or explosion, do not install
the inverter in compartments containing batteries or
flammable materials or in locations that require ignition-
protected equipment.
WARNING: Fire hazard
To reduce the risk of fire, do not cover or obstruct the
ventilation openings. Do not install the XPower 300 in a
zero-clearance compartment. Overheating may result.
WARNING: Shock and fire hazard
During installation route all cable/wiring away from sharp
edges and hot surfaces of the engine compartment or
vehicle.
Xantrex300E.book Page 3 Thursday, February 16, 2006 10:11 AM
4
CAUTION: Risk of damage to equipment
The XPower 300 is designed to be directly connected to
standard electrical and electronic equipment in the manner
described in this guide. Do not connect it to household or
RV AC distribution wiring. Do not connect it to any AC
load circuit in which the neutral conductor is connected to
ground (earth) or to the negative of the DC (battery)
source.
CAUTION: Risk of damage to the XPower
300
Reverse battery polarity (negative connected to positive;
positive connected to negative) will damage the XPower
300, and it will require servicing. Damage caused by
reverse polarity is not covered by your warranty.
Xantrex300E.book Page 4 Thursday, February 16, 2006 10:11 AM
