USER MANUAL
H6 Pro Smart Diagnostic System
V6.5
I
Please read this user manual carefully before using the H6 Pro Smart Diagnostics System. When reading the
manual, please pay attention to the words “Note” or “Caution” and read them carefully for appropriate operation.
TRADEMARKS
is a registered trademark of Shenzhen Xtooltech Intelligent CO., LTD. In countries where the
trademarks, service marks, domain names, logos, and the name of the company are not registered, Xtool
claims that it still reserves the ownership of the unregistered trademarks, service marks, domain names, logos,
and the company name. All other marks for the other products and the company’s name mentioned in the
manual still belong to the original registered company.
You may not use the trademarks, service marks, domain names, logo, and company name of Xtool or other
companies mentioned without written permission from the trademark holder.
Xtool reserves the right to the final interpretation of this manual content.
COPYRIGHT
Without the written consent of Shenzhen Xtooltech Intelligent Co., Ltd., any company or individual shall not
copy or backup this operation manual in any form (electronic, mechanical, photocopying, recording, or other
forms).
DECLARATION
This manual is designed for the usage of the H6 PRO Smart Diagnostics System and provides operating
instructions and product descriptions for users of the H6 PRO Smart Diagnostics System.
No part of this manual can be reproduced, stored in a retrieval system, or transmitted, in any form or by any
means (electronic, mechanical, photocopying, recording, or otherwise), without the prior written permission of
Xtool.
Use the device only as described in this manual. Xtool is not responsible for any consequences of violating the
laws and regulations caused by using the product or its data information
Xtool shall not be liable for any incidental or consequential damages or for any economic consequential
damages arising from the accidents of individual users and the third parties, misuse or abuse of the device,
unauthorized change or repair of the device, or the failure made by the user not to use the product according
to the manual.
All information, specifications, and illustrations in this manual are based on the latest configurations and
functions available at the time of printing. Xtool reserves the right to make changes at any time without notice.
OPERATION INSTRUCTIONS
For safe operation, please follow the instructions below:
II
⚫Keep the device away from heat or fumes when you are using it.
⚫If the vehicle battery contains acid, please keep your hands and skin or fire sources away from the battery
during testing.
⚫The exhaust gas of the vehicle contains harmful chemicals, please ensure adequate ventilation.
⚫Do not touch the cooling system components or exhaust manifolds when the engine is running due to the
high temperatures reached.
⚫Make sure the car is securely parked, Neutral is selected or the selector is at P or N position to prevent
the vehicle from moving when the engine starts.
⚫Make sure the (DLC) diagnostic link connector is functioning properly before starting the test to avoid
damage to the Diagnostic Tablet.
⚫Do not switch off the power or unplug the connectors during testing, otherwise, you may damage the ECU
and/or the Diagnostic Tablet.
CAUTIONS!
⚫Avoid shaking or dismantling the unit as it may damage the internal components.
⚫Do not use hard or sharp objects to touch the LCD screen;
⚫Do not use excessive force;
⚫Do not expose the screen to strong sunlight for a long period.
⚫Please keep it away from water, moisture, high temperature, or very low temperature.
⚫If necessary, calibrate the screen before testing to ensure the accuracy of LCD performance.
⚫Keep the main unit away from strong magnetic fields.
⚫Please keep your device always connected to the Internet. When the device is off the Internet for 30 days,
The diagnosis APP may be locked and you need to synchronize data with the Internet to activate it.
AFTERSALES-SERVICES
[email protected] (for Europe, North America and Latin America )
Tel: +86 755 21670995 | +86 755 86267858 (China)
Monday through Friday
09:00~18:30（UTC/GMT+08:00）
Official Website: www.xtooltech.com | www2.xtooltech.com (alternate site)
Please provide your device serial number, VIN code, vehicle model, software version, and other details when
seeking technical support. If there are screenshots or videos, it will better help us locate your problem.
III
Content
TRADEMARKS ................................................................................................................................................. I
COPYRIGHT ..................................................................................................................................................... I
DECLARATION................................................................................................................................................. I
OPERATION INSTRUCTIONS.......................................................................................................................... I
CAUTIONS!...................................................................................................................................................... II
AFTERSALES-SERVICES............................................................................................................................... II
1GENERAL INTRODUCTION..................................................................................................................... 5
1.1. Tablet Overview ............................................................................................................................ 5
Front View of Tablet...........................................................................................................................................5
Back View of Tablet...........................................................................................................................................6
Host Ports...............................................................................................................................................................6
1.2. VCI box........................................................................................................................................... 7
Front/Back View..................................................................................................................................................7
Top/Bottom View.................................................................................................................................................7
1.3. Technical Specifications.............................................................................................................. 8
1.4. Packing Kit .........................................................................................................错误!未定义书签。
2GETTING STARTED................................................................................................................................. 8
2.1. Activation....................................................................................................................................... 8
2.2. Main Interface...............................................................................................................................10
Operation System.............................................................................................................................................10
Main Menu...........................................................................................................................................................11
Function Buttons...............................................................................................................................................12
Navigation Buttons...........................................................................................................................................13
Notification Bar...................................................................................................................................................13
2.3. Factory Reset...............................................................................................................................14
3UPDATE & DELETE................................................................................................................................17
3.1. Update software...........................................................................................................................17
3.2. Delete Software............................................................................................................................18
4DIAGNOSIS .............................................................................................................................................19
4.1. Vehicle Connection......................................................................................................................19
4.2. Vehicle Selection .........................................................................................................................20
4.3. Diagnostics Functions.................................................................................................................24
4.4. ECU Coding & Programming......................................................................................................32
5SPECIAL FUNCTIONS ............................................................................................................................33
5.1. OIL RESET....................................................................................................................................34
5.2. EPB ...............................................................................................................................................35
5.3. SAS ...............................................................................................................................................36
5.4. DPF................................................................................................................................................38
5.5. BMS RESET..................................................................................................................................41
5.6. THROTTLE....................................................................................................................................43
5.7. INJECTOR CODING .....................................................................................................................43
IV
5.8. GEARBOX MATCH.......................................................................................................................45
5.9. GEAR LEARNING.........................................................................................................................46
6REPORT...................................................................................................................................................47
6.1. Report ...........................................................................................................................................47
6.2. Replay...........................................................................................................................................49
6.3. File Manager.................................................................................................................................50
7SETTINGS................................................................................................................................................51
7.1. Languages....................................................................................................................................51
7.2. Units..............................................................................................................................................52
7.3. Bluetooth......................................................................................................................................54
7.4. My Workshop Info........................................................................................................................54
7.5. VCI Information ............................................................................................................................55
7.6. About ............................................................................................................................................55
8REMOTE ASSISTANCE ..........................................................................................................................56
9FAQ..........................................................................................................................................................57
Q1: Failed to generate diagnosis report.................................................................................................57
Q2: How to print diagnosis report...........................................................................................................58
Q3: Failed to extract files.........................................................................................................................58
Q4: Mailbox supported.............................................................................................................................58
Q5: Why can’t I receive the email after sharing the diagnostic report? ..............................................59
Q6: How to make an appointment for remote support..........................................................................59
Q7: How to generate and upload diagnostic log files ...........................................................................59
Q8: How to switch languages..................................................................................................................59
Q9: Failed to diagnose vehicle................................................................................................................59
Q10: Failed to activate or register...........................................................................................................59
Q11: Failed to turn on when charging....................................................................................................60
Q12: Failed to open the diagnosis app...................................................................................................60
Q13: Failed to enter Vehicle menu..........................................................................................................60
10 WARRANTY & SERVICES ..................................................................................................................61
SHENZHEN XTOOLTECH INTELLIGENT CO., LTD .....................................................................................62
5
1 GENERAL INTRODUCTION
The H6 PRO Smart Diagnostics System is an advanced scanning tool based on the Android operating system.
It supports multi-language switching and is suitable for different countries and regions.
The advantage of this scanner is not only its comprehensive functions, including complete system diagnosis,
and full OBDⅡfunctions, but various reset functions can also achieve a faster and more accurate diagnosis.
The H6 PRO Smart Diagnostics System mainly includes:
⚫Car Diagnostics Tablet
⚫Wireless Diagnostics Module
⚫Main test cable
⚫Connectors
⚫Power adapter
Before performing the diagnosis program, please make sure that the VCI box is successfully connected to your
vehicle, and connect the VCI box with Bluetooth on the tablet.
Some old cars with non-OBD2 standard protocol need to be connected with our VCI box through specific pin
connectors.
Using the wrong connector may cause your car to be unrecognized by the diagnostic tool.
Please confirm the OBD connector specifications configured on your car before connecting.
1.1.TABLET OVERVIEW
The main unit of the H6 PRO Smart Diagnostics System is the tablet. It allows you to operate all diagnosis
functions, and it can also work as a normal Android tablet.
FRONT VIEW OF TABLET
Figure 1-1 Sample of Tablet Front View
The front of the tablet is mainly a touchable display screen, you can use your fingers to operate on the screen
to finish most of the diagnosis process.
6
BACK VIEW OF TABLET
Figure 1-2 Sample of Tablet Back View
①Camera: Used for taking pictures.
②Nameplate: Show the basic information about the tablet such as product name and serial number, etc.
③Loudspeaker: It supports external sound playback.
HOST PORTS
Figure 1-3 Sample of Tablet Host Ports
①DOIP port: Supports ECU programming for vehicles with DOIP protocol
②USB 3.0 port: Used for data transfer for tablet & PC communication, and data transfer with VCI box
when working.
③VGA port: A reserved interface can be used for charging.
④DC charging port: Charging port, connected to the power adapter to charge the device.
⑤Power button: Long press to turn the device on/off, short press to switch the device into sleep mode.
Hold for about 20 seconds to force shut down the device.
⑥Wireless charging port: Can be used with a wireless charging base for charging
③
①
②
①
②
③
④
⑤
⑥
7
1.2.VCI BOX
To communicate with the vehicle via OBD, H6 PRO also comes up with a wireless diagnostics module, also
known as the VCI box. The tablet needs a Bluetooth connection with the VCI box to get access to all software.
Although some functions (like EEPROM Adapter) will not need you to communicate to the vehicle, please power
up the VCI box using a 12V power adapter to get access to the software.
FRONT/BACK VIEW
Front Back
Figure 1-4 Sample of VCI Box, screen 1
①Display Screen: Show status of the VCI box-like battery voltage, Bluetooth connection, and car
communication status.
②Nameplate: Show basic information about the VCI box, like the serial number.
Make sure that you’re using the VCI box that is paired with the tablet, or it will not communicate. The serial number
of the VCI box must be the same as the serial number of the tablet.
TOP/BOTTOM VIEW
Top Bottom
Figure 1-5 Sample of VCI Box, screen 2
①
②
①
②
8
①DB15 Port: Used to connect the VCI box to the OBDII port on the vehicle.
②USB-B Port: Used to connect the VCI box to the tablet using USB-B to USB3.0 cable
1.3.TECHNICAL SPECIFICATIONS
Table 1-1 Specification
Item
Description
Processor
Quad-core processor 1.8GHz
Ram
2G
Rom
128G
Display
10.1-inch capacitive, 1024×768 resolution
Connectivity
USB
Wi-Fi
Bluetooth
Camera
8-megapixel autofocus rear camera with flash
Sensor
Gravity sensor
Audio Input/ Audio Output
Microphone/ Loudspeaker
Ports
USB3.0
DC charging port
VGA port
Battery
13000mAh 3.7V lithium polymer battery
Input Voltage
12V DC
Operating Temperature
-10~50℃
Relative Humidity
< 90%
Dimensions
315.07×218.35×34.61 mm
2 GETTING STARTED
2.1. ACTIVATION
After first-time users press and hold the power button to turn on the system, the system will automatically enter
the guide process and request to select the language for the operating system.
Altri manuali per H6PRO
2
Indice
Altri manuali Xtool Apparecchiature diagnostiche
Xtool
Xtool A80 Manuale utente
Xtool
Xtool D1 Pro Manuale utente
Xtool
Xtool PS90 Manuale utente
Xtool
Xtool H6EB Manuale utente
Xtool
Xtool TP200 Manuale utente
Xtool
Xtool HD900 Manuale utente
Xtool
Xtool Anyscan A30 Manuale utente
Xtool
Xtool PS2 Manuale utente
Xtool
Xtool PS70 Pro Manuale utente
Xtool
Xtool H6 EB Manuale utente
Xtool
Xtool PS80 Manuale utente
Xtool
Xtool IP616 Manuale utente
Xtool
Xtool TP Series Manuale utente
Xtool
Xtool EZ400PRO Manuale utente
Xtool
Xtool H6 Elite Manuale utente
Xtool
Xtool PS70PRO Manuale utente
Xtool
Xtool D8 Manuale utente
Xtool
Xtool ASD60 Manuale utente
Xtool
Xtool IP608 Manuale utente
Xtool
Xtool H6PRO Manuale utente
