Xtrons HD106 Manuale utente
USER MANUAL
Thank you for buying this XTRONS product. Please read through these instructions so you will
know how to operate this product properly. After you have finished reading the instructions,
keep this document in a safe place for future reference.
HD106
NOTICE OF INTENDED USE
Our products are designed to enable viewing of video
ONLY for rear-seat occupants, and are not intended for
viewing by the driver when the vehicle is in motion.
Such use might distract the driver or interfere with the
driver’s safe operation of the vehicle, and thus result in
serious injury or death. Such use might also violate
state or local laws.
Manufacturer disclaims any liability for any bodily
injury or property damage that might result from any
improper or unintended use.
NOTE: Features and specifications listed in this manual are subject to
change without notice.
NOTICES
Contents
1
Precaution .........................................................................................................
Checking part names and functions .......................................................
Remote control ...............................................................................................
Playing a disc ...................................................................................................
USB/SD ...............................................................................................................
Using AV input and AV output ..................................................................
Listening over the vehicle’s speakers .....................................................
Using the external wireless IR headset ..................................................
Using an HDMI source ..................................................................................
Appendix ...........................................................................................................
2
4
6
10
10
10
10
11
11
12
Precaution
Before installing this product
- Use this unit with a 12-volt battery and negative grounding only. Failure to do so
- To avoid shorts in the electrical system, be sure to disconnect the (-) battery cable
2
Certain country and government laws may prohibit or restrict the placement and
use of this product in your vehicle. Please comply with all applicable laws and
regulations regarding the use, installation and operation of this product.
If you want to dispose this product, do not mix it with general household waste.
There is a separate collection system for used electronic products in accordance
with legislation that requires proper treatment, recovery and recycling.
Important safety information
WARNING
- Do not attempt to install or service this product by yourself. Installation or
may result in a fire or malfunction.
before installation.
servicing of this product by persons without training and experience in
electronic equipment and automotive accessories may be dangerous and could
expose you to the risk of electric shock, injury or other hazards.
- Do not disassemble or modify this product, as there are high-voltage components
3
WARNING
To avoid battery exhaustion
Be sure to run the vehicle engine while using this product. Using this product without
running the engine can drain the battery.
- Do not allow this product to come into contact with liquids. Electrical shock could
- If liquid or foreign matter should get inside this product, park your vehicle in a safe
- If you notice smoke, a strange noise or odor from this product, or any other
result. Also, damage to the product, smoke and overheating could result from
contact with liquids.
place, turn the ignition switch off (ACC OFF) immediately and consult your dealer.
Do not use this product in this condition because doing so may result in a fire,
electric shock, or other failure.
abnormal signs on the screen, turn off the power immediately and consult your
dealer. Using this product in this condition may result in permanent damage to the
system.
inside which may cause an electric shock. Be sure to consult your dealer for internal
inspection, adjustments or repairs.
Do not install this product in a vehicle that does not have an ACC wire or circuitry
available.
4
Checking part names and functions
2
3
4
5
6
71
1. +>
Touch to turn the volume up.
2. MENU
Touch to display the menu.
3. <-
Touch to turn the volume down.
4. Power button/Mode button
Press to turn on or turn off the power.
Press to switch between the application screen and the AV operation screen.
5.
Touch to skip to the next track/chapter.
6.
Touch to pause or resume playback.
7.
Touch to skip to the previous track/chapter.
5
9
10
8
11
13
14
12
8. HDMI port
Connect a device to the product using an optional appropriate HDMI cable or
adapter.
9. USB port
Plug a USB storage device into the USB port.
10. SD card slot
Insert an SD memory card into the SD card slot.
11.AV input jack
Use to receive AV signals from another device.
12.Headset jack
Use to connect an external headset to the product.
13.DC input jack
Use to connect DC 12V power supply.
14.Disc loading drive
Put in a disc to play.
6
Remote control
21
24
20
22
23
28
25
26
27
29
30
31
32
33
34 1
2
3
4
5
6
7
9
10
8
11
13
14
15
16
12
17
18
19
7
1. D button
Action button in Game mode.
2. B button
Action button in Game mode.
3. C button
Action button in Game mode.
4. A button
Action button in Game mode.
5. TITLE
Press to display the title number during DVD playback.
6. MUTE
Press to mute. Press again to unmute.
7. PROGRAM
8. Direction buttons
Press to move in a specified direction.
9. USB/SD
Press to choose to play files in USD mode or in SD mode.
10. VOL+/VOL-
Press to turn the volume up or down.
11. /
Press to skip to the previous track/chapter or skip to the next track/chapter.
12. ZOOM
Press to zoom in during DVD playback.
13. SLOW
Press to slow down the playback speed.
8
14. AUDIO
Press to choose Left, Right or Stereo for the audio channel.
15. Up direction button in Game mode
16. Right direction button in Game mode
17. Down direction button in Game mode
18. Left direction button in Game mode
19. RETURN
Press to return to the previous menu.
20. SUBTITLE
Press to display the subtitle during DVD playback.
21. DVD/AV
Press to select DVD mode or AV mode.
22. Number buttons
Press to choose a track or a chapter by the track number or chapter number during
DVD playback.
23.
Press to stop playback.
24.
Press to pause or resume playback.
25. /
Press to perform rewind or perform fast-forward.
26. ANGLE
Press to adjust the viewing angle during DVD playback.
