ZALMAN FX100 Manuale utente

User's Manual

Ver. 130620

To ensure safe and easy installation,

please read the following precautions.

www.ZALMAN.com

FX100

AMD Socket FM2 / FM1 / AM3+ / AM3 / AM2+ / AM2 CPU&APUs

Intel Socket LGA 2011 / 1366 / 1156 / 1155 / 1150 / 775 CPUs

* Optional 92mm fan is required for Intel LGA 2011/1366 sockets.

.COM

2. Specifications

1. Precautions

1) Do not ingest the Thermal Grease, and avoid its contact with skin and eyes.

If contact is made with skin, wash off with water. If ingested or irritation

persists, seek medical attention.

2) To prevent possible injuries, gloves must be worn while handling this product.

3) Excessive force exerted on the fan may cause damage to the fan and/or

system.

4) Use and keep product away from reach of children.

5) Check the components list and condition of the product before installation.

If any problem is found, contact the retailer to obtain a replacement.

6) During transportation of the system, the cooler must be removed. Zalman

is not responsible for any damages that occur during the transport of a system.

7) Product design and specifications may be revised to improve quality and

performance.

FX100

Material Pure Aluminum & Copper

Weight 770g

Dimensions 156(L) x 156(W) x 157(H)mm

Noise Level 0dBA

Thermal

Grease

[ZM-STG2M]

Capacity 1g

Temperature

Range -40°C ~ +150°C (-40℉ ~ +302℉)

Model

Spec.

Disclaimer) Zalman Tech Co., Ltd. is not responsible for any damages due to

external causes, including but not limited to, improper use, problems with

electrical power, accident, neglect, alteration, repair, improper installation,

or improper testing.

.COM

Nipple A

Fan Clip

Nuts

Thermal Grease

Bolts

Manual

Block

Intel Washer

(0.1mm)

AMD Washer

(1mm)

Double-sided

Tape

Backplate

Nipple B

Clip support

Cooler

Nuts & Side Caps

Installation Clip

3. Components

.COM

4. Installation Requirements

1) Space Requirments

2) Air Guide Removal

3) Cooler Orientation

The cooler’s installation requires an unobstructed space of 156mm(width),

156mm(length), and 157mm(height), with the CPU as a central reference

point. Please check if components such as ODDs and PSU protrude into the

required space.

Air guides on enclosures must be removed before the cooler’s installation

since they protrude into the cooler’s required space.

Mount the CPU cooler with the C-shaped heatpipe portion facing towards the

VGA card (as shown below).

※ There may be clearance issues with the graphics card if the CPU cooler is

improperly installed.

156㎜

Air Guide

Case Cover

157㎜

156㎜

Mother

Board

C-shaped

heatpipe

.COM

5. Installation

Intel Socket Installation

※ Make sure to install the Clip Support by following specific instructions

based on your CPU socket.

※ Optional fan is required for LGA 2011 socket CPUs. (fan sold separately)

Intel Socket 2011 Installation

① Fasten Nipple B to the clip support’s hole on the motherboard.

※ Backplate, Loading Block, and Intel's Washers(0.1mm) are not required for LGA

2011 socket CPUs.

② Install the clip support on the motherboard using nuts.

Please make a note of the

orientation of the Clip Support.

Caution

.COM

2) Intel Socket LGA 1366/1156/1155/1150 Installation

Socket 775

Socket 1156/1155/1150

Socket 1366

② Attach Double-sided Tape to the center of the Backplate and remove

the Double-sided Tape’s Cover.

※ Socket LGA 1366/1156/1155/1150 Installation does not require the Loading Block.

① Install Bolts to the Backplate according to the Socket Type and secure with

Side Caps.

③ Align the Backplate’s nuts with

motherboard’s clip support

holes, attach it to the back side

of the motherboard, and then

fix it with Intel’s washer(0.1mm)

and Nipple A.

* Optional fan is required for LGA 1366 socket CPUs. (fan sold separately)

Intel Washer

.COM

3) Intel Socket 775 Installation

① Install Bolts to the Backplate according to the Socket Type and secure with

Side Caps.

③ Attach Double-sided Tape to the Loading Block and remove the Double-sided

Tape Cover.

②

Remove the Sticker Cover from the Lower Tier of the Loading Block

and attach it to the Backplate.

Double-sided

Tape

Block

④ Install the clip support on the motherboard using nuts.

Nut

Clip Support

Please make a note of the

orientation of the Clip Support.

Caution

Socket 775

Socket 1156/1155/1150

Socket 1366

.COM

④ Align the Backplate’s nuts

with motherboard’s clip

support holes, attach it to the

back side of the motherboard,

and then fix it with Intel’s

washer(0.1mm) and Nipple A.

Intel Washer

⑤ Install the clip support on the motherboard using nuts.

Nut

Clip Support

Please make a note of

the orientation of the Clip Support.

Caution

Please make a note of the orientation of the Loading Block.

.COM

1) AMD Socket FM2/FM1/AM3+/AM3/AM2+/AM2 Installation

B. AMD Socket Installation

① Install Bolts to the Backplate according to the Socket Type and secure

with Side Caps.

② Remove the Sticker Cover from the Lower Tier of the Loading Block and

attach to the Backplate.

③ Attach Dobule-sided Tape to the Loading Block and remove

the Double-sided Tape Cover.

Loding

Block

Double-sided

Tape

Please make a note of the orientation of the Loading Block.

Caution

.COM

AMD Washer

Nut

Clip Support

④ Take away the fixed Clip support from the motherboard, and then install

the included Clip support using Nipple A, AMD’s washer(1mm) and nuts.

※After installing the Clip Support, please mount the CPU cooler as following.

C. Cooler Installation

① Apply a suitable amount of

the included Thermal Grease

on the CPU’s surface.

Intel or AMD CPU

Please make a note of

the orientation of the Clip Support.

Caution
