Zanussi ZEFSTV2001B Manuale utente

For Customer Services & Spare Parts please call 0330 1230 597

Or visit us at www.zanussiheatingandcooling.uk

PLEASE RETAIN

FOR FUTURE REFERENCE

Model Number:

ZEFSTV2001B

This product is only suitable for well insulated spaces or

occasional use.

2KW Black Electric Stove Fire

User Guide

CONTENTS

Page(s)

Safety Instructions

3 - 5

Product Overview

Using

your Electric Stove 7-8

Cleaning

and Care 9

Problem

Solving 10

Guarantee

and Customer Services 11

Connection

to the Mains Supply 12

Information Requirements for Electric Local Space

Heaters

13-14

Notes

Disposal

Information 16

SAFETY INSTRUCTIONS

When using electrical appliances, basic safety precautions should always be observed,

including the following:

•Read all instructions.

•Check that the your mains voltage corresponds with the rating on the appliance.

•The appliance must not be left unattended while it is connected to the mains

supply.

•This appliance must be positioned upright on the floor away from curtains,

furniture or wall coverings and other flammable items.

•Do not touch hot surfaces. Use the handle or the controls.

•To protect against electrical shock do not immerse cord, plug, or appliance in

water or other liquid. Do not operate with wet hands.

•Do not let the cord hangover the edge of a worktop, table etc. or touch hot

surfaces.

•Do not operate any appliance with a damaged cord or plug, or after the appliance

malfunctions or is dropped or damaged in any manner. The supply cord cannot be

replaced. If the cord is damaged the appliance should be scrapped.

•The use of accessory attachments not recommended by the appliance

manufacturer may cause fire, electric shock or injury.

•This appliance must not be immersed

•To disconnect remove the plug from the mains outlet. Do not pull the plug out by

the cord.

•Never remove parts from the appliance, such as the feet, screws and so on.

•Never use the appliance near a bath, shower or a swimming pool.

•Never use the appliance on or near hot surface.

•Never move the appliance by pulling the cord.

•Never place flammable objects or clothing on top of the appliance.

•Never move the heater when it is operating. Turn the heater off before move it.

•Allow at least 15cm safe area around the appliance on the top, at the front and

sides to provide good air circulation.

•Prevent overheating of the appliance by keeping the air inlets and outlets clean

and free of anything that may cause blockage. Check all inlets and outlets from

time to time for accumulated dust. DO NOT COVER.

WARNING: In order to avoid overheating,

do not cover the heater.

SAFETY INSTRUCTIONS

•Never use the appliance in a room with explosive gas such as petrol, or while using

any kinds of flammable glues, sprays or solvents.

•The appliance must not be used with an extension lead.

•Do not place any part of your body near the air inlet, outlet or on the fins ,to avoid

personal injury, electric shock or fire.

•If overheating should occur, the built-in overheating safety device will shut the

appliance off.

•Caution: Some parts of this product can become very hot and cause burns.

Particular attention must be given when children vulnerable people are present.

•Do not insert any foreign objects into the grill.

•Keep all grills clear of any draped fabric or curtains.

•The appliance must not be located immediately below a mains socket. Do not use

the appliance with a programmer, timer or any other device that switches the

appliance on automatically. A fire risk exists if the appliance is covered or

positioned incorrectly.

•Do not operate this appliance for any thing other than its intended use.

•This appliance is not intended for commercial use

•This product is intended for household use only. Do not use outdoors.

•This product is only intended for heating.

•Warning: It is hazardous for anyone other than a competent person to carry out

any service or repair operation which involves the removal of a cover which gives

protection against exposure to electrical parts.

•Warning: Children should not use this appliance. Close supervision is necessary

when any appliances are used near children.

•This appliance can be used by children aged from 8 years and above and persons

with reduced physical, sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or instruction concerning use of

the appliance in a safe way and understand the hazards involved. Children shall

not play with the appliance. Cleaning and user maintenance shall not be made by

children without supervision.

•Children of less than 3 years should be kept away unless continuously supervised.

•Children aged from 3 years and less than 8 years shall only switch on/off the

appliance provided that it has been placed or installed in its intended normal

operating position and they have been given supervision or instruction concerning

use of the appliance in a safe way and understand the hazards involved. Children

aged from 3 years and less than 8 years shall not plug in, regulate and clean the

appliance or perform user maintenance.

SAFETY INSTRUCTIONS

•Warning: This appliance is not intended for use by persons (including children)

with reduced physical, sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction concerning use

of the appliance by a person responsible for their safety. Children should be

supervised to make sure that they do not play with the appliance.

•Warning: This heater is not equipped with a device to control the room

temperature. Do not use this heater in small rooms when they are occupied by

persons not capable of leaving the room on their own, unless constant supervision

is provided.

Electrical Safety

THIS APPLIANCE MUST BE PLUGGED INTO AN EARTHED SOCKET

•Before switching on, make sure that the voltage of your electricity supply is the

same as that indicated on the rating plate. This product is designed to operate on

220 –240V AC; 50Hz. Connection to any other power source may damage the unit.

•This product may be fitted with a non re-wireable plug. If it is necessary to change

the fuse in the plug, the fuse cover must be refitted. If the fuse cover becomes lost

or damaged, the plug must not be used until a suitable replacement is obtained.

•If the plug has to be changed because it is not suitable for your socket, or becomes

damaged in any way, it should be cut off and an appropriate plug fitted. This should

be carried out by a qualified electrician. The plug removed must be disposed of

safely, as insertion into a 13 Amp socket is likely to cause an electrical hazard.

1. Top of the electric fire

2. Log effect fire bed

3. Air outlet

4. Handle

PRODUCT OVERVIEW

USING YOUR ELECTRIC STOVE

•Before connecting to the mains socket, position the appliance

away from curtains, furniture or wall coverings and other

flammable materials.

•Insert the mains plug into a suitable 13 Amp mains socket.

•To activate the heater, press ON/OFF switch to turn on the

heater.

•Turn Thermostat Control clockwise to increase the

temperature or turn anti-clockwise to decrease the

temperature.

•Press the ‘I’ switch for the low heat setting and then press the

‘II’ switch for the maximum heat setting.

Note: maximum heat can only be switched on when press ‘I’ and

then ‘II’ afterwards. If only press ‘II’, the maximum heat will not

work.

1. On/Off switch

2. Low heat setting ‘I’ 3. High heat setting ‘II’

4. Thermostat control dial

1234

Safety Protective Devices

The appliance is fitted with an over heat protection and safety

cut off system.

•Overheat protection - the power to the heating elements

will automatically cut off if the temperature of the heating

elements exceeds a certain limit. In the event of

overheating, the heater will stop operating. Switch the

appliance off and allow it to completely cool.

•This appliance is fitted with a safety cut-off which will

operate if the heater overheats (e.g. Due to blocked air

vents). For safety reasons, the heater will NOT

automatically reset. To reset the appliance, disconnect the

appliance from the mains supply for at least 15 minutes.

Reconnect the supply to the mains and switch on the

appliance.

USING YOUR ELECTRIC STOVE

CLEANING AND CARE

WARNING: Electrical Shock Hazard.

Before you clean the appliance, disconnect the mains plug from

the wall socket.

•Allow the appliance to cool down completely before

cleaning.

•Do not immerse cord, plug or appliance in any liquid or allow

moisture to come into contact with electrical parts.

•Clean the outer surface using a moist cloth and wipe over

with a dry, soft cloth.

•Do not use harsh detergents, abrasives or spray on cleaners.

•Don’t allow water to seep into the openings or come into

contact with electrical connections.

•Allow sufficient drying time before operating again.

•Clean the air inlets and outlets regularly with a vacuum

cleaner using the brush attachment (with a regular use, at

least twice a year).

•When the appliance is not in use. We recommend that, the

heater is re-packed in its original packaging and stored in a

cool, dry place.

PROBLEM SOLVING

My appliance does not work when I turn it on:

1. Check that your appliance is plugged in and the power is

turned on at the mains socket.

2. Try another mains socket.

3. Check the appliance is in an upright position.

4. Check that the thermostat setting has not been set too low.

5. If the appliance still doesn’t work, do not try to repair it

yourself.

If your appliance power is automatically cut off, follow the step

below:

1. Unplug your appliance from the mains socket and allow it to

completely cool down.

2. Inspect your appliance. Clean the air inlet and air outlet with

a vacuum cleaner if necessary. If there are any signs of

physical damage (e.g. melting, or burning of the case), do

not attempt to use the appliance. Please leave all

maintenance work to qualified personnel.

3. Plug in the appliance and switch it on again. If it cuts off

again, move the appliance to a better ventilated location.

Note: This appliance has LED light bulbs to create the flame

effect, therefore it should only be serviced by qualified

electricians.
