Zehnder Rittling ComfoClime 24 Manuale utente
1 - EN
ComfoClime 24
ComfoClime 36
User manual
Decorative radiators Comfortable indoor ventilation Heating and cooling ceiling Clean air solutions
EN - 2
All rights reserved.
This manual has been compiled with the utmost care. The publisher cannot be held liable for any
damage caused as a result of missing or incorrect information in this manual.
Table of Contents
Preface............................................................................................................................3
1 Installation..................................................................................................................... 4
2 The provisioning ............................................................................................................5
2.1 Special circumstances......................................................................................................12
2.2 Settings ..........................................................................................................................14
3 The home page........................................................................................................... 16
4 The main menu ........................................................................................................... 17
5 Your devices ............................................................................................................... 18
6 The thermal profile ....................................................................................................... 20
7 Scenarios ................................................................................................................... 23
8 The scheduler ............................................................................................................. 24
9 Notification.................................................................................................................. 25
10 Firmware updates ...................................................................................................... 26
3 - EN
Preface
IMPORTANT!
Carefully read this manual before use.
The ComfoClime is hereinafter referred to as "device".
This manual explains how to install, configure and use the App in order to control the ComfoClime.
Since that application is continuously developed and improved, your actual release may differ a bit
from the descriptions shown in this document.
Due to the automatic update procedure of mobile app stores (Google Play and Apple Store), the App
will automatically upgrade as soon as an update is released.
NOTE : this manual has been compiled with the utmost care. However, no rights
can be derived from it. In addition, we at all times reserve the right to change the
contents of this manual, without prior notice.
The following pictograms are used in this document:
Symbol Meaning
Consult the manual before using/operate the equipment.
Point of attention / important informations.
Risk of compromised performance or damage to the ventilation system / risk of
personal injury.
Caution electrical hazard!
Zehnder Group International - Via G. di Vittorio 6 - 41011 Campogalliano (MO), Italy
T +39 059 978 62 00 - F +39 059 978 62 01
EN - 4
1 Installation
To configure and operate the ComfoClime the user must install the ComfoClime Control app by
downloading it from Google Play or Apple Store.
Once installed the app will appear among the phone apps with it's icon:
All the manuals are downloadable scanning this QR-code.
You’ll be redirected to the download page where you can select
among a wide range of languages.
5 - EN
2 The provisioning
At the first launch of the app, the user will be prompted to detect the ComfoClime and connect it to
his home WiFi network (if available).
The ComfoClime can be controlled only through the ComfoClime Control app.
In case the user doesn’t have a WiFi network running in the house there is the possibility to get
connected to the ComfoClime anyway through the Bluetooth connection or through a local WiFi
network generated by the ComfoClime itself.
ACTION IMAGE
Launching the APP the installation page, called
Apartment select, will appear.
To begin detecting the ComfoClime, proceed
by tapping the ADD button.
EN - 6
ACTION IMAGE
In the next page the user is asked to select
between a WiFi present or not can choose
whether to go for a brand new installation or
connect an already installed ComfoClime.
Advise: please ensure in your mobile phone WiFi
settings that your WiFi allows to add additional
devices.
Note: check also if the router allows to add other
devices to the local network and in case, enable
the feature.
In the first provisioning screen there are two
possibilities:
YES: the user will install the ComfoClime in the
WiFi network searching the unit via Bluetooth.
NO: the user will install the ComfoClime using
a local direct WiFi connection between the
smartphone and the unit (go to pag. 7).
WIFI PRESENT
Answering YES (Step 1) the following page allows
the user to connect the smartphone to the WiFi
in case it wasn’t yet done, firstly tapping on Go
To Wifi Settings and going temporarily in the
smartphone settings to set up the wifi connection
Afterwards, in any case, tap on Next to move to
the next step.
7 - EN
ACTION IMAGE
Step 2: the app asks the user to check and
confirm that the smartphone has the Bluetooth
enabled. Once confirmed tap Next.
In this page please confirm the authorization
to use also the geolocation in order to let the
smartphone looking for the ComfoClime tapping
on Grant.
EN - 8
ACTION IMAGE
When the app finds a Bluetooth signal (the one
generated by the ComfoClime), it will show it and
the user must tap on New Device to trigger the
connection phase between the two devices.
The app will move automatically to the next step.
In this page the user confirms the authorization
to the Bluetooth pairing tapping on Pair.
9 - EN
ACTION IMAGE
In this page it is possible to assign the WiFi
connection to the ComfoClime among the ones
found in the environment (usually in a house
there is only one)
Important: insert the user’s WiFi router password.
Once the WiFi is chosen the app moves to the
next page.
WiFi Home
Tap on Next.
EN - 10
ACTION IMAGE
Now the ComfoClime has been found and
included in the network with a generic name
ComfoClime.
Tap on the name to enter the personalization
page.
In case of the ComfoClime was already installed
before but it is necessary to repeat the procedure
only for the part regarding the search of the
unit, the page will show directly the unit with the
name that was assigned to during the previous
provisioning.
In this page it is possible to change the name
of the unit (apartment), assigning if desired the
address, city and country.
Finally an icon can be assigned as well.
Then tap on Save to confirm the choices.
