User guide –Holiday calendar
www.zennio.com - 1 - Z41 Pro/Lite/COM
HOW TO CONFIGURE THE HOLIDAY CALENDAR?
HOLIDAY CALENDAR
It lets you define on your
calendar which days are
holidays.
It allows you to define different
sendings depending on whether
it is holiday or workday.
① Press on the Holiday calendar button.
Seleccione los días de la semana en que el
User guide –Holiday calendar
www.zennio.com - 2 - Z41 Pro/Lite/COM
②Set holiday days.
For example, let’s say that the current month is April, 2018, and the non-working days that we
want to define are:
•4th April
•From 13th to 20th April
Navigate among the
different months of the
year.
Select the days of the month that
you want to set as holidays.
Days marked as holidays will remain
highlighted in orange colour.
To deselect an already marked day,
you just need to tap on it again. It will
not be marked in orange then.
By sliding across the days while
holding pressed, it is possible to
select several days in a quicker way.
Close the pop-up
window.
User guide –Macro
www.zennio.com - 3 - Z41 Pro/Lite/COM
HOW TO CONFIGURE MACROS?
Run / Stop
① Press on the Macro settings button.
MACRO
It is a control that lets configure
and execute a set of sequential
actions.
These actions are selected among
those already configured for the
different boxes of the touch
panel.
Settings
User guide –Macro
www.zennio.com - 4 - Z41 Pro/Lite/COM
Add action
Close the pop-up
window.
②Add a new action
Up to 10 actions per macro can be configured.
User guide –Macro
www.zennio.com - 5 - Z41 Pro/Lite/COM
Delay of each action.
With delay of 0 s the actions will be
executed simultaneously.
Move among the actions.
Controls already configured
for that box.
Delete. With a long press
on the selected action, it
will be removed.
Boxes configured in the page that
has been selected.
③Select actions from the list
In each section, you can move and select among the different options by using the controls and .
Pages already configured in the
touch panel.
User guide –Macro
www.zennio.com - 6 - Z41 Pro/Lite/COM
④ Example
Let’s imagine that in our macro we want, for instance, the following actions to be executed
sequentially, with an Interval of 5 seconds between them:
1. Mirror light →ON
2. Bathroom light →ON
3. Bathroom light →OFF
4. Living room. LEDs →Green
In this example, the Macro will take
19 seconds to be completed.
User guide –Scheduler
www.zennio.com - 7 - Z41 Pro/Lite/COM
HOW TO CONFIGURE A SCHEDULER?
SCHEDULER
It programs the execution of
time-controlled actions.
These actions are selected
among those already configured
for the different boxes of the
touch panel, and can be defined
depending on the day type
(working/holiday).
① Press on the Scheduler settings button.
Enable / Disable
When disabled, the icon
will appear between both
buttons.
Settings
User guide –Scheduler
www.zennio.com - 8 - Z41 Pro/Lite/COM
Add action.
Close the pop-up
window.
②Add a new time-controlled action
Up to 30 time-controlled actions per scheduler can be configured.
Note: It is not possible to set time-controlled actions for boxes either configured as indicator or of the type
“Other”, except for Macros, Logical functions and RGB(W) control.
User guide –Scheduler
www.zennio.com - 9 - Z41 Pro/Lite/COM
Time when the action will be
executed.
Calendar that has been chosen.
Day type selected:
Working / Holiday /
Both (if no calendar is selected)
Move among the actions.
Select the days of the week for
which the scheduler should
operate.
Pages already configured in
your touch panel.
Controls already configured for
that box.
③Select actions from the list
For each box, you can move and select among the different options by using the controls and .
.
Delete. With a long press on the
selected action, it will be removed.
Boxes already configured in the
page that has been chosen.
User guide –Scheduler
www.zennio.com - 10 - Z41 Pro/Lite/COM
④ Example
Let’s imagine that we want to program a time-controlled action so that at 18:10 on Saturdays and
Sundays of my holiday calendar, a setpoint of 26,5 ºC for the air conditioning in the living room is
set. The settings will be as follows:
