Zhumell COMMODORE BRASS Manuale utente

0˚

15˚W

30˚W

45˚W

60˚W

15˚E

30˚E

75˚W

OWNER’S MANUAL

COMMODORE BRASS TELESCOPE

ZHUMELL COMMODORE BRASS TELESCOPE

Zhumell customers know that there are plenty of ways to

experience the world. They also understand that, however

you choose to explore it, the best experience is one that fully

immerses you in the world’s most striking details.

That’s where our optics products come in. We strive to put

high-performance products in the hands of our customers

so that they can experience the world up close, with their

own eyes.

With Zhumell, you get ﬁeld-tested, precision-crafted optics

at the best possible value. So even if you’re just starting

out as an amateur birder or astronomer, you don’t have to

settle for entry-level products. Zhumell customers enjoy life’s

pursuits, hobbies, and adventures in rich, colorful detail- the

kind of detail that only high-performance optics can produce.

At Zhumell, we design our binoculars, telescopes, and

spotting scopes for discerning, price-conscious users

who are uncompromising on quality. If you’re looking for

accessibly priced optics that will bring your world within

reach, you’re looking for Zhumell.

Enjoy the view.

ENJOYING YOUR

ZHUMELL BRASS TELESCOPE

1. Caring For Your Telescope

2. Using Your Telescope

3. Spotting Scope Legend

4. Using Your Spotting Scope

5. Warranty

i. Warnings

ii. Cleaning and Maintenance

WARNINGS

• Do not use telescope to look at the sun without an

appropriate solar ﬁlter. Doing so will cause permanent and

irreversible eye damage.

• Make sure no screws are loose before using telescope.

• Do not drop or shake your telescope as doing so may

damage the optics or harm you or the people around you.

CARING FOR YOUR

ZHUMELL BRASS TELESCOPE

Zhumell telescopes are precision astronomical instruments

designed for ease of use and versatility in their application.

Your Zhumell Brass Telescope is built with the highest-quality

optics and top-notch construction to provide years of reliable

functionality, but will require proper care.

If, after reading this manual, you still have questions about your

Zhumell telescope, please visit http://www.zhumell.com for

more helpful tips and contact information. Our customer service

representatives are available to address any problems you

encounter with your telescope. Please let us know about your

experiences; we would like to hear your feedback.

Enjoy your Zhumell.

CARING FOR YOUR

ZHUMELL BRASS TELESCOPE

CLEANING AND MAINTENANCE

A telescope is carefully aligned during construction, and great care

should be taken to maintain this alignment over the life of the telescope.

Cleaning should be done as little as possible and then only with mild

soap solution and a soft, lint-free cloth. Do not rub elements when

cleaning. Blot optical components gently and allow telescope to air dry.

Store your telescope in its box or in a telescope case when not in use.

Do not use pure alcohol or solvents to clean any parts of the telescope.

Do not remove optical elements from the telescope as doing so may

affect the alignment of optical components when reassembled.

If telescope needs realignment, contact Zhumell or another professional.

• Brush telescope optics with camel-hair brush or blow off dust with

an ear syringe (can be purchased at any pharmacy). Do not use a

commercial photographic lens cleaner.

• Remove organic materials (e.g. ﬁngerprints) with short gentle

strokes using soft white tissue paper and a solution of three parts

distilled water and one part isopropyl alcohol. You may also add

one drop of biodegradable dish soap to one pint of the homemade

solution. Do not use lotioned or scented tissues as they could

damage the optics of your telescope.

• Wipe down the outside of your telescope with a dry cloth to remove

condensation prior to packing up your telescope. Do not wipe any

of the optical surfaces. Instead, allow the optics to dry naturally in

warm indoor air prior to packing up your telescope.

• Protect your telescope from excessive heat. For example do not

store your telescope in a sealed car on a warm day. Excessive

storage temperatures can damage your telescope.

SPECIFICATIONS FOR YOUR

ZHUMELL BRASS TELESCOPE

Aperture (mm) 60

Magnification 20-60×

Optical Tube Length (in.) 20

Tripod Height 52

Optical Design Refractor

Mount Design Alt-Az

Optical Tube Assembly with Arc Mount, Legs (3), Leg Pivot Bolts (3),

Plastic Washers (12), Tripod Chain

PARTS LIST

SETTING UP YOUR

ZHUMELL BRASS TELESCOPE

a. Place the brass top of the leg over the holes where the pivot

bolts were.

b. Placing plastic washers between all connection points,

thread the pivot bolt back through the mount and leg

assembly and re-attach the nut.

c. Repeat on all three legs. Be sure that all the nuts are secure

before moving on.

1. Remove all the pieces from the box. Keep them within reach.

2. There are (3) brass pivot bolts located on the bottom of the arc

mount. Remove one nut from the end of each brass pivot bolt and

pull it out. Remove the plastic washers from the bolts.

3. With the optical tube assembly and arc mount lying sideways on the

ﬂoor, attach the legs one at a time.

4. Extend the legs the desired length and tighten securely.

Adjusting the angle of your telescope, or pointing it at what you’d like

to view, is simple. Follow these instructions o accurately and securely

adjust your telescope.

1. Only adjust the telescope one axis at a time. This will keep it

secure on the other axis while you make the change.

2. To move the telescope up or down, loosen the ﬂip-lever located

on the right side of the arc-mount. Once you’ve set the scope

where you want it, retighten the ﬂip-lever to secure the telescope.

3. To turn the telescope on it’s horizontal axis, loosen the

thumbscrew located near the base of the mount column. Once

you’ve set the scope where you want it, retighten the thumbscrew

to secure the telescope.

4. Always make sure that you’ve secured the telescope after making

an adjustment.

FOCUS AND ZOOM YOUR

ZHUMELL BRASS TELESCOPE

To focus the telescope, turn the copper focus knob located in

front of the eyepiece. Do not force the focus knob as you may

damage the focusing mechanism.

ADJUSTING THE ANGLE OF YOUR

ZHUMELL BRASS TELESCOPE

SETTING UP YOUR

ZHUMELL BRASS TELESCOPE

5. Carefully lift the optical tube assembly and legs until the entire

telescope is in standing position. Spread the legs as far as the chain

will allow and double-check that all connections are secure. Your

Zhumell Brass Telescope is ready to use.

WARRANTY

Zhumell products are designed to provide you with the highest quality

and best value available, which is why we’re proud to offer a world-class

warranty on all of our products. All Zhumell telescopes are covered by a

3-year no-fault warranty.

To obtain warranty service, the damaged equipment must be returned

to Zhumell. Our Customer Care associates will be happy to assist you in

completing this return to get your Zhumell in working order as quickly as

possible. There is a $25 surcharge associated with warranty returns to

cover return shipping and handling.

For more information, contact information, and to download the Zhumell

Warranty Return Form, please visit http://www.zhumell.com
