5
3. Choose the correct PTZ
protocol in menu [Config]
[Channel]
[P/T/Z].
Note: 120Ω resistors should be
connected in parallel with
remote A/B lines to reduce the
signal distortion if a larger
number of PTZs are connected.
2 Basic Operation Guide
2.1 Power On
Install the DVR correctly (as above) and connect it to the power. DVR’s LED lights will be on
and it will boot up automatically.
The DVR will detect any connected hardware (cameras, monitors, etc.) automatically. This
process should last about 20 seconds. You will hear a “beep”sound when the process has
completed. The DVR will enter the multi-screen real-time surveillance mode. If the current
time which the DVR displayed is within the recording period scheduled, the DVR will start
recording accordingly.
2.2 Power Off
There are two ways to shut down the DVR:
1. Right-click on [Main Menu]
[Shut Down].
2. If there are buttons on the front panel, press the switch button to shut the device down.
2.3 Login
Right-click and select “Login” from the menu, then
input the username and password.
Note: The default User Name is admin and the
default Password is 123456. Users can modify the
password. The administrator can add, delete and
modify other accounts’ parameters.
