Zmotion VPLC532E Manuale utente

Foreword

The motion controller provides rich interface, and it has excellent motion control performance, which

can meet the expansion requirements of various projects.

This manual is copyrighted by Shenzhen Technology Co., Ltd., without the written permission of the

Zmotion Technology, no person shall reproduce, translate and copy any content in this manual. The

above-mentioned actions will constitute an infringement of the copyright of the company's manual, and

Zmotion will investigate legal responsibility according to law.

For details about the ZMC controller software and the introduction and routine of each command,

please refer to the ZBASIC software manual.

Information contained in this manual is only for reference. Due to improvements in design and

functions and other aspects, Zmotion Technology reserves the final interpretation! Subject to change

without notice!

Pay attention to safety when debugging the machine!

Please be sure to design an effective safety protection device in the machine, and add an error

handling program in the software, otherwise Zmotion has no obligation or responsibility for the loss

caused.

In order to ensure the safe, normal and effective use of the product, please be sure to read this

product manual carefully before installing and using the product.

Safety Statement

⚫This chapter describes the safety precautions required for the correct use of this product. Before

using this product, please read the instructions for use and correctly understand the relevant

information on safety precautions.

⚫This product should be used in an environment that meets the design specifications, otherwise

it may cause equipment damage or personal injury, and malfunctions or component damage

caused by failure to comply with relevant regulations are not within the scope of product quality

assurance.

⚫Zmotion will not take any legal responsibility for personal safety accidents and property losses

caused by failure to comply with the contents of this manual or illegal operation of products.

Safety Level Definition

According to the level, it can be divided into " Danger " and " Caution ". Failure to operate as required

may result in moderate injury, minor injury or equipment damage.

Please keep this guide in a safe place for reading when needed, and be sure to hand this manual to

the end user.

Install

Danger

◆When the controller is disassembled, all external power supplies used by the

system should be disconnected before operation, otherwise it may cause

misoperation or damage to the equipment.

◆It is forbidden to use in the following places: places with dust, oil fume, conductive

dust, corrosive gas and flammable gas; places exposed to high temperature,

condensation, wind and rain; places with vibration and shock. Electric shock, fire

and misuse can cause product damage and deterioration.

Notice

◆Avoid metal shavings and wire ends falling into the hardware circuit board during

installation.

◆After installation, ensure that there are no foreign objects on the hardware circuit

board.

◆When installing, make it tightly and firmly with the mounting frame.

◆Improper installation of the controller may result in misoperation, failure and fire.

Wiring

Danger

◆The specifications and installation methods of the external wiring of the

equipment shall comply with the requirements of local power distribution

regulations.

◆When wiring, all external power supplies used by the system should be

disconnected before operation.

◆When powering on and running after the wiring work is completed, the terminals

attached to the product must be installed.

◆Cable terminals should be well insulated to ensure that the insulation distance

between cables will not be reduced after the cables are installed on the terminal

block.

Notice

◆Avoid metal shavings and wire ends falling into the hardware circuit board during

installation.

◆The cable connection should be carried out correctly on the basis of confirming

the type of the connected interface.

◆It should be confirmed that the cables pressed into the terminals are in good

contact.

◆Do not bundle the control wires and communication cables with the main circuit

or power supply wires, etc., and the distance between the wires should be more

than 100 mm, otherwise noise may cause malfunction.

◆If the controller is not installed properly, it may cause electric shock or equipment

failure or malfunction.

 VPLCE532E Vision Motion Controller User Manual V1.5

Content

Chapter I Production Information........................................................................................3
1. Product Information ..........................................................................................3
2. Function Features..............................................................................................3
3. System Frame ...................................................................................................5
4. Hardware Installment........................................................................................5
Chapter II Product Specification .........................................................................................7
1. Basic Specification............................................................................................7
2. Order Information..............................................................................................8
3. Interface Definition............................................................................................8
4. Work Environment ...........................................................................................10
Chapter III Wiring & Communication.................................................................................11
1. Power Input, CAN Communication Interface ..................................................11
1.1. Power Specification..............................................................................11
2. RS485, CAN Communication Interface ...........................................................11
2.1. RS232, CAN Communication Specification & Wiring...........................12
1.2. Basic Usage Method ............................................................................14
3. RS232 Serial Port ............................................................................................16
3.1. RS232 Communication Port Specification & Wiring............................16
3.2. Basic Usage Method ............................................................................17
4. IN Digital Input & High-Speed Latch Port .......................................................18
4.1. Digital Input Specification & Wiring .....................................................19
4.2. Basic Usage Method ............................................................................21
5. OUT Digital Output & PWM & Hardware Comparison Output & Single-ended
Pulse 21
5.2. Digital Output Specification & Wiring...................................................22
5.3. Basic Usage Method ............................................................................25

 VPLCE532E Vision Motion Controller User Manual V1.5
6. DA Analog Output............................................................................................25
6.1. Analog Output Specification & Wiring..................................................26
6.2. Basic Usage Method ............................................................................27
7. USB Interface...................................................................................................27
8. HDMI Interface ................................................................................................28
9. LAN Ethernet ...................................................................................................29
10. EtherCAT Bus Interface................................................................................30
11. AXIS Differential Pulse Axis Interface .........................................................32
11.1. AXIS Interface Signal Specification & Wiring.......................................33
11.2. Basic Usage Method ............................................................................36
Chapter IV Expansion Module ...........................................................................................38
1. CAN Bus Expansion.........................................................................................38
1.1. CAN Bus Expansion Wiring...................................................................38
1.2. CAN Bus Expansion Resource Mapping ..............................................40
2. EtherCAT Bus Expansion.................................................................................44
2.1. EtherCAT Bus Expansion Wiring...........................................................44
2.2. EtherCAT Bus Expansion Resource Mapping ......................................45
Chapter V Program & Applications....................................................................................48
1. ZDevelop Software Usage...............................................................................48
2. PC Upper-Computer Program Application .....................................................53
Chapter VI Run and Maintain ............................................................................................56
1. Regular Inspection and Maintenance .............................................................56
2. Common Problems..........................................................................................57



VPLCE532E Vision Motion Controller User Manual V1.5

Chapter I Production Information

1.1. Product Information

VPLC532E is a kind of bus type vision motion controller. The controller itself supports

32-axis at most that can achieve all kinds of complex motion control functions, such as,

electronica cam, linear, circular, continuous trajectory processing, robot, etc., and

machine vision applications, positioning, measurement, detection, and identification.

VPLC532E motion controller can be applied in 3C electronics, lithium, printing and

packaging equipment, medical equipment, robot, semiconductor, and laser.

1.2. Function Features

◆Support 32 axes motion control at most.

◆Pulse output mode: pulse / direction or dual-pulse.

◆IO can be expanded through ZCAN and EtherCAT bus, 4096 isolated inputs and 4096

isolated outputs can be extended at most.

◆There are 24 NPN inputs, among them, 4 are high-speed inputs, 12 are low-speed

inputs, and high-speed inputs can be configured as latch signal.

◆There are 12 NPN outputs, among them, 4 are high-speed outputs, they can be

configured as high-speed comparison and PWM. 8 are general outputs, and max

output current can reach 300mA, which can drive some solenoid valve directly.

◆There are 2 USB3.0 interfaces and 2 USB2.0 interfaces to connect to camera, mouse,

keyboard, U disk, and other external devices.

◆There are one RS485, one RS232, one CAN bus interface, one 100M EtherCAT

interface and two 1000M ethernet interfaces.

VPLCE532E Vision Motion Controller User Manual V1.5

◆There is one HDMI interface, which means high-definition display is supported.

◆There are two voltage type analog outputs, 0-10V, 12 bits.

◆Support up to 32 axes linear interpolation, any circular interpolation, helical

interpolation, and spline interpolation.

◆Support electronic cam, electronic gear, position latch, synchronous follow, virtual

axis, and other functions.

◆Support hardware comparison output (HW_PSWITCH2), hardware timer, precision

output when in motion.

◆Support pulse closed loop, pitch compensation, etc.

◆Support multi-task and multi-file programming in Basic.

◆A variety of program encryption methods to protect the intellectual property rights of

customers.

◆Support power failure detection and power failure storage.

VPLCE532E Vision Motion Controller User Manual V1.5

1.3. System Frame

1.4. Hardware Installment

VPLC532E motion controller is fixed by screws in horizontal installment method, each

controller needs 4 screws to be fixed.

(Unit: mm, Mounting Hole Diameter 4.5mm, Thickness: 53mm)

VPLCE532E Vision Motion Controller User Manual V1.5

Installation

attention

⚫Non-professionals are strictly prohibited to operate. Specifically,

professionals who had been trained related electrical equipment,

or who master electrical knowledge.

⚫Please be sure to read the product instruction manual and safety

precautions carefully before installation.

⚫Before installation, please ensure that the product is powered off.

⚫Do not disassemble the module, otherwise the machine may be

damaged.

⚫In order to facilitate ventilation and controller replacement, 2-3cm

should be left between the upper and lower parts of the controller

and the installation environment and surrounding components.

⚫Considering the convenient operation and maintenance of the

controller, please do not install the controller in the following

places:

a) places where the surrounding ambient temperature exceeds

the range of -10° C- 55°C

b) places where the ambient humidity exceeds the range of 10%-

95% (non-condensing)

c) places with corrosive gases and flammable gases

d) places with many conductive powders such as dust and iron

powder, oil mist, salt, and organic solvents

e) places with direct sunlight

Indice

Altri manuali Zmotion Controllori

Zmotion

Zmotion ZMC460N Manuale utente

Zmotion

Zmotion ZMC004WEA Manuale utente

Zmotion

Zmotion ZMC460 Manuale utente

Zmotion

Zmotion ZMC408CE Manuale utente

Zmotion

Zmotion ZMC464 Manuale utente

Zmotion

Zmotion ZMC006CE Manuale utente

Zmotion

Zmotion ZMC212BE Manuale utente

Zmotion

Zmotion ZMC416BE Manuale utente

Zmotion

Zmotion ZMC420SCAN Manuale utente

Zmotion

Zmotion ZMC308BE Manuale utente

Zmotion

Zmotion VPLC516E Manuale utente

Zmotion

Zmotion ZMC304X306X Manuale utente

Zmotion

Zmotion ZMC420SCAN Manuale utente

Zmotion

Zmotion ECI1000 Manuale utente

Zmotion

Zmotion XPLC108E Manuale utente

Zmotion

Zmotion XPLC300 Manuale utente

Zmotion

Zmotion ZMC303 Manuale utente

Zmotion

Zmotion XPLC3264E Manuale utente

Zmotion

Zmotion ZMC464 Manuale utente

Zmotion

Zmotion XPLC864E Manuale utente

Zmotion

Zmotion ZMC408SCAN Manuale utente

Zmotion

Zmotion VPLC710 Series Manuale utente

Zmotion

Zmotion ZMC412 Manuale utente

Zmotion

Zmotion ZMC408SCAN Manuale utente

Manuali Controllori popolari di altre marche

Digiplex

Digiplex DGP-848 Istruzioni operative

YASKAWA

YASKAWA SGM series Manuale utente

Sinope

Sinope Calypso RM3500ZB Manuale utente

Isimet

Isimet DLA Series Style 2 Manuale di installazione

LSIS

LSIS sv-ip5a Manuale utente

Rockwell Automation

Rockwell Automation 1769-L31 Manuale utente

Airflow

Airflow Uno hab Manuale utente

ABB

ABB ACS580-01 drives Manuale utente

Panasonic

Panasonic GM1 Series Manuale utente

Emerson

Emerson SW93 Manuale utente

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuale utente

Panasonic

Panasonic FP? Positioning Unit RTEX Manuale utente

Samson

Samson Type 5824 Manuale di servizio

Alpha IP

Alpha IP MIOB 21001 Manuale utente

Siemens

Siemens OpenAir GMA 1 Series Manuale utente

Surecom

Surecom SR-629 Manuale utente

Fishman

Fishman TriplePlay Manuale utente

Regulus

Regulus SRS1 T Manuale utente
