Zotac GAMING MEK1 Manuale utente
291-MA345-06R9F
ZOTAC GAMING MEK1 Gaming PC
1
ZOTAC GAMING MEK1 GAMING PC
User’s Manual
No part of this manual, including the products and software described in it, may
be reproduced, transmitted, transcribed, stored in a retrieval system, or translated
into any language in any form or by any means, except documentation kept by the
purchaser for backup purposes, without the express written permission of ZOTAC.
Products and corporate names mentioned in this manual may not be registered
trademarks or copyrights of their respective companies, and are used for identication
purposes only. All trademarks are the property of their respective owners.
Every effort has been made to ensure that the contents of this manual are correct and
up to date. However, the manufacturer makes no guarantee regarding the accuracy of
its contents, and reserves the right to make changes without prior notice.
CAUTION:
Risk of explosion if the battery is replaced with an incorrect type. Batteries should be
recycled where possible. Disposal of used batteries must be in accordance with local
environmental regulations.
ZOTAC GAMING MEK1 Gaming PC
2
Table of Contents
Product specications ----------------------------------------------------------------------------------------3
Safety information ----------------------------------------------------------------------------------------------4
Setting up your system-------------------------------------------------------------------------------------4
Care during use ----------------------------------------------------------------------------------------------4
Welcome -----------------------------------------------------------------------------------------------------------5
Package contents -------------------------------------------------------------------------------------------5
Getting to know your ZOTAC GAMING MEK1 Gaming PC ----------------------------------------6
Front view -----------------------------------------------------------------------------------------------------6
Rear view ------------------------------------------------------------------------------------------------------7
Side view ------------------------------------------------------------------------------------------------------8
Standing your ZOTAC GAMING MEK1 Gaming PC --------------------------------------------------9
Setting up your ZOTAC GAMING MEK1 Gaming PC ------------------------------------------------10
Congure your ZOTAC GAMING MEK1 Gaming PC-------------------------------------------------12
Conguring a wireless connection ----------------------------------------------------------------------12
Conguring a wired connection --------------------------------------------------------------------------12
Using a static IP----------------------------------------------------------------------------------------------12
Conguring audio output-----------------------------------------------------------------------------------13
Mouse & Keyboard ---------------------------------------------------------------------------------------------14
Standard keyboard shortcuts -----------------------------------------------------------------------------14
Lighting effects -----------------------------------------------------------------------------------------------14
Macro -----------------------------------------------------------------------------------------------------------15
ZOTAC GAMING MEK1 Gaming PC
3
Product specications
qMicroprocessor support
vIntel Core i5-7400 (quad-core 3.0GHz, up to 3.5GHz)
qOperating systems:
v Windows 10 Home (pre-installed)
qSystem Memory support
v Two DDR4 DIMM slots (2x8G 2400MHz pre-installed)
qOnboard Serial ATA
v Supports one 2.5-inch SATA HDD or SSD (1TB HDD pre-installed)
qExpansion slot
vOne M.2 PCIe x4 (240GB NVMe SSD pre-installed)
qUSB Ports
v Two USB 3.0 port(Front)
v Two USB 2.0 port(Rear)
v Four USB 3.0 ports(Rear)
q Onboard Dual LAN
v Supports 10/100/1000 Mbps operation
vSupports IEEE 802.3
qWiFi/Bluetooth support
v Compliant with IEEE802.11ac standard
vBluetooth v4.2
qOnboard Audio
v 7.1 audio output and Microphone input with Optical output
qPower Management
v Supports ACPI (Advanced Conguration and Power Interface)
qOnboard Graphics support
vZOTAC GeForce GTX 1060 w/ 6GB GDDR5, 192bit
v3 x DisplayPort 1.4, 1 x HDMI 2.0b, 1 x DL-DVI
qProduct Size
v 418.3 x 118 x 415.2 mm (LxWxH)
qPower Supply
v 450W
ZOTAC GAMING MEK1 Gaming PC
4
Safety information
Your ZOTAC GAMING MEK1 Gaming PC is designed and tested to meet the latest standards of
safety for information technology equipment. However, to ensure your safety, it is important that you
read the following safety instructions.
Setting up your system
Read and follow all instructions in the documentation before operating your system.
Do not use this product near water or a heat source such as a radiator.
Set up the system on a stable surface.
Openings on the chassis are for ventilation. Do not block or cover these openings. Make sure
you leave plenty of space around the system for ventilation. Never insert objects of any kind into
the ventilation openings.
Use this product in environments with ambient temperatures between 0℃and 35℃.
If you use an extension cord, please use the UL listed cord and make sure that the total
ampere rating of the devices plugged into the extension cord does not exceed its ampere
rating.
Care during use
Do not walk on the power cord or allow anything to rest on it.
Do not spill water or any other liquids on your system.
When the system is turned off, a small amount of electrical current still ows. Always unplug all
power, modem, and network cables from the power outlets before cleaning the system.
If you encounter the following technical problems with the product, unplug the power cord and
contact a qualied service technician or your retailer.
¾The power cord or plug is damaged.
¾Liquid has been spilled onto the system.
¾The system does not function properly even if you follow the operating instructions.
¾The system was dropped or the cabinet is damaged.
ZOTAC GAMING MEK1 Gaming PC
5
Welcome
Congratulations on your purchase of the ZOTAC GAMING MEK1 Gaming PC. The following illustration
displays the package contents of your new MEK1 Gaming PC. If any of the below items is damaged
or missed, contact your retailer.
Package contents
• 1 x ZOTAC GAMING MEK1 Gaming PC
• 2 x MEK1 Gaming PC Stand
• 1 or 2 x Power Cord (depends on region)
• 2 x Antenna
• 1 x Windows recovery DVD
• 1 x USB ash drive with Windows drivers
• 1 x User Manual & Warranty Card
• 1 x Quick Start Guide
• 1 x Gaming mouse*
• 1 x Gaming keyboard*
• 1 x Gaming mouse pad*
*Only applicable on select bundles
ZOTAC GAMING MEK1 Gaming PC
6
Getting to know your ZOTAC GAMING MEK1 Gaming PC
Front view
Refer to the diagram below to identify the components on this side of the system
1. Power switch
The power switch allows powering ON and OFF the system. The ring LED will be lit while
system is On.
2. Headphone/Audio Out jack
The stereo headphone jack (3.5mm) is used to connect the system’s audio out signal to
gaming headset.
3. Microphone jack
The microphone jack is designed to connect the microphone used for easy connection with
gaming headset.
4. USB 3.0 ports
The USB 3.0 port supports the SuperSpeed USB 3.0 devices and is backwards compatible
with USB 2.0/1.1 devices. Use this port for USB 3.0 devices for maximum performance with
USB 3.0 compatible devices.
1
2
3
4
ZOTAC GAMING MEK1 Gaming PC
7
Rear view
1. Power input (IEC C14, standard power cord connection)
Connected with power cord to mains for AC input.
2. DVI port
The DVI port supports connection to digital display devices.
3. DisplayPorts
DisplayPorts supports both external (box-to-box) and internal (laptop LCD panel) display
connections.
4. HDMI port
The HDMI (High Denition Multimedia Interface) port supports a UHD device such as an LCD
TV or monitor to allow viewing on a larger external display.
5. Audio ports
Use the ve audio ports to connect audio devices. The pink jack is for microphone. The green
jack is for front speaker out signal. The blue jack is for side speaker out signal. The orange
jack is for rear speaker out signal. The black jack is for center/subwoofer signal.
6. Optical (SPDIF OUT) jack
The optical S/PDIF output enables connectivity with digital audio receivers and speakers for
crystal clear digital audio and surround sound from compatible soundtracks.
7. USB 3.0 ports
The USB 3.0 port supports the SuperSpeed USB 3.0 device. Use this port for USB 3.0 devices
for maximum performance with USB 3.0 compatible devices.
8. LAN ports
The eight-pin RJ-45 LAN ports support standard Ethernet cables for connection to a local
network.
9. WiFi antenna connectors
The WiFi antenna connector supports WiFi antenna module.
1
2
3 4 5
67
89
10
311
ZOTAC GAMING MEK1 Gaming PC
8
Side view
1. LED Strips
Lighting effects are controlled by ZOTAC GAMING Spectra software. Customize color, 5
different lighting modes, and brightness. Visit www.zotac.com website for the latest version.
Do not block the ventilation inlet / outlet. Lack of ventilation may cause system overheating.
10. USB 2.0 ports
The USB (Universal Serial Bus) port is compatible with USB devices such as keyboards,
mice, cameras and hard disk drives.
11. PS/2 port
The PS/2 port is used to connect with keyboard or mouse.
Do not block ventilation outlet for warm air exhaust.
ZOTAC GAMING MEK1 Gaming PC
9
Standing your ZOTAC GAMING MEK1 Gaming PC
1. Lay the MEK1 Gaming PC on its side on a at surface.
2. Position the two MEK1 Gaming PC feet outside the edge of the at surface.
3. Slide MEK1 Gaming PC stands on the MEK1 Gaming PC feet.
4. Lift the MEK1 Gaming PC up and position it upright.
*Standing the MEK1 Gaming PC without installing the stand is not recommended as it may be
unstable and can be easily unbalanced.
