A002ZT

USB Modem

Quick Start Guide

Getting to Know Your

Modem

Your modem supports data services through the

mobile phone network, enabling you to

communicate anytime and anywhere.

The following figure is only for your reference.

The actual product may be different.

1. Rotatable USB connector

2. Indicator light

Red

blinking

• There is no nano-SIM card inserted

or the nano-SIM card is damaged.

• The PIN or PUK is enabled.

Red on • The device is just powered on.

• The device is searching for available

networks.

• There is no network service

available.

Green

The device is connected to the 2G/3G

mobile network and data is being

transferred.

Green

blinking

The device is registered to the 2G/3G

mobile network.

Blue on The device is connected to the LTE

network and data is being transferred.

Blue

blinking

The device is registered to the LTE

network.

3. nano-SIM card slot cover

Installing the nano-SIM

Card

1. Open the nano-SIM card slot cover.

NOTE:

Do not remove the cover rudely, because it is

connected with the device.

2. Install a nano-SIM card to the nano-SIM card

slot.

WARNING!

To avoid damage to the device, do not use any

other kind of SIM cards, or any non-standard

nano-SIM card cut from a SIM card. You can get

a standard nano-SIM card from your service

provider.

3. Close the nano-SIM card slot cover.

Connecting the Modem to

Your PC

Rotate the USB connector and insert the modem

into your computer’s USB port securely. The

operating system automatically detects and

identifies your modem and installs the software

automatically.

NOTE:

If the system does not launch installation

automatically, you can double-click the modem

installation icon in My Computer > ZTEMODEM

to install the software.

Logging in to the Device

Manager Website

1. Launch the Internet browser and enter

http://192.168.0.1 in the address bar or click

on your desktop.

2. Click Login and enter the password to log in to

the

Device Manager Website.

NOTE:

View the label on the device to get the default

password.

Accessing the Internet

After a client device is successfully connected to

your device, you can access the Internet in Auto

or Manual mode. The default mode is Manual.

Mode Operation

Auto Your device is automatically

connected to the Internet.

To set Auto mode:

1. Log in to the Device Manager

Website.

2. Select Settings > Mobile

Network > Network

Settings > Connection

Mode > Auto, and then click

Save Changes.

Manual 1. Log in to the Device Manager

Website.

2. Select Home, and click

Connect to connect to the

Internet.

NOTE:

To change the current connection setting, please

disconnect from the Internet first.

Getting More Help

You can get help by:

Sending an email to [email protected]

Visiting www.ztedevices.com

LEGAL INFORMATION

No part of this publication may be excerpted,

reproduced, translated or utilized in any form or by

any means, electronic or mechanical, including

photocopying and microfilm, without the prior written

permission of ZTE Corporation.

The manual is published by ZTE Corporation. We

reserve the right to make modifications on print errors

or update specifications without prior notice.

Version No.: R1.0

Warning and Notice

Using Your Modem

If inadequately shielded, some electronic devices

may be affected by the electromagnetic

interference caused by the modem, such as the

electronic system of vehicles. Consult the

manufacturers of such devices before using the

modem if necessary.

Operating the modem may interfere with medical

instruments such as hearing aids and pacemakers.

Always keep the modem more than 20

centimeters away from such medical instruments

when your modem is turned on. Turn the modem

off if necessary. Consult a physician or the

manufacturers of medical instruments before

using the modem if necessary.

Be aware of the usage limitation when using the

modem at places such as oil warehouses or

chemical factories, where there are explosive

gases or explosive products being processed.

Turn off the modem if necessary.

Do not use electronic transmission devices in

aircrafts, at petrol stations or in hospitals. Observe

and obey all warning signs, and turn off the

modem in these conditions.

Do not touch the inner antenna area unless it is
