ZyXEL Communications PLA-400 Manuale utente

200 Mbps

HomePlug AV PowerLine

Ethernet Adapter

pla-400

Extends LAN Solutions through Existing Electrical Lines

The ZyXEL HomePlug AV PLA-400 is an extended access solution that allows your house

to be completely networked using your existing electrical power lines. With no need for

additional wiring, simply connect the ZyXEL HomePlug AV PLA-400 to an existing

electrical outlet, and it will transform your electrical power lines into a house-wide network

infrastructure. It’s the easiest way to extend the network connection from your

broadband router.

High Transmission Rate of up to 200 Mbps*

up to 200 Mbps*. The HomePlug AV solution allows users to surf the Internet, access

e-mail, and deliver large ﬁles easily and safely using high-speed PowerLine connection.

Home entertainment solutions such as Network Capable DVR systems or Set Top box

can now be networked using existing electrical power lines within your home instead of

using complicated wireless setups or messy wiring solutions.

Highly Secured 128-bit AES Security Protection

With 128-bit AES encryption, the PLA-400 provides secure Internet access and allows ﬁle

and peripheral sharing. Now you can surf the Internet from any room in your house

through the network over existing power lines without worry of security holes and hackers

to exploit.

Easy Installation , Simple Plug-and-Play

No new wire, no driver reguired and compatible with all OS. The ZyXEL PLA-400 is the

ideal solution for residential users who need LAN extension without laying new cables.

Since there are no drivers to install, there are no OS compatibility issues whatsoever!

Simply plug the ZyXEL PLA-400 into a electrical outlet and an Internet connection then

you’re ready to go on line! With the low proﬁle cable included with each PLA-400, there’s

never a fear of the desktop device occupying valuable power outlet space.

Up to 200 Mbps* Speeds over existing

electrical powerline

HomePlug AV Compatible

128-bit AES protection for secure data

transmissions

Simple, compact and stylish design

Perfect solution for High Bandwidth

applications such as:

Digital Audio and Video streaming

from a Networked DVR system to

your PC

Extending your high-speed Wi-Fi

connection

Sharing data between multiple

computers around your application

■

Benefits

Take Advantage of Your Power Lines

Back View

10/100 Ethernet port Power plug connect

to electrical outlet

Specifications

Network Capabilities HomePlug AV compliant.

Delivery up to 200* Mbps data rate.

Supports up to 16 (Tone Map) HomePlug AV devices communicating on a single network.

Up to 4 network groups can be simultaneously connected, together supports up to 64 PLA devices.

128-bit AES Encryption with Key ManagementSecurity

1x 10/100 Mbps Ethernet Port

1x 200 Mbps PowerLine Plug

Network Interface

PWR: Power – Light Located on Case-top

LINK: PowerLine Link/ACT Located on Case-top

ETHN: LINK/ACT Located on Case-top

LED Display

100~240VAC, 50~60Hz, 0.08 AmpPower Input

Dimensions: 112mm(W) x 106mm(D) x 28.5mm(H)Physical Speciﬁcations

Operating Temperature: 32˚F ~ 113˚F (0˚C ~ 45˚C)

Humidity: 10% ~ 90% Non-condensing

Environment Speciﬁcations

FCC, CE, UL, CSA, HomePlug AV compliantCertiﬁcation

**Typical applications are estimated for a 5,000 square foot homeCoverage

ZyXEL 2-year Limited WarrantyWarranty

PLA-400 HomePlug AV PowerLine and Ethernet Adapter

Power Cord

Support CD with User Guide

Quick Start Guide

Ethernet Cable

Package Contents

264856 - 08192005

For more product information, visit us on the web www.US.ZyXEL.com

Tel: +1-714-632-0882 •

Fax: +1-714-632-0858

•

Email: [email protected]

•

http://www.us.zyxel.com

ZyXEL North America

other brands, product names, or trademarks mentioned are the property of their respective owners. All specifications are subject to change without

notice.

* Theoretical maximum data rate is 200 Mbps on physical layer.. Actual speed may vary depending on interference with household power

circuits and quality of electrical installation.

** Data rates are dependant on power circuit designs and overall physical condition of powerlines therefore performance may vary

VoIP

PLA-400

Network

Printer

PLA-400

Online Gaming

PLA-400

IP Set Top Box/IP TV/ Media Player

PLA-400

HDTV

all devices connecting to PLA-400 must be Ethernet ready

Internet

Broadband Modem

Broadband Router

PLA-400 Poweroutlet

42:00

power lines
