ZyXEL Communications MAX-706 Manuale utente
www.zyxel.com
MAX-706
WiMAX MIMO 2.5GHz Express Card
User’s Guide
Version 1.00
7/2008
Edition 1
About This User's Guide
MAX-706 User’s Guide 3
About This User's Guide
Congratulations on your purchase of the ZyXEL MAX-706 WiMAX MIMO 2.5 GHz Express
Card. Your MAX-706 allows you to access WiMAX wireless networks.
Your MAX-706 is easy to install and configure.
Intended Audience
This manual is designed to guide you through the configuration of your MAX-706 for its
various applications.
Related Documentation
• Quick Start Guide
The Quick Start Guide is designed to help you get up and running right away. It contains
information on setting up your network and configuring for Internet access.
• Supporting Disc
Refer to the included CD for support documents.
• ZyXEL Web Site
Please refer to www.zyxel.com for additional support documentation and product
certifications.
User’s Guide Feedback
Help us help you. Send all User’s Guide-related comments, questions or suggestions for
improvement to the following address, or use e-mail instead. Thank you!
The Technical Writing Team,
ZyXEL Communications Corp.,
6 Innovation Road II,
Science-Based Industrial Park,
Hsinchu, 300, Taiwan.
E-mail: [email protected]
Document Conventions
MAX-706 User’s Guide
4
Document Conventions
Warnings and Notes
These are how warnings and notes are shown in this User’s Guide.
1Warnings tell you about things that could harm you or your MAX-706.
"Notes tell you other important information (for example, other things you may
need to configure or helpful tips) or recommendations.
Syntax Conventions
• The ZyXEL MAX-706 may be referred to as the “MAX-706”, the “device”, the “system”
or the “product” in this User’s Guide.
• Product labels, screen names, field labels and field choices are all in bold font.
• A key stroke is denoted by square brackets and uppercase text, for example, [ENTER]
means the “enter” or “return” key on your keyboard.
• “Enter” means for you to type one or more characters and then press the [ENTER] key.
“Select” or “choose” means for you to use one of the predefined choices.
• A right angle bracket ( > ) within a screen name denotes a mouse click. For example,
Maintenance > Log > Log Setting means you first click Maintenance in the navigation
panel, then the Log sub menu and finally the Log Setting tab to get to that screen.
• Units of measurement may denote the “metric” value or the “scientific” value. For
example, “k” for kilo may denote “1000” or “1024”, “M” for mega may denote “1000000”
or “1048576” and so on.
• “e.g.,” is a shorthand for “for instance”, and “i.e.,” means “that is” or “in other words”.
Icons Used in Figures
Figures in this User’s Guide may use the following generic icons. The MAX-706 icon is not an
exact representation of your MAX-706.
Document Conventions
MAX-706 User’s Guide 5
Table 1 Common Icons
MAX-706 Computer Notebook
Wireless Signal Wireless Base Station Internet Cloud
Router Server Firewall
Safety Warnings
MAX-706 User’s Guide
6
Safety Warnings
1For your safety, be sure to read and follow all warning notices and instructions.
For your safety, be sure to read and follow all warning notices and instructions.
• Do NOT use this product near water, for example, in a wet basement or near a swimming
pool.
• Do NOT expose your device to dampness, dust or corrosive liquids.
• Do NOT store things on the device.
• Do NOT install, use, or service this device during a thunderstorm. There is a remote risk
of electric shock from lightning.
• Connect ONLY suitable accessories to the device.
• ONLY qualified service personnel should service or disassemble this device.
• Make sure to connect the cables to the correct ports.
• Place connecting cables carefully so that no one will step on them or stumble over them.
• Always disconnect all cables from this device before servicing or disassembling.
• Use ONLY an appropriate power adaptor or cord for your device.
• Connect the power adaptor or cord to the right supply voltage (for example, 110V AC in
North America or 230V AC in Europe).
• Do NOT allow anything to rest on the power adaptor or cord and do NOT place the
product where anyone can walk on the power adaptor or cord.
• Do NOT use the device if the power adaptor or cord is damaged as it might cause
electrocution.
• If the power adaptor or cord is damaged, remove it from the power outlet.
• Do NOT attempt to repair the power adaptor or cord. Contact your local vendor to order a
new one.
• Do not use the device outside, and make sure all the connections are indoors. There is a
remote risk of electric shock from lightning.
• Do NOT obstruct the device ventilation slots, as insufficient airflow may harm your
device.
• Use only No. 26 AWG (American Wire Gauge) or larger telecommunication line cord.
• Antenna Warning! This device meets ETSI and FCC certification requirements when
using the included antenna(s). Only use the included antenna(s).
Safety Warnings
MAX-706 User’s Guide 7
Your product is marked with this symbol, which is known as the WEEE mark. WEEE stands
for Waste Electronics and Electrical Equipment. It means that used electrical and electronic
products should not be mixed with general waste. Used electrical and electronic equipment
should be treated separately.
Safety Warnings
MAX-706 User’s Guide
8
Contents Overview
MAX-706 User’s Guide 9
Contents Overview
Introduction and Tutorials .....................................................................................................17
Getting Started ........................................................................................................................... 19
WiMAX Utility ..........................................................................................................................21
Tutorial ....................................................................................................................................... 23
Troubleshooting and Specifications ....................................................................................25
WiMAX Utility ............................................................................................................................. 27
Appendices and Index ...........................................................................................................37
Troubleshooting ......................................................................................................................... 39
Product Specifications ............................................................................................................... 43
Contents Overview
MAX-706 User’s Guide
10
