ZyXEL Communications IES-708 Manuale utente

Benefits

8-port G.SHDSL

IP DSLAM with AC/DC

Power Input

IES-708-22A

IES-708-22

Ultra Symmetric High Bandwidth with

Port Bonding

Ŝ1U-height Multi-service IP DSLAM,

each Port Operates at Up to

5.69 Mbps

Ŝ16 and 32 Trellis Coded Pulse

Amplitude Modulation

ŜAC (100 V ~ 240 V) or DC (-36 V ~

-72 V)(*) Power Input

ŜSTU-C or STU-R Mode with

Different FW Download

ŜATM-based Multi-paired Bonding

Support (G.998.1); Bonding of Up

to 8 ports at 45.6 Mbps is

Supported

End-to-end Solution for Symmetric Bandwidth Services

With different firmware uploaded, the IES-708-22A/IES-708-22 can act as either a STU-C or a STU-R.The per-port

line rate can be configured as 2.3 Mbps, 4.096 Mbps or 5.69 Mbps.When configured as a STU-C, the IES-708-

22A/IES-708-22 can work with the P-791/P-792 to provide 2-wire G.SHDSL connections, work with the P-793 to

provide 4-wire G.SHDSL connections,or work with another IES-708-22A/IES-708-22 (in STU-R mode) to provide

16-wire G.SHDSL connections. If configured as a STU-R, the IES-708-22A/IES-708-22 can work with various SLC

line cards in the IES DSLAM portfolio.

Robust Ultra-high Bandwidth for Business Applications

With the ATM-based multi-paired bonding feature, the IES-708-22A/IES-708-22 supports up to 8 bonded

groups and 8 member links in each group.All upper-layer traffics of a bonded group will be segmented and

transmitted over the member links. If one of the member links fails, the conveyed traffic will be moved to other

working links; when the failed link recovers,it will seamlessly return to the bonded group and share the

transmission of the upper-layer traffic.

Within a bonded group,the underlying bit rates of the individual ports can be freely and independently

changed by their respective PHY layer.The port-bonding feature not only provides higher symmetric

bandwidth to subscribers, but also offers more reliable bandwidth pipes for business applications.

Different TCPAM for Lower Power Spectrum Density

The IES-708-22A/IES-708-22 supports 16-layer and 32-layer TCPAM modulations. Operators can select one of

these in“auto”or“force”mode; the former determines the modulation by negotiating with the peer device,

while the latter forces the use of configured modulation. In order to avoid the cross-line noise, many Telco

operators restrict the power spectrum density for G.SHDSL service but allow the transmission rate of the links

to increase.With the dual-modulation feature, the goal will be much easier to realize.

Sophisticated Features for Triple-Play Services

The IES-708-22A/IES-708-22 comes with complete ATM and Ethernet QoS, as well as various IP QoS features

(Packet classification/Rate Limitation/Queue Scheduling).The seamless QoS-mapping not only allows

consistent and appropriate traffic treatment of packets, but also enables fulfillment of triple-play services.

The number of the supported multicast groups is 256, while each group can have 9 members.At least 30

multicast IGMP join/leave requests can be processed in one second and the maximum channel processing time

is less than 250 ms. For security, anti MAC address spoofing, broadcast storm prevention, MAC count limiting

and packet filtering features are provided.Triple-play services like high-speed Internet access,VoIP, Near VOD,

Broadcast TV and TV on Demand can be easily provided as well.

SpecificationsSpecifications

Software Specifications

• Delivery of Ethernet in the first mile using

legacy LAN technologies

• Support expandable configuration with device

stacking

• SNMP v1,v2 manageable

• Web management

• FTP/TFTP for firmware upload

• Console port configuration (RS-232)

• Telnet configuration and monitoring

• Spanning tree algorithm (802.1D) for loop free

connection

• 802.1Q VLAN aware bridging

- IGMP snooping supports multicast traffic

- QoS support with 802.1p

- DHCP relay agent option 82

- Port isolation

- 256 static VLAN entries (full-range VLAN ID

1 ~ 4094)

- 4 K MAC address entries

• Packet prioritizing per 802.1p (QoS)

- Static configuration—default priority setting

- 4 priority queues per PVC (up to 4 PVCs)

• Multicast

- IPv4 multicast forwarding (through L2 MAC)

- Static multicast membership configuration

- IGMP v1, v2 snooping & IGMP proxy mode

support

- Shared VLAN multicast

- 256 multicast groups and each group can

contain 13 members

- IGMP filtering profile

- IGMP count limiting

- MVLAN

- DSL port multicast bandwidth control

• Management support

- CLI-based management from console/

Ethernet port

- SNMP v1, v2 and telnet through Inband

Ethernet interface and NetAtlas Access,

PC-based EMS management support

- Web-based management through Inband

Ethernet interface

- Secured Host: configure remote host IP

addresses for management

- UNIX syslog

- F/W upgrade,configuration backup & restore

via FTP and Web

- Text-based configuration file support

- Port configuration

- Alarm/Status Surveillance

- Performance monitoring

- Security and Memory Backup

- Self diagnostics

- Remote reset

- EMS Management support (*)

• MIB

- SNMP MIB II (RFC1213)

- SNMP v1

- SNMP v2

- RFC1493 Bridge MIB

- RFC1643 Ethernet MIB

- RFC1757 Four group of RMON

- RFC2674

- RFC4319 (formerly RFC3276) SHDSL Line MIB

Hardware Specifications

• Line coding: 16/32TC-PAM

• Transmit power: up to 13.5 dBm

• SHDSL payload format: ATM

• Rate Adaptation Mode: fixed, line probing

• Annex A and annex B PSD mask

• SHDSL line profile

• SHDSL alarm profile

• Power backoff

• ATM-based multi-paired bonding

• Standard Compliance

- ETSI SDSL (ETSI TS 101 524 V 1.2.1)

- ITU G.shdsl (ITU-T G.991.2 (2001))

- ITU G.shdls.bis (ITU-T G.991.2 (2004))

- ITU-T G.998.1

Physical Specifications

• 19”1U rack mountable

• Dimensions:270 (W) x 350 (D) x 44.45 (H) mm

• Weight: 4.8 Kg

• One Telco 50 connectors for 8-port G.SHDSL.bis

• One mini RJ11 console port for local

management

• Two 100Base-TX for uplink/cascading

• Status LEDs- System Status, Ethernet Link Status,

Ethernet Active Status, G.SHDSL.bis ports status,

Alarm

Power Supply (AC/DC)

IES-708-22A

• AC Power: 100 ~ 240 VAC, 50 ~ 60 Hz

IES-708-22

• DC Power: -36 ~ -72 V DC (*)

Power Consumption

• 12.84 Watt (AC power)

Environmental Specifications

• Operating Temperature: 0°C ~ 50°C

• Storage Temperature: -20°C ~ 70°C

• Operating Humidity: 10% ~ 90%

(non-condensing)

• Storage Humidity: 10% ~ 95%

(non-condensing)

Certification

• RoHS

• Safety

- UL 60950-1

- CSA 60950-1

- EN60950-1

- IEC 60950-1

• EMC

- FCC Part 15B Class A

- EN55022 Class A

- EN55024 Class A

- ETSI 300 386

• Reliability

- ETSI 300 019

• Telecom

- ITU-T K20

(*) Firmware upgradeable for future enhancement

IES MSAN Family Matrix

System Overview

Dimensions W x D x H (mm)

Splitter

Rack Mountable

Total Slot No.

Max DSL Line Card Slot

Max DSL Port No.

Management & Switching

Card Redundancy

Power Input

Power Redundancy

Hot Swappable

Interfaces

Uplin

Subtending

ADSL2/2+ Line Card

G.SHDSL.bis Line Card

VDSL2 Line Card

VoIP Line Card

ADSL2/2+ Features

Annex M

SRA

INP (Min=2)

SELT

DELT

ADSL2+ Bonding

G.SHDSL Features

G.SHDSL Bonding

QoS Function

802.1p Priority Queuing

802.1q Tag-based VLAN

SPQ/WRR

ATM QoS to 802.1p Priority Mapping

IP Bridge

Security Function

IEEE 802.1x

Multiple PVC per Port

Q in Q (VLAN Stacking)

DHCP Snooping

DHCP Relay Option 82

MAC/Packet Filtering

MAC Count Filtering

Packet Filtering

IEEE 802.3ad Link Aggregation

VoIP Function

Signaling Protocol

Voice Codec: G.711 a/µlaw, G.726,

G.729 a/b & G.723.1

Metallic Link Test

DTMF

Fax/Modem (T.38)

Call Waiting/Hold/Transfer

Dial Tone,Ringing Tone, Busy Tone

Multicast Function

Snooping

IGMP Proxy

v1/v2/v3 Multicast Group

VLAN Static Multicast Group

Multicast VLAN

Network Management

SNMP v1, v2

SNMP v3

Web Management

CLI Management

EMS Management

x 44.4

uilt in

Standalon

(

ADSL2+

)

r D

2FE

(

Future

)

ueu

256

VLAN

es (no v3

)

es (no v3

)

etAtlas Acces

x 44.4

Standalon

(

G.SHDSL

)

N/A

r D

N/A

2FE

N/A

ueu

256

VLA

N/A

Yes (no v3

)

Yes (no v3

)

Yes

etAtlas Acces

(

Future

)

IES-1000

320

x 44.4

Built i

r D

2FE

(

Future

)

ueu

VLA

NetAtlas Access

IES-1248-5

51 x

Built i

1.5

tandalon

N/A

r D

2 100

1000Base-

2 M

GBI

ueue

24 VLAN

etAtlas Acces

IES-1248-51

51 x

Built i

1.5

tandalon

N/A

r D

100

1000Base-

GBI

Yes

(

Future

)

ueu

24 VLAN

H.248

Yes

etAtlas Acces

IES-500

289

eparate

6.5U

ueue

K VLAN

, WR

H.24

NetAtlas Access

IES-6000

1 x 54

Separated

12.5

786

115

2 x 1

G +

x GE

ueu

4 K VLA

, WRR

H.248

etAtlas Acces

IES-500

x 15

eparated

192

ueu

4 K VLA

, WRR

H.248

Yes

etAtlas Acces

IES-708-22A

IES-708-22

IES-612-51A

IES-612-51

For more product information, visit us on the web www.ZyXEL.com

65-100-070801B 10/07

product names, or trademarks mentioned are the property of their respective owners. All specifications are subject to change without notice.

Questo manuale è adatto per i seguenti modelli

Altri manuali ZyXEL Communications Hardware di rete

ZyXEL Communications

ZyXEL Communications NSA-2400 Manuale utente

ZyXEL Communications

ZyXEL Communications Internet Security Gateway ZyWALL 100 Manuale utente

ZyXEL Communications

ZyXEL Communications ZyAir G-100 Manuale utente

ZyXEL Communications

ZyXEL Communications VMG4005-B50B Manuale utente

ZyXEL Communications

ZyXEL Communications NSA-220 Plus Manuale utente

ZyXEL Communications

ZyXEL Communications NSA-220 Plus Manuale

ZyXEL Communications

ZyXEL Communications IES-1248-51V Manuale

ZyXEL Communications

ZyXEL Communications Centralized Network Management Vantage CNM Manuale utente

ZyXEL Communications

ZyXEL Communications NSA-220 Plus Manuale utente

ZyXEL Communications

ZyXEL Communications 2-Slot 10GBase-CX4 10Gigabit Module EM-412 Manuale utente

ZyXEL Communications

ZyXEL Communications ZYWALL OTPV2 - SUPPORT NOTE V1 Manuale

ZyXEL Communications

ZyXEL Communications NSA-2400 Guida di riferimento

ZyXEL Communications

ZyXEL Communications NSA-220 Series Manuale utente

ZyXEL Communications

ZyXEL Communications FTU2000 Manuale utente

ZyXEL Communications

ZyXEL Communications Prestige 1600 Manuale utente

ZyXEL Communications

ZyXEL Communications ZYAIR Manuale utente

ZyXEL Communications

ZyXEL Communications POE-12 Guida di riferimento

ZyXEL Communications

ZyXEL Communications ZYAIR EXT-109 Manuale utente

ZyXEL Communications

ZyXEL Communications ZYAIR G-110 Manuale utente

ZyXEL Communications

ZyXEL Communications PK5000Z Manuale utente

ZyXEL Communications

ZyXEL Communications NSA-220 Plus Manuale utente

ZyXEL Communications

ZyXEL Communications Prestige 2602R Series Manuale utente

ZyXEL Communications

ZyXEL Communications POE-12 Manuale utente

ZyXEL Communications

ZyXEL Communications IES-6000 Series Manuale utente

Manuali Hardware di rete popolari di altre marche

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manuale utente

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manuale utente

Yudor

Yudor YDS-16 Manuale utente

D-Link

D-Link ShareCenter DNS-320L Manuale utente

Samsung

Samsung ES1642dc Istruzioni per l’uso

Honeywell Home

Honeywell Home LTEM-PV Istruzioni per il montaggio

evertz

evertz 7700 Series Manuale utente

D-Link

D-Link ShareCenter DNS-343 Manuale utente

Asante

Asante AsanteBridge 1012 Manuale utente

FireBrick

FireBrick FB2700 Manuale utente

Audiovox Electronics

Audiovox Electronics ARWH2T Manuale utente

ADC

ADC DSX-1 Manuale

NetComm

NetComm NF2 Manuale utente

Alcatel-Lucent

Alcatel-Lucent 5620 Manuale utente

Dell EMC

Dell EMC XC6420 Series Manuale utente

Lanner

Lanner NCA-1020A Manuale utente

Allied Telesis

Allied Telesis AT-TN121-A Manuale utente

Arista

Arista CCA-ETM-Q12 Manuale utente
