ZyXEL Communications NBG4604 Manuale utente

Wireless Network Guide; Zyxel NBG4604 routers Last amended: 09/10/2014

Wireless Networking Guide

Getting the best from your wireless

network with the Zyxel NBG4604 router

234

LAN4POWER LAN3 LAN2 LAN1 WAN RESET WPS

seethelight.co.uk 02921 678 544/[email protected]

Wireless Network Guide; Zyxel NBG4604 routers Last amended: 09/10/2014

1. Connecting to a wireless network 2

2. Troubleshooting a wireless connection 3

3. Other things to consider when connecting wirelessly 4

4. Changing the wireless router’s channel/frequency 5

5. Changing the Encryption Type 6

6. Changing the Wireless Network Name (SSID) 6

7. Changing the Encryption Key (Password) 7

8. Removing wireless networks 7

8.1 Windows XP 7

8.2 Windows Vista 7

8.3 Windows 7 and 8 7

Contents

You will ﬁnd a sticker attached to the underside of your router. It will contain the following information:

ˉYour SSID: The name of your wireless network associated with your router

ˉWPA2 PSK: The password you will need to enter on your PC’s wireless client to gain access to this network

You will ﬁnd more instructions on how to set up a wireless connection in our Internet User Guide

1. Connecting to a Wireless Network

FYI:

SSID: Or Service Set Identiﬁer, is used to identify wireless networks. By displaying

a list of SSIDs in your range you can select one to connect to.

WPA2: Security protocols used to secure wireless computer networks.

Wireless Network Guide; Zyxel NBG4604 routers Last amended: 09/10/2014

Wireless networking is a great way of accessing the internet. However, due to the nature of wireless

networking and environmental inﬂuences - for example interference from other equipment or thickness of

internal walls - we cannot guarantee that wireless will work in every location.

Like radio and television waves, wireless is subject to interference from electrical sources. If you have low

signal strength, or you keep losing connection, it could be because some objects are interfering with your

router and causing ‘noise’. Your wireless signal will be the strongest when it is clear of any obstacles and is in

a clear space. Try these tips to get the best out of your wireless:

2. Troubleshooting a wireless connection

LAN4POWER LAN3 LAN2 LAN1 WA N RESET WPS

Power on and o your PC/laptop

and router to see if this helps.

LAN4POWER LAN3 LAN2 LAN1 WAN RESET WPS

Do not place your router in an

enclosed space, such as a cupboard as

this can limit the signal. Your router

needs space and should be in your

line of sight.

LAN4POWER LAN3 LAN2 LAN1 WAN RESET WPS

Move your router to a common area,

such as a living room. Make sure your

router isn’t crowded and is in a central

location.

LAN4POWER LAN3 LAN2 LAN1 WAN RESET WPS

Ensure your router is in an upright

position and is NOT on the ﬂoor

LAN4POWER LAN3 LAN2 LAN1 WAN RESET WPS

Do not place your router next to

metallic objects, microwaves, cordless

phones or RF transmission devices

as these send out radio signals which

can interfere with your router,

Thick walls can reduce the range of

your wireless connection. Place the

router away from walls

Bluetooth equipped devices like

mobile phones send out radio signals.

which can interfere with your router.

Try turning these o one at a time to

see if it make a dierence.

Keep your router away from reﬂec-

tive or shiny surfaces such as ﬁsh

tanks, mirrors, windows and ﬁling

cabinets, as the signal can bounce of

these objects.

LAN4POWER LAN3 LAN2 LAN1 WAN RESET WPS

A wired connection is always going

to be faster than wireless. For faster

speeds, try connecting your PC and

router with an ethernet cable and

leave Wi-Fi for your other devices.

Back to contents page

Wireless Network Guide; Zyxel NBG4604 routers Last amended: 09/10/2014

• Most wireless routers will provide a range of approximately 100 meters. If you live in a larger property and

need greater coverage then you may need to add an additional wireless access point. If you are unsure on

how to do this we recommend you contact a local computer technician to assist.

• Your wireless performance could be slowing down due to interference from other wireless networks

in your area. Your router will automatically look for the channel with the least interference or “noise”,

however from time to time, other devices in your area could overlap onto the channel your router is

broadcasting on and will compete for the airwaves, causing the Wi-Fi to slow down. You can try and

overcome this by changing the channel/frequency that your router will communicate on. We have

provided instructions in section 4. Changing the wireless channel on how to do this.

• Try disabling your ﬁrewall software and then try to connect again. If this works then contact your ﬁrewall

supplier for more help

• Remove any old wireless networks as your router may be trying to connect to these instead of the new

one. See section 8. Removing wireless networks

• Change the Wireless Network Name (SSID) of the router and then try connecting to this newly named

network. If you are using a router not supplied by seethelight then refer to the manufacturer’s

instructions.

• Check your computer for viruses by running an anti-virus software. You can get a free trial download of

AVG anti-virus software at www.seethelight.co.uk

• And remember...wireless Encryption Keys are case sensitive

• Check the lights on your router to make sure there are no faults here. More about your routers’ lights can

be found in the internet user guide, hosted on our website at www.seethelight.co.uk

If none of the above solutions worked, we recommend connecting your PC to the router via an Ethernet

cable and check for online solutions, or getting a computer technician to look at the problem.

3. Other things to consider when connecting wirelessly

Back to contents page

Wireless Network Guide; Zyxel NBG4604 routers Last amended: 09/10/2014

4. Changing the wireless router’s channel/frequency

Your wireless performance could be slowing down due to interference from other wireless networks in your

area.

From time to time, other devices in your area could overlap onto the channel your router is broadcasting

on and will compete for the airwaves, causing interference, or “noise” which will in turn cause the Wi-Fi to

slow down. You can try and overcome this by changing the channel/frequency that your router will com-

municate on.

Your router will automatically look for the channel with the least interference or “noise”. If your laptop/PC

is unable to “see” your Wireless Network Names (SSID), you may need to login to the router and change

the channel manually.

To change the wireless router’s channel/frequency:

1. Connect your router to your computer or laptop via an Ethernet Cable

2. Launch the wireless router’s administration webpage by typing the address http://192.168.1.254 into

your web browser. When prompted, enter the username admin and the password quick

3. Click Network on the left hand side of the screen and then click Wireless LAN on the left hand side of

the screen

4. If it is ticked already, un-tick Auto Channel Selection

5. Select a preferred value in the Channel Selection dropdown menu and apply the settings

6. Wait for conﬁrmation that settings have been applied and then power your router o an on again

7. Wait 1 minute before scanning for the Wireless Network on your computer or laptop

Back to contents page

Wireless Network Guide; Zyxel NBG4604 routers Last amended: 09/10/2014

There are a number of options you can select:

No security

This is not recommended by seethelight as this will allow anyone with a wireless device to connect to

your router and use your internet connection and possibly access devices and information in your home

network. This option would generally be used for fault ﬁnding & turning it to this mode is at your own risk.

WEP

This is an older version of security and although it is secure, it is the weakest of the options. This works

best with older router models.

WPA

This option is more secure than WEP and the password can be letters and numbers.

WPA2

This is the latest security standard and is the recommended security type. The password can be letters

and numbers.

To change the Encryption Type:

5. Changing the Encryption Type

1. Connect your router to your computer or laptop using an Ethernet Cable

2. Launch the wireless router’s administration webpage by typing the address http://192.168.1.254 into

your web browser. When prompted, enter the username admin and the password quick

3. Click Network on the Left side of the screen and then click Wireless LAN on the left of the screen

4. Select a new Security Mode. Selecting WEP option may require a pass number to be entered. Click

Apply

When the wireless router restarts, it will operate the new Encryption Type. You may need to delete the

wireless network from your preferred networks list, and then reconnect using the new password.

6. Changing the Wireless Network Name

The wireless network name (SSID) is the name your router shows, enabling you to see your own network

to connect. Changing the wireless name can sometimes correct or ﬁx errors with wireless networks.

1. Connect your router to your computer or laptop using an Ethernet Cable

2. Launch the wireless router’s administration webpage by typing the address http://192.168.1.254 into

your web browser. When prompted, enter the username admin and the password quick

3. Click Network on the left side of the screen and then click Wireless LAN on the left of the screen

4. Enter your desired Wireless Network Name (SSID) in the Name (SSID)1: Box then click Apply

When the wireless router restarts, it will operate the new Wireless Network Name (SSID). You may need

to delete the wireless network from your preferred networks list, and then reconnect using the new

password.

Back to contents page

Wireless Network Guide; Zyxel NBG4604 routers Last amended: 09/10/2014

We recommend you regularly change the Encryption key/password to help keep your wireless network

secure.

Note: The Length of the password you can use depends on the Encryption Type you have selected.

WEP ASCII : 64 bit = 5 ASCII characters

WEP ASCII : 128 Bit 13 ASCII characters

WEP Hex : Hex 64 bit = 10 hexadecimal characters “0-9 , A-F”

WEP Hex : Hex 128 bit = 26 hexadecimal characters “0-9 , A-F”

WPA-PSK & WPA2-PSK encryption recommended characters is around 8 or above “0-1 - A-Z” ,

Make it secure but easy for you to remember.

8.1 Windows XP

1. Open network connections and right click Wireless Network Connections, then click properties.

2. Under preferred networks, click the wireless network you want to remove and select “Remove”

8.2 Windows Vista

1. Click “Start”, right click “Network” and then select “Properties”

2. Find the task list for the “Network and Sharing Centre” dialogue box and click “Manage Wireless

Networks”.

3. Select the old connection you wish to remove from the list and select “Remove”

8.3 Windows 7 and 8

1. Open your Control Panel and select “Network and Sharing Centre” and then click on “Manage

Wireless Networks”

2. Select the old connection you wish to remove from the list and select “Remove”

7. Changing the Encryption Key (Password)

8. Removing Wireless Networks

Back to contents page

1. Connect your router to your computer or laptop using an Ethernet Cable

2. Launch the wireless router’s administration webpage by typing the address http://192.168.1.254 into

your web browser. When prompted, enter the username admin and the password quick

3. Click Network on the left side of the screen and then click Wireless LAN on the left of the screen

4. Enter a New Wireless Password in the Pre-Shared Key box. For WEP enter the pass number in the KEY

1 Box and then click Apply

When the wireless router restarts, it will use the new Key (Password). You may need to delete the wireless

network from your preferred networks list, and then reconnect using the new password.

Altri manuali per NBG4604

Indice

Altri manuali ZyXEL Communications Router di rete

ZyXEL Communications

ZyXEL Communications P-2602R-D1A Manuale

ZyXEL Communications

ZyXEL Communications ES-2024A Manuale

ZyXEL Communications

ZyXEL Communications P-2802HW-I Manuale utente

ZyXEL Communications

ZyXEL Communications NBG4604 Manuale utente

ZyXEL Communications

ZyXEL Communications N4100 Manuale utente

ZyXEL Communications

ZyXEL Communications P-660RU-Tx v3 SERIES Manuale utente

ZyXEL Communications

ZyXEL Communications GS1920 Series Manuale di istruzioni

ZyXEL Communications

ZyXEL Communications PRESTIGE 100 - VERSION 2.20 Manuale utente

ZyXEL Communications

ZyXEL Communications FSG2200HNU Manuale utente

ZyXEL Communications

ZyXEL Communications MAX-306 Manuale utente

ZyXEL Communications

ZyXEL Communications Prestige 650HW Manuale utente

ZyXEL Communications

ZyXEL Communications XGS3700-24HP Manuale del proprietario

ZyXEL Communications

ZyXEL Communications VMG8924 Manuale utente

ZyXEL Communications

ZyXEL Communications ES-2024 Series Manuale utente

ZyXEL Communications

ZyXEL Communications VMG8924-B10A Manuale utente

ZyXEL Communications

ZyXEL Communications Prestige 623R-A1 Manuale utente

ZyXEL Communications

ZyXEL Communications Prestige 642 Manuale utente

ZyXEL Communications

ZyXEL Communications ZyXEL Dimension ES-2108-F Manuale utente

ZyXEL Communications

ZyXEL Communications P-335WT Manuale utente

ZyXEL Communications

ZyXEL Communications AMG1202-T10A Manuale utente

ZyXEL Communications

ZyXEL Communications Prestige 642M series Supplemento

ZyXEL Communications

ZyXEL Communications VMG8825-T50 Manuale utente

ZyXEL Communications

ZyXEL Communications NBG-420N Manuale utente

ZyXEL Communications

ZyXEL Communications NBG-417N Manuale utente

Manuali Router di rete popolari di altre marche

Allnet

Allnet ALL0333AU Manuale utente

HomeSeer

HomeSeer HT-SEL Manuale utente

Sercomm

Sercomm Genesis OC3505D Manuale utente

Billion

Billion BIPAC 5102 Series Manuale utente

TP-Link

TP-Link TD-8817 Manuale utente

Motorola

Motorola MR1900 Manuale utente

Digi

Digi IX14 Manuale utente

Cisco

Cisco NCS 540 Manuale

XAVi

XAVi X8821e Manuale utente

BEC

BEC 6200WZL Manuale utente

MikroTik

MikroTik hAP ac3 Series Manuale utente

Korenix

Korenix JetNet 5428G Series Manuale utente

NETGEAR

NETGEAR FS526T - Switch Manuale utente

Korenix

Korenix JetNet 5710G Series Manuale utente

Automated Logic

Automated Logic ZN551 Manuale del proprietario

Cisco

Cisco ASR 1000 Series Manuale dell'operatore

EnGenius

EnGenius ESR-9710 Manuale utente

Cisco

Cisco 805 Series Istruzioni operative e di sicurezza
