ZyXEL Communications ZYWALL 2 WG Manuale utente

Internet Security

Appliance

zywall 2wg

Internet Access through 3G

Networks (HSDPA, UMTS,

GPRS, EDGE, EVDO, CDMA)

Dual-band,Tri-mode Access

Point with Wireless

802.11a/b/g Network

Web-based Content Filtering

Services Available

Advanced ZyNOSTM ICSA

Certified SPI Firewall and IPSec

VPN Protection

Configurable 4-Port

LAN/DMZ/WLAN Zones

■

Benefits

3G and Wi-Fi Mobile Broadband Security

Appliance for Remote Office (RO)/SOHO

Internet access through 3G networks

(HSDPA, UMTS, GPRS, EDGE, EVDO, CDMA)

The ZyWALL 2WG provides users even more convenient Internet access with 3G service to

eliminate the limitation of the wired network and extends the last-mile service wirelessly.

Incorporated the wired environment, the solution can apply Backup WAN and Load Balancing

features to various applications while offering more mobility with Wi-Fi connectivity. The

ZyWALL 2WG supports both HSDPA/CDMA Cellular networks. For a list of speciﬁc cards

supported, please see speciﬁcations.

Virtual Private Network (VPN) Connection

The ZyWALL 2WG supports ZyNOS ICSA-certiﬁed IPSec VPN suitable for deployments from

remote sites to the central server. As data encryption over the Internet ensures secure

transmission between two sites without expensive leased lines, global interconnectivity can

be achieved at a minimal cost. Thanks to the Redundant IPSec VPN feature, the ZyWALL

2WG’s dialup client will keep the connection running even the primary VPN connection fails.

Secured Firewall Protection

The ICSA-certiﬁed ZyNOS Firewall on the ZyWALL 2WG provides robust, reliable ﬁrewall

security with high performance. Based on Stateful Packet inspection and Denial of Service

(DoS) technology, it provides the ﬁrst-line defense against hackers, network intruders and

other hazardous threats.

Secure Zone Technology

The ZyWALL 2WG offers the Secure Zone technology that SOHO users can simply deploy

access servers in a DMZ zone separated from the trusted local network (LAN). The DMZ

zone and WLAN zone have their own DHCP service, and all zones are securely segregated

by ﬁrewall rules.

Specifications

264856 - 08192005

For more product information, visit us on the web www.US.ZyXEL.com

Tel: +1-714-632-0882 • Fax: +1-714-632-0858 •Email: [email protected] • http://www.us.zyxel.com

ZyXEL North America

other brands, product names, or trademarks mentioned are the property of their respective owners. All specifications are subject to change without

notice.

System Speciﬁcations

Mode of Operation

• Routing Mode

• Transparent Mode (Bridge)

• NAT (Network Address Translation)

• Dial Backup

Virtual Private Network

• 5 simultaneous IPSec VPN Connections

• DES/3DES/AES encryption

• Manual Key, IKE and PKI (X.509)

• IPSec NAT Traversal

• Xauth User Authentication

• Redundant VPN connection (VPN HA)

Firewall Security

• Transparent Firewall (Bridge mode)

• Stateful Packet Inspection

• DoS and DDoS Protection

• Real-time Attack Alert and Logs

Content Filtering

• Java/AactiveX/Cookie/ Proxy Blocking

• URL and Key word Blocking

• Web Content Filtering

Network

• DHCP client/server/relay

• PPPoE

• PP

System Management

• Web GUI (HTTP, HTTPS)

• Command Line Interface (Console, Telnet, SSH)

• Vantage Centralized Network Management

Wireless

• IEEE 802.11a/b/g compliant

• MAC Filter

• 64/128-bits WEP encryption

• IEEE 802.1x (EAP-MD5/TLS/TTLS/PEAP)

• WPA/WPA-PSK/WPA2/WPA2-PSK

• Roaming

• Conﬁgurable output power

Hardware Speciﬁcations

• Status LED Indicator: PWR, LAN/DMZ 1 ~ 4,

WAN, AUX, WLAN, CARD

• Power adapter: 12 VDC

• Reset Button: Yes

• LAN/DMZ: 4-port switch, 10/100 Mbps Auto

MDI/MDIX

• WAN: 10/100 Mbps Auto MDI/MDIX

• Dial Backup: RS-232 on RJ-45 Null Modem Port

• Console: RS-232 on RJ-45 Port

Physical Speciﬁcations

• Dimensions: 220 (W) x 148 (D) x 30.5 (H) mm

• Weight: 517 g

Environmental Speciﬁcations

• Operating Temperature: 0C ~ 50C

• Operating Humidity: 20% ~ 95% (non-condensing)

• Storage Temperature: -30C ~ 60C

• Storage Humidity: 20% ~ 95% (non-condensing)

Certiﬁcation

• EMC: FCC Part 15 Class B, CE-EMC Class B,

C-Tick Class B, VCCI Class B

• Safety: CSA International, CE EN60950-1

(UL60950-1, CSA60950-1, EN60950-1, IEC60950-1)

• C-Tick

• VCCI

• Green Product and WEEE comply with

Supported Cards

EVDO

• Sierra Wireless 595 AirCard*

• Sprint AirCard 595*

• Verizon AirCard 595*

• Telus AirCard 595*

HSDPA

• Sierra Wireless 860 AirCard*

• Cingular/AT&T AirCard 860*

• Sierra Wireless 875 AirCard*

• Cingular/AT&T AirCard 875*

Application Diagram

Wi-Fi Security

- WEP/WPA/WPA2

- 802.1x EAP Auth.

3G Data Card Access

- Primary WAN

- Backup WAN

- Dual WAN (LB)

ZyWALL 2WG Internet

ZyWALL 70 UTM

3G Card

Remote Ofﬁce Central Ofﬁce/HQ

IPSec

Tunnel

IPSec

Tunnel

Internet

*We are neither afﬁliated any of the above brand name or trade marks nor doing promotion of their products. The above name or trademark belongs to the respective owner.
