ZyXEL Communications P-336M Manuale utente

Say Goodbye to Wireless Dead-spots and

Lag-filled Home Network

802.11g Wireless MIMO Router

p-336m

Benefits

MIMO and Smart Antenna Technology

The ZyXEL P-336M XtremeMIMO Broadband Router featuring 108Mbps Super

G Wireless and MIMO (Multiple Input Multiple Output) Smart Antenna

Technology provides the ultimate solution for speed and coverage.The P-336M

eliminates dead zones by using Smart Antenna technology. Backwards

compatible with any IEEE 802.11b/g Wi-Fi certified device.

Built-In StreamEngineTM Technology for QoS

The ZyXEL P-336M enables you to run multiple applications without

degrading the quality of your internet experience.With its built-in

StreamEngineTM technology, the ZyXEL P-336M automatically prioritizes

delay sensitive traffic and eliminates internet lag.

Enhanced Security with WPA2 and Firewall

To protect your wireless data transmissions,the P-336M provides Wi-Fi

Protected Access and WPA2 featuring AES standard.The P-336M has

Stateful Packet Inspection (SPI) firewall and VPN pass-through creating a

secure connection at any remote location.Policies can be defined on the

ZyXEL P-336M providing customized filters.

Easy Setup with Windows Connect Now

Users who have upgraded their Windows operating system to Microsoft

Windows XP Service Pack 2, the P-336M can now be setup even easier using

a USB flash drive and Microsoft Windows Connect Now (WCN). Connect

multiple users to the network without any necessary configuration utilities

or applications on each client.

router

ł

Maximized Wireless Coverage with MIMO Smart

Antenna Technology

ł

Secure connection with WPA and WPA2

ł

USB port to support Windows Connect Now

ł

Built-in Stream Engine technology for traffic shaping

ł

Stateful Packet Inspection (SPI) firewall

ł

VPN pass-through support

802.11g Wireless

MIMO Router

p-336m

65-100-336007G 01/06

System Standard

• IEEE 802.3 and 802.3u 10Based-T and 100Based-TX

• IEEE 802.11g compliance

Memory Size

• 4MB Flash, 8MB DRAM

Hardware Specifications

• Power: 5.0V DC 2.0A

• Ethernet RJ45 10/100Mbps

• Ethernet Port with MDI/MDIX

Physical Specifications

• Dimension: 190(W) x 150(D) x 33(H) mm

• Net Weight: 412 g

Environmental Specifications

• Temperature: 0°C ~40°C

• Humidity: 10% ~ 70%

• Storage Temperature: -20°C ~ 70°C

• Storage Humidity: 10% ~ 85%

System Requirement

• Broadband Internet service device

(DSL/Cable modem)

• For using Microsoft Windows Connect Now, USB

drive with 256KB minimum capacity and Microsoft

Windows XP with Service Pack2 (SP2) are required

Specifications

Application Diagram

MIMO

Multiple-Input-Multiple-Output.This is a

next generation Wireless LAN technology

capable of providing outstanding

performance and whole-house coverage

comparing to the traditional Wi-Fi devices.

-336

ess

802.11g Wirele

MIMO Router

DSL/Cable

Modem

M-102

802.11g Wireless

MIMO Cardbus Card

M-302

802.11g Wireless

MIMO PCI Adapter

Internet

For more product information, visit us on the web www.ZyXEL.com
