POS-420 Expander plus

All-in-One Point of Sales System

User Manual

Ver. Draft 1.0_2009/12/30

Before installing and operating the unit, please read this

user manual thoroughly and retain for reference.

How to Use This Manual

This manual contains information to set up and use the POS-420 Expander plus. In addition, instructions

are included for added hardware, upgrades, and optional items, as well as for software.

Chapter 1 An introduction to what you find in the box and an overview of product specifications,

appearance, and interface.

Chapter 2 Detailed installation information for the base unit and upgrades, including the HDD, main

memory, and Compact Flash.

Chapter 3 Mounting procedures for optional devices, such as MSR, Fingerprint, I-Button, IC Card, WiFi,

Bluetooth, RFID, rear mount VFD, pole-type 2nd display, and cash drawer.

Chapter 4 PI-91X main board diagrams, locations of jumpers, and connectors.

Chapter 5 I/O board diagrams, locations of jumpers, and connectors.

Chapter 6 Installation instructions for the Intel chip set driver, video driver, touch screen tools, audio,

LAN, RFID, Fingerprint, IC Card, system and OPOS drivers.

WARNING! Text set off in this manner indicates that failure to follow directions could result

in bodily harm or loss of life.

CAUTION: Text set off in this manner indicates that failure to follow directions could result

in damage to equipment or loss of information.

NOTE: Text set off in this manner provides important supplemental information.

Federal Communications Commission (FCC) Notice

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant

to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and the receiver.

•Connect the equipment to an outlet on a circuit different from that to which the receiver is

connected.

•Consult the dealer or an experienced radio/TV technician for help.

NOTE: Shielded interconnect cables and shielded AC power cables must be employed

with this equipment to insure compliance with pertinent RF emission limits

governing this device. Changes or modifications not expressly approved by the

system’s manufacturer could void the user’s authority to operate the equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause undesired

operation.

The information in this guide is subject to change without prior notice.

The manufacturer shall not be liable for technical or editorial errors or omissions contained herein, nor for

incidental or consequential damages resulting from the furnishing, performance, or use of this material.

This manual contains information protected by copyright. No part of this manual may be photocopied or

reproduced in any form without prior written consent from the manufacturer.

The software described in this guide is furnished under a license agreement or nondisclosure agreement.

The software may be used or copied only in accordance with the terms of the agreement.

Product names mentioned herein may be trademarks and/or registered trademarks of their respective

companies.

First Edition December 2009

Precautions

1. Please read these safety instructions carefully.

2. Keep this User Manual for later reference.

3. Disconnect this equipment from the AC outlet before cleaning. Do not use liquid or spray detergent

for cleaning. Use only a moistened sheet or cloth.

4. For pluggable equipment, the socket outlet should be installed near the equipment and should be

easily accessible.

5. Avoid humidity and moisture.

6. Install equipment on a stable surface.

7. Do not leave this equipment running in an enclosed or non-air-circulated environment, nor store in

temperatures above 60°C. Such conditions may damage the equipment.

8. Ventilation openings on the unit are for air circulation and protect the equipment from overheating.

DO NOT COVER THE OPENINGS.

9. Check the voltage of the power source before connecting the equipment to the power outlet.

10. Place the power cord so that it will not be stepped on. Do not place anything over the power cord.

The power cord must be rated for the product and for the voltage and current marked on the

product’s electrical ratings label. The voltage and current rating of the cord should be greater than

the voltage and current rating marked on the product.

11. All cautions and warnings on the equipment should be noted.

12. If the equipment is not used for a long time, disconnect the equipment from the power outlet to

avoid damage.

13. Never allow any liquid into ventilation openings. This could cause fire or electrical shock.

14. Never open the equipment. For safety reasons, qualified service personnel should only open the

equipment.

15. If one of the following situations may arise, get the equipment checked by qualified service

personnel:

a. The power cord or plug is damaged.

b. Liquid has penetrated the equipment.

c. The equipment has been exposed to moisture.

d. The equipment does not work well or you cannot get it work according to the user manual.

e. The equipment has been dropped and damaged.

f. The equipment has obvious signs of damage.

WARNING! Not intended for outdoor use.

CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with same

type, and discard used batteries according to manufacturer's instructions.

Contents

Chapter 1 Introduction ............................................................................................... 1

Features ............................................................................................................................................... 1

Specifications ........................................................................................................................................ 1

Package Contents.................................................................................................................................. 3

Base System ......................................................................................................................................... 4

Expandable Main Display ....................................................................................................................... 5

Convertible Pole-Type 2nd Display (optional) .......................................................................................... 6

Dimensions ........................................................................................................................................... 7

Connector Panel .................................................................................................................................... 8

Chapter 2 Standard Hardware and Upgrades.............................................................. 9

Precautions ........................................................................................................................................... 9

Adjusting LCD Panel Height and Angle .................................................................................................... 9

Removing and Opening System Box ..................................................................................................... 11

Clearing CMOS .................................................................................................................................... 12

Compact Flash Card Installation ........................................................................................................... 13

Additional Memory Installation ............................................................................................................. 14

Changing the CPU on the PI-915 Main Board ........................................................................................ 16

Removing and Replacing the SATA Hard Disk........................................................................................ 19

Chapter 3 Optional Components and Peripherals ..................................................... 21

Universal Power Supply (UPS) Installation............................................................................................. 21

MSR/Fingerprint/I-Button Module Installation........................................................................................ 24

Wireless Module Installation................................................................................................................. 26

Rear Mount VFD Installation (need install rear mount USB driver) .......................................................... 27

RFID Module Installation...................................................................................................................... 29

Cash Drawer Installation ...................................................................................................................... 30

Pole-Type 2nd Display Module Installation ............................................................................................ 31

Adding a 15cm Pole Tube Extension ..................................................................................................... 33

Chapter 4 PI-91X Main Board Configuration............................................................. 35

Jumper and Connector Locations.......................................................................................................... 35

Connectors Pin Assignments................................................................................................................. 36

Jumper Settings .................................................................................................................................. 38

Chapter 5 I/O Board Configuration........................................................................... 39

IOTR Board: Connector Pin Definitions and Jumper Settings .................................................................. 39

Top I/O Board: Connector Pin Definitions and Jumper Settings .............................................................. 45

Bottom I/O Board: Pin Definitions and Jumper Settings ......................................................................... 46

Chapter 6 Software Setup......................................................................................... 49

Driver Software List ............................................................................................................................. 49

Intel Chipset Driver Installation ............................................................................................................ 50

Intel Graphics Driver Installation .......................................................................................................... 51

ELO Touch Screen Driver Installation.................................................................................................... 52

Abon Touch Screen Driver Installation .................................................................................................. 54

Audio Driver Installation ...................................................................................................................... 56

Ethernet Driver Installation .................................................................................................................. 57

Wireless LAN Driver Installation (optional) ............................................................................................ 58

RFID Driver Installation (optional) ........................................................................................................ 60

MSR Driver Installation (optional) ......................................................................................................... 61

Fingerprint Reader Driver Installation (optional) .................................................................................... 62

IC Card Reader Driver Installation (optional) ......................................................................................... 64

System Driver Installation (Required for Cash Drawer and UPS) ............................................................. 65

OPOS CCO Driver Installation ............................................................................................................... 66

OPOS Driver Installation ...................................................................................................................... 68

Appendix A. Sample C++ Cash Drawer Code for Windows ..................................................................... 69

Appendix B. Sample Visual Basic Cash Drawer Code for Windows........................................................... 71

Chapter 1 Introduction

Features

•15inch TFT Touch Screen

•Fanless Operation with Intel®Celeron®M 1GHz, up to Intel® Pentium®M 1.8GHz with Fan

•Magnesium-aluminum alloy shell for greater reliability

•Detachable PC box for easy maintenance

•Cable-less docking reduces clutter

•Dual hinge stand for flexible display adjustment

•Convertible 2nd display options

•6 x COM, 8 x USB (1 x 5V, 1 x 12V), 1 x CF II

•Flexible options: UPS, MSR, I-Button, Fingerprint, RFID, WiFi and Bluetooth

•RoHS compliant

Specifications

POS-420 Expander plus 2 System Configuration

CPU (μPGA) Intel®Celeron M (up to 1.8GHz)

System Chipset Intel 910GME+ICH6M or Intel 915GME+ICH6M

System Memory Maximum supports 2 x 1GB SO-DIMM DDR2 SDRAM (up to 2GB)

Video Memory Supports Intel DVMT, shared system memory up to 224MB

Compact Flash Supports 1 x Compact Flash Card Type II

HDD 1 x internal 2.5 inch 80GB SATA hard disk drive (up to 160GB)

Power 1 x external 120W 19VDC power adapter (100~240VAC, 50~60Hz, 6.32A)

Current/Power Usage

Maximum 0.4A / 45W with 1.5G CPU, 1GB DDRII and 80G HDD

Standby 0.23A / 25W with 1.5G CPU, 1GB DDRII and 80G HDD

Typical 0.28A / 35W with 1.5G CPU, 1GB DDRII and 80G HDD

OS Support Windows®2000 / Windows®XP Pro Embedded / WEPOS®/ Windows®POS

Ready 2009 / Linux®

LCD Touch Panel

Resolution Size 15 inch TFT LCD / 1024 x 768

Brightness 250cd/m2(adjustable)

Touch Screen Type ELO or Abon 5-wire resistive

I/O Ports

USB Ports Supports 8 USB 2.0 ports for future expansion (3 x internal, 5 x external)

Front side x 1, Rear side x 4 (1 x 12V power USB, 1 x 5V power USB)

Serial Ports 4 x external: COM1, COM2, COM5 (D-SUB); COM6 (RJ-45)

2 x internal: COM3 for primary touch screen, COM4 for 2nd display

Parallel Port 1 x bi-directional parallel port (D-SUB25)

2nd Display Port 1 x display port for 2nd LCD/VFD display

Cash Drawer Port 1 x 12V or 24V RJ11 connector (maximum 2 drawers)

LAN Port 1 x Giga LAN (10/100/1000Mbps Base-T), RJ45 connector

Audio Port 1 x Line-out

Speaker 2 x Internal stereo 2W speakers

Mechanics and Environment

Construction Die-cast, magnesium-aluminum alloy housing

Dimensions 322(D) x 379(W) x 401(H) mm

Housing Color Silver/Black, Black

Net Gross Weight 9 Kg

Operating Temperature 0 °C ~ 40 °C

EMI/Safety CE, FCC, CB, RoHS

Lithium-ion Rechargeable Battery (optional)

Battery Type 4S – 1P 18650 cell Li-Ion pack with protection circuit

Height with tube 65±0.2 mm

Battery Dimensions Thickness with tube 18.1+0.3/-0 mm

Battery Weight 40±5g

Full Capacity 1100mAh

Typical Capacity 1050mAh

Charging Voltage 3.6±0.05V

Maximum Charge Voltage 14.6V

Maximum Current of

Continuous Discharge 4.5A (5~10 minutes)

Charging Time Approximately 2.5 hours

Operating Temperatures 0 °C ~ 45 °C (charge), -20 °C ~ 60 °C (discharging)

Package Contents

The following items come standard with the POS-420 Expander plus:

POS System

Power Adaptor

Utility and Main

Board Chipset

Driver CD

AC Power Cord

COM6 to RS-232C

Adaptor Cable

Options

•Magnetic Stripe Reader (MSR) Module: triple track*

•2-in-1 Module (Magnetic Stripe Reader + Fingerprint Reader) *

•2-in-1 Module (Magnetic Stripe Reader + I-Button Reader) *

•3-in-1 Module (Magnetic Stripe Reader + I-Button Reader + IC Card Reader) *

•Wireless Module: WiFi 802.11b/g or Bluetooth

•Radio Frequency Identification (RFID) Module: internal 13.56MHz

•Uninterruptible Power Supply (UPS): internal battery pack (5 minutes run time after power loss)

•VFD Customer Display: 9 cm height, 2 lines 20 characters each (rear mount type or pole type)

•2nd Customer Display: 8.9 inch or 15 inch, tempered glass LCD 15 cm set on a 15 cm tube pole

* Available in front or side swipe formats.

Indice

Altri manuali 4pos Terminale touch

4pos

4pos POS-400 Expander II Manuale utente

Manuali Terminale touch popolari di altre marche

Wincor Nixdorf

Wincor Nixdorf iPOS plus Advanced Manuale utente

Ingenico

Ingenico AXIUM EX4000 Manuale utente

Heisei Electronics

Heisei Electronics Q-POS 815 Manuale utente

Amano

Amano MTX-15 Manuale utente

FLOWBIRD

FLOWBIRD CWT Compact Touch Manuale utente

Demco

Demco SP7 Manuale utente

Lathem

Lathem PC600 Series Manuale utente

Partner

Partner MF-2352 Manuale utente

NCR

NCR RealPOS 7460-2 Manuale

Simrad

Simrad MS50 Istruzioni per il montaggio

Unitech

Unitech MR350 MKII Guida rapida

Jungheinrich

Jungheinrich WMT 210 Manuale utente

Motorola

Motorola MTP850 Manuale utente

YASKAWA

YASKAWA 62H-MDC0 Manuale utente

MVG industries

MVG industries NeptuLink Manuale utente

Price Industries Limited

Price Industries Limited FDC Manuale di istruzioni

Honeywell

Honeywell TemaKey Manuale utente

EBN

EBN BPC65-B-A16G Manuale utente
