Aaeon ACP-5210 Manuale utente

Multi-Touch Panel PC

ACP-5210

21.5” Fanless Multi-Touch

Panel PC

AMD G-Series T56N

Processor

2GB RAM Inside

ACP-5210 Manual 1st Ed

April 16, 2014

Multi-Touch Panel PC

ACP-5210

This document is copyrighted, 2014. All rights are reserved. The

original manufacturer reserves the right to make improvements to

the products described in this manual at any time without notice.

No part of this manual may be reproduced, copied, translated, or

transmitted in any form or by any means without the prior written

permission of the original manufacturer. Information provided in this

manual is intended to be accurate and reliable. However, the

original manufacturer assumes no responsibility for its use, nor for

any infringements upon the rights of third parties, which may result

from its use.

The material in this document is for product information only and is

subject to change without notice. While reasonable efforts have

been made in the preparation of this document to assure its

accuracy, AAEON, assumes no liabilities resulting from errors or

omissions in this document, or from the use of the information

contained herein.

AAEON reserves the right to make changes in the product design

without notice to its users.

Multi-Touch Panel PC

ACP-5210

Acknowledgments

AMD is trademark of Advanced Micro Devices, Inc.

Microsoft®Windows is a registered trademark of Microsoft®

Corporation.

RTL is a trademark of Realtek Semi-Conductor Co., Ltd.

C&T is a trademark of Chips and Technologies, Inc.

UMC is a trademark of United Microelectronics Corporation.

ITE is a trademark of Integrated Technology Express, Inc.

All other product names or trademarks are properties of their

respective owners.

Multi-Touch Panel PC

ACP-5210

iii

Packing List

Before you begin installing your Panel PC, please make sure

that the following items have been shipped:

ACP-5210 Infotainment Multi-Touch Panel PC

Power Adapter x 1

Product DVD

Contains User’s Manual (in PDF format), Drivers and

Utilities

If any of these items are missing or damaged, you should contact your

distributor or sales representative immediately.

Multi-Touch Panel PC

ACP-5210

Safety & Warranty

1. Read these safety instructions carefully.

2. Keep this user's manual for later reference.

3. Disconnect this equipment from anyAC outlet before cleaning. Do

not use liquid or spray detergents for cleaning. Use a damp cloth.

4. For pluggable equipment, the power outlet must be installed near

the equipment and must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a reliable surface during installation.

Dropping it or letting it fall could cause damage.

7. The openings on the enclosure are for air convection. Protect the

equipment from overheating. DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before

connecting the equipment to the power outlet.

9. Position the power cord so that people cannot step on it. Do not

place anything over the power cord.

10. All cautions and warnings on the equipment should be noted.

11. If the equipment is not used for a long time, disconnect it from the

power source to avoid damage by transient over-voltage.

12. Never pour any liquid into an opening. This could cause fire or

electrical shock.

13. Never open the equipment. For safety reasons, only qualified

service personnel should open the equipment.

Multi-Touch Panel PC

ACP-5210

14. If any of the following situations arises, get the equipment

checked by service personnel:

a. The power cord or plug is damaged.

b. Liquid has penetrated into the equipment.

c. The equipment has been exposed to moisture.

d. The equipment does not work well, or you cannot get it to

work according to the user’s manual.

e. The equipment has been dropped and damaged.

f. The equipment has obvious signs of breakage.

15. DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED

ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS

BELOW -20°C (-4°F) OR ABOVE 70°C (158°F). IT MAY

DAMAGE THE EQUIPMENT.

16. External equipment intended for connection to signal input/output

or other connectors, shall comply with relevant UL / IEC standard

(e.g. UL 1950 for IT equipment and UL 60601-1 / IEC 60601 series

for systems –shall comply with the standard IEC 60601-1-1,

Safety requirements for medical electrical systems. Equipment

not complying with UL 60601-1 shall be kept outside the patient

environment, as defined in the standard.

Caution:

It may cause the danger of explosion if battery is incorrectly

replaced. Replace only with same or equivalent type

recommended by the manufacturer.

Multi-Touch Panel PC

ACP-5210

Classification

1. Degree of production against electric shock: not classified

2. Degree of protection against the ingress of water: IPX1

3. Equipment not suitable for use in the presence of a flammable

anesthetic mixture with air or with oxygen or nitrous oxide.

4. Mode of operation: Continuous

5. Type of protection against electric shock: Class I equipment

Multi-Touch Panel PC

ACP-5210

vii

FCC

This device complies with Part 15 FCC Rules.

Operation is subject to the following two

conditions: (1) this device may not cause

harmful interference, and (2) this device

must accept any interference received

including interference that may cause

undesired operation.

Multi-Touch Panel PC

ACP-5210

viii

UL Module Description

ACP-5210 AC modules are developed to

suitable for the Classification Mark

requirement

Multi-Touch Panel PC

ACP-5210

Safety Symbol Description

The following safety symbols are further explanations for your

reference.

Medical equipment with respect to electric

shock, fire and mechanical hazards only in

accordance with UL 60601-1, and

CAN/CSA C22.2 NO. 601.1

Attention, consult ACCOMPANYING

DOCUMENTS.

Ground wire

Protective Ground wire.

Medical equipment with respect to electric

shock, fire and mechanical hazards only in

accordance with UL 60601-1, and

CAN/CSA C22.2 NO. 601.1
