RELION® 650 SERIES
—
Bay control REC650
Version 2.2
Product guide
Contents
1. Application..................................................................... 3
2. Available functions..........................................................5
3. Control......................................................................... 15
4. Multipurpose protection................................................18
5. Secondary system supervision..................................... 18
6. Logic............................................................................ 18
7. Monitoring.................................................................... 20
8. Metering.......................................................................23
9. Human machine interface.............................................23
10. Basic IED functions..................................................... 23
11. Ethernet...................................................................... 24
12. Station communication ...............................................24
13. Remote communication.............................................. 26
14. Hardware description.................................................. 26
15. Connection diagrams.................................................. 29
16. Technical data............................................................. 30
17. Ordering for pre-congured IED...................................62
18. Ordering for Accessories............................................. 65
Disclaimer
The information in this document is subject to change without notice and should not be construed as a commitment by ABB. ABB assumes no responsibility for any
errors that may appear in this document. Drawings and diagrams are not binding.
© Copyright 2017 ABB.
All rights reserved.
Trademarks
ABB and Relion are registered trademarks of the ABB Group. All other brand or product names mentioned in this document may be trademarks or registered
trademarks of their respective holders.
1MRK 511 426-BEN B
Bay control REC650 2.2
Product version: 2.2
2 ABB
1. Application GUID-0021B61F-B1F1-4B39-81C5-E1FB78EA87ED v3
REC650 is used for the control, protection and monitoring of
different types of bays in power networks. The IED is
especially suitable for applications in control systems with
distributed control IEDs in all bays with high demands on
reliability. It is suitable for the control of all apparatuses in the
following switchgear arrangements:
• Single busbar, with a single circuit breaker
• Double busbar, with a single circuit breaker
The control is performed from remote (SCADA/Station)
through various communication protocols or from the local
HMI.
Different control configurations can be used, and one control
IED per bay is recommended. Interlocking modules are
available for common types of switchgear arrangements. The
control is based on the select before execute principle to give
highest possible security. A synchronism control function is
available to interlock breaker closing. A synchronizing
function where breaker closes at the right instance in
asynchronous networks is also provided.
Disturbance recording is available to allow independent post-
fault analysis after primary disturbances.
One pre-configured package has been defined for the
following application:
• Single breaker, double busbar (A02)
The package is configured and ready for direct use. Analog
and control circuits have been pre-defined and other signals
need to be applied as required for each application. The pre-
configured IED can be changed and adapted to suit specific
applications with the application configuration tool.
The IED can be used in applications with the
IEC 61850-9-2LE process bus with up to four Merging Units
(MU). Each MU has eight analog channels, four current and
four voltages. Conventional input transformer module and
Merging Unit channels can be mixed freely in your application.
Forcing of binary inputs and outputs is a convenient way to
test wiring in substations as well as testing configuration logic
in the IEDs. Basically it means that all binary inputs and
outputs on the IED I/O modules (BOM, BIM and IOM) can be
forced to arbitrary values.
Central Account Management is an authentication
infrastructure that offers a secure solution for enforcing
access control to IEDs and other systems within a substation.
This incorporates management of user accounts, roles and
certificates and the distribution of such, a procedure
completely transparent to the user.
The Flexible Product Naming allows the customer to use an
IED-vendor independent IEC 61850 model of the IED. This
customer model will be used as the IEC 61850 data model,
but all other aspects of the IED will remain unchanged (e.g.,
names on the local HMI and names in the tools). This offers
significant flexibility to adapt the IED to the customers'
system and standard solution.
Description of A02
GUID-FC962706-6409-4D2D-9745-7A30F2C44A0D v1
Single breaker for double busbar.
1MRK 511 426-BEN B
Bay control REC650 2.2
Product version: 2.2 Issued: March 2018
Revision: B
ABB 3
QB1
REC650 A02 –Double busbar in single breaker arrangement
S CILO
3 Control S CSWI
3 Control S XSWI
3 Control
S CILO
3 Control S CSWI
3 Control S XSWI
3 Control SES RSYN
25 SC/VC
VN MMXU
MET UN
S CILO
3 Control S CSWI
3 Control S XCBR
3 Control
VN MMXU
MET UN
WA1
WA2
WA2_VT
WA1_VT
S CILO
3 Control S CSWI
3 Control S XSWI
3 Control
S CILO
3 Control S CSWI
3 Control S XSWI
3 Control
IEC09000649-6-en.vsdx
Other Functions available from the function library
R ESIN
3 Control
CCS SPVC
87 INd/I CV GAPC
2(I>/U<)
LMB RFLO
21FL FL
QB9
S CILO
3 Control S CSWI
3 Control S XSWI
3 Control
S CILO
3 Control S CSWI
3 Control S XSWI
3 Control
DRP RDRE
DFR/SER DR
CV MMXN
MET P/Q
VN MMXU
MET UN
ETP MMTR
MET W/Varh
QC9
Q CBAY
3 Control Q CRSV
3 Control
V MMXU
MET U V MSQI
MET Usqi
C MMXU
MET I C MSQI
MET Isqi
LINE_CT
LINE_VT
FUF SPVC
U>/I<
S SIMG
63 S SIML
71
S SCBR
S SCBR
S SCBR
QA1
QC1
QC2
QB2
12AI (7I + 5U)
QB1
QB2
QC1
QA1
QC2
QB9
QC9
SMP PTRC
94 1→0
IEC09000649 V6 EN-US
Figure 1. Configuration diagram for configuration A02
1MRK 511 426-BEN B
Bay control REC650 2.2
Product version: 2.2
4 ABB
2. Available functions GUID-F5776DD1-BD04-4872-BB89-A0412B4B5CC3 v1
The following tables list all the functions
available in the IED. Those functions that
are not exposed to the user or do not need
to be congured are not described in this
manual.
Back-up protection functions
GUID-A8D0852F-807F-4442-8730-E44808E194F0 v13
IEC 61850 or
function name
ANSI Function description Bay Control
REC650 (A02)
Multipurpose protection
CVGAPC General current and voltage protection 1
1MRK 511 426-BEN B
Bay control REC650 2.2
Product version: 2.2
ABB 5
Control and monitoring functions
GUID-E3777F16-0B76-4157-A3BF-0B6B978863DE v16
IEC 61850 or
function name
ANSI Function description Bay control
REC650 (A02)
Control
SESRSYN 25 Synchrocheck, energizing check and synchronizing 1
APC10 Control functionality for a single bay, max 10 objects (1CB), including interlocking 1
QCBAY Bay control 1
LOCREM Handling of LR-switch positions 1
LOCREMCTRL LHMI control of PSTO 1
SXCBR Circuit breaker 3
SLGAPC Logic rotating switch for function selection and LHMI presentation 15
VSGAPC Selector mini switch 30
DPGAPC Generic communication function for Double Point indication 16
SPC8GAPC Single point generic control function 8 signals 5
AUTOBITS Automation bits, command function for DNP3.0 3
SINGLECMD Single command, 16 signals 4
I103CMD Function commands for IEC 60870-5-103 1
I103GENCMD Function commands generic for IEC 60870-5-103 50
I103POSCMD IED commands with position and select for IEC 60870-5-103 50
I103POSCMDV IED direct commands with position for IEC 60870-5-503 50
I103IEDCMD IED commands for IEC 60870-5-103 1
I103USRCMD Function commands user defined for IEC 60870-5-103 4
Secondary system supervision
CCSSPVC 87 Current circuit supervison 1
FUFSPVC Fuse failure supervision 1
Logic
SMPPTRC 94 Tripping logic 6
SMAGAPC General start matrix block 6
STARTCOMB Start combinator 32
TMAGAPC Trip matrix logic 12
ALMCALH Logic for group alarm 5
WRNCALH Logic for group warning 5
INDCALH Logic for group indication 5
AND, GATE, INV,
LLD, OR,
PULSETIMER,
RSMEMORY,
SRMEMORY,
TIMERSET, XOR
Basic configurable logic blocks (see Table 2) 40–420
1MRK 511 426-BEN B
Bay control REC650 2.2
Product version: 2.2
6 ABB
IEC 61850 or
function name
ANSI Function description Bay control
REC650 (A02)
ANDQT,
INDCOMBSPQT,
INDEXTSPQT,
INVALIDQT,
INVERTERQT,
ORQT,
PULSETIMERQT,
RSMEMORYQT,
SRMEMORYQT,
TIMERSETQT,
XORQT
Configurable logic blocks Q/T (see Table 3) 1
FXDSIGN Fixed signal function block 1
B16I Boolean to integer conversion, 16 bit 18
BTIGAPC Boolean to integer conversion with logical node representation, 16 bit 16
IB16 Integer to Boolean 16 conversion 18
ITBGAPC Integer to Boolean 16 conversion with Logic Node representation 16
TEIGAPC Elapsed time integrator with limit transgression and overflow supervision 12
INTCOMP Comparator for integer inputs 30
REALCOMP Comparator for real inputs 30
1MRK 511 426-BEN B
Bay control REC650 2.2
Product version: 2.2
ABB 7
Table 1. Number of function instances in APC10
Function name Function description Total number of instances
SCILO Interlocking 10
BB_ES 3
A1A2_BS 2
A1A2_DC 3
ABC_BC 1
BH_CONN 1
BH_LINE_A 1
BH_LINE_B 1
DB_BUS_A 1
DB_BUS_B 1
DB_LINE 1
ABC_LINE 1
AB_TRAFO 1
SCSWI Switch controller 10
SXSWI Circuit switch 9
QCRSV Apparatus control 2
RESIN1 1
RESIN2 59
POS_EVAL Evaluation of position indication 10
XLNPROXY Proxy for signals from switching device via
GOOSE
12
GOOSEXLNRCV GOOSE function block to receive a switching
device
12
Table 2. Total number of instances for basic congurable logic blocks
Basic congurable logic block Total number of instances
AND 280
GATE 40
INV 420
LLD 40
OR 298
PULSETIMER 40
RSMEMORY 40
SRMEMORY 40
TIMERSET 60
XOR 40
1MRK 511 426-BEN B
Bay control REC650 2.2
Product version: 2.2
8 ABB
Table 3. Total number of instances for congurable logic blocks Q/T
Congurable logic blocks Q/T Total number of instances
ANDQT 120
INDCOMBSPQT 20
INDEXTSPQT 20
INVALIDQT 22
INVERTERQT 120
ORQT 120
PULSETIMERQT 40
RSMEMORYQT 40
SRMEMORYQT 40
TIMERSETQT 40
XORQT 40
1MRK 511 426-BEN B
Bay control REC650 2.2
Product version: 2.2
ABB 9
IEC 61850 or
function name
ANSI Function description Bay control
REC650 (A02)
Monitoring
CVMMXN Power system measurement 6
CMMXU Current measurement 10
VMMXU Voltage measurement phase-phase 6
CMSQI Current sequence measurement 6
VMSQI Voltage sequence measurement 6
VNMMXU Voltage measurement phase-earth 6
AISVBAS General service value presentation of
analog inputs
1
SSIMG 63 Insulation supervision for gas medium 21
SSIML 71 Insulation supervision for liquid medium 3
SSCBR Circuit breaker condition monitoring 3
EVENT Event function 20
DRPRDRE,
A1RADR-
A4RADR,
B1RBDR-
B22RBDR
Disturbance report 1
SPGAPC Generic communication function for single
point indication
64
SP16GAPC Generic communication function for single
point indication 16 inputs
16
MVGAPC Generic communication function for
measured values
24
BINSTATREP Logical signal status report 3
RANGE_XP Measured value expander block 66
LMBRFLO Fault locator 1
I103MEAS Measurands for IEC 60870-5-103 1
I103MEASUSR Measurands user defined signals for IEC
60870-5-103
3
I103AR Function status auto-recloser for IEC
60870-5-103
1
I103EF Function status earth-fault for IEC
60870-5-103
1
I103FLTPROT Function status fault protection for IEC
60870-5-103
1
I103IED IED status for IEC 60870-5-103 1
I103SUPERV Supervision status for IEC 60870-5-103 1
I103USRDEF Status for user defined signals for IEC
60870-5-103
20
L4UFCNT Event counter with limit supervision 30
1MRK 511 426-BEN B
Bay control REC650 2.2
Product version: 2.2
10 ABB
Altri manuali per REC650 ANSI
6
Indice
Altri manuali ABB Altro
ABB
ABB SACE Tmax XT UL Manuale utente
ABB
ABB Vmax 12 Guida rapida
ABB
ABB REM 610 Manuale utente
ABB
ABB VD4 12 Guida rapida
ABB
ABB REX 521 Manuale per l'uso e la cura
ABB
ABB SPAA 341 C /E351 Manuale utente
ABB
ABB REU 610 Manuale del prodotto
ABB
ABB REM 610 Manuale utente
ABB
ABB SACE Emax E1.2 Guida rapida
ABB
ABB AMVAC Guida rapida
ABB
ABB REF 542plus Manuale del prodotto
ABB
ABB REG650 ANSI Manuale utente
ABB
ABB RET620 Manuale utente
ABB
ABB REX 521 Manuale per l'uso e la cura
ABB
ABB MREL-01 Manuale utente
ABB
ABB RELION REF610 Manuale del prodotto
ABB
ABB CM-MPS.11 Manuale utente
ABB
ABB SACE Tmax XT2 Manuale utente
ABB
ABB REM 610 Manuale utente
ABB
ABB EP010 Guida rapida
