Accu-Chek Compact Manuale utente
Roche 014103 – Accu-Chek Compact_CAN – Cover Schwarz Cyan Magenta Gelb PMS 249 Prüfmittel-Nr. 30 X
ACCU-CHEK and SOFTCLIX
are trademarks of a Member
of the Roche Group
Made in Germany for export to:
Roche Diagnostics
201 Boul. Armand-Frappier
Laval, Québec
CANADA, H7V 4A2
Diabetes Care Info-Line:
Montreal area: (450) 686-7100
Outside Montreal (toll free): 1-800-363-7949
www.accu-chek.ca
Roche Diagnostics GmbH
D-68298 Mannheim, Germany
www.accu-chek.com
0088
0 3535517001(01) - 02/03
BLOOD GLUCOSE MONITOR
User’s Manual
Integrated test strips
ACCU-CHEK
®
Compact
u2 1
CONTENTS CONTENTS
1Introduction 6
2Inserting or replacing batteries 10
3Inserting or replacing the test strip drum 16
4Settings 26
4.1 Enabling/disabling the beep tone 28
4.2 Setting the year 30
4.3 Changing the date/time format 32
4.4 Setting the time 34
4.5 Setting the date 36
5Performing a blood glucose test 38
5.1 Using the Accu-Chek Softclix lancing device 38
5.2 Testing blood glucose 40
5.3 Testing conditions 48
6Reviewing stored blood glucose results 50
6.1 Highest value, lowest value, average 52
6.2 Downloading test results to a computer 54
7Checking, cleaning and storing your monitor 56
7. 1 Checking the monitor 56
7. 2 Cleaning the monitor 60
7. 3 Storing the monitor 65
8Technical data 66
9Problem checklist 68
10 Display messages and troubleshooting guide 70
11 Guarantee 90
12 Customer support and service 92
13 System components 94
14 Alphabetical index 98
014103 AC_Compact_ImP_CAN 12.08.2003 11:23 Uhr Seite u2
23
32
1
2
3
4
5
6
7
8
9
10
11
1
2
3
4
5
6
7
8
11
Display window
ON/OFF button
MEMO button
SET button
Optical system
Drum compartment release button
Drum compartment
Test strip drum
Test strip
Optical system cover*
Display cover*
Front edge of strip that draws up
the blood * available as replacement part
10
9
014103 AC_Compact_ImP_CAN 12.08.2003 11:23 Uhr Seite 2
45
54
15
12
13
14
16
17
Infrared data transmission window
Control window (shows the number of strips remaining)
Battery compartment
Batteries: Type AAA, LR 03, AM 4, Micro
Battery compartment cover*
Test strip guide
12
13
14
15
16
17
* available as replacement part
014103 AC_Compact_ImP_CAN 12.08.2003 11:23 Uhr Seite 4
67
67
Accu-Chek Compact is a completely new type of blood glucose
monitor for people with diabetes who test their own blood
glucose regularly. We have designed it to be as easy and safe
to use as possible. You will quickly discover that Accu-Chek
Compact is a reliable blood glucose monitor that you can take
anywhere.
Operating Accu-Chek Compact is easy: there is just one button
to press. You no longer have to handle individual test strips,
as they now come conveniently loaded in a drum. Each drum
holds 17 strips and two simple steps are all it takes to insert
the drum into the monitor. Coding occurs automatically.
When you want to take a blood glucose reading, just press the
button and a test strip moves from the drum into the correct
position. Once you have completed the test, just press the
button again and the strip is ejected automatically. Your results
are stored in memory and can be transferred to your computer
if you wish.
We recommend that you use the Accu-Chek Softclix lancing
device to obtain capillary blood samples. Blood collection with
an Accu-Chek Softclix lancing device is virtually pain-free.
With Accu-Chek Compact you’ve got it all at your fingertips.
You can monitor your blood glucose quickly, simply, and with
no cumbersome preparations – anywhere, anytime.
1Introduction
014103 AC_Compact_ImP_CAN 12.08.2003 11:23 Uhr Seite 6
This User’s Manual gives you full details of how to operate
Accu-Chek Compact. It also tells you how to clean and look
after your monitor. At the back of the manual is a list of all
possible error messages with recommendations for trouble-
shooting.
Please read carefully all text preceded by the following
symbols:
Warning!
This warns of a situation that may pose a risk to your
health (e.g. as a result of you calculating the wrong
insulin dose).
Caution!
This symbol indicates that your monitor is at risk of being
damaged (e.g. through improper cleaning), or that there
may be a problem during testing.
8
89
9
Important!
This symbol highlights important information that will
help you get the most out of your monitor.
Please take time to read this Manual and the instructions that
came with your lancing device and test strip drums. Also, when
you have a quiet moment, practise testing. To help you learn,
check the instructions and other information in this Manual
against the description of the monitor’s parts on pages 2-5.
Check that the pack contains all of the items listed. If any are
missing, please call our Diabetes Care Info-Line (for details
see Chapter 12 “Customer support and service”).
1Introduction
014103 AC_Compact_ImP_CAN 12.08.2003 11:23 Uhr Seite 8
11
11
Opening
the battery
compartment
10
10
2Inserting or replacing batteries
10
If the monitor is on, turn it off.
Press lightly on the lid of the battery
compartment and slide it in the direction
of the arrow . Open the battery
compartment .
2
1
1
2
014103 AC_Compact_ImP_CAN 12.08.2003 11:23 Uhr Seite 10
12
Remove any used batteries.
Insert two batteries (type AAA, LR 03, AM 4
or Micro). Make sure that the minus (-) pole
of the battery is next to the minus contact in
the battery compartment.
A new set of batteries provides enough power
to carry out a minimum of 500 blood glucose
tests. When battery power is low, the battery
symbol will appear. You can then per-
form a minimum of 50 more blood glucose
tests.
13
13
Battery types
12
2Inserting or replacing batteries
014103 AC_Compact_ImP_CAN 12.08.2003 11:23 Uhr Seite 12
14
To keep things simple, we recommend you
use up any current drum of strips before
replacing the batteries. Otherwise, it may
take the monitor a long time to advance the
first test strip from the next drum, and the
“use-by” date warning may also be lost.
(see Chapter 3).
Please take used batteries to a collection
point or to your local dealer.
15
15
Replacing
batteries
Important
When you replace the batteries, your stored results are
retained in memory. However, you will need to re-enter
the date and time. If you fail to do so, any blood glucose
test results you obtain from this point forward will be
displayed and saved without the date and time. In this
case, the test results saved in memory will be numbered
consecutively so you can still see the order in which you
took the readings.
14
2Inserting or replacing batteries
014103 AC_Compact_ImP_CAN 12.08.2003 11:23 Uhr Seite 14
17
17
Opening the
drum
compartment
16
3Inserting or replacing the test strip drum
If the monitor is on, turn it off. Wait for the
motor to stop before you open the monitor.
Slide the release button on the right side
of the monitor in the direction indicated by
the arrow. The drum compartment opens.
16
014103 AC_Compact_ImP_CAN 12.08.2003 11:23 Uhr Seite 16
