SERVICE MANUAL

SI : TSE: Check: Approved:

Date Revise Version Description

2008.01.24 V1.0 Initial Issue

H5350

H5350:95.87U20G019;95.87U20GC0E

Emy Roch

H5350 Condential

Preface

This manual is applied to H5350 projection system. The manual gives you a brief

description of basic technical information to help in service and maintain the product.

Your customers will appreciate the quick response time when you immediately identify

problems that occur with our products. We expect your customers will appreciate the

service that you offer them.

This manual is for technicians and people who have an electronic background. Please

send the product back to the distributor for repairing and do not attempt to do anything that

is complex or is not mentioned in the troubleshooting.

Notice:

The information found in this manual is subject to change without prior notice. Any

subsequent changes made to the data herein will be incorporated in future edition.

H5350 Service Manual

Manual Version 1.0

H5350 Condential

Table of Content

Chapter 1 Introduction

Highlight 1-1

Compatible Mode 1-3

Product Overview 1-7

Chapter 2 Disassembly Process

Equipment Needed & Product Overview 2-1

Disassemble Lamp Cover Module 2-2

Disassemble Lamp Module 2-2

Disassemble Top Cover Module 2-3

Disassemble Top Shielding 2-4

Disassemble Main Board Module & I/O Cover Module 2-4

Disassemble Front Cover Module 2-6

Disassemble Engine Module 2-7

Disassemble Color Wheel Module 2-8

Disassemble Zoom Ring & Focus Ring 2-9

Disassemble DMD Board and DMD Chip Module 2-10

Disassemble Fan Module 2-11

Disassemble Blower Module 2-12

Disassemble Speaker Module 2-13

Disassemble LVPS Module 2-14

Disassemble Interrupt Switch Module 2-15

Disassemble Lamp Driver Module 2-16

Disassemble Bottom Cover Module 2-18

Rod Adjustment 2-19

Re-write Lamp Usage Hour 2-20

H5350 Condential

Assemble Bottom Cover Module 2-21

Assemble Lamp Driver Module 2-22

Assemble Interrupt Switch Module 2-24

Assemble LVPS Module 2-25

Assemble Speaker Module 2-26

Assemble Blower Module 2-26

Assemble Fan Modul 2-27

Assemble DMD Board and DMD Chip 2-28

Assemble Zoom Ring&Focus Ring 2-29

Assemble Color Wheel Module 2-30

Assemble Engine Module 2-31

Assemble Front Cover Module 2-32

Assemble Main Board Module & I/O Cover Module 2-33

Assemble Top Shielding 2-34

Assemble Top Cover Module 2-35

Assemble Lamp Module 2-36

Assemble Lamp Cover Module 2-36

Chapter 3 Troubleshooting

LED Lighting Message 3-1

Main Procedure 3-2

Chapter 4 Function Test & Alignment Procedure

Test Equipment Needed 4-1

Service Mode 4-1

OSD Reset 4-1

Test Condition 4-2

Test Inspection Procedure 4-3

H5350 Condential

PC Mode 4-3

   Defectspecicationtable     4-7

Video Performance 4-7

Optical Performance Measure 4-9

Other 4-10

Chapter 5 Firmware Upgrade

Equipment Needed 5-1

DLP Composer Lite Setup Procedure 5-2

USB Driver Upgrade Procedure 5-4

Firmware Upgrade Procedure 5-5

Chapter 6 EDID Upgrade

EDID Introduction 6-1

Equipment Needed 6-2

Setup Procedure (VGA) 6-3

EDID Key-In Procedure 6-4

Setup Procedure (HDMI) 6-6

Appendix A Exploded Image I

Appendix B

   SerialNumberSystemDenition     XXI

   PCBACodeDenition      XXII

H5350 Condential 1-1

Chapter 1

Introduction

1-1 Highlight

No Item Description

1Dimensions (WxHxD) - 267 mm X 187 mm X 80 mm

2 Weight - <5 lbs

3Tilt Angle - 4 degree with elevator mechanism

4 Power Supply

- Universal AC 100 – 240 V ~ 50-60 Hz with PFC input

- 180W for Osram E20.6 Lamp @ normal operation

- Variant FAN speed control (Depends on temperature vari

ance)

5Keystone correction - +/ -40 degree (80 degree)

6 Cooling system

- Advanced Air Flow

- Two fans with system acoustic noise level 35 dB(A) (typi

cal)

- Temperature control circuits with adaptive fan rotational

speeds

- Maximum touch temperature follow UL60950-1

7 Brightness -1700 ANSI Lumens (Typical; Full power mode)

-1450 ANSI Lumens (Minimum; Full power mode)

8 Contrast - 1500 : 1 Full White and Black (Minimum; Full power mode)

- 1800 : 1 Full White and Black (Typical; Full power mode)

9 Uniformity - 65% Japan standard (Minimum; Full power mode)

- 80% Japan standard (Typical; Full power mode)

10 Throw ratio - 58”@2M(1.55 ~ 1.70 :1)

11 Audio - 2W*1

12 Projection lens - F# 2.44~2.58, f = 21.83~23.81 mm, 1.10X Mechanical

Zoom Lens

13 Lamp life - 3500 hours min, 50% survival rate

14 System controller - TI DDP2230

H5350 Condential 1-2

No Item Description

15 Terminal

- One HDMI input

- One D-sub VGA input

- One RCA Composite input

- Three RCA Component input

- One S-Video input(4 pin Mini din)

- One audio input (2.5m phone jack)

- One USB port (Type B Female)

16 Lamp housing

- Lamp Assembly could be changed by customer himself,

but should read the user manual for instruction in advance.

- Lamp Assembly should be provided by Coretronic and dis

tributed through authorized agencies.

17 Input signal spec.

- Hsync Frequency 31 ~ 100 kHz

- Vsync Frequency 56 ~ 85 Hz

- Video Signal RGB (PC)

● Analog RGB 0.7Vp-p, 75 ohm, Separate TTL H,V Sync

● Analog RGB 1Vp-p, 75 ohm, Sync. On Green signal

● Analog RGB 0.7Vp-p, 75 ohm, Composite TTL Sync.

- Video

● Composite video 1Vp-p,75 ohm

● S-video Luminance 0.714Vp-p, 75 ohm

● Chrominance 0.286Vp-p, 75 ohm

● Component Video 1Vp-p, 75 ohm

18 TI DMD - TI DMD 0.62” 12° 2xLVDS Type-A 720p Digital Mirror

Device

19 Video compatibility

- Standards :

● NTSC (3.58/4.43)

● PAL (B/D/G/H/I/M/N)

● SECAM (B/D/G/K/K1/L)

● HDTV - 480i,576i 480p, 576p, 720p, 1080i,1080p

20 XGA / Compression - Compression :

by using “DDP2230” Chips can make image compression

21 Number of active dots - 1280(H) x 720(V)

22 Color wheel - 6 segments (R90/Y35/G90/C35/W28/B82)

- 7200 rpm

23 Lamp - 180 – Watt OSRAM Lamp (user replaceable) for full power

mode

24 Temperature - Operating: 5°C -- 35°C

- Storage: -20°C -- 60°C

H5350 Condential 1-3

1-2 Compatible Mode

Computer Compatibility (Analog)

A. VGA Analog

(1) VGA Analog - PC Signal

Modes Resolution V.Frequency

[Hz]

H.Frequency

[KHz]

VGA

640x480 60 31.5

640x480 72 37.9

640x480 75 37.5

640x480 85 43.3

720x400 70 31.5

720x400 85 37.9

SVGA

800x600 56 35.2

800x600 60 37.9

800x600 72 48.1

800x600 75 46.9

800x600 85 53.7

832x624 75 49.725

XGA

1024x768 60 48.4

1024x768 70 56.5

1024x768 75 60

1024x768 85 68.7

SXGA

1152x864 70 63.8

1152x864 75 67.5

1152x864 85 77.1

1280x1024 60 63.98

1280x1024 72 76.97

1280x1024 75 79.98

1280x1024 85 91.1

QuadVGA 1280x960 60 59.7

1280x960 75 75.23

SXGA+ 1400x1050 60 63.98

UXGA 1600x1200 60 75

Power Mac G4 640x480 66.6(67) 34.93

Power Mac G4 800x600 60 37.9

Power Mac G4 1024x768 60 48.4

Power Mac G4 1152x870 75 68.68

Power Mac G4 1280x960 75 75

PowerBook G4 640x480 60 31.35

PowerBook G4 640x480 66.6(67) 34.93

PowerBook G4 800x600 60 37.9

PowerBook G4 1024x768 60 48.4

H5350 Condential 1-4

Modes Resolution V.Frequency

[Hz]

H.Frequency

[KHz]

PowerBook G4 1152x870 75 68.68

PowerBook G4 1280x960 75 75

i Mac DV(G3) 1024x768 75 60

(2) VGA Analog - Extended Wide timing

WXGA

1280x768 60 48.36

1280x768 75 57.6

1280x768 85 68.63

Native

1280x720 60 45

1280x800 60 49.702

1440x900 60 55.935

1680x1050 60 65.3

H5350 Condential 1-5

B. HDMI Digital

(1) HDMI – PC Signal

Modes Resolution V.Frequency

[Hz]

H.Frequency

[KHz]

VGA

640x480 60 31.5

640x480 72 37.9

640x480 75 37.5

640x480 85 43.3

720x400 70 31.5

720x400 85 37.9

SVGA

800x600 56 35.1

800x600 60 37.9

800x600 72 48.1

800x600 75 46.9

800x600 85 53.7

832x624 75 49.7

XGA

1024x768 60 48.4

1024x768 70 56.5

1024x768 75 60

1024x768 85 68.7

SXGA

1152x864 70 63.8

1152x864 75 67.5

1152x864 85 77.1

1280x1024 60 64

1280x1024 72 77

1280x1024 75 80

1280x1024 85 91.1

QuadVGA 1280x960 60 60

1280x960 75 75.2

SXGA+ 1400x1050 60 65.3

UXGA 1600x1200 60 75

Power Mac G4 640x480 66.6(67) 34.9

Power Mac G4 800x600 60 37.9

Power Mac G4 1024x768 60 48.4

Power Mac G4 1152x870 75 68.7

Power Mac G4 1280x960 75 75

PowerBook G4 640x480 60 31.4
