Acer K130 Series Manuale utente

Acer Projector

Multi-media

User's Guide

Introduction 1

Multimedia Features 1

Getting Started 2

Connecting multi-media device to the projector 2

Control Panel and Remote Control 3

Onscreen Display (OSD) Menus 5

Media Gallery 6

Setup 9

Photo Setting 10

Music Setting 11

Video Setting 12

Using MPtG Converter Tool 13

Wireless Projection via acer USB WiFi Adapter 14

Projection with MobiShow 17

Using MobiShow 17

Photo reviewer 18

Wireless PtG 19

Using the PtG2 converter 20

Acer EquiView - Screen Projection from Acer Tablet21

Display over USB 22

Appendices 23

Troubleshooting 23

Problems and Solution 23

Multi-media format supported 24

1. Photo Format 25

2. Music Format 25

3. Video Format 26

Contents

English

Introduction

The Acer multimedia support offers easier projection without PC and player

connected. Through Micro SD card reader and USB type A slot, you can easily

access various photo, video and music media formats (See format supported

table). The stylish user interface gives you best experience while playing media

files.

Multimedia Features

•Fancy and stylish user interface for better experience.

Supports Micro SD/ SDHC card, USB memory stick and mass storage (FAT32,

FAT16, NTFS) device.

•Supports high resolution JPEG and BMP picture formats, slideshow and

kinds of slideshow effects for the best viewing experience.

•Supports MP3, PCM and WMA...audio formats, music spectrum and

random play function for your please control.

•Supports MJPEG, MPEG4, H.264, WMV, MKV and RMVB...video formats.

Smooth video playback with 1080p@30Hz.

•Support office documents playback (Word, Excel, Powerpoint, PDF).

•Easy control for all media functions by remote controller.

Changes may be made periodically to the information in this publication

without obligation to notify any person of such revisions or changes.

Such changes will be incorporated in new editions of this manual or

supplementary documents and publications.

This company makes no representations or warranties, either expressed or

implied, with respect to the contents hereof and specifically disclaims the

implied warranties of merchantability or fitness for a particular purpose.

English

Getting Started

Connecting multi-media device to the

projector

Note: The media contents in external HDD drive via USB cable is

not supported.

#Icon Component Description

1 MicroSD Card

Slot

Connects to MicroSD Card.

2 USB connector Connects to USB disk/stick/cable.

USB

HDMI

UNIVERSAL I/O

AV IN DC IN

micro

USB

English

Control Panel and Remote Control

#Icon Component Description

1 Back/Stop Stop playing media file or go back to upper

data folder.

2 Menu Press to be back or stop function in multimedia

controls.

3 Media Toggle between USB A, Micro SD and RAM

sources.

4 Empowering

key

Unique Acer functions: eView, eTimer, e3D and

ePower Management.

Toolbar During Office Reader viewing, press to

bring up the toolbar.

Thumbnail Press to display folders or photos as

thumbnails at Photo category.

5 Enter/Play/

Pause

Confirm your selection of items or play/pause

media file.

Rotate During Office Reader viewing, press to

rotate the image from the toolbar.

English

6 Pre./Next Press / to select previous or next item

when the media is playing.

Rewind/Fast

forward Long press / to rewind or fast forward

when the media is playing.

Volume Press / to decreases or increases the

volume when the media is playing.

Select

Enter When the Media Gallery is displayed, press /

to make a selection and then press to

enter submenu for feature setting .

Enter/Play

Back Press to enter or play function or press

to be back function in most multimedia

controls.

Zoom During Office Reader viewing, select / to

zoom out or zoom in from the toolbar.

English

Onscreen Display (OSD) Menus

Setting

Main menu

Sub menu

English

Media Gallery

Note:

Change source to USB A to play your media contents in USB

drive.

Note:

Change source to Micro SD to play your media contents in

Micro SD card.

Photo: For access of photo files. Music: For access of music files.

Video: For access of video files. Office Reader: For access of WORD,

EXCEL, PPT, PDF files.

MPtG: For access of MPtG files. Please

refer to section "Using MPtG Converter

Tool"

Setup: For access of kinds of settings.

English

Note:

Change source to RAM to play your media contents in

internal memory.

Note:

Change source to USB B, make sure to plug USB cable well

and you can see disk and edit 1GB free space of internal memory.

Note:

Only support USB 2.0 handy drive. USB hubs are not

supported. External USB Hard disk is not supported.

Note:

Support USB handy drive/ Micro SD card upto 32GB.

English

Note: Office Reader:

1. All IPR, including but not limited to copyright, in the Picsel

Products is owned by Picsel suppliers.

2. The End User may not:

• Make copies of the Picsel Products or make them available

for use by third parties.

• Reverse engineer, disassemble, reverse translate, or in any

way decode the Picsel Products or any copy or part of it in

order to derive any source code, save only as is permitted

by any applicable law.

3. Picsel make no representations or warranties whether express

or implied (by statute or otherwise) relating to the

performance, quality, merchantability or fitness for a

particular purpose of the Picsel Products or otherwise and all

such representations or warranties are specifically disclaimed

and excluded.

4. Picsel agrees and acknowledges that Picsel and the Picsel

Products will not be specifically mentioned in the end user

license agreement.

Note: No support for advanced settings, such as Microsoft Word

drawing plug-in or table background settings.

Note: Contents outside the defined borders in Microsoft Word

will not be displayed.

Note: Microsoft PowerPoint slide effects not supported.

Note: Worksheets are displayed individually and sequentially

when the workbook has multiple worksheets.

Note: Page layout and numbering may be changed during

decoding.

Note: Objects embedded in files cannot be activated or viewed.

Note: Decoding may take a while for large files with complex

contents.
