Acer X1160 Serie Manuale utente
SERVICE MANUAL
SI : TSE: Check: Approved:
Date Revise Version Description
2007.08.27 V1.0 Initial Issue
2008.07.09 V2.0 Add X1160 Refresh/X1260 Refresh
2008.08.25 V3.0 Add X1160Z/X1160Z Refresh
2008.10.10 V4.0 Add X1260K Refresh
2008.12.12 V5.0 Add X1160P/X1160PZ/X1260P
X1160 Family/X1260 Family
Copyright Dec.2008. All Rights Reserved P/N: 36.88T03G001
X1160 Family X1160/X1160 refresh/X1160Z/X1160Z refresh/X1160P/X1160PZ
X1260 Family X1260/X1260 refresh/X1260K refresh/X1260P
X1160 Family/X1260 Family
Condential
Comparison table
PARTS X1160 X1160refresh X1160P X1160Zrefresh X1160PZ X1160Z X1260 X1260refresh X1260P X1260Krefresh
LOGO MY-
LAR
35.88T02G001 35.88T02G041 35.88T03G001 35.88T02G041 35.88T03G001 35.89B02G001 35.89B02G001 35.89B02G021 35.89B02G001
IO MYLAR 35.88T01G001 35.89B01G001
DMD 48.87K01G001 48.87M01G001 48.89B01G001
SPEAKER N/A 49.89B01G001
SYS FAN 49.88T01G001
BLOWER N/A 49.86E02G001 N/A 49.86E02G001 N/A 49.86E02G001
ZOOM
RING
N/A 51.89B04G001 51.89B04G001
FRONT IR
CAP
N/A 51.88T24G001 51.88T24G001 N/A N/A 51.88T24G001
FRONT
COVER
51.88T03G001 51.88T27G001 75.89B02G001 75.89B01G001 75.89B02G001
IR SENSOR
BD
N/A 80.87Y05G001 N/A N/A 80.87Y05G001
COLOR
WHEEL
70.88T11GR01 70.88T35GR01 70.8BA15GR01 70.88T35GR01 70.8BA15GR01 70.88T11GR01 70.88T11GR01 70.88T35GR01
ENGINE 70.88T12GR01 70.88T37GR01 70.88T20GR01 70.89B10GR01 70.89B28GR01
MAIN BD 70.88T13GR01 70.88T36GR01 70.88T39GR01 70.88T38GR01 70.88T40GR01 70.88T21GR01 70.89B07GR01 70.89B27GR01 70.89B44GR01 70.89B43GR01
LAMP
DRIVER
70.88T22GR01 70.88T34GR01 70.88T22GR01 70.88T22GR01 70.88T34GR01
LVPS 75.88T01G101 75.88T08G001 75.8BE01G001 75.88T08G001 75.8BE01G001 75.88T01G101 75.88T01G101 75.88T08G001 75.8BE01G001
THERMAL
SWITCH
N/A 43.89T17G001 N/A 43.89T17G001 N/A 43.89T17G001
MB TO
LVPS CA-
BLE
42.00454G001 42.00455G001 42.00454G001 42.00455G001 42.00454G001 42.00455G001 42.00455G002
X1160 Family/X1260 Family
Condential
Preface
This manual is applied to
X1160 Family/X1260 Family
projection system. The manual
gives you a brief description of basic technical information to help in service and maintain
the product.
Your customers will appreciate the quick response time when you immediately identify
problems that occur with our products. We expect your customers will appreciate the
service that you offer them.
This manual is for technicians and people who have an electronic background. Please
send the product back to the distributor for repairing and do not attempt to do anything that
is complex or is not mentioned in the troubleshooting.
Notice:
The information found in this manual is subject to change without prior notice. Any
subsequent changes made to the data herein will be incorporated in future edition.
X1160 Family/X1260 Family
Service Manual
Copyright Dec.2008
All Rights Reserved
Manual Version 5.0
Condential
X1160 Family/X1260 Family
Table of Content
Chapter 1 Introduction
Highlight 1-1
Compatible Mode 1-3
Product Overview 1-5
Chapter 2 Disassembly Process
Equipment Needed & Product Overview 2-1
Disassemble Lamp Cover Module 2-2
Disassemble Lamp Module 2-2
Disassemble Top Cover Module 2-3
Disassemble Top Shielding 2-4
Disassemble Front Cover Module 2-4
Disassemble Main Board Module & Back Cover Module 2-6
Disassemble Color Wheel Module 2-8
Disassemble Engine Module 2-9
Disassemble DMD Board and DMD Chip 2-10
Disassemble Speaker Module (For X1260 Family only)
2-11
Disassemble Fan Module & Blower Module 2-12
Disassemble Interrupt Switch Module 2-13
Disassemble Lamp Driver Module 2-14
Disassemble LVPS Module 2-15
Disassemble Bottom Cover Module 2-16
Rod Adjustment 2-17
Re-write Lamp Usage Hour 2-18
X1160 Family/X1260 Family
Condential
Assemble Bottom Cover Module 2-19
Assemble LVPS Module 2-20
Assemble Lamp Driver Module 2-21
Assemble Interrupt Switch Module 2-22
Assemble Fan Module & Blower Module 2-23
Assemble Speaker Module (For X1260 Family only)
2-24
Assemble DMD Board and DMD Chip 2-25
Assemble Engine Module 2-26
Assemble Color Wheel Module 2-27
Assemble Main Board Module & Back Cover Module 2-28
Assemble Front Cover Module 2-30
Assemble Top Shielding 2-31
Assemble Top Cover Module 2-32
Assemble Lamp Module 2-33
Chapter 3 Troubleshooting
LED Lighting Message 3-1
Main Procedure 3-2
Beep Sound 3-3
Chapter 4 Function Test & Alignment Procedure
Test Equipment Needed 4-1
Service Mode 4-1
OSD Reset 4-1
Test Condition 4-2
Test Inspection Procedure 4-3
PC Mode 4-3
Condential
X1160 Family/X1260 Family
Calibration 4-7
Video Performance 4-9
Optical Performance Measure 4-11
Other 4-12
Chapter 5 Firmware Upgrade
Equipment Needed 5-1
DLP Composer Lite Setup Procedure 5-2
USB Driver Upgrade Procedure 5-4
Firmware Upgrade Procedure 5-5
Waveform Download 5-8
Chapter 6 EDID Upgrade
EDID Introduction 6-1
Equipment Needed 6-2
Setup Procedure 6-3
EDID Key-In Procedure 6-4
Default Language Reset 6-5
Appendix A
Exploaded Overview
I
Appendix B
SerialNumberSystemDenition XXIV
PCBACodeDenition XXV
Appendix C
RS232 function command summary table I
X1160 Family/X1260 Family Condential 1-1
Chapter 1
Introduction
1-1 Highlight
No Item Description
1Dimensions (LxWxH) - 267 mm x 187 mm x 80 mm
2Weight - <5 lbs
3Tilt Angle
- 7 degree with elevator mechanism
(for X1160/X1260/ X1160Z)
- 3 degree with elevator mechanism
(for X1160 refresh /X1260 refresh/X1160Z refresh/X1260K
refresh/X1160P/X1160PZ/X1260P)
4Power Supply
- Universal AC 100 – 240 V ~ 50-60 Hz with PFC input
- 160W for Osram E20.6 Lamp @ normal operation
(for X1160/X1160 refresh/X1260/X1260 refresh/X1160Z/
X1160Z refresh)
- 180W for Osram E20.6 Lamp @ normal operation
(for x1260k refresh/X1160P/X1160PZ/X1260P)
- Variant FAN speed control (Depends on temperature
variance)
5Keystone correction - +/- 40 degree (80 degree)
6Cooling system
- Advanced Air Flow
- One fan with system acoustic noise level 36 dB(A) (typical)
- Temperature control circuits with adaptive fan rotational
speeds
- Maximum touch temperature follow UL60950-1
X1160 Family/X1260 Family Condential 1-2
No Item Description
7 Brightness
Engineering Spec:
- 1700 ANSI Lumens (Typical) (for X1160/X1260/X1160Z)
- 1445 ANSI Lumens (Minimum) (for X1160/X1260/X1160Z)
- 1800 ANSI Lumens (Typical)
( for X1160 refresh/X1260 refresh/X1160Z refresh/X1260K
refresh)
- 1600 ANSI Lumens (Minimum)
(for X1160 refresh /X1260 refresh/X1160Z refresh/X1260K
refresh)
- 2100 ANSI Lumens (Typical) (for X1160P/X1260P/
X1160PZ)
- 1850 ANSI Lumens (Minimum) (for X1160P/X1260P/
X1160PZ)
Marketing Spec:
- 2000 ANSI Lumens (for X1160/X1160 refresh/X1260/
X1260 refresh/X1160Z/X1160Z refresh/X1260K refresh)
- 2400 ANSI Lumens (for X1160P/X1160PZ/X1260P)
8Contrast
Engineering Spec:
- 1500 : 1 Full White and Black (Minimum; Full power mode)
- 1800 : 1 Full White and Black (Typical; Full power mode)
(for X1160/X1260/X1160Z)
- 1400 : 1 Full White and Black (Minimum; Full power mode)
- 1800 : 1 Full White and Black (Typical; Full power mode)
(for X1160 refresh/X1260 refresh/X1160Z refresh)
- 400 : 1 Full White and Black (Minimum; Full power mode)
- 600 : 1 Full White and Black (Typical; Full power mode)
(only for X1260K refresh)
- 1900 : 1 Full White Black (Minimum; full power mode)
- 2400 : 1 Full White Black (Typical; full power mode)
(for X1160P/X1160PZ/X1260P)
Marketing Spec:
- 2000:1 (for X1160/X1160 refresh/X1260/
X1260 refresh/X1160Z/X1160Z refresh/X1260K refresh)
- 2500:1 (for X1160P/X1160PZ/X1260P)
9 Uniformity
Engineering Spec:
- 65% Japan standard (Minimum; Full power mode)
- 80% Japan standard (Typical; Full power mode)
Marketing Spec:
- 85%
10 Throw ratio
- 1.95:1 distance/width @60”
(For X1160 refresh /X1160/X1160P)
- 1.95 – 2.15:1 distance/width @60”
(For X1260 refresh /X1260/X1160Z/X1160Z refresh/
X1260K refresh/ X1160PZ/X1260P)
11 Lamp door protection - Lamp Power Supply shut off automatically when lamp
cover open
X1160 Family/X1260 Family Condential 1-3
No Item Description
12 Projection lens
- F# 2.41 ,f = 21.79mm, Fix lens (For X1160 refresh /X1160/
X1160P)
- F# 2.41~2.55, f = 21.79~23.99 mm, 1.10X Mechanical
Zoom Lens (For X1260 refresh/X1260/X1160Z/X1160Z
refresh/X1260K refresh/ X1160PZ/X1260P)
13 Lamp life - 3500 hours min, 50% survival rate
- 4000 hours, 50% survival rate (Eco power Mode)
14 System controller - TI DDP2230
15 Terminal
For X1160 refresh/X1160/X1160P/X1160PZ
- One D-sub VGA input
- One Composite input
- One S-Video input(4 pin Mini din)
- One USB port (Type B Female)
For X1260 refresh/X1260/X1260K refresh/X1260P
- One D-sub VGA input
- One D-sub VGA output
- One Composite input
- One S-Video input(4 pin Mini din)
- One audio input (2.5m phone jack)
- One USB port (Type B Female)
- One RS-232 (3 pin Mini din)
16 Number of active dots
- Number of active dots : 800(H) x 600(V) (for X1160/
X1160 refresh/1160Z/X1160Z refresh/X1160P/X1160PZ)
- Number of active dots : 1024(H) x 768(V) (for
X1260/X1260 refresh/X1260K refresh/X1260P)
17 Input signal spec.
- Hsync Frequency 31 ~ 69 kHz (for X1160 refresh/X1160/
X1160Z/X1160Z refresh/X1160P/X1160PZ)
- Hsync Frequency 31 ~ 80 kHz (for X1260 refresh/X1260K
refresh/X1260P)
- Vsync Frequency 50 ~ 85 Hz
- Video Signal RGB (PC)
● Analog RGB 0.7Vp-p, 75 ohm, Separate TTL H,V Sync
● Analog RGB 1Vp-p, 75 ohm, Sync. On Green signal
● Analog RGB 0.7Vp-p, 75 ohm, Composite TTL Sync
- Video
● Composite video 1Vp-p,75 ohm
● S-video Luminance 0.714Vp-p, 75 ohm,Chrominance
0.286Vp-p, 75 ohm
● Component Video 1Vp-p, 75 ohm
18 TI DMD
- TI DMD 0.55” 12° 2xLVDS Type-X SVGA Digital Mirror
Device (for X1160/X1160 refresh/X1160Z/X1160Z refresh/
X1160P/X1160PZ)
- TI DMD 0.55” 12° 2xLVDS Type-X XGA Digital Mirror De
vice (for X1260 refresh/X1260/X1260K refresh/X1260P)
X1160 Family/X1260 Family Condential 1-4
No Item Description
19 Video compatibility
- Standards :
● NTSC (3.58/4.43)
● PAL (B/D/G/H/I/M/N)
● SECAM (B/D/G/K/K1/L)
● HDTV - 480i, 576i, 480p, 576p, 720p, 1080i
20 Power consumption
- 225W Max
- Standby < 8W at AC 110V (for X1160/X1260/X1160Z)
- Standby < 5W at AC 110V
(for X1160 refresh/X1260 refresh/X1160Z refresh)
- 250W Max.
- Standby < 5W at AC 110V
(only for X1260K refresh/X1160P/X1160PZ/X1260P)
21 Color wheel
- 6 segments (R90/Y28/G90/C28/W42/B82)
(for X1160 refresh/X1260 refresh/X1160Z refresh/X1260K
refresh)
- 6 segments (R85Y37G90C28W42B78)
(for X1160P/X1160PZ/X1260P)
- 7200 rpm CW 2X
- 9000 rpm @ CW 3X, PAL 50Hz
22 Lamp
- 160 Watt OSRAM (for X1160/X1160 refresh/X1260/X1260
refresh/X1160Z/X1160Z refresh)
- 180 Watt OSRAM (only for X1260K refresh/X1160P/
X1160PZ/X1260P)
23 Temperature - Operating: 5°C -- 35°C
- Storage: -20°C -- 60°C
Altri manuali per X1160 Serie
1
Questo manuale è adatto per i seguenti modelli
8
Indice
Altri manuali Acer Proiettore
Acer
Acer H5360 Series Manuale utente
Acer
Acer B123D Series Manuale utente
Acer
Acer P1250B Series Manuale utente
Acer
Acer S5301WM Series Manuale utente
Acer
Acer P7505 Series Manuale utente
Acer
Acer M511 Manuale utente
Acer
Acer H9500 Series Manuale utente
Acer
Acer PD523 Series Manuale utente
Acer
Acer H6815BD Series Manuale utente
Acer
Acer SL 700X Manuale utente
Acer
Acer PI 173 Series Manuale utente
Acer
Acer U5313W Series Manuale utente
Acer
Acer PE-833 Manuale utente
Acer
Acer H6800BD Manuale utente
Acer
Acer P5260E Series Manuale del sistema
Acer
Acer K750/EB151E/HL-800K Series Manuale utente
Acer
Acer H7531D Series Manuale utente
Acer
Acer P1166 Series Manuale utente
Acer
Acer P7270I Refresh Manuale del sistema
Acer
Acer X1161 Series Manuale utente
