Acronis® Backup & Recovery ™ 10

Server for Windows

Command Line Reference

Table of contents

1Command-line mode and scripting in Windows.........................................................................3

1.1 Agent for Windows command-line utility..............................................................................3

1.1.1 Supported commands..............................................................................................................................3

1.1.2 Common options...................................................................................................................................... 8

1.1.3 Specific options.......................................................................................................................................12

1.1.4 trueimagecmd.exe usage examples.......................................................................................................23

1.2 Scripting .............................................................................................................................28

1.2.1 Script execution parameters...................................................................................................................28

1.2.2 Script structure.......................................................................................................................................29

1.2.3 Script usage examples ............................................................................................................................30

1Command-line mode and scripting in Windows

Acronis Backup & Recovery 10 supports the command-line mode and enables backup automation by

executing XML scripts.

Acronis Backup & Recovery 10 uses the Acronis True Image Echo command line utility with the

following additions:

1. Ability to use the before/after data capture commands.

2. Ability to use the VSS support option.

3. Ability to check for a license on the license server with the /ls_check command.

4. Ability to use file exclusion at disk backup.

5. Ability to export archives and backups.

The rest of the commands and options are exactly the same. For this reason, the command line

reference uses the terminology accepted in Acronis True Image Echo.

The command line logs are saved in the old (Echo) format and cannot be converted to Acronis

Backup & Recovery 10 logs.

Command line mode limitations

The command-line mode functionality is somewhat more limited than the GUI mode. You will not be

able to perform:

recovery of a system volume

operations that require a user interaction, such as inserting removable media (CD, DVD or tape).

The operation fails if there is no media in the drive or the inserted media is full.

These operations only can be done through the GUI.

Scripting is intended only for backup.

1.1 Agent for Windows command-line utility

An administrator might need a console interface in some situations. Acronis Backup & Recovery 10

supports this mode with trueimagecmd.exe utility. The file is located in the folder where Acronis

Backup & Recovery 10 Agent for Windows has been installed, by default it is C:\Program

Files\Acronis\BackupAndRecovery.

This utility is also available when operating under the PE-based bootable media.

1.1.1 Supported commands

trueimagecmd has the following format:

trueimagecmd /command /option1 /option2…

Commands may be accompanied with options. Some options are common for most trueimagecmd

commands, while others are specific for individual commands. Below is a list of supported commands

and compatible options.

Command

Common Options

Specific Options

create

Creates an image of

specified disks and

partitions

/vault:[path]

/arc:[archive name]

/arc_id:[archive id]

/filename:[file name]

/password:[password]

/crypt:[AES128|AES192|AES256]

/asz:[number of archive]

/net_user:[username]

/net_password:[password]

/ftp_user:[username]

/ftp_password:[password]

/incremental

/differential

/compression:*0…9+

/split:[size in MB]

/oss_numbers

/progress:[on|off]

/reboot

/log:[file name]

/log_net_user:[remote user]

/log_net_password:[password]

/silent

/harddisk:[disk number]

/partition:[partition number]

/file_partition:[partition letter]

/raw

/exclude_names:[names]

/exclude_masks:[masks]

/exclude_system

/exclude_hidden

/before:[pre-data capture command]

/after:[post-data capture command]

/use_vss

filebackup

Backs up specified files

and folders

/vault:[path]

/arc:[archive name]

/arc_id:[archive id]

/filename:[file name]

/password:[password]

/crypt:[AES128|AES192|AES256]

/asz:[number of archive]

/net_user:[username]

/net_password:[password]

/ftp_user:[username]

/ftp_password:[password]

/incremental

/differential

/compression:*0…9+

/split:[size in MB]

/reboot

/log:[file name]

/log_net_user:[remote user]

/log_net_password:[password]

/silent

/include:[names]

/exclude_names:[names]

/exclude_masks:[masks]

/exclude_system

/exclude_hidden

/before:[pre-data capture command]

/after:[post-data capture command]

/use_vss

deploy

Restores disks and

partitions, except for

the MBR, from an


/vault:[path]

/arc:[archive name]

/arc_id:[archive id]

/filename:[file name]

/password:[password]

/asz:[number of archive]

/index:N

/net_user:[username]

/net_password:[password]

/ftp_user:[username]

/file_partition:[partition letter]

/harddisk:[disk number]

/partition:[partition number]

/target_harddisk:[disk number]

/target_partition:[partition number]

/start:[start sector]

/size:[partition size in sectors]

/fat16_32

/type:[active|primary|logical]

/preserve_mbr

/ftp_password:[password]

/oss_numbers

/reboot

/log:[file name]

/log_net_user:[remote user]

/log_net_password:[password]

/silent

When using the Acronis Universal Restore

option:

/ur_path:[path]

/ur_username:[user]

/ur_password:[pwd]

/ur_driver:[inf-filename]

deploy_mbr

Restores the MBR from

a disk or partition


/vault:[path]

/arc:[archive name]

/arc_id:[archive id]

/filename:[file name]

/password:[password]

/asz:[number of archive]

/index:N

/net_user:[username]

/net_password:[password]

/ftp_user:[username]

/ftp_password:[password]

/reboot

/log:[file name]

/log_net_user:[remote user]

/log_net_password:[password]

/silent

/harddisk:[disk number]

/target_harddisk:[disk number]

filerestore

Restores files and

folders from a file

archive

/vault:[path]

/arc:[archive name]

/arc_id:[archive id]

/filename:[file name]

/password:[password]

/asz:[number of archive]

/index:N

/net_user:[username]

/net_password:[password]

/ftp_user:[username]

/ftp_password:[password]

/reboot

/later

/log:[file name]

/log_net_user:[remote user]

/log_net_password:[password]

/silent

/target_folder:[target folder]

/overwrite:[older|never|always]

/restore_security:[on|off]

/original_date:[on|off]

/include:[names]

verify

Verifies the archive

data integrity

/vault:[path]

/arc:[archive name]

/arc_id:[archive id]

/filename:[file name]

/password:[password]

/asz:[number of archive]

/net_user:[username]

/net_password:[password]

/ftp_user:[username]

/ftp_password:[password]

/reboot

/log:[file name]

/log_net_user:[remote user]

/log_net_password:[password]

folder_name:[path]

no_subdir

/silent

pit_info

Displays the numbered

list of backups,

contained in the

specified archive

/filename:[file name]

/password:[password]

/asz:[number of archive]

/net_user:[username]

/net_password:[password]

/ftp_user:[username]

/ftp_password:[password]

consolidate

Creates a consistent

copy of the archive

which will contain only

the specified backups

/include_pits:[pits numbers]

/filename:[file name]

/password:[password]

/ftp_user:[username]

/ftp_password:[password]

/reboot

/log:[file name]

/log_net_user:[remote user]

/log_net_password:[password]

/silent

/target_filename:[file name]

/net_src_user:[username]

/net_src_password:[password]

/net_user:[username]

/net_password:[password]

export

Creates a copy of an

archive or a

self-sufficient part copy

of an archive in the

location you specify

/vault:[path]

/arc:[archive name]

/arc_id:[archive id]

/include_pits:[pits numbers]

/password:[password]

/ftp_user:[username]

/ftp_password:[password]

/progress:[on|off]

/log:[file name]

/log_net_user:[remote user]

/log_net_password:[password]

/silent

/net_src_user:[username]

/net_src_password:[password]

/ftp_src_user:[username]

/ftp_src_password:[password]

/target_vault:[target path]

/target_arc:[target archive name]

/net_user:[username]

/net_password:[password]

convert

Converts an image to

virtual disk format for

using with a virtual

machine

/filename:[file name]

/password:[password]

/asz:[number of archive]

/index:N

/net_user:[username]

/net_password:[password]

/ftp_user:[username]

/ftp_password:[password]

/log:[file name]

/log_net_user:[remote user]

/log_net_password:[password]

/silent

/target_filename:[file name]

/harddisk:[disk number]

/vm_type:[vmware|esx|microsoft|parallels]

/ur

/ur_path:[path]

list

Lists available drives

and partitions. When

used with the filename

option, it lists the

image contents.

When used with the

vault option, it lists

archives located in the

specified location.

/password:[password]

/index:N

/asz:[number of archive]

/net_user:[username]

/net_password:[password]

/ftp_user:[username]

/ftp_password:[password]

/filename:[file name]

/vault:[path]

/arc:[archive name]

/arc_id:[archive id]

When the arc, or the

arc_id option is added,

it lists all backups

contained in the

archive.

explore

Connects an image as a

virtual drive

/vault:[path]

/arc:[archive name]

/arc_id:[archive id]

/filename:[file name]*

/password:[password]

/asz:[number of archive]

/index:N

/net_user:[username]

/net_password:[password]

/log:[file name]

/log_net_user:[remote user]

/log_net_password:[password]

/silent

*for a split image, the name of the

last created file

/partition:[partition number]

/letter:X

unplug

Disconnects the image

connected as a virtual

drive

/letter:X

/letter:all

asz_create

Creates the Acronis

Secure Zone on the

selected drive

/password:[password]

/oss_numbers

/reboot

/later

/log:[file name]

/log_net_user:[remote user]

/log_net_password:[password]

/silent

/harddisk:X

/partition:[partition number]

/size:[ASZ size in sectors|unallocated]

asz_content

Displays the Acronis

Secure Zone size, free

space and contents

/password:[password]

asz_files

Displays the Acronis

Secure Zone size, free

space and contents

using the generated file

names

/password:[password]

asz_delete_files

Deletes the most

recent backup in the

archive located in the

Acronis Secure Zone

/filename:[file name]

/password:[password]

/log:[file name]

/log_net_user:[remote user]

/log_net_password:[password]

/silent

asz_delete

Deletes the Acronis

Secure Zone

/password:[password]

/oss_numbers

/reboot

/later

/log:[file name]

/log_net_user:[remote user]

/log_net_password:[password]

/silent

/partition:[partition number]

asrm_activate

Activates the Acronis

Startup Recovery

Manager

asrm_deactivate

Deactivates the Acronis

Startup Recovery

Manager

clone

Clones a hard disk

/reboot

/later

/silent

/harddisk:[disk number]

/target_harddisk:[disk number]

help

Shows usage

ls_check

Checks if there are

licenses for the local

machine on the license

server

1.1.2 Common options

1.1.2.1 Access to archives

vault:[path]

Specifies a path to the location that contains the archive. Used in combination with the arc, or the

arc_id option.

The following locations are supported:

Local folders, e.g.: /vault:C:\Test, or /vault:"C:\Test 1"

Network folders, e.g.: /vault:\\ServerA\Share\

Managed vaults (for advanced product editions only), e.g.:

/vault:bsp://StorageNode/VaultName

FTP and SFTP, e.g.: /vault:ftp://ServerA/Folder1

CD, DVD –with the path specified as a local path, e.g.: /vault:F:\

Acronis Secure Zone, e.g.: /vault:atis:///asz

Tapes, e.g.: /vault:atis:///tape?0

Unmanaged vaults are specified by their path. For example, if a vault is located in a folder,

specify the path to that folder.

If the vault option is specified the filename option is ignored.

arc:[archive name]

The name of the archive. If not specified, the arc_id option is used. If both the arc and arc_id options

are specified, the arc_id option is used.

arc_id:[archive id]

Specifies the Universally Unique Identifier (UUID) of the archive, e.g.:

/arc_id:183DE307-BC97-45CE-9AF7-60945A568BE8

If not specified, the arc option is used. If both options are specified, the arc_id option is used.

filename:[file name]

a) Backup file name, if the archive location is other than ASZ.

b) Archive name, when restoring or deleting files from ASZ. Can be obtained with asz_files.

If the vault option is specified the filename option is ignored.

password:[password]

a) Password for the archive, if the archive location is other than ASZ.

b) Password for the ASZ, if archive location is ASZ.

asz:[number of archive]

Addresses to the ASZ and selects the archive (a full backup with or without increments).

To get the archive number, use asz_content.

index:N

N = Number of the backup in an archive:

1 = basic full backup

2 = 1st increment… and so on

0 (default) = latest increment

Selects a backup in a sequence of incremental backups inside the archive.

To get a backup index from the ASZ, use asz_content.

include_pits:[pits numbers]

Specifies the backups (pits) to be included in the archive copy. To get the numbers of pits, use

pit_info. Separate multiple values with a comma, for example:

/include_pits:2,4,5

The "0" value means the last backup in the archive, for example:

/include_pits:0

If not specified the whole archive is selected.

net_user:[username]

Specify a user name for network drive access.

net_password:[password]

Specify a password for network drive access.

ftp_user:[username]

Specify a user name for access to an FTP server.

ftp_password:[password]

Specify a password for access to an FTP server.

1.1.2.2 Backup options

incremental

Set the backup type to incremental.

If not specified or there is no basic full backup, a full backup will be created.

differential

Set the backup type to differential.

If not specified or there is no basic full backup, a full backup will be created.

compression:[0…9]

Specify the data compression level.

It ranges from 0 to 9 and is set to 3 by default.

crypt:[AES128|AES192|AES256]

Specifies the key size for the AES algorithm encryption of the password-protected archive. The option

is used together with the /password (p. 9) option. For example:

/password:QWerTY123 /crypt:AES256

The randomly generated encryption key is then encrypted with AES-256 using a SHA-256 hash of the

password as a key. The password itself is not stored anywhere on the disk or in the backup file; the

password hash is used for verification purposes. With this two-level security, the backup data is

protected from any unauthorized access, but recovering a lost password is not possible.

Altri manuali per BACKUP AND RECOVERY 10 SERVER FOR LINUX - COMMAND LINE REFERENCE UPDATE...

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali ACRONIS Software

ACRONIS

ACRONIS DISK DIRECTOR SUITE 10 Manuale utente

ACRONIS

ACRONIS DNS-1250-04 Manuale utente

ACRONIS

ACRONIS TRUE IMAGE 9.1 - ENTERPRISE SERVER Manuale utente

ACRONIS

ACRONIS PRIVACYEXPERT 2003 Manuale utente

ACRONIS

ACRONIS TRUE IMAGE CORPORATE WORKSTATION 9.1 Manuale utente

ACRONIS

ACRONIS BACKUP AND RECOVERY 10 ADVANCED SERVER - INSTALLATION UPDATE... Manuale utente

ACRONIS

ACRONIS RECOVERY - FOR MS SQL SERVER Manuale utente

ACRONIS

ACRONIS RECOVERY - FOR MS SQL SERVER Manuale utente

ACRONIS

ACRONIS BACKUP AND RECOVERY 10 ADVANCED SERVER VIRTUAL EDITION - COMMAND LINE REFERENCE UPDATE... Manuale di istruzioni

ACRONIS

ACRONIS TRUE IMAGE 9.1 - FOR LINUX Manuale utente

ACRONIS

ACRONIS BACKUP AND RECOVERY 10 SERVER FOR LINUX - Manuale utente

ACRONIS

ACRONIS ACRONIS TRUE IMAGE SOFTWARE DEVELOPMENT KIT Guida all'installazione

ACRONIS

ACRONIS TRUE IMAGE ECHO - ENTERPRISE SERVER Manuale utente

ACRONIS

ACRONIS RECOVERY - FOR MICROSOFT EXCHANGE Manuale utente

ACRONIS

ACRONIS BACKUP AND RECOVERY 10 SERVER FOR LINUX - Manuale utente

ACRONIS

ACRONIS BACKUP RECOVERY 10 ADVANCED SERVER - Manuale utente

ACRONIS

ACRONIS TRUE IMAGE - VIRTUAL EDITION Manuale utente

ACRONIS

ACRONIS DISK DIRECTOR SUITE 10 Manuale utente

ACRONIS

ACRONIS SNAP DEPLOY 2.0 - Manuale utente

ACRONIS

ACRONIS BACKUP RECOVERY 10 ADVANCED SERVER VIRTUAL... Manuale utente

ACRONIS

ACRONIS BACKUP RECOVERY 10 WORKSTATION Manuale utente

ACRONIS

ACRONIS TRUE IMAGE ECHO - FOR LINUX Manuale utente

ACRONIS

ACRONIS BACKUP AND RECOVERY 10 SERVER FOR LINUX - Manuale utente

ACRONIS

ACRONIS BACKUP RECOVERY 10 ADVANCED SERVER SBS... Manuale utente

Manuali Software popolari di altre marche

COMPRO

COMPRO COMPROFM Manuale utente

Muratec

Muratec OFFICEBRIDGE ONLINE Manuale utente

Oracle

Oracle Contact Center Anywhere 8.1 Manuale utente

Adobe

Adobe 65007312 - Photoshop Lightroom Manuale

Avaya

Avaya NULL One-X for RIM Blackberry Manuale utente

HP ProLiant BL420c Manuale utente

PS Audio

PS Audio PowerPlay Manuale del proprietario

Brady

Brady LOCKOUT PRO 3.0 Manuale di servizio

Avaya

Avaya Interaction Center Manuale utente

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manuale

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manuale utente

Oracle

Oracle Application 9i Manuale utente

Acer

Acer RDM Manuale utente

Canon

Canon Vixia HF21 Manuale utente

Canon

Canon ZR950 Manuale utente

Samsung

Samsung Auto Backup Manuale utente

Polycom

Polycom Vortex EF2201 Istruzioni per l'installazione e il funzionamento

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manuale utente
