ACSI 1000 Series Manuale utente
MECHANISM CASE
RATCHET CLIP
PUSH BAR
COVER
SUPPLIED CONNECTING PIN
SUPPLIED CONNECTING BRACKET
SUPPLIED SCREWS
SUPPLIED LOCKNUT
LOWER PUSH BAR MOUNTING PINS
BASEPLATE ASSEMBLY
FRONT PUSH BAR
END CAP
REAR PUSH BAR
END CAP
END CAP SCREWS
DEIE AR
ELERI EI DEIE I IALLAIO IRIO
MOOR DRIE ELERI LA RERAIO
Electrical Input Requirements:
Filtered and Regulated Power Supply
Voltage: 24VDC
10%
Current: 1A MAX Inrush, 400mA MAX Holding
Non-polarized Leads
MD
DESIGN HARDWARE 1000 SERIES
ROIDE IMLAEO ELERI LA RERAIO AD DOI AR DEREED
Installation:
Separate the mechanism case from the baseplate assembly.
1.
Remove the manual dogging assembly, if present, from the baseplate assembly and discard.
2.
Skip to step 11 if installing in a 33" device or a 42" device with an 18" push bar.
3.
Separate the push bar from the baseplate assembly by removing the lower push bar mounting pins.
4.
Separate the front push bar end cap from the push bar.
5.
Slide the push bar cover forward to expose the rear push bar end cap mounting screws.
6.
Replace the rear push bar end cap mounting screws one at a time with the supplied screws to maintain the
7.
correct position of the end cap.
Attach the supplied connecting bracket with connecting pin installed using the supplied locknut.
8.
Slide the push bar cover back to the original position and attach the front push bar end cap to the push bar.
9.
Attach the push bar to the baseplate assembly using the lower push bar mounting pins.
10.
Locate the 1550K-MDH Kit near the holes that secured the manual dogging assembly.
11.
Attach the connecting link to the installed connecting bracket and pin for the 42" device with 24" push bar or
12.
the rear mechanism of the push bar for the 33" device or for the 42" device with 18" push bar.
Attach the motor bracket to the baseplate assembly using the supplied screws and lockwashers through the
13.
holes that secured the manual dogging assembly.
Attach the mechanism case to the baseplate assembly.
14.
Install the ratchet clip into the mechanical dogging hole of the slide cover.
15.
Apply the supplied technical assistance labels to the head cover and the end cover.
16.
Do not remove an regulator labels adhered to the device
Alloable uto rom Device Length
tandard tandard
1.50" 4.25"
onductor ire Run
Distance
ire auge
70'
22
110'
20
180'
18
280'
16
450'
14
720'
12
2720 CLARK AVE. ~ ST. LOUIS, MO 63103 ~ 1-800-753-5558 ~ www.acsi-inc.com
II-E1500-39
REV. 10/2019
INDICATOR LIGHTS
ADJUSTMENT SCREW
12
DEIE AR
MOTOR BRACKET
CONNECTING LINK
DEIE AR
12
Motor Drive Electric Latch Retraction Adjustment:
Verify the device is properly adjusted for mechanical operation. Electric operation should not exceed the
1.
mechanical operation or there will be a high risk of damage to the device.
e suggest setting the latch
retraction under electric operation at less than the latch retraction under mechanical operation
Locate the adjustment screw in the rear of the motor assembly. Rotate the adjustment screw clockwise to
2.
increase the latch retraction or counterclockwise to decrease the latch retraction.
Onboard Indicator Light Assignments:
Maintain input power to the exit device and check the onboard indicator lights.
Remove input poer beore attempting a solution
reen
oer
ello
ensor
Red
Error
Indication
ossible olution
Off Off Off
No Power.
Connect the wiring between the power
supply and the exit device.
On On
Off
Normal Operation. The push bar is retracted to the dogged
position and dogged; the latch is retracted by default. The
device is allowed 2 attempts.
On
Off
On
Error in operation. The push bar did not retract to the dogged
position within 2 attempts.
Rotate the adjustment screw
counterclockwise to decrease the latch
retraction.
On On On
Error in operation. Without power being removed, the push bar
went from being dogged to unintentionally being extended,
and then the push bar did not retract to the dogged position
within 2 attempts.
Clear the jam condition manually.
On
Blink
On
Error in operation. The push bar did not extend from the
dogged position when the power was last removed. The
device will not attempt a retraction.
Clear the jam condition manually.
On
Simultaneous
Blink
Error in operation. The input voltage dropped below the
specification during operation.
Decrease the wire run or increase the wire
gauge.
On
Alternating Blink
Error in operation. An electronics fault was detected.
An electronics replacement is required.
2720 CLARK AVE. ~ ST. LOUIS, MO 63103 ~ 1-800-753-5558 ~ www.acsi-inc.com
II-E1500-39
REV. 10/2019
