Q960 Configuration Guide

with RAS

2019/05/28

www.acti.com

CONFIGURATION GUIDE

2

Part one: Access the Camera

1. Open the IP utility tool on the desktop.

2. Find the camera (Q960) you would like to install.

Note: MAC Address will be used in the second part of 1-2,

please record it for easy operation.

3. Open IE browser. (Please be sure to use IE browser.)

4. Enter the Camera IP on your browser, press “Enter” to go to the

Camera login page.

5. Fill in the account / password and click login to log in.

(Default account/ password→ User name: admin, Password: Aa123456)

www.acti.com

CONFIGURATION GUIDE

3

Part two: Settings of Camera

Please refer to the following figure for the People counting setting:

1. Click “Configuration”.

2. Click “People Counting”.

3. Click “Rule”.

4. Make sure “Enable People Counting” has been checked.

5. Adjust “Auto” to “Manual”.

6. Enter the ceiling height (from the floor) and click “Calibration”.

7. Adjust the detection area and the detection line as the picture below.

*Note: The detection lines should be drawn on the same level (There

should be no unevenness on the detection line)

www.acti.com

CONFIGURATION GUIDE

4

8. Click “Save” for the settings.

Click to draw an orange detection line.

Click to change the direction

of entry and exit.

Click to draw a polygon

detection line.

www.acti.com

CONFIGURATION GUIDE

5

A. Please refer to the following steps for data upload settings.

1. Click “Data Uploading”, check “ON” for Real-Time Upload Data

2. IP should be set the same as the MGB Server.

3. Please set URL as “/PeopleCountingApi/Q960Receiver”

4. Set the Port ” 9005”

5. Click “Save” to save the settings

6. Click “Advanced”

7. Click “Enter/Leave” for Flow Overlay

www.acti.com

CONFIGURATION GUIDE

6

8. Click “Save”.

B. Please refer below to modify the camera IP address

1. Click “Configuration”

2. Click “Network”

3. Click “Basic Settings”

4. Click “TCP/IP”

5. Uncheck “DHCP” to undo dynamic IP address setting

6. This is the IP address to configure

7. Subnet mask

8. Router address

9. Click “Save” to save the settings

www.acti.com

CONFIGURATION GUIDE

7

10. When the settings are done, restart to apply all the settings. Click OK

to restart.

www.acti.com

CONFIGURATION GUIDE

8

Part three: Set up related parameters for the webpage

1. Open the webpage (Using Google chrome browser)

http://localhost/MAS_RetailPackage/Setting/mgbmanagement.aspx

2. Sign in RAS (admin/123456)

3. Add new device settings

3-1. Click “Overview” “Setting” “MGB Server”

3-2. Click the same name as the one attached to the server. (Ex: MGB

Server)

3-3. Click “Add new device” as the picture below

www.acti.com

CONFIGURATION GUIDE

9

3-4 Choose “Q960A” for the Device Type (Please refer to the picture

below)

www.acti.com

CONFIGURATION GUIDE

10

3-5 Configure the details of the device

Camera name:

(Store name +960+location)

MAC Address:

Fill in the default Camera

MAC, please refer to step 2

of the first part.

Note: The minus sign (-) of

the MAC address must be

replaced with a colon (:)

Stream URL: Please

keep it blank.

Camera IP:Enter the IP of

Q960.

HTTP PORT Maintain the

number “80”

Account:admin

Password:Aa123456

3-6 Click “ Save”

3-7 Be sure all the devices

have been set properly,

then click “Lock”.

Click “Lock”→ Press “Save”

（If there are still other devices that need to be added (except Q960),

please click “Lock” after all the devices have been set without error.）

Note: The saved settings cannot be changed after clicking “Lock”！

（If there’s any setting error and need to adjust, please contact ACTi

customer service to unlock.）
