ACU-RITE Intelli-Time 13041RM Manuale utente

Instruction Manual

SAVE THIS MANUAL FOR FUTURE REFERENCE.

Questions? Contact Customer Support at

(877) 221-1252 or visit www.AcuRite.com.

CONTENTS

Unpacking Instructions ........... 2

Package Contents .................. 2

Product Registration ............... 2

Features & Benets: Sensor..... 2

Features & Benets: Clock ...... 3

Setup .................................... 4

Sensor Setup ......................... 4

Clock Setup........................... 5

Intelli-Time® Clock .................. 6

Set the Time, Date & Units ...... 6

Placement Guidelines ............. 7

Using the Alarm Clock............ 8

Backlight Settings................... 8

USB Charging........................ 9

Troubleshooting ....................10

Care & Maintenance............. 11

Replace Intelli-Time®Battery .. 11

Specications........................12

FCC Information ...................12

Customer Support .................13

Warranty..............................13

Intelli-Time Alarm Clock

model 13041RM

Congratulations on your new AcuRite product. To ensure the best

possible product performance, please read this manual in its entirety

and retain it for future reference.

Unpacking Instructions

Remove the protective lm that is applied to the LCD screen prior to using this

product. Locate the tab and peel off to remove.

Package Contents

1. Alarm Clock

2. Outdoor Sensor

3. Power Adapter

4. Instruction Manual

PRODUCT REGISTRATION

to receive 1 year

warranty protection

www.AcuRite.com

IMPORTANT PRODUCT MUST BE REGISTERED

TO RECEIVE WARRANTY SERVICE

►

Features & Benets

OUTDOOR SENSOR

1. Integrated Hanger

for easy placement.

2. Wireless Signal Indicator

Flashes when data is being

sent to the clock.

3. Battery Compartment

4. A-B-C Switch

ID code that must match clock’s

A-B-C switch to ensure units

synchronize.

5. Battery Compartment Cover

Features & Benets

BACK OF CLOCK

18. USB Charger

For compatible Smartphones

19. Plug in for Power Adapter

20. A-B-C Switch

ID code that must match the

sensor's A-B-C switch to ensure

units synchronize.

21. Battery Compartment

22. Intelli-Time® Battery

Compartment

411 12

18 19 2120 22

3 2

FRONT OF CLOCK

1. SNOOZE Button

2. Time

3. Moon Phase

4. Outdoor Sensor Signal Strength

5. Current Outdoor Temperature

6. Day of the Week

7. Date

8. Current Indoor Temperature

9. Humidity Level Icon

Indicates a high, low or ideal

humidity comfort level.

10. Current Indoor Humidity

11. Alarm ON/OFF Indicator

12. Icon

Indicates display backlight

“AUTO DIM” mode activated.

SIDE OF CLOCK

13. “ ” Button

For setup and backlight

brightness preferences.

14. SET Button

For setup preferences

15. “ ” Button

For setup and backlight

brightness preferences.

16. Alarm ON/OFF Switch

17. Battery Compartment Cover

SETUP

Set the A-B-C Switch

The A-B-C switch is located inside

the battery compartment. It can

be set to A, B or C. However,

you must select the same letter

choices for both the sensor and

the clock in order for the units to

synchronize.

Install or Replace Batteries

AcuRite recommends high quality

alkaline or lithium batteries for

the best product performance.

Heavy duty or rechargeable

batteries are not recommended.

The sensor requires lithium

batteries in low temperature

conditions. Cold temperatures

can cause alkaline batteries

to function improperly. Use

lithium batteries in the sensor for

temperatures below -4ºF / -20ºC.

1. Slide off the battery

compartment cover. Take

note of the A-B-C switch

setting inside the battery

compartment for clock setup.

2. Insert 2 x AA batteries into

the battery compartment, as

shown. Follow the polarity

(+/-) diagram in the battery

compartment.

3. Replace the battery cover.

Sensor Setup

1A-B-C Switch

set to match

clock

2Install Batteries

2 AA batteries

A B C

PLEASE DISPOSE OF OLD OR DEFECTIVE BATTERIES IN AN ENVIRONMENTALLY SAFE

WAY AND IN ACCORDANCE WITH YOUR LOCAL LAWS AND REGULATIONS.

BATTERY SAFETY: Clean the battery contacts and also those of the device prior to battery installation. Remove batteries from equipment which is not to be

used for an extended period of time. Follow the polarity (+/-) diagram in the battery compartment. Promptly remove dead batteries from the device. Dispose of used

batteries properly. Only batteries of the same or equivalent type as recommended are to be used. DO NOT incinerate used batteries. DO NOT dispose of batteries in ﬁre,

as batteries may explode or leak. DO NOT mix old and new batteries or types of batteries (alkaline/standard). DO NOT use rechargeable batteries. DO NOT recharge

non-rechargeable batteries. DO NOT short-circuit the supply terminals.

Clock Setup

Set the A-B-C Switch

Locate the A-B-C switch inside

the battery compartment. Set

the A-B-C switch to A, B or C.

You must select the same letter

choices for both the clock and

the sensor in order for the units

to synchronize.

Plug in Power Adapter

For the best performance, plug

in the power adapter as the main

power source for this product.

Install or Replace Backup

Batteries

1. Remove the battery

compartment cover.

2. Insert 2 x AAA alkaline

batteries into the battery

compartment, as shown.

Follow the polarity

(+/-) diagram in the battery

compartment.

3. Replace the battery cover.

A B C

IMPORTANT: Batteries are a backup power source to preserve records in the event of a

power outage. Power adapter recommended as the primary power source to enjoy the full

functionality of the product.

Install or

Replace Backup

Batteries

2 AAA alkaline

batteries

2Plug in Power

Adapter

(on back of unit)

1A-B-C Switch

set to match

sensor

Intelli-Time®Clock

Intelli-Time clock and calendar are pre-programmed to the correct time and

date, and update automatically for Daylight Saving Time. All you need to do is

select your time zone during clock setup.

Set the Time, Date & Units

Press and HOLD the “SET” button, located on the side of the clock until

"SELECT TIME ZONE" appears on the display to enter SET MODE. Once in

SET MODE the preference you are currently setting will blink on the clock.

To adjust the currently selected (ashing) item, press and release the “”or

“” buttons (press and HOLD to fast adjust).

To save your adjustments, press and release the “SET” button to adjust the next

preference. The preference set order is as follows:

TIME ZONE (PST MST CST EST AST HAT AKT NDT)

AUTO DST ON/OFF*

CLOCK HOUR

CLOCK MINUTE

CALENDAR MONTH

CALENDAR DATE

CALENDAR YEAR

TEMPERATURE SCALE (ºF or ºC)

You will automatically exit SET MODE if no buttons are pressed for 5 seconds.

Enter SET MODE at any time by pressing and holding the “SET” button until

"SELECT TIME ZONE" appears on the display.

*If you live in an area that observes daylight saving time, DST should be set to

ON.

Alarm Clock Placement

Place alarm clock in a dry area free of dirt and dust. To help ensure

an accurate indoor temperature measurement, be sure to place the

clock away from heat sources or vents.

Outdoor Sensor Placement

Sensor must be placed outside to observe outdoor conditions.

Sensor is water resistant and is designed for general outdoor use,

however, to extend its life place the sensor in an area protected from

direct weather elements.

Hang the sensor using the integrated hang holes or hanger, or by

using string (not included) to hang it from a suitable location, like a

well covered tree branch. The best location is 4 to 8 feet above the

ground with permanent shade and plenty of fresh air to circulate

around the sensor.

Placement for Maximum Accuracy

AcuRite sensors are sensitive to surrounding environmental conditions. Proper

placement of both the clock and outdoor sensor are critical to the accuracy

and performance of this product.

Important Placement Guidelines

• To ensure accurate temperature measurement, place units out of direct

sunlight and away from any heat sources or vents.

• Clock and outdoor sensor must be within 330 ft (100 m) of each other.

• To maximize wireless range, place units away from large metallic items, thick

walls, metal surfaces, or other objects that may limit wireless communication.

• To prevent wireless interference, place both units at least 3 ft (.9 m) away

from electronic devices (TV, computer, microwave, radio, etc.).

Setup is Complete

The sensor will now synchronize with the alarm clock. It may take a few

minutes for synchronization to complete.

(100 meters)

(330 feet maximum)

(.91 m)

LEAST

APART

Using the Alarm Clock

Set the Alarm Time

To set alarm time, press and RELEASE the “SET” button to enter ALARM SET

MODE.

To adjust the currently selected (ashing) item, press and release the “”or

“” buttons (press and HOLD to fast adjust).

To save your adjustments, press and release the “SET” button to adjust the next

preference. The preference set order is as follows:

ALARM CLOCK HOUR (Please note AM/PM indicator)

ALARM CLOCK MINUTE

You will automatically exit ALARM SET MODE if no buttons are pressed for

5 seconds. Enter ALARM SET MODE at any time by pressing and RELEASING

the “SET” button.

Alarm Clock ON or OFF

To turn alarm on: Slide the ON/OFF switch on the side of the clock to ON. The

indicator appears on the screen.

To turn alarm off: Slide the ON/OFF switch on the side of the clock to OFF.

The indicator appears on the screen.

Alarm Clock SNOOZE

The alarm clock will sound, increasing in volume over a 2 minute period. When

the alarm is sounding, press the "SNOOZE" button to activate the SNOOZE

function for 10 minutes. The SNOOZE function can be activated up to 10 times.

Backlight Settings

This clock’s color display features 6 different lighting settings: 100% (High),

70%, 50% (Medium), 30%, 10% and 5% (Low) brightness.

When clock is powered with the power adapter, backlight remains on at 100%

brightness by default. Press the "SNOOZE" button at any time to momentarily

light the display at 100% brightness. After 5 seconds, the clock will return to

the user-selected brightness setting.

Using battery power alone, the backlight is available momentarily for 10

seconds by pressing the “SNOOZE” button.

Manually adjust the backlight brightness by pressing and releasing the “”

or " " buttons when not in SET MODE or ALARM SET MODE. Press the

“” button a sixth time to enter “AUTO DIM” mode. will appear to the

right of the time.

OPERATION

OFF

USB Charging

Charge your mobile device by plugging your device’s USB power cord

(not included) into the USB charging port on the back of the clock.

USB charging is only available during power adapter

use; USB charging is not active when operating

on battery power only.

Note: Follow the manufacturer’s instructions for your

mobile device(s) to determine compatibility with the

USB charging feature on this product. Some devices may not

support USB charging or may require a higher power rating

than this product provides. Observe the charging status on

your device. Ensure your device is working properly before

attempting to charge.

Humidity Level Icon

The Humidity Level Icon easily conveys a low, high or ideal indoor humidity

level for your home and health:

Learn more at http://www.acurite.com/humidity-health

Moon Phase

Track the phases of the moon, conveyed through simple lunar phase icons:

LOW Humidity Level

Humidity is

low relative to

temperature.

Makes for a

DRY environment.

OK Humidity Level

Humidity is

OK relative to

temperature.

Makes for an

IDEAL environment.

HIGH Humidity Level

Humidity is

high relative to

temperature.

Makes for a HUMID

environment.

LOW

HIGH

AUTO DIM MODE: Automatically adjusts display brightness based on time of day.

7:00 a.m. - 9:00 p.m. = 100% brightness

9:01 p.m. - 6:59 a.m.= 5% brightness

FULL

NEW WAXING

CRESCENT

WANING

CRESCENT

1ST

QUARTER

3RD

QUARTER

If your AcuRite product does not operate properly after trying

the troubleshooting steps, visit www.AcuRite.com or call

(877) 221-1252 for assistance.

Troubleshooting

No outdoor sensor

reception

no bars

If the wireless signal indicator shows no bars:

• Relocate the clock and/or the outdoor sensor. The units

must be within 330 ft (100 m) of each other.

• Make sure both units are placed at least 3 feet

(.9 m) away from electronics that may interfere with

the wireless communication (such as TVs, microwaves,

computers, etc).

• Use standard alkaline batteries (or lithium batteries

in sensor when temperature is below -4ºF/-20ºC). Do

not use heavy duty or rechargeable batteries. NOTE:

It may take up to 20 minutes for clock and sensor to

synchronize after batteries are replaced.

Clock is too dark, hard

to read or doesn’t

work

• Verify power adapter is plugged in.

• Check that the batteries are installed correctly. Batteries

may need to be replaced.

• Increase brightness using “”/ “” buttons, located

on the back of the clock.

• The optimum viewing angle for this product is from

slightly above it.

Inaccurate

temperature

• Make sure both the clock and sensor are placed out of

direct sunlight and away from any heat sources or vents

(see page 7).

Outdoor

temperature

is ashing or

showing dashes

Flashing of the outdoor temperature is generally an

indication of wireless interference.

1. Bring both the sensor and clock indoors, side by side

and remove batteries from each.

2. Make sure the A-B-C switch on both units match.

3. Reinstall batteries in outdoor sensor.

4. Reinstall batteries in clock.

5. Let the units sit within a couple feet of each other for

about 20 minutes to gain a strong connection.

Indice

Altri manuali ACU-RITE Sveglia

ACU-RITE

ACU-RITE Atomic Clock Manuale utente

ACU-RITE

ACU-RITE 13131A3 Manuale utente

ACU-RITE

ACU-RITE 13131A3 Manuale utente

ACU-RITE

ACU-RITE 47391 Manuale utente

ACU-RITE

ACU-RITE Set and Forget Manuale utente

ACU-RITE

ACU-RITE Intelli-Time 13019W2 Manuale utente

ACU-RITE

ACU-RITE 13239CC Manuale utente

ACU-RITE

ACU-RITE 13239CCDI Manuale utente

ACU-RITE

ACU-RITE 13020 Manuale utente

ACU-RITE

ACU-RITE Intelli-Time 13030 Manuale utente

ACU-RITE

ACU-RITE 13022 Manuale utente

ACU-RITE

ACU-RITE 13131 Manuale utente

ACU-RITE

ACU-RITE 15606 Manuale utente

ACU-RITE

ACU-RITE Intelli-Time 13027 Manuale utente

ACU-RITE

ACU-RITE Intelli-Time 13001 Istruzioni operative

ACU-RITE

ACU-RITE 47311 Manuale utente

ACU-RITE

ACU-RITE 13024 Manuale utente

ACU-RITE

ACU-RITE 13131A3 Manuale utente

ACU-RITE

ACU-RITE 13131W2 Manuale utente

ACU-RITE

ACU-RITE 15605 Manuale utente

ACU-RITE

ACU-RITE Intelli-Time 13027W5 Manuale utente

ACU-RITE

ACU-RITE 13021 Manuale utente

ACU-RITE

ACU-RITE 13019W2 Manuale utente

ACU-RITE

ACU-RITE 13036 Manuale utente

Manuali Sveglia popolari di altre marche

Steren

Steren CLK-210 Manuale utente

COP-USA

COP-USA ALCDVR32-SL Manuale utente

Philips

Philips HF3505/70 Manuale tecnico

Casio

Casio PQ-70 Manuale utente

iHome

iHome IA63 Manuale utente

Coopers

Coopers 9765 Manuale utente

ANJANK

ANJANK AC-190 Guida

TFA

TFA 98.1075 Manuale utente

Sharper Image

Sharper Image 204050 Manuale utente

Lumie

Lumie Zest Manuale utente

Dexford

Dexford RCT200 Manuale utente

Philips

Philips AJL303/37B Manuale utente

RST

RST Q754 Manuale utente

iHome

iHome iKT50 Manuale utente

Sony

Sony dash HID-B7 Manuale utente

SVINZ

SVINZ SCC009 Manuale utente

Clas Ohlson

Clas Ohlson 918863 Manuale utente

IKEA

IKEA FNURRA Manuale utente
