Adaptec USBConnect2000 Manuale utente
USER’SGUIDE
USBCONNECT 2000
Adaptec, Inc.
691 South Milpitas Boulevard
Milpitas, CA 95035
R
© 1999 Adaptec, Inc.
All rights reserved. Adaptec, and the Adaptec logo
are trademarks of Adaptec, Inc. which may be regis-
tered in some jurisdictions.
Printed in Singapore
STOCK NO.: 512323-00, Rev. A MO 7/99
R
▼ ▼ ▼ ▼ USBConnect 2000
User’s Guide
iii
▼ ▼ ▼ ▼ Contents
Introduction
Overview 1
Contents of Kit 2
System Requirements 2
Installing the USBConnect 2000 Adapter
Hardware Installation 3
Software Installation 4
Completing the Installation
Installing the Windows 98 Driver 5
Installing Macintosh 6
Understanding SCSI
SCSI IDs 7
Terminating the SCSI Bus 8
Obtaining SCSI Cables 8
Troubleshoting
Contacting Adaptec
Electronic Support 13
Technical and Product Support 14
Sales and Ordering Information 14
1
Introduction
Congratulations on your purchase of Adaptec’s USBConnectTM 2000
adapter. The USBConnect 2000 adapter allows SCSI devices to plug
into the Universal Serial Bus (USB) port of your PC or MAC
computer.
The built-in SCSI controller in the USBConnect 2000 adapter allows
you to connect up to seven SCSI devices to your desktop or portable
PC or MAC. These devices include the Iomega Jaz drive, CD-ROM
drives, hard disk drives, Magneto-optical (MO) drives and most
scanners.
Overview
The USBConnect 2000 adapter is designed as an integrated adapter
and 50-pin high-density (SCSI 2) connector and is available as a
■USB-to-SCSI with a 50 pin Micro-D SCSI-2 type connector
Note: The USBConnect 2000 adapter is designed as a self-
powered device and as such receives it’s power from the ter-
mination power line of the attached SCSI devices. As a
result, all SCSI devices must supply termination power.
Some devices such as the Iomega Zip drive and some
scanners do not provide termination power and therefore
can only be used if they are attached to the SCSI chain with
another SCSI device that provides termination power.
2
USBConnect 2000 User’s Guide
Contents of Kit
■USBConnect 2000 adapter
■CD-ROM for Windows®98 and Macintosh OS v8.5
■USBConnect 2000 adapter User’s Guide
■Registration Card
System Requirements
■Macintosh, PC or Portable PC with a USB compliant port
■Windows 98 on PC or Portable PCs or Macintosh v8.5 on iMac,
G3s or PowerBook
■SCSI device such as CD-ROM scanner, hard disk drive, Jaz
drive, MO or other SCSI device with termination power
3
Installing the USBConnect 2000 adapter
Installing the USBConnect
2000 adapter
The following information describes the hardware and software
installation for the USBConnect 2000 adapter.
Hardware Installation
Follow these steps to install the USBConnect 2000 adapter:
1Remove the USBConnect 2000 adapter from its packaging.
2Connect the USBConnect 2000 adapter into the SCSI device
you want to connect.
3Connect the USB connector (small end) into your systems USB
port. (See diagram below.)
4If attaching the USBConnect 2000 adapter through a USB hub,
we recommend using A/C powered hubs.
Note: The USBConnect 2000 adapter receives its +5V
power from the terminator power line of the attached SCSI
device. See Terminating the SCSI Bus, on page 8.
USB Port
USB Connect
4
USBConnect 2000 User’s Guide
Note: Do not turn on the power until the SCSI device is
attached to the USBConnect 2000 adapter. Once the attach-
ment is made, you can make the connection with the power
either on or off.
Note: The USBConnect 2000 adapter is hot-pluggable, that
is you can connect and disconnect it from a live system.
This completes the physical installation of your USBConnect 2000
adapter. Next you need to install the installation CD.
Software Installation
Follow these steps for the software installation of the USBConnect
2000 adapter:
1Insert the USBConnect 2000 adapter CD into the CD-ROM.
2Click Run, then type c:setup (or use the appropriate CD-ROM
letter) in the Run dialog box.
3Click OK.
4Follow the instructions on the screen to complete the setup
process.
