UltraWAVE Micro IP BS Plus
IP GSM Base Station Controller and Base Transceiver Station
www.adc.com • +1-952-938-8080 • 1-800-366-3891
Spec Sheet
The UltraWAVE Micro IP BS Plus is an integrated base station controller (BSC) and base transceiver
station (BTS) in a single enclosure.
UltraWAVE R4S softswitch and Micro IP BS Plus work hand-in-hand to reduce the total cost of
network ownership, providing a network growth path for existing and future customers, and
expand the addressable markets of ADC’s GSM products. They serve as the flagship GSM product
line for ADC.
Thanks to its All-IP architecture, Micro IP BS Plus backhauls traffic to carrier networks via an IP
connection over DSL or cable modem networks, this allows for faster and simpler setup and
configuration than any other products.
Key BS Plus Features:
SMS support•
Sectorization supported•
GPRS supported (CS-1, CS-2, CS-3, CS-4)•
2-way combined PA output at the antenna port•
Full alarm reporting to OMC•
10/08•106419AE UltraWAVE Micro IP BS Plus
UltraWAVE Micro IP BS Plus
IP GSM Base Station Controller and Base Transceiver Station
2
www.adc.com • +1-952-938-8080 • 1-800-366-3891
Features:
Availablein850,900,1800and1900MHzfrequencybands•
Frequencyhopping•
Sectorization•
General Packet Radio Service (GPRS)•
Dynamic power control (uplink and downlink)•
Significantly improved BTS sensitivity: -114 dBm (optimal combining diversity) or -111 dBm (no diversity)•
Remote monitoring: Temperature, fan, power supply (PSU), power amp, VSWR can be monitored from•
centralofceenablingremotediagnosisandquickrecovery
Externalalarmsforthirdpartyequipmentarealsosupported.•
Optional redundant power supply with PSU failure alarm support.•
-48 VDC power supply. AC rectifier available.•
Integratedfullracksolutionavailable:UltraWAVEintegratedwithadditionalon-siteequipmentsuchas•
transmission, battery backup, etc. in one rack.
Common hardware modules: single slot TRX, ICP, RFU.•
Supports AMR,EFR, FR codecs. Upgradable to EDGE.•
The Micro product line provides a compact and cost-effective platform, which helps lower the cost
of network ownership. They are easy to upgrade or repair in the field and provide a range of new
monitoring and control functions. The UltraWAVE Micro IP BS Plus supports up to two TRXs in one
chassis. With a single compact chassis, it can support an S11 or O2 site. It has the industry leading
poweramplifierofupto50Wattswhenconfiguredfor850,900,1800and1900MHzGSMnetworks.
MicrosupportsallthekeyBTSfeatures,suchasfrequencyhopping,sectorization,andGPRS.
The Micro IP BS Plus increases the BTS coverage with industry leading power output (50W measured at
antenna port without combining). Receive sensitivity with antenna diversity is up to -114 dBm. Designed
for easy expansion of the BTS capacity, the Micro BS Plus is field upgradable. Operators can start with a
small system and pay as they go to add capacity.
The Micro IP BS Plus is designed for low cost maintenance with remote monitoring, external alarms,
overheating protection, redundant power supply, field replaceable modules, and easy front access. It can
reduce the on-going operation expenses for the operators. An integrated turn-key BTS package option
isavailablewithtransmission,battery,andothersiteequipment.
10/08•106419AE UltraWAVE Micro IP BS Plus
UltraWAVE Micro IP BS Plus
IP GSM Base Station Controller and Base Transceiver Station
3
www.adc.com • +1-952-938-8080 • 1-800-366-3891
Specifications
BTS Configurations (single cabinet): O1, O2, S11
Frequency Support: GSM850MHz,GSM900MHz,DCS1800MHz,PCS1900MHz
CAPACITY
Number of TRXs: 2 internal
Number of Traffic Channels: 15EFRtrafficchannelsor30AMR/HRtrafficchannels
Traffic Capacity: 9.0Erlangs@2%GoS(O2,EFR)
21.4Erlangs@2%GoS(O2,AMR/HR)
Output Power: Up to 50 Watts
Speech Coding: EFR,AMR/HR5.9kbps
RF Receiver Sensitivity: -111dBm without diversity
-114 dBm with diversity
INTERFACES
RF Interface: GSMCompliantUmInterface;GSMSpec.04.06,04.08,05.01-05.05,
05.08&05.10;GSMspec03.64,04.60(Rel98)
MSC Interface: Compliant A interface over SIGTRAN
Network Interface: 100 Mbps Ethernet, RJ-45 connector
Serial Port: RS232, RJ-45 connector
OPERATION
Remote Monitoring: Monitor temperature, PA, fan, PSU, VWSR from central office;
External alarms supported
Overtemp Protection: Automatic detection and intervention
Access to Equipment: Front and Rear Access
Field Support: All modules are field replaceable
POWER SUPPLY
Input Voltage: -48 VDC; 110/220 VAC optional
Redundancy: Redundant power supply
Alarm: PSU failure alarm reported OMC
MECHANICAL
Rack Mount: Versatilemountingoptionsfor19”,23”and24”racks
Radio Chassis Dimensions (HxWxD):1051x560x647mm(41.8x22.05x25.5inches)
Weight: 213kg(470lbs)
OPERATING ENVIRONMENT
Temperature: -5° to 55° C (23° to 131° F)
Humidity (non-condensing): 10%to90%
COMPLIANCE: EN60950,UL60950
FCClicensefor850MHz/1900MHz
CEmarkingfor900MHz/1800MHz
Spec Sheet
Website: www.adc.com
FromNorthAmerica,CallTollFree:1-800-366-3891•OutsideofNorthAmerica:+1-952-938-8080
Fax:+1-952-917-3237•ForalistingofADC’sglobalsalesofficelocations,pleaserefertoourwebsite.
ADC Telecommunications, Inc., P.O. Box 1101, Minneapolis, Minnesota USA 55440-1101
Specifications published here are current as of the date of publication of this document. Because we are continuously
improving our products, ADC reserves the right to change specifications without prior notice. At any time, you may
verify product specifications by contacting our headquarters office in Minneapolis. ADC Telecommunications, Inc.
views its patent portfolio as an important corporate asset and vigorously enforces its patents. Products or features
containedhereinmaybecoveredbyoneormoreU.S.orforeignpatents.AnEqualOpportunityEmployer
106419AE 10/08 Original © 2008 ADC Telecommunications, Inc. All Rights Reserved
