Spec Sheet

OmniReach™FTTX Solutions

Outdoor Fiber Distribution Terminal 48 (oFDT-48)

The ADC Outdoor Fiber Distribution Terminal 48F (oFDT-48) is designed to terminate, splice

and interconnect fiber optic cables in an outdoor environment. This terminal may be adapted to

Fiber-to-The-Premise (FTTP) Multiple Dwelling Unit (MDU) applications by mounting the enclosure

to the exterior surface of a dwelling and connecting between the distribution cable and drops

routed to individual living units. The oFDT-48 is typically divided into two side-by-side sections

with distribution cable routed into one side and drop cable routed into the other side. The cables

meet at a central connector field that includes termination for the distribution cable and parking

for the drop cables. Each side of the cabinet may be configured with splice trays for splicing

the cable to connector pigtails. The oFDT-48 may be pre-terminated on the distribution side

with outside plant cable stubs so that the unit is quickly connected to the plant. The oFDT-48 may

be pre-wired with pigtails on the drop side so that individual drops routed into the unit can be

spliced to the connectorized pigtails.

The unit accommodates a variety of OSP cable types via sealed grommet entry. Cables are secured

with standard grip clamps to provide required pull out strength. The enclosure provides grounding

for metallic members and for the cabinet.

7/07 • 103333AE OmniReach™FTTX Solutions

www.adc.com • +1-952-938-8080 • 1-800-366-3891

OmniReach™FTTX Solutions

Outdoor Fiber Distribution Terminal

48 (oFDT-48)

Sizes

The oFDT-48 product accommodates up to 48 living units. Distribution cable fibers are terminated

on standard SC/APC adapters that are easily accessible for service connection and maintenance. Drop

pigtails are initially terminated on parking adapters adjacent to the distribution termination adapters and

staged at the parking positions until the living units request service. Moving the drop pigtails from the

parking position to the assigned distribution fiber easily makes service connections.

Mounting Applications

All units are configurable for a variety of mounting arrangements including wall, pole and pedestal

mounting. Each unit is provided nominally with a wall mount bracket. Optional pole-mount brackets

and pedestals may be ordered separately.

Special Features

These heavy gauge aluminum enclosures provide the necessary protection against rain, wind, dust,

rodents and other environmental contaminants while remaining lightweight for easy installation.

The aluminum construction with heavy powder coat finish also provides for corrosion resistance.

Features and Benefits

• Environmental enclosure provides heavy-

duty protection from wind, rain, and other

contaminants

• Aluminum welded construction provides

strength and resists corrosion

• Flexible design accommodates 24 and 48

fibers including termination and parking

• Lightweight structure provides for easy

installation

• Lockable tool or padlock offers flexible

security options

• Cable entrance ports seal cable at entry

• Cable management and routing limits radius

and adds strain relief

7/07 • 103333AE OmniReach™FTTX Solutions

www.adc.com • +1-952-938-8080 • 1-800-366-3891

OmniReach™FTTX Solutions

Outdoor Fiber Distribution Terminal

48 (oFDT-48)

Specifications

oFDT-48

Height 22.0 in (56 cm)

Width 20.0 in (51 cm)

Depth 10.0 in (25 cm)

Weight (Empty) 21.0 lbs (46 kg)

Fiber Terminations Up to 48

Parking Adapters 12, 24 or 48

Splice Trays 1 to 4/side

Cable Ports 2 on bottom

Color Beige

Ordering Information

Enclosure

F OFDT-48

Connector Type

J SC/APC

Splice Tray

0 No Tray

2 Heat Shrink Fusion

3 Mechanical/Ribbon

Fiber Count

24 24 Fibers

48 48 Fibers

Parking

P Parking

N No Parking

Pigtails

P Pigtails (2mm)

X No Pigtails

Cable Type

Pigtails

Bare Ribbon Pigtail Assembly

C Pigtails (Colored)

Stubs

S Ribbon OSP w/Conn

R Ribbon IFC w/Conn

T Loose Tube OSP w/Conn

V Loose Tube IFC w/Conn

Stub Length

000 0 Feet

025 25 Feet

100 100 Feet

200 200 Feet

300 300 Feet

500 500 Feet

Catalog Number

FDT- __ __ __ __ __ __ __ __ __ __ __

Website: www.adc.com

From North America, Call Toll Free: 1-800-366-3891 • Outside of North America: +1-952-938-8080

Fax: +1-952-917-3237 • For a listing of ADC’s global sales office locations, please refer to our website.

ADC Telecommunications, Inc., P.O. Box 1101, Minneapolis, Minnesota USA 55440-1101

Specifications published here are current as of the date of publication of this document. Because we are continuously

improving our products, ADC reserves the right to change specifications without prior notice. At any time, you may

verify product specifications by contacting our headquarters office in Minneapolis. ADC Telecommunications, Inc.

views its patent portfolio as an important corporate asset and vigorously enforces its patents. Products or features

contained herein may be covered by one or more U.S. or foreign patents. An Equal Opportunity Employer

Spec Sheet
