ADF Web HD67C54 Manuale utente

Industrial Electronic Devices

ADFweb.com S.r.l.

User Manual

EnOcean

Mod

bus TCP

Slave

Document code: MN67C54_ENG Revision 1 000 Page 1 of 27

User Manual

Revision 1 000

English

EnOcean / Modbus TCP Slave - Converter

(Order Code: HD67C54-B2)

For Website information:

www adfweb com?Product=HD67C54-B2

For Price information:

www adfweb com?Price=HD67C54-B2

Benefits and Main Features:

Very easy to configure

Power Supply 18…35V DC and 8…24 V AC

Temperature range: -40°C/+85°C (-40°F/+185°F)

For others EnOcean products, see also the following links:

Converter EnOcean to

www adfweb com?Product=HD67C50 (Serial)

www adfweb com?Product=HD67C52 (Modbus Slave)

www adfweb com?Product=HD67C54 (Modbus TCP Slave)

www adfweb com?Product=HD67C56 (BACnet Slave)

www adfweb com?Product=HD67C57 (CA )

www adfweb com?Product=HD67C58 (CA open)

www adfweb com?Product=HD67C61 (Device et Slave)

www adfweb com?Product=HD67C63 (Ether et/IP Slave)

www adfweb com?Product=HD67C65 (IEC61850 Server)

www adfweb com?Product=HD67C66 (J1939)

www adfweb com?Product=HD67C67 (K X)

www adfweb com?Product=HD67C70 (MQTT)

www adfweb com?Product=HD67C72 ( MEA 0183)

www adfweb com?Product=HD67C73 ( MEA 2000)

www adfweb com?Product=HD67C75 (PROFIBUS Slave)

www adfweb com?Product=HD67C77 (PROFI ET Slave)

www adfweb com?Product=HD67C79 (S MP Agent)

Do you need to choose a device? Do you want help?

www adfweb com?Cmd=helpme

User Manual

Industrial Electronic Devices

ADFweb.com S.r.l.

User Manual

EnOcean

Mod

bus TCP

Slave

Document code: MN67C54_ENG Revision 1 000 Page 2 of 27

I DEX:

Page

INDEX 2

UPDATED DOCUMENTATION 2

REVISION LIST 2

WARNING 2

TRADEMARKS 2

SECURITY ALERT 3

EXAMPLE OF CONNECTION 4

CONNECTION SCHEME 5

CHARACTERISTICS 6

CONFIGURATION 6

POWER SUPPLY 7

FUNCTION MODES 8

LEDS 9

ETHERNET 10

ENOCEAN 11

USE OF COMPOSITOR SW67C54 12

NEW CONFIGURATION / OPEN CONFIGURATION 13

SOFTWARE OPTIONS 14

SET COMMUNICATION 16

ENOCEAN ACCESS 17

UPDATE DEVICE 20

MODBUS MAP 22

MECHANICAL DIMENSIONS 24

ORDERING INFORMATIONS 25

ACCESSORIES 25

DISCLAIMER 26

OTHER REGULATIONS AND STANDARDS 26

WARRANTIES AND TECHNICAL SUPPORT 27

RETURN POLICY 27

UPDATED DOCUME TATIO :

Dear customer, we thank you for your attention and we remind you that

you need to check that the following document is:

Updated

Related to the product you own

To obtain the most recently updated document, note the “document code”

that appears at the top right-hand corner of each page of this document

With this “Document Code” go to web page www adfweb com/download/

and search for the corresponding code on the page Click on the proper

“Document Code” and download the updates

REVISIO LIST:

WAR I G:

ADFweb com reserves the right to change information in this manual about

our product without warning

ADFweb com is not responsible for any error this manual may contain

TRADEMARKS:

All trademarks mentioned in this document belong to their respective

owners

Revision

Date Author Chapter

Description

1 000 05/12/2019

Ff All First release version

Industrial Electronic Devices

ADFweb.com S.r.l.

User Manual

EnOcean

Mod

bus TCP

Slave

Document code: MN67C54_ENG Revision 1 000 Page 3 of 27

SECURITY ALERT:

E ERAL

FORMATIO

To ensure safe operation, the device must be operated according to the instructions in the manual When using the device, legal and

safety regulation are required for each individual application The same applies also when using accessories

TE DED

Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i e

independent limit switches, mechanical interlocks, etc )

UALIFIED

ERSO EL

The device can be used only by qualified personnel, strictly in accordance with the specifications

Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and

who have appropriate qualifications for their job

ESIDUAL

ISKS

The device is state-of-the-art and is safe The instruments can represent a potential hazard if they are inappropriately installed and

operated by untrained personnel These instructions refer to residual risks with the following symbol:

This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or

death and / or the possibility of damage

CO FORMITY

The declaration is made by our company You can send an email to support@adfweb com or give us a call if you need it

Industrial Electronic Devices

ADFweb.com S.r.l.

User Manual

EnOcean

Mod

bus TCP

Slave

Document code: MN67C54_ENG Revision 1 000 Page 4 of 27

EXAMPLE OF CO ECTIO :

Industrial Electronic Devices

ADFweb.com S.r.l.

User Manual

EnOcean

Mod

bus TCP

Slave

Document code: MN67C54_ENG Revision 1 000 Page 5 of 27

CO ECTIO SCHEME:

Figure 1: Connection scheme for HD67C54- 2

Industrial Electronic Devices

ADFweb.com S.r.l.

User Manual

EnOcean

Mod

bus TCP

Slave

Document code: MN67C54_ENG Revision 1 000 Page 6 of 27

CHARACTERISTICS:

The HD67C54-B2 is a EnOcean / Modbus TCP Slave Converter

It allows the following characteristics:

Electrical isolation between Ethernet and Power Supply;

Mountable on 35mm Rail DIN;

Wide power supply input range: 18…35V DC and 8…24V AC;

Wide temperature range: -40°C / 85°C [-40°F / +185°F]

CO FIGURATIO :

You need Compositor SW67C54 software on your PC in order to perform the following:

Define the parameter of Modbus TCP line;

Define the parameter of EnOcean line;

Update the device

Industrial Electronic Devices

ADFweb.com S.r.l.

User Manual

EnOcean

Mod

bus TCP

Slave

Document code: MN67C54_ENG Revision 1 000 Page 7 of 27

POWER SUPPLY:

The devices can be powered at 8…24V AC and 12…35V DC For more details see the two tables below

VAC

VDC

Vmin Vmax Vmin Vmax

8V 24V 12V 35V

Consumption at 24V DC:

Device Consumption [W/VA]

HD67C54-B2 3 5

HD67C54-B2

Caution: ot reverse the polarity power

Industrial Electronic Devices

ADFweb.com S.r.l.

User Manual

EnOcean

Mod

bus TCP

Slave

Document code: MN67C54_ENG Revision 1 000 Page 8 of 27

FU CTIO MODES:

The device has got two functions mode depending of the position of the ‘Dip1 of Dip-Switch A’:

The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device

The second, with ‘Dip1 of Dip-Switch A’ at “ON” position, is used for upload the Project and/or Firmware

For the operations to follow for the updating, see ‘UPDATE DEVICE’ section

According to the functioning mode, the LEDs will have specifics functions, see ‘LEDS’ section

Industrial Electronic Devices

ADFweb.com S.r.l.

User Manual

EnOcean

Mod

bus TCP

Slave

Document code: MN67C54_ENG Revision 1 000 Page 9 of 27

LEDS:

The device has got four LEDs that are used to give information of the functioning status

The various meanings of the LEDs are described in the table below

LED ormal Mode Boot Mode

1: Device State (green) Blinks slowly (~1Hz) Blinks quickly: Boot state

Blinks very slowly (~0.5Hz): update in progress

2: EnOcean communication

(yellow) Blinks when EnOcean data is received Blinks quickly: Boot state

Blinks very slowly (~0.5Hz): update in progress

3: Modbus TCP

communication (yellow) Blinks when Modbus TCP communication is running Blinks quickly: Boot state

Blinks very slowly (~0.5Hz): update in progress

4: Error state (yellow) O : An error in the communication busses occurs

OFF: No errors are present

Blinks quickly: Boot state

Blinks very slowly (~0.5Hz): update in progress

Industrial Electronic Devices

ADFweb.com S.r.l.

User Manual

EnOcean

Mod

bus TCP

Slave

Document code: MN67C54_ENG Revision 1 000 Page 10 of 27

ETHER ET:

The Ethernet port is used for programming the device and for Modbus TCP communication

The Ethernet connection must be made using Connector2 of HD67C54-B2 with at least a Category 5E cable The maximum length of the

cable should not exceed 100m The cable has to conform to the T568 norms relative to connections in cat 5 up to 100 Mbps To connect the

device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC is recommended the use of a cross cable
