Advantech ADAM-6541 Manuale utente

ADAM-6541

10/100Base-TX Ethernet to

100Base-FX Multi-Mode

Fiber Optic Converter

User Manual

ADAM-6541 User Manual ii

The documentation and the software included with this product are copy-

righted 2006 by Advantech Co., Ltd. All rights are reserved. Advantech

Co., Ltd. reserves the right to make improvements in the products

described in this manual at any time without notice. No part of this man-

ual may be reproduced, copied, translated or transmitted in any form or

by any means without the prior written permission of Advantech Co., Ltd.

Information provided in this manual is intended to be accurate and reli-

able. However, Advantech Co., Ltd. assumes no responsibility for its use,

nor for any infringements of the rights of third parties, which may result

from its use.

Acknowledgements

Intel and Pentium are trademarks of Intel Corporation.

Microsoft Windows and MS-DOS are registered trademarks of

Microsoft Corp.

All other product names or trademarks are properties of their respective

owners.

This manual covers the following models:

• ADAM-6541

• ADAM-6541/ST

Part No. 2003654101 2nd Edition

Printed in Taiwan March 2006

iii

Product Warranty (2 years)

Advantech warrants to you, the original purchaser, that each of its prod-

ucts will be free from defects in materials and workmanship for two years

from the date of purchase.

This warranty does not apply to any products which have been repaired or

altered by persons other than repair personnel authorized by Advantech,

or which have been subject to misuse, abuse, accident or improper instal-

lation. Advantech assumes no liability under the terms of this warranty as

a consequence of such events.

Because of Advantech’s high quality-control standards and rigorous test-

ing, most of our customers never need to use our repair service. If an

Advantech product is defective, it will be repaired or replaced at no

charge during the warranty period. For out-of-warranty repairs, you will

be billed according to the cost of replacement materials, service time and

freight. Please consult your dealer for more details.

If you think you have a defective product, follow these steps:

1. Collect all the information about the problem encountered. (For

example, CPU speed, Advantech products used, other hardware

and software used, etc.) Note anything abnormal and list any

onscreen messages you get when the problem occurs.

2. Call your dealer and describe the problem. Please have your man-

ual, product, and any helpful information readily available.

3. If your product is diagnosed as defective, obtain an RMA (return

merchandize authorization) number from your dealer. This allows

us to process your return more quickly.

4. Carefully pack the defective product, a fully-completed Repair and

Replacement Order Card and a photocopy proof of purchase date

(such as your sales receipt) in a shippable container. A product

returned without proof of the purchase date is not eligible for war-

ranty service.

5. Write the RMA number visibly on the outside of the package and

ship it prepaid to your dealer.

ADAM-6541 User Manual iv

Declaration of Conformity

This product has passed the CE test for environmental specifications

when shielded cables are used for external wiring. We recommend the use

of shielded cables. This kind of cable is available from Advantech. Please

contact your local supplier for ordering information.

This product has passed the CE test for environmental specifications. Test

conditions for passing included the equipment being operated within an

industrial enclosure. In order to protect the product from being damaged

by ESD (Electrostatic Discharge) and EMI leakage, we strongly recom-

mend the use of CE-compliant industrial enclosure products.

FCC Class A

Note: This equipment has been tested and found to comply with the limits

for a Class A digital device, pursuant to part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environ-

ment. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instruction

manual, may cause harmful interference to radio communications. Opera-

tion of this equipment in a residential area is likely to cause harmful inter-

ference in which case the user will be required to correct the interference

at his own expense.

Safety Precaution - Static Electricity

Follow these simple precautions to protect yourself from harm and the

products from damage.

1. To avoid electrical shock, always disconnect the power from your

PC chassis before you work on it. Don't touch any components on

the CPU card or other cards while the PC is on.

Disconnect power before making any configuration changes. The sudden

rush of power as you connect a jumper or install a card may damage sen-

sitive electronic components.

Technical Support and Assistance

Step 1. Visit the Advantech web site at www.advantech.com/support

where you can find the latest information about the product.

Step 2. Contact your distributor, sales representative, or Advantech's cus-

tomer service center for technical support if you need additional

assistance. Please have the following information ready before

you call:

- Product name and serial number

- Description of your peripheral attachments

- Description of your software (operating system, version, appli-

cation software, etc.)

- A complete description of the problem

- The exact wording of any error messages

ADAM-6541 User Manual vi

vii Table of Contents

Contents

Chapter 1 Overview .......................................................... 2

1.1 Introduction ....................................................................... 2

1.2 Features ............................................................................. 3

1.3 Specifications .................................................................... 3

1.4 Ordering Information ........................................................ 4

Chapter 2 Installation ....................................................... 6

2.1 LED Indicators .................................................................. 6

Table 2.1:ADAM-6541 LED Definition ....................... 6

2.2 Dimensions (units:mm) ..................................................... 7

Figure 2.1:ADAM-6541-Front Panel ............................ 7

Figure 2.2:ADAM-6541-Bottom ................................... 7

2.3 Full / Half-Duplex Selection ............................................. 8

2.4 Connecting the Hardware.................................................. 9

2.4.1 Choosing a Location ...................................................... 9

Figure 2.3:Figure 2-3 Panel Mounting .......................... 9

Figure 2.4:Din Rail Mounting ..................................... 10

Figure 2.5:Figure2-5 Piggyback Stack ........................ 11

2.5 Network Connection ....................................................... 11

2.5.1 Connection to the devices ............................................ 11

2.5.2 Connection to other Hubs or Switch ............................ 12

2.5.3 Connection to fiber network ........................................ 12

2.5.4 Power Connection ........................................................ 12

Appendix A Pin Assignments & Wiring........................... 14

Figure A.1:RJ-45 Pin Assignment ............................... 14

Figure A.2:EIA/TIA-568B ........................................... 14

ADAM-6541 User Manual viii

CHAPTER

Overview

This chapter gives an overview of

ADAM-6541 modules.

Sections include:

• Introduction

• Features

• Specifications

• Ordering Information

ADAM-6541 User Manual 2

Chapter 1 Overview

1.1 Introduction

The ADAM-6541 is an industrial grade converter designed to convert

Ethernet network (10/100Base-TX) to fiber network (100Base-FX). It

transparently converts Ethernet signals into optic signals. The advantages

of Fiber optic are wide bandwidth, anti-EMI and suitable for long-dis-

tance transmission. Therefore, ADAM-6541 is an ideal solution for “fiber

to building” application in central offices or local sites.

The ADAM-6541 can be mounted in the following three ways: DIN Rail,

panel, piggyback mounting. +10~30 VDC operating voltages are also sup-

plied over the terminal block. In addition, the operating temperature

ranges from -10 ~ 65° C. The above functions make the ADAM-6541 a

stable and reliable industrial grade converter.

High-Speed Transmissions

The ADAM-6541 supports MDI/MDI-X of auto detection. You will not

need to crossover. A switch controller that can automatically sense trans-

mission speed (10/100 Mbps) will be included. Both Ethernet and fiber

ports have memory buffers that support store-and-forward mechanism; it

assures proper data transmission.

Flexible Mounting

The ADAM-6541 is extremely compact and can be mounted in three dif-

ferent ways: DIN rail, panel and piggyback mounting.

Easy Troubleshooting

The ADAM-6541 provides three LED indicators: Power, Full/Link, 10/

100Mbps, which easily let you troubleshoot.

Robust Enough for Industrial Environments

The ADAM-6541 can normally work from -10° C to 65° C and accepts

wide unregulated voltage range from +10 ~ 30 VDC. Besides, it also pro-

vides 3,000 VDC surge protection (EFT) to protect it from over-voltage

damages. It is suitable for any harsh operating environment.
