AEG IPE84531FB Manuale utente
USER
MANUAL
EN User Manual
Hob
IPE84531FB
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you impeccable
performance for many years, with innovative technologies that help make life simpler –
features you might not find on ordinary appliances. Please spend a few minutes reading
to get the very best from it.
Visit our website to:
Get usage advice, brochures, trouble shooter, service and repair information:
www.aeg.com/support
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following data
available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
CONTENTS
1. SAFETY INFORMATION................................................................................................ 2
2. SAFETY INSTRUCTIONS.............................................................................................. 4
3. INSTALLATION...............................................................................................................7
4. PRODUCT DESCRIPTION.............................................................................................8
5. DAILY USE......................................................................................................................9
6. HINTS AND TIPS..........................................................................................................13
7. CARE AND CLEANING................................................................................................ 15
8. TROUBLESHOOTING.................................................................................................. 16
9. TECHNICAL DATA....................................................................................................... 17
10. ENERGY EFFICIENCY...............................................................................................18
11. ENVIRONMENTAL CONCERNS................................................................................19
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible
for any injuries or damage that are the result of incorrect
2 ENGLISH
installation or usage. Always keep the instructions in a safe
and accessible location for future reference.
1.1 Children and vulnerable people safety
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved. Children of less than 8 years of age and
persons with very extensive and complex disabilities shall
be kept away from the appliance unless continuously
supervised.
•Children should be supervised to ensure that they do not
play with the appliance.
•Keep all packaging away from children and dispose of it
appropriately.
•WARNING: Keep children and pets away from the
appliance when it operates or when it cools down.
Accessible parts become hot during use.
•If the appliance has a child safety device, it should be
activated.
•Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
1.2 General Safety
•WARNING: The appliance and its accessible parts become
hot during use. Care should be taken to avoid touching
heating elements.
•WARNING: Unattended cooking on a hob with fat or oil can
be dangerous and may result in fire.
•NEVER try to extinguish a fire with water, but switch off the
appliance and then cover flame e.g. with a lid or a fire
blanket.
•WARNING: The appliance must not be supplied through an
external switching device, such as a timer, or connected to
a circuit that is regularly switched on and off by a utility.
ENGLISH 3
•CAUTION: The cooking process has to be supervised. A
short term cooking process has to be supervised
continuously.
•WARNING: Danger of fire: Do not store items on the
cooking surfaces.
•Metallic objects such as knives, forks, spoons and lids
should not be placed on the hob surface since they can get
hot.
•Do not use the appliance before installing it in the built-in
structure.
•Do not use a steam cleaner to clean the appliance.
•After use, switch off the hob element by its control and do
not rely on the pan detector.
•If the glass ceramic surface / glass surface is cracked,
switch off the appliance and unplug it from the mains. In
case the appliance is connected to the mains directly using
junction box, remove the fuse to disconnect the appliance
from power supply. In either case contact the Authorised
Service Centre.
•If the supply cord is damaged, it must be replaced by the
manufacturer, an authorized Service or similarly qualified
persons in order to avoid a hazard.
•WARNING: Use only hob guards designed by the
manufacturer of the cooking appliance or indicated by the
manufacturer of the appliance in the instructions for use as
suitable or hob guards incorporated in the appliance. The
use of inappropriate guards can cause accidents.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must
install this appliance.
WARNING!
Risk of injury or damage to the
appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions
supplied with the appliance.
• Keep the minimum distance from other
appliances and units.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
4 ENGLISH
• Seal the cut surfaces with a sealant to
prevent moisture from causing swelling.
• Protect the bottom of the appliance from
steam and moisture.
• Do not install the appliance next to a door
or under a window. This prevents hot
cookware from falling from the appliance
when the door or the window is opened.
• Each appliance has cooling fans on the
bottom.
• If the appliance is installed above a
drawer:
– Do not store any small pieces or
sheets of paper that could be pulled
in, as they can damage the cooling
fans or impair the cooling system.
– Keep a distance of minimum 2 cm
between the bottom of the appliance
and parts stored in the drawer.
• Remove any separator panels installed in
the cabinet below the appliance.
2.2 Electrical Connection
WARNING!
Risk of fire and electric shock.
• All electrical connections should be made
by a qualified electrician.
• The appliance must be earthed.
• Before carrying out any operation make
sure that the appliance is disconnected
from the power supply.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Make sure the appliance is installed
correctly. Loose and incorrect electricity
mains cable or plug (if applicable) can
make the terminal become too hot.
• Use the correct electricity mains cable.
• Do not let the electricity mains cable
tangle.
• Make sure that a shock protection is
installed.
• Use the strain relief clamp on the cable.
• Make sure the mains cable or plug (if
applicable) does not touch the hot
appliance or hot cookware, when you
connect the appliance to a socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug (if applicable) or to the mains
cable. Contact our Authorised Service
Centre or an electrician to change a
damaged mains cable.
• The shock protection of live and insulated
parts must be fastened in such a way that
it cannot be removed without tools.
• Connect the mains plug to the mains
socket only at the end of the installation.
Make sure that there is access to the
mains plug after the installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to disconnect
the appliance. Always pull the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have an
isolation device which lets you disconnect
the appliance from the mains at all poles.
The isolation device must have a contact
opening width of minimum 3 mm.
2.3 Use
WARNING!
Risk of injury, burns and electric
shock.
• Remove all the packaging, labelling and
protective film (if applicable) before first
use.
• This appliance is for household (indoors)
use only.
• Do not change the specification of this
appliance.
• Make sure that the ventilation openings
are not blocked.
• Do not let the appliance stay unattended
during operation.
• Set the cooking zone to “off” after each
use.
• Do not put cutlery or saucepan lids on the
cooking zones. They can become hot.
• Do not operate the appliance with wet
hands or when it has contact with water.
• Do not use the appliance as a work
surface or as a storage surface.
• If the surface of the appliance is cracked,
disconnect immediately the appliance
ENGLISH 5
from the power supply. This to prevent an
electrical shock.
• Users with a pacemaker must keep a
distance of minimum 30 cm from the
induction cooking zones when the
appliance is in operation.
• When you place food into hot oil, it may
splash.
WARNING!
Risk of fire and explosion
• Fats and oil when heated can release
flammable vapours. Keep flames or
heated objects away from fats and oils
when you cook with them.
• The vapours that very hot oil releases can
cause spontaneous combustion.
• Used oil, that can contain food remnants,
can cause fire at a lower temperature than
oil used for the first time.
• Do not put flammable products or items
that are wet with flammable products in,
near or on the appliance.
WARNING!
Risk of damage to the appliance.
• Do not keep hot cookware on the control
panel.
• Do not put a hot pan cover on the glass
surface of the hob.
• Do not let cookware boil dry.
• Be careful not to let objects or cookware
fall on the appliance. The surface can be
damaged.
• Do not activate the cooking zones with
empty cookware or without cookware.
• Do not put aluminium foil on the
appliance.
• Cookware made of cast iron, aluminium or
with a damaged bottom can cause
scratches on the glass / glass ceramic.
Always lift these objects up when you
have to move them on the cooking
surface.
• This appliance is for cooking purposes
only. It must not be used for other
purposes, for example room heating.
2.4 Care and cleaning
• Clean the appliance regularly to prevent
the deterioration of the surface material.
• Switch off the appliance and let it cool
down before cleaning.
• Do not use water spray and steam to
clean the appliance.
• Clean the appliance with a moist soft
cloth. Use only neutral detergents. Do not
use abrasive products, abrasive cleaning
pads, solvents or metal objects.
2.5 Service
• To repair the appliance contact the
Authorised Service Centre. Use original
spare parts only.
• Concerning the lamp(s) inside this product
and spare part lamps sold separately:
These lamps are intended to withstand
extreme physical conditions in household
appliances, such as temperature,
vibration, humidity, or are intended to
signal information about the operational
status of the appliance. They are not
intended to be used in other applications
and are not suitable for household room
illumination.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Contact your municipal authority for
information on how to dispose of the
appliance.
• Disconnect the appliance from the mains
supply.
• Cut off the mains electrical cable close to
the appliance and dispose of it.
6 ENGLISH
3. INSTALLATION
WARNING!
Refer to Safety chapters.
3.1 Before the installation
Before you install the hob, write down the
information below from the rating plate. The
rating plate is on the bottom of the hob.
Serial number ...........................
3.2 Built-in hobs
Only use the built-in hobs after you assemble
the hob into correct built-in units and work
surfaces that align to the standards.
3.3 Connection cable
• For a single phase or two phase
connection, use the cable type: H03V2V2-
F or H05BB-F which withstands a
temperature of 90 °C or higher.
• To replace the damaged mains cable, use
the cable: H03V2V2-F or H05BB-F which
withstands a temperature of 90 °C or
higher. Contact an Authorised Service
Centre. The connection cable may only be
replaced by a qualified electrician.
3.4 Assembly
If you install the hob under a hood, please
see the installation instructions of the hood
for the minimum distance between the
appliances.
min.
50mm
min.
500mm
If the appliance is installed above a drawer,
the hob ventilation can warm up the items
stored in the drawer during the cooking
process.
Find the video tutorial "How to install your
AEG Induction Hob - Worktop installation" by
typing out the full name indicated in the
graphic below.
ENGLISH 7
www.youtube.com/electrolux
www.youtube.com/aeg
How to install your AEG
Induction Hob - Worktop installation
4. PRODUCT DESCRIPTION
4.1 Cooking surface layout
1 1
11
2
1Induction cooking zone
2Control panel
4.2 Control panel layout
68
19
2
345
7
To see the control panel and the zone positions activate the appliance with
Use the sensor fields to operate the appliance. The displays, indicators and sounds tell which
functions operate.
Sensor
field
Function Comment
1ON / OFF To activate and deactivate the hob.
2Hob²Hood To activate and deactivate the manual mode of the func‐
tion.
8 ENGLISH
Sensor
field
Function Comment
3Pause To activate and deactivate the function.
4 / - To increase or decrease the time.
5- To set the timer function.
6- Timer display To show the time in minutes.
7- Control bar To set a heat setting.
8PowerBoost To activate the function.
9Lock / Child Safety Device To lock / unlock the control panel.
4.3 OptiHeat Control (3 step
Residual heat indicator)
WARNING!
/ / As long as the
indicator is on, there is a risk of
burns from residual heat.
The induction cooking zones produce the
heat necessary for the cooking process
directly in the bottom of the cookware. The
glass ceramic is heated by the heat of the
cookware.
The indicators / / appear when a
cooking zone is hot. They show the level of
the residual heat for the cooking zones you
are currently using.
The indicator may also appear:
• for the neighbouring cooking zones even
if you are not using them,
• when hot cookware is placed on cold
cooking zone,
• when the hob is deactivated but the
cooking zone is still hot.
The indicator disappears when the cooking
zone has cooled down.
5. DAILY USE
WARNING!
Refer to Safety chapters.
5.1 Activating and deactivating
Touch for 1 second to activate or
deactivate the hob.
The control panel comes on after you
activate the hob and goes off after you
deactivate the hob.
When the hob is deactivated you can only
see .
5.2 Automatic Switch Off
The function deactivates the hob
automatically if:
• you do not place any cookware on the
hob for 50 seconds,
• you do not set the heat setting for 50
seconds after you place the cookware,
• you spill something or put something on
the control panel for more than 10
seconds (a pan, a cloth). When you hear
the acoustic signal, the hob deactivates.
Remove the object or clean the control
panel.
ENGLISH 9
• the hob gets too hot (e.g. when a
saucepan boils dry). Let the cooking zone
cool down before you use the hob again.
• you do not deactivate a cooking zone or
change the heat setting. After some time,
the hob deactivates.
The relation between the heat setting and
the time after which the hob deactivates:
Heat setting The hob deactivates
after
1 - 2 6 hours
3 - 4 5 hours
5 4 hours
6 - 9 1.5 hours
5.3 Using the cooking zones
CAUTION!
Do not place hot cookware on
the control panel. There is a risk
of damage to the electronic
parts.
Place the cookware in the centre of the
selected zone. Induction cooking zones
adapt to the dimension of the bottom of the
cookware automatically.
Once the pot is detected, the heat setting 0
comes on.
5.4 Heat setting
1. Press the desired heat setting on the
control bar. You can also move your
finger along the control bar to set or
change the heat setting for a cooking
zone.
2. To deactivate a cooking zone, press 0.
Once you place a pot on the cooking zone
and set the heat setting, it remains the same
for 50 seconds after you remove the pot. The
control bar blinks for the second half of that
time. If you place the pot on the cooking zone
again within this time, the heat setting
reactivates. Otherwise the cooking zone
deactivates.
5.5 PowerBoost
This function activates more power for the
appropriate induction cooking zone,
depending on the cookware size. The
function can be activated only for a limited
period of time.
Touch to activate the function for the
cooking zone.
The function deactivates automatically.
For maximum duration values,
refer to "Technical data".
5.6 Timer
Count Down Timer
Use this function to specify how long a
cooking zone should operate during a single
cooking session.
First set the heat setting, then set the
function.
1. Touch to activate the function or
change the time.
The timer digits and the indicators
and come on the display.
10 ENGLISH
Altri manuali per IPE84531FB
2
Indice
Altri manuali AEG Piano cottura
AEG
AEG EPE55526BM Manuale utente
AEG
AEG HK954400FB Manuale utente
AEG
AEG IKB64301XB Manuale utente
AEG
AEG HG674550 Manuale utente
AEG
AEG HG995440 Manuale utente
AEG
AEG HK854200FB Manuale utente
AEG
AEG HK764400FB Manuale utente
AEG
AEG HKB95541NB Manuale utente
AEG
AEG HG694340XB Manuale utente
AEG
AEG 79902G Manuale utente
AEG
AEG 30" HK854080XB Manuale utente
AEG
AEG HG644351 Manuale utente
AEG
AEG IKE41600KB Manuale utente
AEG
AEG HK654070FB Manuale utente
AEG
AEG HK634020XB Manuale utente
AEG
AEG 6310 DK Manuale utente
AEG
AEG HE604060XB Manuale utente
AEG
AEG HK874400FB Manuale utente
AEG
AEG IEB64000XB Manuale utente
AEG
AEG 66331 K-MN Manuale utente
