TSC8M181CS
EN User Manual | Fridge Freezer
aeg.com\register
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you impeccable
performance for many years, with innovative technologies that help make life simpler –
features you might not find on ordinary appliances. Please spend a few minutes reading
to get the very best from it.
Visit our website to:
Get usage advice, brochures, trouble shooter, service and repair information:
www.aeg.com/support
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following data
available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
CONTENTS
1. SAFETY INFORMATION................................................................................ 2
2. SAFETY INSTRUCTIONS.............................................................................. 4
3. INSTALLATION...............................................................................................6
4. CONTROL PANEL.......................................................................................... 9
5. DAILY USE....................................................................................................12
6. HINTS AND TIPS.......................................................................................... 18
7. CARE AND CLEANING................................................................................ 21
8. TROUBLESHOOTING.................................................................................. 23
9. NOISES.........................................................................................................26
10. TECHNICAL DATA..................................................................................... 26
11. INFORMATION FOR TEST INSTITUTES.................................................. 27
12. ENVIRONMENTAL CONCERNS................................................................27
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible
for any injuries or damage that are the result of incorrect
2 ENGLISH
installation or usage. Always keep the instructions in a safe
and accessible location for future reference.
1.1 Children and vulnerable people safety
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved. Children aged from 3 to 8 years and
persons with very extensive and complex disabilities are
allowed to load and unload the appliance provided that they
have been properly instructed. Children of less than 3 years
of age should be kept away from the appliance unless
continuously supervised.
• Children should be supervised to ensure that they do not
play with the appliance.
• Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
• Keep all packaging away from children and dispose of it
appropriately.
1.2 General Safety
• This appliance is for storing food and baverages only.
• This appliance is designed for single household domestic
use in an indoor environment.
• This appliance may be used in, offices, hotel guest rooms,
bed & breakfast guest rooms, farm guest houses and other
similar accommodation where such use does not exceed
(average) domestic usage levels.
• To avoid contamination of food respect the following
instructions:
– do not open the door for long periods;
– clean regularly surfaces that can come in contact with
food and accessible drainage systems;
ENGLISH 3
– store raw meat and fish in suitable containers in the
refrigerator, so that it is not in contact with or drip onto
other food.
• WARNING: Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
• WARNING: Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
• WARNING: Do not damage the refrigerant circuit.
• WARNING: Do not use electrical appliances inside the food
storage compartments of the appliance, unless they are of
the type recommended by the manufacturer.
• Do not use water spray and steam to clean the appliance.
• Clean the appliance with a moist soft cloth. Only use neutral
detergents. Do not use abrasive products, abrasive
cleaning pads, solvents or metal objects.
• When the appliance is empty for long period, switch it off,
defrost, clean, dry and leave the door open to prevent
mould from developing within the appliance.
• Do not store explosive substances such as aerosol cans
with a flammable propellant in this appliance.
• If the supply cord is damaged, it must be replaced by the
manufacturer, its Authorised Service Centre or similarly
qualified persons in order to avoid a hazard.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must install this
appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Do not use the appliance before installing
it in the built-in structure due to safety
manner.
• Follow the installation instructions supplied
with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use safety
gloves and enclosed footwear.
• Make sure the air can circulate around the
appliance.
• At first installation or after reversing the
door wait at least 4 hours before
connecting the appliance to the power
supply. This is to allow the oil to flow back
in the compressor.
• Before carrying out any operations on the
appliance (e.g. reversing the door),
remove the plug from the power socket.
4 ENGLISH
• Do not install the appliance close to
radiators or cookers, ovens, or hobs,
unless otherwise specified in the
installation instructions.
• Do not expose the appliance to the rain.
• Do not install the appliance where there is
direct sunlight.
• Do not install this appliance in areas that
are too humid or too cold.
• When you move the appliance, lift it by the
front edge to avoid scratching the floor.
• The appliance contains a bag of
desiccant. This is not a toy. This is not
food. Please dispose of it immediately.
2.2 Electrical connection
WARNING!
Risk of fire and electric shock.
WARNING!
When positioning the appliance, ensure
the supply cord is not trapped or
damaged.
WARNING!
Do not use multi-plug adapters and
extension cables.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Make sure not to cause damage to the
electrical components (e.g. mains plug,
mains cable, compressor). Contact the
Authorised Service Centre or an
electrician to change the electrical
components.
• The mains cable must stay below the level
of the mains plug.
• Connect the mains plug to the mains
socket only at the end of the installation.
Make sure that there is access to the
mains plug after the installation.
• Do not pull the mains cable to disconnect
the appliance. Always pull the mains plug.
2.3 Use
WARNING!
Risk of injury, burns, electric shock or
fire.
The appliance contains flammable gas,
isobutane (R600a), a natural gas with a high
level of environmental compatibility. Be
careful not to cause damage to the refrigerant
circuit containing isobutane.
• Do not change the specification of this
appliance.
• Any use of the built-in product as free-
standing is strictly prohibited.
• Do not put electrical appliances (e.g. ice
cream makers) in the appliance unless
they are stated applicable by the
manufacturer.
• If damage occurs to the refrigerant circuit,
make sure that there are no flames and
sources of ignition in the room. Ventilate
the room.
• Do not let hot items to touch the plastic
parts of the appliance.
• Do not put soft drinks in the freezer
compartment. This will create pressure on
the drink container.
• Do not store flammable gas and liquid in
the appliance.
• Do not put flammable products or items
that are wet with flammable products in,
near or on the appliance.
• Do not touch the compressor or the
condenser. They are hot.
• Do not remove or touch items from the
freezer compartment if your hands are wet
or damp.
• Do not freeze again food that has been
thawed.
• Follow the storage instructions on the
packaging of frozen food.
• Wrap the food in any food contact material
before putting it in the freezer
compartment.
• Do not allow food to come in contact with
the inner walls of the appliance
compartments.
ENGLISH 5
2.4 Internal lighting
WARNING!
Risk of electric shock.
• This product contains one or more light
sources of energy efficiency class G.
• Concerning the lamp(s) inside this product
and spare part lamps sold separately:
These lamps are intended to withstand
extreme physical conditions in household
appliances, such as temperature,
vibration, humidity, or are intended to
signal information about the operational
status of the appliance. They are not
intended to be used in other applications
and are not suitable for household room
illumination.
2.5 Care and cleaning
WARNING!
Risk of injury or damage to the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains plug
from the mains socket.
• This appliance contains hydrocarbons in
the cooling unit. Only a qualified person
must do the maintenance and the
recharging of the unit.
• Regularly examine the drain of the
appliance and if necessary, clean it. If the
drain is blocked, defrosted water collects
in the bottom of the appliance.
2.6 Service
• To repair the appliance contact the
Authorised Service Centre. Use original
spare parts only.
• Please note that self-repair or non-
professional repair can have safety
consequences and might void the
guarantee.
• The following spare parts will be available
for 7 years after the model has been
discontinued: thermostats, temperature
sensors, printed circuit boards, light
sources, door handles, door hinges, trays
and baskets. Please note that some of
these spare parts are only available to
professional repairers, and that not all
spare parts are relevant for all models.
• Door gaskets will be available for 10 years
after the model has been discontinued.
2.7 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the mains
supply.
• Cut off the mains cable and discard it.
• Remove the door to prevent children and
pets to be closed inside of the appliance.
• The refrigerant circuit and the insulation
materials of this appliance are ozone-
friendly.
• The insulation foam contains flammable
gas. Contact your municipal authority for
information on how to discard the
appliance correctly.
• Do not cause damage to the part of the
cooling unit that is near the heat
exchanger.
3. INSTALLATION
WARNING!
Refer to Safety chapters.
WARNING!
Refer to installation instruction document
to install your appliance.
WARNING!
Fix the appliance in accordance with
installation instruction document to avoid
a risk of instability of the appliance.
6 ENGLISH
3.1 Dimensions
B
A
H1
W1
D1
W2
D2
W3
D3
90°
Overall dimensions ¹
H1 mm 1772
W1 mm 546
D1 mm 549
¹ the height, width and depth of the appliance
without the handle
Space required in use ²
H2 (A+B) mm 1816
W2 mm 546
D2 mm 551
A mm 1780
Space required in use ²
B mm 36
² the height, width and depth of the appliance
including the handle, plus the space
necessary for free circulation of the cooling
air
Overall space required in use ³
H3 (A+B) mm 1816
W3 mm 546
D3 mm 1068
³ the height, width and depth of the appliance
including the handle, plus the space
necessary for free circulation of the cooling
ENGLISH 7
air, plus the space necessary to allow door
opening to the minimum angle permitting
removal of all internal equipment
3.2 Location
To ensure appliance's best functionality, you
should not install the appliance in a place with
direct sunlight. Do not install the appliance
close to radiators or cookers, ovens, or hobs,
unless otherwise specified in the installation
instructions.
Make sure that air can circulate freely around
the back of the cabinet.
This appliance should be installed in a dry,
well ventilated indoor position.
This appliance is intended to be used at
ambient temperature ranging from 10°C to
43°C.
The correct operation of the appliance
can only be guaranteed within the
specified temperature range.
If you have any doubts regarding where
to install the appliance, please turn to the
vendor, to our customer service or to the
nearest Authorised Service Centre.
It must be possible to disconnect the
appliance from the mains power supply.
The plug must therefore be easily
accessible after installation.
3.3 Electrical Connection
CAUTION!
Any electrical work required to install this
appliance should be carried out by a
qualified electrician or competent person.
WARNING!
This appliance must be earthed.
The manufacturer declines any liability
should these safety measures not be
observed.
The wires in the mains lead are coloured in
accordance with the following code:
A B
C
D
E
•A - green and yellow: Earth
•C - brown: Live
•D - blue: Neutral
As the colours of the wires in the mains lead
of this appliance may not correspond with the
coloured markings identifying the terminals in
your plug, proceed as follows:
1. Connect the wire coloured green and
yellow to the terminal marked either with
the letter “E“ or by the earth symbol or
coloured green and yellow.
2. Connect the wire coloured blue to the
terminal either marked with the letter
“N“ or coloured black.
3. Connect the wire coloured brown to the
terminal either marked with the “L“ or
coloured red.
4. Check that no cut, or stray strands of wire
is present and the cord clamp (E) is
secure over the outer sheath.
Make sure the electricity supply voltage is
the same as that indicated on the
appliance rating plate.
5. Switch on the appliance.
The appliance is supplied with a 13 amp fuse
(B). In the event of having to change the fuse
in the plug supplied, a 13 amp ASTA
approved (BS 1362) fuse must be used.
WARNING!
A cut off plug inserted into a 13 amp
socket is a serious safety (shock) hazard.
Ensure that it is disposed of safely.
8 ENGLISH
3.4 Ventilation requirements
The airflow behind the appliance must be
sufficient.
min. 200 cm2
min.
200 cm2
min.
38 mm
min.
38 mm
CAUTION!
Refer to the installation instructions for
the installation.
3.5 Door reversibility
Please refer to the separate document with
instructions on installation and door reversal.
CAUTION!
At every stage of reversing the door
protect the floor from scratching with a
durable material.
4. CONTROL PANEL
1 3 6
91112 10
4 52 7 8
1ECOMETER indicator
2Extra Cool button / indicator
3Fridge compartment indicator
4Alarm indicator
5Door open alarm indicator
6Freezer compartment indicator
7Extra Freeze button / indicator
8Filter Reset alarm button / indicator
9Freezer temperature button / indicator
10 Air filter change indicator
11 Fridge temperature button / indicator
12 ECO button
4.1 Switching on
Connect the mains plug to the power socket.
To select a different set temperature, refer to
"Temperature regulation".
If appears on the display, refer to
"Troubleshooting".
4.2 Switching off
1. Press and hold the freezer temperature
button for 5 seconds.
The display shows blinking .
2. Once the appliance is switched off, the
display reads .
3. Disconnect the mains plug from the
power socket.
ENGLISH 9
4.3 Temperature regulation
The temperature range may vary between
-15°C and -24°C for freezer and between 2°C
and 8°C for fridge.
Press the temperature buttons to set the
temperature of the appliance.
The recommended set temperature is:
• +4°C for the fridge
• -18°C for the freezer
You may set the recommended temperature
manually with temperature buttons or by
switching on the ECO function. Refer to "ECO
function" for more information
The temperature indicators show the set
temperature.
The set temperature will be reached
within 24 hours.
After a power failure, the appliance goes
back to the set temperature.
4.4 Switching off the fridge
It is possible to switch off only the fridge
compartment leaving the freezer
compartment on.
1. Press and hold the fridge temperature
button for 5 seconds.
The display shows blinking .
2. Once the fridge compartment is switched
off, the display reads .
4.5 Switching on the fridge
To switch on the fridge:
1. Press and hold the fridge temperature
button for 5 seconds.
The display shows blinking .
2. The fridge compartment is switched on
and the previous set temperature is
restored.
To adjust the temperature, refer to
"Temperature regulation".
4.6 ECO function
The ECO function sets the optimal
temperature to ensure food preservation
while minimizing energy consumption.
1. To activate the function press the ECO
button.
The fridge temperature is set to +4°C and the
freezer temperature to -18°C.
2. To deactivate the function, press the ECO
button again or select a different set
temperature (refer to "Temperature
regulation").
After deactivating the ECO function, the
fridge temperature is set to +2°C and the
freezer temperature to -20°C.
Activation of the ECO deactivates Extra
Cool and Extra Freeze functions.
The ECOMETER indicator shows the
appliance's current energy consumption.
Three fully lit bars indicate the most
energy-efficient setup.
4.7 Extra Cool function
With the Extra Cool function, you may rapidly
cool large amounts of warm food, for example
after doing grocery shopping, without
warming food already stored in the fridge
compartment.
To activate the function, press the Extra Cool
button.
The Extra Cool indicator lights up. When the
Extra Cool function is on, the fan may work
automatically.
This function stops automatically after
approximately 6 hours. Once the function is
off, the Extra Cool indicator goes out.
Press the Extra Cool button to deactivate the
Extra Cool function before it automatically
ends.
To set a different fridge temperature,
switch off the Extra Cool function and
refer to "Temperature regulation".
10 ENGLISH
Indice
Altri manuali AEG Frigorifero
AEG
AEG SFE712FAAS Manuale utente
AEG
AEG SCE81864TC Manuale utente
AEG
AEG SFB48811AS Manuale utente
AEG
AEG SKZ71800F0 Manuale utente
AEG
AEG Santo 1530TK Manuale utente
AEG
AEG S75578KG3 Manuale utente
AEG
AEG S54000KMW0 Manuale utente
AEG
AEG RKS439F1DW Manuale utente
AEG
AEG RDB424E1AW Manuale utente
AEG
AEG SKB818E1DC Manuale utente
AEG
AEG SFB682F1AF Manuale utente
AEG
AEG s63300kdx0 Manuale utente
AEG
AEG SANTO U 9 60 40-4 i Manuale utente
AEG
AEG SANTO Compact Refrigerator Freezer Manuale utente
AEG
AEG S83430CTX2 Manuale utente
AEG
AEG SKE81826ZC Manuale utente
AEG
AEG SCE81826TC Manuale utente
AEG
AEG ColdSense LTB1AF28W0 Manuale utente
AEG
AEG SFE81821DC Manuale utente
AEG
AEG SKS91240F0 Manuale utente
