AERMEC WLRCA10 Manuale utente
www.aermec.com
Translation from original
User manual
EN
Q
REMOTE CONTROL
19.12 - 5790410_00
WLRCA10
2
All specifications are subject to change without prior notice. Although every effort has been made to
ensure accuracy, Aermec shall not be held liable for any errors or omissions.
Dear customer,
Thank you for choosing an AERMEC product. It is the fruit of many years of experience and special
design studies and has been made of the highest grade materials and with cutting edge technology.
In addition, all our products bear the EC mark indicating that they meet the requirements of the
European Machine Directive regarding safety. The quality level is being constantly monitored, so
AERMEC products are synonymous with Safety, Quality and Reliability.
The data may undergo modifications considered necessary for the improvement of the
product, at any time and without the obligation for any notice thereof.
Thank you once again.
AERMEC S.p.A
This marking indicates that this product should not be disposed with other household
wastes throughout the EU.
To prevent possible harm to the environment or human health from uncontrolled disposal
of Waste Electrical and Electronic Equipment (WEEE), please return the device using
appropriate collection systems, or contact the retailer where the product was purchased.
Please contact your local authority for further details.
Illegal dumping of the product by the user entails the application of administrative
sanctions provided by law
INFORMATION FOR USER
This device is universal.
By pressing a key for a function that is not available, the unit will not change the operating status.
Never install the device in a damp area and do not expose it to direct sunlight.
Do not bump, throw or disassemble the device frequently.
Never use the device with wet hands.
Carefully read the manual before using and installing the device.
4
CERTIFICATIONS
COMPANY CERTIFICATIONS
SAFETY CERTIFICATIONS
REMOTE CONTROL.................................................................................................................................................................................................................6
FUNCTIONS AVAILABLE THROUGH THE REMOTE CONTROL................................................................................................................................8
SWITCHING THE UNIT ON OR OFF...................................................................................................................................................................................8
SETTING THE OPERATING SETPOINT............................................................................................................................................................................8
SELECTING AN OPERATING MODE..................................................................................................................................................................................9
SETTING THE VENTILATION SPEED ..............................................................................................................................................................................10
ACTIVATING / DEACTIVATING THE TURBO FUNCTION.........................................................................................................................................10
SETTING THE MOTORISED DELIVERY FIN VERTICAL SWING...........................................................................................................................11
SETTING THE MOTORISED DELIVERY FIN HORIZONTAL SWING ...................................................................................................................11
ACTIVATING / DEACTIVATING THE IFEEL FUNCTION ............................................................................................................................................12
AIR PURIFIER HEALTH BUTTON...................................................................................................................................................................................13
SETTING THE UNIT SELFCLEANING FUNCTION ICLEAN ................................................................................................................................. 13
ENABLING / DISABLING THE LIGHTING OF THE INDOOR UNIT DISPLAY...................................................................................................... 14
ACTIVATING / DEACTIVATING THE ANTIF EXTENDED VENTILATION FUNCTION.....................................................................................14
SETTING OR CANCELLING A PROGRAMMED SWITCH ON TIMER ON.........................................................................................................15
SETTING OR CANCELLING A PROGRAMMED SWITCH OFF TIMER OFF......................................................................................................15
ACTIVATING / DEACTIVATING THE NIGHTTIME COMFORT FUNCTION SLEEP.......................................................................................16
SETTING THE MEASUREMENT UNIT FOR THE TEMPERATURE SETPOINTS °C OR °F.............................................................................16
ACTIVATING / DEACTIVATING THE ELECTRIC HEATING FUNCTION................................................................................................................17
ACTIVATING OR DEACTIVATING THE ENERGY SAVING FUNCTION................................................................................................................. 17
REPLACING THE REMOTE CONTROL’S BATTERIES..................................................................................................................................................18
INDEX
iFEEL
1
2
3
5
7
9
11 4
6
8
10
12
15
13
14
16
17
6
REMOTE CONTROL
• Some of the buttons of the remote control are
not used for the required air conditioner and are
therefore not described in these instructions.
• Check there are no obstructions between the
receiver and the remote control.
• The maximum distance between the IR receiver and
the remote control is 8 metres, to ensure the signal is
correctly received.
• Position the remote control at least 1 metre away
from TVs, radios, stereos, etc. There may be some
audio and video interference.
• Do not drop or throw the remote control.
• Do not let liquids enter the remote control, and do
not leave it in direct sunlight or in hot places.
• When the remote control sends a signal, the
symbol appears on the display and the indoor unit
receiver emits a sound to confirm reception of the
signal.
Buttons available
on the remote control
Index Function of the button
1Switches the unit on or off
2Selects the unit of measurement - °C / °F
3Sets the fan speed
4Activates or deactivates the lighting of the
indoor unit display
5Activates or deactivates the iFEEL function
6Activates, deactivates or changes the
programmed switch on or switch off timer
7Activates the HEALTH function or the
iCLEAN function
8
Increases or reduces the value of the
active function:
• Temperature
• Time
• Start-up timer
• Shut-down timer
9Activates or deactivates the maximum fan
speed (TURBO)
10 Operating mode selection
11 Activates or deactivates the SLEEP
function
12 Sets the operation of the motorised
delivery fin (vertical SWING function)
13 Sets the operation of the motorised
delivery fin (horizontal SWING function)
14
Activates or deactivates the extended
ventilation function in cooling mode or
dehumidification mode
15
Activates the ELECTRIC HEATING function
(ELE.H.) in heating mode, or the ECO
(energy saving) function in cooling mode
16 IR transmitter
17 Liquid crystal display
iFEEL
7
Remote control display icons available
Index Functions represented by the icons
Indicates the setting has been
transmitted to the receiver located on
the indoor unit
AUTO Indicates the AUTOMATIC mode is active
COOL Indicates the COOLING mode is active
Dry Indicates the DEHUMIDIFICATION mode
is active
HEAT Indicates the HEATING mode is active
Indicates that you are looking at the
working set-point
Indicates that you are looking at the
room temperature (IFEEL function)
Indicates that the indoor unit is ON
Indicates that you are looking at the
system time or the on/off timer on the
remote control display
/ Indicates the unit of measurement for
the temperature set-points ( °C or °F)
Indicates that the iFEEL function was
activated
Indicates if a timer is set for starting
Indicates if a timer is set for switching off
FAN Indicates the current ventilation speed
- FAN
HIGH Indicates the current ventilation speed
- HIGH
MID Indicates the current ventilation speed
- MEDIUM
Low Indicates the current ventilation speed
- LOW
Indicates the system time, or the start
and switch off timer
or Indicates the function selected
8
FUNCTIONS AVAILABLE THROUGH THE REMOTE
CONTROL
Switching on
iFEEL
SETTING THE OPERATING SETPOINT
All the operating modes (except automatic) require a
target temperature for the ambient air; this is called the
"working set-point".
If the unit is on (and automatic mode is not selected),
you can press the or button to decrease or increase
the working set-point. The value will be shown in the
central part of the remote control display.
Operating set-point
iFEEL
SWITCHING THE UNIT ON OR OFF
By pressing the button it is possible to switch
the unit on or off. When off, some information is still
displayed on the remote control: the working set-point
of the last mode used, and possibly of the icons linked
with the functions activated during the last period of
use of the unit. When the unit is switched on, it resumes
the settings used during the last session.
9
SELECTING AN OPERATING MODE
If the unit is on, you can press the MODE button to pass
from one operating mode to another, in the following
sequence:
AUTO mode COOL mode DRY mode
FAN mode HEAT mode
The various operating modes have different features
and ranges:
• AUTOMATIC mode (AUTO): in this mode, the
remote control does not show any set-point value
and the fan speed is set to AUTO.
• COOLING mode (COOL): in this mode, the user must
set the working set-point and a fan speed; if the
room temperature is higher than the set value, which
can be seen on the display, the air conditioner will
continue to cool the air until the room temperature
will reach the set-point value.
• DEHUMIDIFICATION mode (DRY):in this mode,
the user must set the working set-point but not
the fan speed (which remains fixed at minimum); if
the room temperature is higher than the set value,
which can be seen on the display, the air conditioner
will continue to dehumidify the air until the room
temperature will reach the set-point value.
• HEATING mode (HEAT):in this mode, the user must
set the working set-point and a fan speed; if the
room temperature is lower than the set value, which
can be seen on the display, the air conditioner will
continue to heat the air until the room temperature
will reach the set-point value.
• VENTILATION mode (FAN):in this mode, the user
must only set the fan speed. This mode provides no
heating or cooling but only uses the internal fan to
ventilate the space.
Operating mode selection
iFEEL
NB:
during operation in FAN mode, the temperatures
shown on the unit display are not implemented.
10
Setting the ventilation
speed
iFEEL
SETTING THE VENTILATION SPEED
Press the SPEED button to modify the fan speed. In the
DRY mode operation (dehumidification), the fan will
automatically change to the minimum speed.
NB:
In addition to the standard speeds, another
ventilation speed is available:
• AUTO: ventilation speed that selects
autonomously the most suitable speed
depending on the room temperature
Minimum speed
Medium speed
Maximum speed
Automatic speed
ACTIVATING / DEACTIVATING THE TURBO FUNCTION
This function is available only for the COOL and HEAT
modes.
Press the TURBO button to activate or deactivate the
turbo function which allows you to quickly set the
maximum fan speed (HIGH speed).
To deactivate the TURBO function, press the button
again and the fan speed will return to the set previously
set.
Activating / deactivating the
turbo function
iFEEL
LOW MID
HIGHAUTO
LOW
MID
HIGH
AUTO
LOW
MID
HIGH
AUTO
