AG Neovo H-W19 Manuale utente

www.agneovo.com

REACH

H-W19

Multimedia performance, built-in

stereo sound and a vibrant 19”

widescreen display that is perfect for

value-oriented desktop environments.

Featuring a brilliant 19” widescreen and integrated stereo speakers,

the H-W19 is an excellent value choice for video, gaming, and other

multimedia applications. Images come alive with the vibrant

super-resolution 1440 x 900 panel. Capable of displaying two

full-sized open windows at the same time, the convenient widescreen

format allows for increased productivity. e slim H-W19 is ideal for

home and oce environments requiring multimedia performance at

an aordable price.

> 19” widescreen format

> WXGA+1440 x 900 resolution

> Slim and sleek design

> Fast 3 ms response time

> Crisp 1000:1 contrast ratio

> High 380 cd/m2brightness

> Built-in speakers

> Easy-to-use friendly OSD

> Auto-adjustment for optimal viewing

> Kensington® security socket

> VESA standard wall mount

All specications are subject to change without prior notice.

All other trademarks are the property of their respective owners.

P/C: HW190A Version 22.0, 20100101

Speciﬁcations H-W19

Panel Panel Type

Panel Size

Max. Resolution

Pixel Pitch

Brightness

Contrast Ratio

Surface Treatments

Viewing Angle (H/V)

Display Colour

Response Time

Panel Life Time

TFT LCD

19.0” (484 mm)

WXGA+1440 x 900

0.285 mm

380 cd/m2( Typical)

1000:1 (Typical)

Hard Coating (3H),

Anti-glare Treatment

170°/160° (Typical)

16.7M

3 ms (GTG)

50,000 hrs (Minimum)

Frequency (H/V) H: 30 kHz - 70 kHz

V: 56 Hz - 75 Hz

Max. Pixel Clock 140 MHz

Input Analogue 15-Pin D-Sub

Audio Audio In

Speaker

3.5 mm Audio Line-in

1 W x 2

Power AC-DC Adaptor

Power

Consumption

Internal

AC 100 - 240 V, 50 - 60 Hz

< 52 W (On)

< 2 W (Stand-by)

< 1 W (Off)

Plug & Play VESA DCC 2B, DCC/CI

Operating

Conditions

Temperature

Humidity

0 °C ~ 40 °C

10% ~ 90%

Storage

Conditions

Temperature

Humidity

-20 °C ~ 60 °C

5% ~ 95%

Mounting VESA FPMPMI Yes (100 mm)

Tilt Tilt -5° ~ +25°

Dimensions Product

(W x H x D)

Packaging

(W x H x D)

439 x 363 x 211 mm

(17.3” x 14.3” x 8.3”)

509 x 442 x 188 mm

(20.0” x 16.6” x 7.4”)

Weight Product Weight

Packaged Product Weight

3.9 kg (8.6 lbs)

5.3 kg (11.7 lbs)

Regulation

Approval

Certiﬁcations &

Compliance

UL/CUL, TUV/GS, CB,

GOST-R, FCC, CE, BSMI,

WEEE, RoHS, Vista/Basic,

REACH

Accessories Supplied Quick Guide, CD ROM (user

manual and drivers),

15-Pin D-Sub cable, audio

cable, AC power cord, base

H-W19

Widescreen format allows for greater productivity by

enabling two windows to be open at the same time

without any overlap

VESA standard wall mount allows for secure

mounting almost anywhere

Integrated stereo speakers provide rich sound to accompany

games, DVDs and other visual entertainment
